Search Results (44)

This article focuses on the fire safety risks associated with conventional glass–aluminum façades—with a particular focus on stick and unitized curtain walling systems—providing an overview of possible fire spread mechanisms, considering the role of the curtain wall in maintaining compartmentation at the spandrel zone. First, it analyzes some of the relevant requirements of different European building regulations. Then, it provides a test evidence-based critical analysis of the gaps and loopholes in the relevant fire resistance standard for partial curtain wall configurations (EN 1364-4), where the evaluation of the propagation within the façade system is not necessarily considered in the fire-resistant spandrel zone. Finally, it presents a proposal for addressing these gaps in the form of a theoretical concept for a new test configuration and additional assessment criteria. This is followed by an initial experimental analysis of the concept. The standard testing campaign showed that temperature rise in mullions can exceed 180 °C after 30 min if limiting measures are not considered in the façade design. However, this can be only detected if framing is in the non-exposed area of the sample, being part of the evaluation surface. Meanwhile, differences are detected between the results from standard and new assessment criteria in the new configuration proposed, including a more rapid temperature rise for framing elements (207 K in a second level mullion at minute 90) than for the common non-exposed assessment surface of the sample (172 K at the same time) in cases where cavities are not protected. Accordingly, the proposed configuration successfully detected vertical temperature transfer within mullions, which can remain undetected in standard EN 1364-4 tests, highlighting the potential for fire spread even in EI120-rated assemblies. Full article

Straw fiber curtain contains a plant fiber blanket woven from crop straw, which is mainly used to protect embankment slopes from rainwater erosion. To investigate the erosion control performance of slopes covered with straw fiber curtains of different structural configurations, physical model tests were conducted in a 95 cm × 65 cm × 50 cm (length × height × width) test box with a slope ratio of 1:1.5 under controlled artificial rainfall conditions (20 mm/h, 40 mm/h, and 60 mm/h). The study evaluated the runoff characteristics, sediment yield, and key hydrodynamic parameters of slopes under the coverage of different straw fiber curtain types. The results show that the A-type straw fiber curtain (woven with strips of straw fiber) has the best effect on water retention and sediment reduction, while the B-type straw fiber curtain (woven with thicker straw strips) with vertical straw fiber has a better effect regarding water retention and sediment reduction than the B-type transverse straw fiber curtain. The flow of rainwater on a slope covered with straw fiber curtain is mainly a laminar flow. Straw fiber curtain can promote the conversion of water flow from rapids to slow flow. The Darcy-Weisbach resistance coefficient of straw fiber curtain increases at different degrees with an increase in rainfall time. Full article

Creating a comfortable microclimate in the premises of buildings is currently becoming one of the priorities in the field of architecture, construction and engineering systems. The increased attention from the scientific community to this topic is due not only to the desire to ensure healthy and favorable conditions for human life but also to the need for the rational use of energy resources. This area is becoming particularly relevant in the context of global challenges related to climate change, rising energy costs and increased environmental requirements. Practice shows that any technical solutions to ensure comfortable temperature, humidity and air exchange in rooms should be closely linked to the concept of energy efficiency. This allows one not only to reduce operating costs but also to significantly reduce greenhouse gas emissions, thereby contributing to sustainable development and environmental safety. In this connection, this study presents a parametric assessment of the influence of climatic and geometric factors on the aerodynamic characteristics of the air cavity, which affect the heat exchange process in the ventilated layer of curtain wall systems. The assessment was carried out using a combined analytical calculation method that provides averaged thermophysical parameters, such as mean air velocity ($V_s$), average internal surface temperature ($t_{in.s}^{av}$), and convective heat transfer coefficient (${\alpha }_s$) within the air cavity. This study resulted in empirical average values, demonstrating that the air velocity within the cavity significantly depends on atmospheric pressure and façade height difference. For instance, a 10-fold increase in façade height leads to a 4.4-fold increase in air velocity. Furthermore, a three-fold variation in local resistance coefficients results in up to a two-fold change in airflow velocity. The cavity thickness, depending on atmospheric pressure, was also found to affect airflow velocity by up to 25%. Similar patterns were observed under ambient temperatures of +20 °C, +30 °C, and +40 °C. The analysis confirmed that airflow velocity is directly affected by cavity height, while the impact of solar radiation is negligible. However, based on the outcomes of the analytical model, it was concluded that the method does not adequately account for the effects of solar radiation and vertical temperature gradients on airflow within ventilated façades. This highlights the need for further full-scale experimental investigations under hot climate conditions in South Kazakhstan. The findings are expected to be applicable internationally to regions with comparable climatic characteristics. Ultimately, a correct understanding of thermophysical processes in such structures will support the advancement of trends such as Lightweight Design, Functionally Graded Design, and Value Engineering in the development of curtain wall systems, through the optimized selection of façade configurations, accounting for temperature loads under specific climatic and design conditions. Full article

