In the context of the automotive industry, this paper proposes an enhancement of the numerical simulation using FEM and performing material choosing with the Ashby method for automotive brake discs, using the symmetric shape of the disc. Automotive braking involves the dissipation of kinetic energy through heat generation due to friction, a physical phenomenon that alters the mechanical properties of brake discs. This prompts automotive development engineers to investigate new materials capable of absorbing heat while maintaining their mechanical properties. A thermomechanical study of a ventilated front brake disc has successfully demonstrated a good performance of cast iron because the equivalent stress is significantly lower than the elastic limit, with a margin of approximately 73 MPa. Compared to validated results extracted from the state of the art, the adopted methodology gives more realistic results with minimum CPU requirements, where the total time of calculation is around 40 min. More than that, the results are suitable to be used for studying durability and other properties like mechanical impact and fatigue. Full article

The results of research on the influence of the chemical composition of cast iron and its potential changes in the production cycle on the elastic properties and the correctness of numerical simulations of the natural frequency of ventilated brake discs are presented. The tests were carried out for three grades of gray cast iron with flake graphite with a eutectic saturation coefficient ranging from 0.88 to 1.01. A quantitative metallographic assessment of the pearlitic cast iron matrix and graphite precipitates was carried out, and the hardness and compressive/tensile strength of individual cast iron grades were determined, taking into account the limit contents of the alloying elements. Next, ultrasonic tests were performed, and the elastic properties of cast iron were determined. Based on the obtained data, a numerical modal analysis of brake discs was performed, the results of which were compared with the actual values of an FRF frequency analysis. The error of the computer simulations was estimated at approx. 1%, and it was found that the accuracy of the calculations of the first natural frequency did not depend on the dimensions (size) of the discs and the chemical composition of the cast iron from which they were cast. The functional relationships between the chemical composition of cast iron, its strength and elasticity and the first natural frequency of the disc vibrations were determined, and a database of the material parameters of the produced cast iron grades was developed. An implementation example showed the validation of the brake disc design with natural frequency prediction and demonstrated a high convergence of the experimental results with the simulated values. Using I-MR control cards, both the effectiveness of designing and predicting the natural vibrations of brake discs based on the implemented material database as well as the stability of the gray cast iron production and disc casting processes were confirmed. Full article

Brake particle emissions number (PN) and mass (PM) of a light-duty hybrid-electric vehicle have been assessed under realistic driving patterns on a chassis dynamometer. Therefore, the front-right disc brake was enclosed in a specifically designed casing featuring controlled high scavenging air ventilation. The WLTC cycle was chosen for most measurements. Different scavenging flow rates have been tested assessing their influence on the measured particles as well as on the temperature of the braking friction partners. Particle transport efficiencies have been assessed revealing scavenging flow rates with losses below 10%. During the performed cycle, most brake particle emissions occurred during braking. There were also isolated emission peaks during periods with no brakes in use, especially during vehicle accelerations. Sequential WLTC cycles showed a continuous decrease in the measured PN and PM emissions; however, size-number and size-mass distributions have been very similar. The measured PN emission factors (>23 nm) at the right front wheel over the WLTC cycle lie at 5.0 × 10¹⁰ 1/km, whereas the PM emission factor lies at 3.71 mg/km for PM < 12 µm and 1.58 mg/km for PM < 2.5 µm. These values need to roughly triple in order to obtain the brake particle emission of all four brakes and wheels of the entire vehicle. Thus, the brake PN emissions factors have been in the same order of magnitude as the tailpipe PN of a Euro 6 light-duty vehicle equipped with a particle filter. Finally, differences between brake particle emissions in hybrid and all-electric operating modes have been assessed by a series of specific measurements, demonstrating the potential of all-electric vehicle operation in reducing brake particles by a factor of two. Full article

For the unique structural characteristics of ventilated brake discs and the complex problem of energy conversion during braking, a calculation method for energy conversion of the ventilated brake disc based on simultaneous heat generation and heat dissipation is proposed. The transient heat transfer model of the ventilated brake disc for high-speed trains is established. Considering the control equations of heat generation–heat dissipation and plate–cylinder convection heat transfer, the virtual simulation of the energy change of the ventilated brake disc during the braking process is carried out. The temperature and stress distribution of contact friction surface and clearance structure of the ventilated brake disc are analysed from the perspective of function conversion. The results show that the heat generated by the ventilated brake disc increases nonlinearly, and the heat dissipated increases linearly. The heat of ventilated brake disc increases with the increase of braking time, but its growth rate decreases continuously. The maximum temperature of the ventilated brake disc is 268 °C, which appears on the friction surface. After braking, its heat is 6.636 × 10⁶ J. The analysis results and methods provide a basis for optimizing the structure of ventilated brake discs. Full article

Vented brake rotors used in an automobile behave similarly to centrifugal fans, drawing cool air from the inboard side, passing it through the disc vents, and exhausting it from the periphery. A vented brake rotor with a better heat dispersing ability is often superior to a solid rotor, in both thermal performance and brake efficiency. In this research, a fully parameterized model for a ventilated brake rotor is created using the ANSYS Parametric Design Language, to uniquely define the rotor’s geometry. With this parameterized model, two structural optimization cases are studied in this paper. The first one investigated is a modal frequency separation problem: The frequency differences in a tangential mode sandwiched between two nodal diameter modes of the brake rotor model are maximized. An automatic identification scheme for extracting correct mode orders is implemented in the program to track the correct modes during optimization. The second case is a thermal deformation problem: The distortion on the frictional surfaces of the rotor loaded with heat flux generated during the braking process is minimized. The optimization results show that a brake rotor design with a thinner outboard disc and a thicker inboard disc provides a great choice for rotor coning reduction. Full article

