Search Results (26)

In this study, we propose a novel wideband aperture-coupled magneto-electric (ME) dipole antenna that achieves enhanced bandwidth by simultaneously leveraging ME resonance and aperture-coupled excitation. Building upon the conventional ME dipole architecture, the antenna integrates a pair of horizontal metal patches forming the electric dipole and a pair of vertical metal patches forming the magnetic dipole. A key innovation is the aperture-coupled feeding mechanism, where electromagnetic energy is transferred from a tapered microstrip line to the dipole structure through a slot etched in the ground plane. This design not only excites the characteristic ME resonances effectively but also significantly improves impedance matching, delivering a markedly broader impedance bandwidth. To validate the proposed concept, a prototype antenna was fabricated and experimentally characterized. Measurements show an impedance bandwidth of 84.48% (3.61–8.89 GHz) for $S_{11}$ ≤ −10 dB and a maximum in-band gain of 7.88 dBi. The antenna also maintains a stable, unidirectional radiation pattern across the operating band, confirming its potential for wideband applications such as 5G wireless communications. Full article

Magnetorheological elastomers (MREs) are smart composite materials with tunable mechanical properties by ferromagnetic particle interactions. This study applied the microstructure-based dipole and Maxwell methods to evaluate the magneto-mechanical coupling and magnetostrictive responses of MREs, focusing on various particle distributions. The finite element modeling of representative volume elements with fixed volume fractions revealed that the straight chain microstructure exhibits the most significant magnetostrictive effect due to its low initial shear stiffness and significant magnetic force contributions. For particle separations exceeding three radii, the dipole and Maxwell methods yield consistent results for vertically or horizontally aligned particles. For particle separations greater than three radii, the dipole and Maxwell methods produce consistent results for vertically and horizontally aligned particles. However, discrepancies emerge for angled configurations and complex microstructures, with the largest deviation observed in the hexagonal particle distribution, where the two methods differ by approximately 27%. These findings highlight the importance of selecting appropriate modeling methods for optimizing MRE performance. Since anisotropic MREs with straight-chain alignments are the most widely used, our results confirm that the dipole method offers an efficient alternative to the Maxwell method for simulating these structures. Full article

A pattern-reconfigurable, vertically polarized (VP), electrically small (ES), Huygens source antenna (HSA) is demonstrated. A custom-designed reconfigurable inverted-F structure is embedded in a hollowed-out cylindrical dielectric resonator (DR). It radiates VP electric dipole fields that excite the DR’s HEM_11δ mode, which in turn acts as an orthogonal magnetic dipole radiator. The HSA’s unidirectional properties are thus formed. It becomes low-profile and electrically small through a significant lowering of its operational frequency band by loading the DR’s top surface with a metallic disk. The entire 360° azimuth range is covered by each of the HSA’s four 90° reconfigurable states, emitting a unidirectional wide beam. A prototype was fabricated and tested. The measured results, which are in good agreement with their simulated values, demonstrate that the developed wideband Huygens source antenna, with its 0.085 λ_L low profile and its 0.20 λ_L × 0.20 λ_L compact transverse dimensions, hence, electrically small size with ka = 0.89, exhibits a wide 14.1% fractional impedance bandwidth and a 6.1 dBi peak realized gain in all four of its pattern-reconfigurable states. Full article

Strain-free GaAs cone-shell quantum dots have a unique shape, which allows a wide tunability of the charge-carrier probability densities by external electric and magnetic fields. Here, the influence of a lateral electric field on the optical emission is studied experimentally using simulations. The simulations predict that the electron and hole form a lateral dipole when subjected to a lateral electric field. To evaluate this prediction experimentally, we integrate the dots in a lateral gate geometry and measure the Stark-shift of the exciton energy, the exciton intensity, the radiative lifetime, and the fine-structure splitting (FSS) using single-dot photoluminescence spectroscopy. The respective gate voltage dependencies show nontrivial trends with three pronounced regimes. We assume that the respective dominant processes are charge-carrier deformation at a low gate voltage U, a vertical charge-carrier shift at medium U, and a lateral charge-carrier polarization at high U. The lateral polarization forms a dipole, which can either enhance or compensate the intrinsic FSS induced by the QD shape anisotropy, dependent on the in-plane orientation of the electric field. Furthermore, the data show that the biexciton peak can be suppressed by a lateral gate voltage, and we assume the presence of an additional vertical electric field induced by surface charges. Full article