The artificial ground freezing method (AGF) is widely used in underground construction to reinforce the ground and ensure construction safety. This study systematically evaluates the implementation of the artificial ground freezing method in the construction of a metro tunnel cross-passage, with a focus on analyzing the soil’s thermo-mechanical behavior and assessing safety performance throughout the construction process. A combined approach integrating field monitoring and refined three-dimensional numerical simulation using FLAC3D is adopted, considering critical factors, such as freezing pipe inclination, thermo-mechanical coupling, and ice–water phase transitions. Both field data and simulation results demonstrate that increasing the density of freezing pipes accelerates temperature reduction and intensifies frost heave-induced displacements near the pipes. After 45 days of active freezing, the freezing curtain reaches a thickness of 3.7 m with an average temperature below −10 °C. Extending the freezing duration beyond this period yields negligible improvement in curtain performance. Frost heave deformation develops rapidly during the initial phase and stabilizes after approximately 25 days, with maximum vertical displacements reaching 12 cm. Significant stress concentrations occur in the soil adjacent to the freezing pipes, with shield tunnel segments experiencing up to 5 MPa of stress. Thaw settlement is primarily concentrated in areas previously affected by frost heave, with a maximum settlement of 3 cm. Even after 45 days of natural thawing, a frozen curtain approximately 3.3 m thick remains intact, maintaining sufficient structural strength. The refined numerical model accurately captures the mechanical response of soil during the freezing and thawing processes under realistic engineering conditions, with field monitoring data validating its effectiveness. This research provides valuable guidance for managing construction risks and ensuring safety in similar cross-passage and cross-river tunnel projects, with broader implications for underground engineering requiring precise control of frost heave and thaw settlement. Full article

To promote sustainable development in urban environments, minimising the reflected light pollution from glass curtain walls is critical. This study investigates numerical evaluation methods for assessing the impact of curtain wall-reflected light on road traffic light pollution. While existing research focuses on indoor glare and static target pollution, limited attention has been given to the dynamic impacts on moving traffic participants. This research evaluates light pollution (discomfort glare) induced by triple-layer hollow glass curtain walls in green buildings. A mathematical model predicting the solar reflection characteristics (reflectivity and brightness) was established using optical equations, with the accuracy verified through field experiments and numerical simulations. Subsequently, a driver discomfort glare (DDG) evaluation model was developed, incorporating the dynamic relationships between reflected light sources and drivers, including relative position variations, vertical eye illumination, and correlations between sightlines, driving speed, and road terrain. A numerical simulation system was implemented using Rhino’s Ladybug + Honeybee tools, demonstrated through a case analysis of high-rise buildings in Dalian. The system simulated glare effects under sunny/snowy conditions while examining thickness-related variations. The results revealed significant correlations between the glass thickness, weather conditions, and discomfort glare intensity. The proposed DDG model and simulation approach offer practical tools for assessing dynamic light pollution impacts, supporting the theoretical evaluation of outdoor light environments in green buildings. This methodology provides an effective framework for analysing the moving-target light pollution from architectural reflections, advancing sustainable urban design strategies. Full article

Using COMSOL finite element software, a three-dimensional numerical transient model of an underground tunnel collapse vertical freezing repair project was established. The model was altered to change the head difference, allowing for analysis of the development of the permafrost curtain, the time of intersection circles, and the freezing temperature field cloud diagram. The results indicated that, without seepage, development of the upstream and downstream permafrost curtains was stable and uniform. However, under seepage conditions, development of the upstream and downstream permafrost curtains became increasingly uneven with increasing seepage velocity. The downstream side of the soil body began freezing earlier than the upstream side, and the final temperature was lower. The intersection time of the freezing wall was an important indicator of development of the permafrost curtain, and the freezing time of the freezing wall was the most critical indicator. A hydraulic head difference of 1 m was found to significantly impact the development of the freezing wall, with less influence from seepage velocity on the overall permafrost curtain intersection time. However, the intersection time of the isotherm increased significantly with increasing seepage flow rate. The findings from this project provide a theoretical reference for future restoration design. Full article