A brake disc decelerates the vehicle through friction with the brake pads. When the brake system is overheated, brake fade can occur, in which the friction coefficient drops significantly. Additionally, an over-heated brake system may cause vapor lock, in which the brake hydraulic fluid is vaporized. These phenomena can lead to the loss of braking power and cause a fatal accident. Therefore, brake systems must have stable braking and heat dissipation performance. Having through-holes and slits on the friction surface of the rotor has been adopted to improve the heat dissipation performance, but the holes become stress points and potentially cause cracks. Therefore, brake systems should be designed to have structural stability as well as good heat dissipation. In this study, finite element (FE) modeling was developed to analyze the structural stability and heat dissipation performance of a brake system, and structural and thermal simulations were performed in ANSYS, a CAE software package. In addition, to minimize concentrated stress and temperature, optimal design of the shape and pattern of holes and slits was carried out using PIAnO, an integrated optimal design software package. The first step of design optimization was performed while considering the shape and pattern of the disc holes and slits as design factors. Among the design factors, those with the largest effects on the objective functions were found and set as new design factors to perform the second step. The designs were compared to existing discs. Through the optimization presented in this paper, it is expected that the performance of the braking system will improve and the life of the brake parts will be increased. Full article

A new approach to numerical simulation using the finite element method (FEM) for the rotational motion of discs for railway vehicle disc brake systems was proposed. For this purpose, spatial models of transient heating due to the friction of such systems with solid and ventilated discs were developed. The performed calculations and the results obtained allowed justification of the possibility of simplifying the shape of the ventilated brake disc through elimination of ventilation channels. This contributes to a significant reduction in computational time, without compromising the accuracy of the results. The spatial and temporal temperature distributions in the ventilated and the solid disc of the same mass were analyzed. The share of energy dissipated due to convection and thermal radiation to the environment in relation to the total work done during a single braking was investigated. The maximum temperature values found as a result of computer simulations were consistent with the corresponding experimental results. Full article

The operating conditions during the braking process in an automobile affect the tribological contact between the pad and disc brake, thus, influencing the times and distances of braking and, in a more significant way, the safety of the braking process. This mathematical work aimed to provide a general visualization of the disc brake’s mechanical, dynamic, and thermal behavior under different operating conditions through 2D maps of the power dissipated, braking time, and braking distance of a disc brake with a ventilation blade N- 38 type. However, the dissipated energy on the disc brake in terms of temperature was analyzed considering Newton’s cooling law and mathematical calculations through classical theories of the dynamic and mechanical behavior of the disc brakes. For this purpose, the Response Surface Methodology (RSM) and Distance Weighted Least Squares (DWLS) fitting model considered different operating conditions of the disc brake. The results demonstrate that the disc brakes can be used effectively in severe operational requirements with a speed of 100 km/h and an ambient temperature of 27 °C, without affecting the occupant’s safety or the braking system and the pad. For the different conditions evaluated, the instantaneous temperature reaches values of 182.48 and 82.94 °C, where the high value was found for a total deceleration to 100 km/h to 0, which represent a total braking distance of around 44.20 to 114.96 m depending on the inclination angle (θ). Furthermore, the energy dissipation in the disc brakes depends strongly on the disc, blades and pad geometry, the type of material, parameters, and the vehicle operating conditions, as can be verified with mathematical calculation to validate the contribution of the effectiveness of the braking process during its real operation. Full article

In the braking system, the heat dissipation generated by the friction between the disc and pad should be evacuated as quickly as possible. In this work, five common different automotive disc brakes were studied through mathematical theories of heat transfer and numerical methods using the ANSYS software. In addition, a direct comparison between experimental, theoretical, and simulation values found in the open literature was performed to propose a disc brake with an improved geometry in terms of dissipation of heat transfer. The numerical results were considered to propose two possible solutions of disc brake geometries using N-38 ventilation blades used in aeronautic engineering. An improvement in temperature dissipation was achieved by approximately 23.8% compared to the five geometries analyzed with a simple type N-38 ventilation blade. The heat dissipation in the brakes strongly depends on the geometry of the disc, the geometry of the blades, the material from which it is manufactured, the material of the pad, the weight of the vehicle, and the operating conditions, as can be verified with mathematical calculations and experiments. The results obtained demonstrate that the discs can be used effectively in extreme working conditions (80 km/h and 33°C), without affecting the safety of the occupants and the braking system. Full article

This paper investigated a failure in a ventilated disc brake in an automobile. The failed brake disc had been in service for approximately 10 years. The observed failure was in the form of radial cracks that appeared to have initiated at the outer edge of the disc brake. The cracks were rather straight with no branching. Optical microscope, scanning electron microscope (SEM), and energy dispersive X-ray spectroscopy (EDS) were used to study the microstructure of the failed disc. Vickers microhardness test was also used to evaluate the hardness of the samples. Results showed that the root cause of crack formation, in this case, was related to the excessive wear in the brake disc. Different wear mechanisms, namely abrasive and adhesive wear, were recognized in the failed specimen. Moreover, the worn surface in some areas was covered with fine oxide particles. These particles appeared to have a significant contribution toward abrasion. To further understand the wear mechanisms, pin-on-disc experiments were also conducted on the samples. Results of the pin-on-disc experiments were compared and correlated to the results obtained from the failed brake disc. Full article