The impact of a lightning electromagnetic pulse (LEMP) on a power line or power station produces an effect similar to that of switching between a significant power source and a power line circuit. This switch closure causes a sudden change in routing conditions, creating a transient state. This situation has been studied in terms of electrostatic and electromagnetic induction, as well as overvoltage changes. Appropriate mathematical models were used to analyze these changes. While vertical electric field analysis has been carried out in a few studies, magnetic field and horizontal electric field vectors have not been studied. In this study, the Rusck formulation and the Heidler current formulation are combined at the current level, developed and analyzed. This is because the Rusck expression can sometimes give incorrect results at the current level. Also, in the analysis, electromagnetic field formulations based on accelerating charges are used instead of the dipole approximation to eliminate the need for interpolation in the graphical results. In contrast to other studies in the literature, this study proposes the use of moving and accelerating load techniques to better understand the effects of LEMPs on power transmission lines. Also, in this study, the double exponential problem of the current form in Rusck’s formulation is addressed in order to obtain a close approximation of the physical form of the LEMP. Additionally, the field–line (coupling) relationship is studied according to a unique closed formulation, leading to important determinations about the overvoltages generated on a line depending on the propagation speed of the LEMP sprout and the electrical changes in the area where the LEMP first occurs. Full article

Magnetoelectric (ME) magnetic field sensors are novel sensing devices of great interest in the field of biomagnetic measurements. We investigate the influence of magnetic crosstalk and the linearity of the response of ME sensors in different array and excitation configurations. To achieve this aim, we introduce a combined multiscale 3D finite-element method (FEM) model consisting of an array of 15 ME sensors and an MRI-based human head model with three approximated compartments of biological tissues for skin, skull, and white matter. A linearized material model at the small-signal working point is assumed. We apply homogeneous magnetic fields and perform inhomogeneous magnetic field excitation for the ME sensors by placing an electric point dipole source inside the head. Our findings indicate significant magnetic crosstalk between adjacent sensors leading down to a 15.6% lower magnetic response at a close distance of 5 mm and an increasing sensor response with diminishing crosstalk effects at increasing distances up to 5 cm. The outermost sensors in the array exhibit significantly less crosstalk than the sensors located in the center of the array, and the vertically adjacent sensors exhibit a stronger crosstalk effect than the horizontally adjacent ones. Furthermore, we calculate the ratio between the electric and magnetic sensor responses as the sensitivity value and find near-constant sensitivities for each sensor, confirming a linear relationship despite magnetic crosstalk and the potential to simulate excitation sources and sensor responses independently. Full article

A mathematical model for an electric field induced by an angularly oscillating magnetic dipole was proposed with magnetic vector potential to analyze the characteristics of the electric field induced by a rotating and angularly oscillating magnetic object. This mathematical model was constructed for the electric field induced by a magnetic object oscillating at a certain angle. On this basis, the phase relationship among the three components of the induced electric field was analyzed (defining the right-hand Cartesian coordinate system). Evidently, a phase difference of π/2 always existed between the horizontal components of the electric field induced by a magnetic dipole rotating around the z-axis. The phase difference between the vertical and transverse components in the x–z plane was also π/2. A phase difference of π was observed in the y–z plane. The above theoretical analysis was verified through simulation and experiment. The results showed that the frequency of the induced electric field was related to the angular velocity and angle of rotation. The amplitude was associated with the magnetic moment and the angular velocity and angle of oscillation. The maximum amplitude did not exceed the amplitude of the electric field induced by a magnetic object angularly oscillating at the same velocity. With regard to the amplitude and phase relationship, the three components of the induced electric field measured in the experiment were consistent with the results of the theoretical analysis. Full article

Great attention has been paid to the propagation of electromagnetic (EM) waves across the sea surface due to its important applications. Most of the previous research, however, focuses on the half-space model illustrating the deep sea environment. In this paper, EM field distribution in the extremely low frequency (ELF) near-region under horizontal electric dipole (HED) excitation in homogeneous half-space seawater is analyzed based on the general expression of the Sommerfeld integral using the quasistatic approximation method. The focus is on deriving complete and effective solutions in air and seawater regions under the cylindrical coordinates for the EM near-field, which is generated by an HED in a shallow sea. The resulting formulas can be given by a few summands in closed form as the well-known Fourier–Bessel integrals. The analytical approximate expression of ELF Sommerfeld EM field integral excited by the HED in the homogeneous half-space seawater is deduced under the condition that the propagation distance ρ satisfies kρ << 1. To this end, the EM field distribution in the range close to the HED antenna in seawater is simulated, the results have shown that the minimum attenuation value of the vertical electric component E_z is about 15 dB, and that of the radical magnetic components H_φ is about 30 dB, and these values are found to be of greatest potential for the near-field region propagation among the electric and magnetic components. Finally, the correctness of the proposed method is verified by comparison with Pan’s approximation method and Margetis’s exact expression approximation method, which demonstrated the correctness of the proposed method. Full article