In recent years, the increasing construction of high-rise buildings has led to the widespread use of glass curtain walls. Regular cleaning is essential to maintain their aesthetic appeal and functionality. However, manual cleaning methods pose significant safety risks, necessitating the development of façade-cleaning robots. This paper presents a 3-Degree-of-Freedom Modular High-Rise Façade-Cleaning Robot (3-DOF-MHRFCR), consisting of a lifting module, an XYZ motion module, and a cleaning module. The robot employs a synchronous belt lifting mechanism for vertical movement, ensuring high positioning accuracy and safety. The XYZ motion module enables precise cleaning and obstacle traversal, while the cleaning module combines high-pressure water jets, rotating brushes, and squeegees for effective contaminant removal. Experimental results demonstrate a maximum glass transmittance enhancement of 72.4% and a 21.8% reduction in water consumption compared to manual cleaning, validating the robot’s efficiency and stability. Full article

In order to ensure the smooth progress of foundation pit engineering, it is necessary to identify and control the seepage risk. At present, there are few research studies and applications on the seepage risk assessment of foundation pits, and the optimization of curtain depth and the interrelation and optimal combination of design variables are rarely considered in the optimization design of foundation pit dewatering scheme based on the objective function method. According to the geological and hydrogeological conditions of the research area, a mathematical model for optimizing foundation pit dewatering was established. The model takes the minimum total dewatering cost as the objective function and comprehensively considers decision-making variables. Additionally, it also takes into account constraints such as the drawdown depth of the water level in a single well and the pumping flow rate of a single well. The calculation results indicate that the errors between the measured water levels and the simulated water levels are within ±3.5%, suggesting that the parameter inversion results are effective. The horizontal and vertical permeability coefficients of the phreatic aquifer are 3.0 m/d and 0.45 m/d, respectively, and the horizontal and vertical permeability coefficients of confined aquifer are 10.28 m/d and 1.25 m/d, respectively. The horizontal and vertical permeability coefficients of the confined aquifer are 10.28 m/d and 1.25 m/d, respectively. Nine different excavation dewatering schemes that curtain depths of 66 m, 61 m, and 56 m were designed, and the optimal excavation dewatering scheme was determined by comparing the total dewatering cost. This scheme has the advantages of shortening the dewatering time, reducing the impact of foundation pit dewatering on the surrounding environment, and saving the total cost of dewatering. The research results provide a relevant decision-making basis for managers. Full article

Long, narrow, deep excavations commonly encountered in practice, such as those for subway stations, require effective groundwater management to prevent disasters in water-rich areas. To achieve this, a cut-off curtain and pumping well are typically employed during long, deep foundation pit dewatering. The unsteady groundwater flow behavior in the confined aquifer must consider the influence of the cut-off curtain during dewatering. This paper establishes a two-dimensional analytical model to describe transient groundwater flow in a confined aquifer with a cut-off curtain. Both the dewatering well pumped at a steady discharge inside the pit and the cut-off curtain are partially penetrating in the anisotropic confined aquifer. With the help of the Laplace and Fourier cosine transformations, the semi-analytical drawdown solution for the model is derived and validated against numerical solution and unsteady pumping test data. It is shown that the inserted cut-off curtain depth and the structural parameters of the pumping well significantly affect the drawdown inside the pit. Sensitivity analysis reveals that, regardless of whether the observation is made inside or outside the curtain, the drawdown is very sensitive to the change in pumping rate, aquifer thickness, storage coefficient, and horizontal hydraulic conductivity. Additionally, drawdown near the cut-off curtain outside the pit is sensitive to the vertical hydraulic conductivity of the aquifer, the width of the pit, and the interception depth of the cut-off curtain, while drawdown far from the curtain outside the pit is not sensitive to the location and length of the well screen. Full article