In the controlled source radiomagnetotelluric (CSRMT) sounding method, a horizontal magnetic dipole, HMD (vertical loop) or a horizontal electric dipole, and HED (grounded line) are used as sources. When working with HMD, the source is usually tuned to resonance to increase the current in the loop. However, the disadvantage of this approach is the narrow frequency range realized in the CSRMT method (1–12 kHz) and the short operating distance from the source (600–800 m). The need to tune the source to resonance at each selected frequency reduces the efficiency of the survey. In the case of using HED for sounding, measurements are performed in a wider frequency range of 1 to 1000 kHz, and along with the signal of the base frequency, its subharmonics are measured. In this case, emitted signal measurements are possible at a distance of up to 3–4 km from the source. At the same time, the disadvantage of using HED is that it requires grounding, the arrangement of which requires additional time when working on frozen ground or dry stony soil. We consider the possibilities of generation and registration of signals of subharmonics of base frequencies when applying the CSRMT method with loop sources—HMD and VMD (horizontal loop). A matching unit (MU) based on a step-up transformer was developed, which increases the output voltage of the CSRMT transmitter. In a field test with base frequencies of 20, 40, and 80 kHz, the signal amplitudes increased by a factor of two to four for subharmonics at frequencies of 60–200 kHz and by up to 10–13 times for subharmonics at frequencies of 200–500 kHz due to transformation of signal spectrum provided by MU. The possibility of using odd subharmonics of base frequencies for inversion has been demonstrated in the results of field experiments with different sources (HED, HMD, and VMD). This expands the frequency range of the method when working with loop sources and increases the survey’s effectiveness. The use of loop sources in the CSRMT method is especially advantageous for winter work in Arctic regions. Full article

In recent years, there has been a growing interest in the detection, location, and classification (DLC) of multiple dipole-like magnetic sources based on magnetic gradient tensor (MGT) data. In these applications, the tilt angle is usually used to detect the number of sources. We found that the tilt angle is only suitable for the scenario where the positive and negative signs of the magnetic sources’ inclination are the same. Therefore, we map the L2 norm of the vertical magnetic gradient tensor on the arctan function, denoted as the VMGT${}_2$ angle, to detect the number of sources. Then we use the normalized source strength (NSS) to narrow the parameters’ search space and combine the differential evolution (DE) algorithm with the Levenberg–Marquardt (LM) algorithm to solve the sources’ locations and magnetic moments. Simulation experiments and a field demonstration show that the VMGT${}_2$ angle is insensitive to the sign of inclination and more accurate in detecting the number of magnetic sources than the tilt angle. Meanwhile, our method can quickly locate and classify magnetic sources with high precision. Full article

The bound state in the continuum (BIC) has paved a new way to achieve excellent localization of the resonant mode coexisting with a continuous spectrum in the metasurface. Here, we propose an all-dielectric metasurface consisting of periodic pairs of asymmetric crosses that supports multiple Fano resonances. Due to the sufficient degrees of freedom in the unit cell, we displaced the vertical bars horizontally to introduce in-plane perturbation, doubling the unit cell structure. Dimerization directly resulted in the folding of the Brillouin zone in k space and transformed the BIC modes into quasi-BIC resonances. Then, simultaneous in-plane symmetry breaking was introduced in both the x and y directions to excite two more resonances. The physical mechanisms of these BIC modes were investigated by multipole decomposition of the scattering cross section and electromagnetic near-field analysis, confirming that they are governed by toroidal dipole (TD) modes and magnetic dipole (MD) modes. We also investigated the flexible tunability and evaluated the sensing performance of our proposed metasurface. Our work is promising for different applications requiring stable and tunable resonances, such as optical switching and biomolecule sensing. Full article