In recent years, with the increasing difficulty of foundation pit projects, the frequency of leakage accidents has also increased. In order to ensure that the excavation of foundation pits is carried out smoothly, water-stop curtains are generally used to protect the foundation pit. Once leakage occurs in the water-stop curtain, it will inevitably delay the schedule, cause significant harm, and even jeopardize life. Therefore, this paper analyses and investigates the two-steady-state seepage field of the foundation pit when the permeable anisotropic soil layer suspends the leakage of the water curtain. To calculate head distribution solutions, the soil layer surrounding the curtain was divided into five regular regions, and the superposition method and method of separating variables were used. These results were then combined with the continuity conditions between the regions to obtain the explicit analytical solutions of the seepage flow field around the pit. Calculations were compared using finite element software and other references, and the results were in good agreement, verifying the correctness of the analytical solution. Parameter analysis showed that the location and width of vertical leakage cracks have limited influence on the head distribution of the foundation pit and water pressure around the water curtain, but significant influence on the seepage flow at the leakage location. Full article

In this paper, the freezing and strengthening project of the Sanya estuary tunnel is analyzed, which is facilitated by the use of the partial differential equation (PDE) module in COMSOL Multiphysics software. The solid–liquid ratio is utilized as the water–heat coupling term, and the solid mechanics module is introduced to achieve three-field coupling. Numerical simulations are conducted to study changes in the temperature field, moisture field, and vertical displacement due to freezing and expansion in the most unfavorable soil layer during the freezing process. The results indicate that a complete freezing curtain forms around the 30th day. The distribution of freezing pipes significantly influences the freezing effect. The strong freezing zone is characterized by a high cooling rate and rapid water content reduction with the opposite trends being observed in the weak freezing zone. Upon completion of the freezing process, a large uplift of the ground surface is observed with more pronounced vertical displacement changes in areas affected by temperature and phase changes. The maximum vertical displacement of the ground surface deviates from the center position. While the frozen soil curtain meets the design requirements for freezing, the effects of freezing and expansion should be taken into account. These findings could be instrumental in elaborating the most effective freezing and expansion control measures for areas with powdery clay-based layers in AGF-based projects. Full article

An anisotropic foundation pit steady-state seepage field under a suspended waterproof curtain support considering the position of the free surface is studied analytically, and an analytical solution for the free surface position is given. The head distribution in the three zones is expressed as a series solution using the separation of variables method, and the explicit solution for the extent of the seepage field in each zone is obtained by combining the continuity condition between zones and the series orthogonality condition. The free surface position is determined according to the condition that the total head of the free surface is equal to the position head. A comparison of the calculation results of the analytical method and the indoor test and finite element analysis results verifies the correctness of the analytical solution, and the analytical method has more calculation efficiency than the finite element numerical method. Employing the aforementioned methods to analyze the influence parameters of the free surface position, the results show that drawdown increases as the ratio of the vertical permeability coefficient to the horizontal permeability coefficient increases; the greater the ratio of pit width to depth, the more significant the drawdown, but when the ratio continues to exceed 1.5, the drawdown is negligible. Full article

Core wall rockfill dams are susceptible to cracking at the dam’s crest, as well as collapse and settlement of the rockfill during storage and operation periods, particularly due to rapid fluctuations in the water level in pumped storage power stations. Most studies on the impact of fluctuations in the reservoir’s water level on dam deformation have considered fluctuations of less than 5 m/d, while pumped storage power stations experience much larger fluctuations. Additionally, the seepage and stress fields within the dam’s rock and soil interact and influence each other. Few studies have used the coupling theory of seepage and stress to analyze seepage and deformation in core wall rockfill dams. To address these issues, a finite element model using seepage–stress coupling theory was utilized to investigate the variations in the phreatic line, earth pressure, and deformation of a core wall rockfill dam due to rapid fluctuations in the reservoir’s water level. Additionally, the results of the finite element simulation were compared with and analyzed alongside safety monitoring data. The results indicated that, upon a sudden decrease in the reservoir’s water level, there was a lag in the decline of the phreatic line in Rockfill I, which created a large hydraulic gradient, resulting in a reverse seepage field on the dam’s slope surface and generating a drag force directed upstream. Consequently, a significant concentration of stress occurred on one-third of the upstream slope surface of the dam and the seepage curtain, and the increase in horizontal displacement was substantially greater than the increase in settlement from one-third of the rockfill’s height to the dam’s foundation. The deformation was more sensitive to the lowest water level of the reservoir rather than to the fastest rate of decline. Sudden rises in the reservoir’s water level result in decreased horizontal displacements and settlement of the dam. Amid rapid fluctuations of the reservoir’s water level, changes in the vertical earth pressure were more pronounced at the bottom of the core wall than in its midsection. Compared with the core wall, variations in the vertical earth pressure in the upstream and downstream filter layers were minor at similar elevations. A peak horizontal displacement of 6.5 mm was noted at one-third the height of Rockfill I, with the greatest increase in settlement of 3.5 mm at the dam’s crest. To ensure a project’s safety, it is crucial to control the elevation of the lowest point during a sudden drop in the reservoir’s level and to carefully monitor for cracks or voids within approximately one-third of the dam’s height in Rockfill I and at the dam crest. This study’s results provide a scientific basis for assessing core wall rockfill dams’ health and securing long-term safety at pumped storage power facilities. Full article