When studying horizontally-inhomogeneous media, it is necessary to apply tensor modifications of electromagnetic soundings. Use of tensor measurements is of particular relevance in near-surface electrical prospecting because the upper part of the geological section is usually more heterogeneous than the deep strata. In the Enviro-MT system designed for the controlled-source radiomagnetotelluric (CSRMT) sounding method, two mutually perpendicular horizontal magnetic dipoles (two vertical loops) are used for tensor measurements. We propose a variant of the CSRMT method with two horizontal electrical dipole sources (two transmitter lines). The advantage of such sources is an extended frequency range of 1–1000 kHz in comparison with 1–12 kHz of the Enviro-MT system, greater operational distance (up to 3–4 km compared to 600–800 m), and the ability to measure the signal at the fundamental frequency and its subharmonics. To implement tensor measurements with the equipment of the CSRMT method described in the paper, a technique of creating a time-varying polarization of the electromagnetic field (rotating field) has been developed based on the use of two transmitters with slightly different current frequencies and two mutually-perpendicular transmitter lines grounded at the ends. In this way, we made it possible to change the direction of the electrical and magnetic field polarization continuously. This approach allows realization of the technique of tensor measurements using the new modification of the CSRMT method. In permafrost areas, the hydrogenic taliks are widespread. These local objects are important in the context of study of environmental changes in the Arctic and can be successfully explored by the tensor CSRMT method. For the numerical modeling, a 2D model of the talik was used. Results of the interpretation of synthetic data showed the advantage of bimodal inversion using CSRMT curves of both TM and TE modes compared to separate inversion of TM and TE curves. These new data demonstrate the prospects of the tensor CSRMT method in the study of permafrost regions. The problems that can be solved using the CSRMT method in the Arctic permafrost regions are discussed. Full article

In this paper, a low-RCS broadband high-gain antenna based on metasurface transmission array is proposed, consisting of two parts: a metasurface transmission array and a feed antenna. When designing the metasurface transmission array, the phase compensation method is used to achieve the beam convergence effect of metasurface in the broadband. By designing the elements and using the checkerboard arrangement, the RCS of the incident wave with fixed polarization can be reduced more than 10 dB at X band or Ku band. The feed antenna is designed as a microstrip magnetic and electric dipole antenna, which has the characteristics of small structure and wide impedance bandwidth. An antenna that can reduce RCS by more than 10 dB in Ku band is simulated and measured. The measurement and simulation results show that the −10 dB operating bandwidth of the high-gain antenna designed in this paper is 6.7~13.5 GHz, and the relative bandwidth is 67%. The designed metasurface can effectively improve the gain of the antenna in the operating frequency band. In this way, the design of high-gain antenna is realized, and the antenna has an obvious RCS reduction effect on the vertically incident y-polarized wave in the whole Ku band. The method to design an antenna in this paper realizes the regulation of radiation and scattering at the same time, which has important reference significance for expanding the function of transmission array antennae and has great application value. Full article

Interpreting the complex interaction of nanostructured fluid flow with a dipole in a duct, with peripherally uniform temperature distribution, is the main focus of the current work. This paper also sheds light on the changes in the Nusselt number, temperature profiles, and velocity distributions for the fully developed nanofluid flow in a vertical rectangular duct due to a dipole placed near a corner of the duct. A finite volume approach has been incorporated for the numerical study of the problem. It is interesting to note the unusually lower values of the Nusselt number for the higher values of the ratio Gr/Re. Due to the nanostructure in the fluid, an enhancement in the Nusselt number has been noted, which is strongly supported by the magnetic field caused by the dipole. However, as the duct shape is transformed from rectangular to square, the Nusselt number is reduced remarkably. Further, as the dipole is brought nearer to the duct corner, the Nusselt number increases significantly. On the other hand, the flow reversal in the middle of the duct has been noted at higher values of the ratio Gr/Re. The dipole is noted to have a low impact on the reversal flow as well as on the temperature distribution. Full article

WiFi energy harvesting is a promising solution for powering microsensors and microsystems through collecting electromagnetic (EM) energies that exist everywhere in modern daily lives. In order to harvest EM energy, we proposed a metamaterial-inspired antenna (MIA) based on the resonant magnetic dipole operating in the WiFi bands. The MIA consists of two metallic split-ring resonators (SRRs), separated by an FR4 dielectric layer, in the broadside coupled configuration. The incident EM waves excite surface currents in the coupled SRRs, and the energy is oscillating between them due to near-field coupling. By varying the vertical distance of the two SRRs, we may achieve impedance matching without complicated matching networks. Collected EM energy can be converted to DC voltages via a rectifier circuit at the output of the coupling coil. Measured results demonstrate that the designed MIA may resonate at 2.4 GHz with a deep-subwavelength form factor (14 mm×14 mm×1.6 mm). The WiFi energy-harvesting capability of the proposed MIA with an embedded one-stage Dickson voltage multiplier has also been evaluated. A rectified DC voltage is approximately 500 mV when the MIA is placed at a distance of 2 cm from the WiFi transmit antenna with a 9 dBm transmitting power. The proposed compact MIA in this paper is of great importance for powering future distributed microsystems. Full article