For water temperature stratified reservoirs, stratified water intake structures are used to extract surface warm water to reduce the adverse effects of low-temperature discharge on river habitats and agricultural irrigation. A physical simulation method has been explored and used to conduct the comparative experimental study on the efficiency of the three types of intake structures: a traditional stoplog gate intake, a stoplog gate with a horizontal curtain and a vertical curtain upstream of the intake. In order to extend the laboratory results to the prototype, a similarity relationship for water temperature stratification was derived based on the principle of equal density stratification Froude number between the model and the prototype, as well as the functional relationship between water density and temperature. The similarity relationship makes it possible to simulate the same prototype density flow under different laboratory water temperature conditions, and this was confirmed through experiments conducted in several months with different water temperatures. Under constant water flow conditions, a stable target water temperature distribution can be formed in the experimental model through continuous stratified heating and real-time power regulation, to simulate the density flow generated by various intake operation in water temperature stratified reservoir. The relationships between the intake water temperature and the reference water temperature at intake depth in reservoir were analyzed to distinguish the difference of water intake efficiency. The experimental results showed that, the traditional stoplog gate has a relatively lower efficiency in extracting warm water affected by the lower edge expansion of the drag layer into the cold water zone below the intake elevation; by setting horizontal curtain to prevent the cold water from climbing below, it is helpful to improve the water intake efficiency; by setting vertical curtain in the upstream area of the intake, the velocity of warm water in the upper part of the drag layer increases, and the intake efficiency has been significantly improved. The above research provides a scientific approach for mechanism research and mathematical model validation of thermal density flow. Full article

In order to reduce the impact of outdoor extreme weather events on crop production in winter, energy saving in greenhouses that are regularly heated is of great importance in reducing production costs and carbon footprints. For this purpose, the variations in indoor temperature, relative humidity and dew point temperature in the vertical direction (2 m, 4 m, 5.7 m) of thermal curtains in greenhouses were determined. In addition, depending on the fuel used, the curtains’ effects on heat energy consumption, heat transfer coefficient, carbon dioxide equivalents released to the atmosphere and fuel cost were investigated. To reach this goal, two greenhouses with the same structural features were designed with and without thermal curtains. As a result of the study, the indoor temperature and relative humidity values in the greenhouse with a thermal curtain increased by 1.3 °C and 10% compared to the greenhouse without a thermal curtain. Thermal curtains in the greenhouse significantly reduced fuel use (59.14–74.11 m³·night⁻¹). Considering the heat energy consumption, the average heat energy consumption was 453.7 kWh·night⁻¹ in the greenhouse with a curtain, while it was 568.6 kWh·night⁻¹ in the greenhouse without a curtain. The average heat transfer coefficient (U) values were calculated at 2.87 W·m⁻² °C with a thermal curtain and 3.63 W·m⁻² °C without a thermal curtain greenhouse. In the greenhouse, closing the thermal curtain at night resulted in heat energy savings of about 21%, related to the decrease in U values. The use of a thermal curtain in the greenhouse reduced the amount of CO₂ released to the atmosphere (116.6–146.1 kg·night⁻¹) and fuel cost (USD 21.3–26.7·night⁻¹). To conclude, extreme weather events in the outdoor environment adversely affect the plants grown in greenhouses where cultivation is performed out of season. A thermal curtain, used to reduce these adverse effects and the amount of energy consumed, is essential in improving indoor climate conditions, providing more economical greenhouse management and reducing the CO₂ released into the atmosphere due to fuel use. Full article
