The Polish Free-Electron Laser (PolFEL), which is currently under construction in the National Centre for Nuclear Research in Świerk near Warsaw, will comprise an electron gun and from four to six cryomodules, each accommodating two nine-cell TESLA RF superconducting resonant cavities. To cool the superconducting resonant cavities, the cryomodules will be supplied with superfluid helium at a temperature of 2 K. Other requirements regarding the cooling power of PolFEL result from the need to cool the power couplers for the accelerating cryomodules (5 K) and thermal shields, which limit the heat inleaks due to radiation (40–80 K). The machine will utilize several thermodynamic states of helium, including two-phase superfluid helium, supercritical helium, and low-pressure helium vapours. Supercritical helium will be supplied from a cryoplant by a cryogenic distribution system (CDS)—transfer line and valve boxes—where it will be thermodynamically transformed into a superfluid state. This article presents the architecture of the CDS, discusses several design solutions that could have been decided on with the use of second law analysis, and presents the design methodology of the chosen CDS elements. Full article

In the past, the possibility to retrieve the total column of water vapour (TCWV) from the thermal infrared (TIR) day and night measurements above water surfaces of the dual-view Along Track Scanning Radiometers (ATSR) has been demonstrated, and an algorithm, named Advanced InfrarRed Water Vapour Estimator (AIRWAVE), was developed and successfully applied to the measurements of the (A)ATSR instrument series. A similar instrument, the Sea and Land Surface Temperature Radiometer (SLSTR), is currently operating on board the Sentinel 3 satellite series. In this paper, we demonstrate that the AIRWAVE algorithm can be successfully applied to the SLSTR instrument to obtain reliable TCWV measurements. The steps performed for upgrading the algorithm are thoroughly described. The new AIRWAVE algorithm makes use of parameters computed offline with a state-of-the-art radiative transfer model using the most recent spectroscopic data and continuum model. For the parameters calculation, a new climatology capable of representing the average atmospheric and sea surface status during SLSTR measurements has been developed. The new algorithm, named AIRWAVE-SLSTR, has been implemented in both IDL and Python languages. In the frame of an EUMETSAT contract, AIRWAVE-SLSTR has been applied to a full year of SLSTR measurements (2021) and the retrieved TCWV have been validated with the help of both satellite- and ground-based measurements. The correlation of the retrieved TCWV with satellite MW measurements is 0.94 and the average bias is of the order of 0.66 kg/m${}^2$. When compared to ground-based measurements, the average correlation is 0.93 and the bias −0.48 kg/m${}^2$. The obtained accuracy is well within the requirements set for both numerical weather predictions (1–5 kg/m${}^2$) and for coastal altimetry applications (1.8–3 kg/m${}^2$). Therefore, the AIRWAVE-SLSTR algorithm can be safely applied to obtain a long time series of reliable TCWV above water surfaces. Full article

When the vapour–gas mixture flow heats the cold walls of a heat exchanger, condensed phase (solid and liquid) precipitation can occur on their surfaces. This study aims to improve a model of thermohydraulic processes in a heat exchanger during condensed phase precipitation on its cold surfaces. The process is considered to occur when a multi-component solid-phase layer and a liquid film are simultaneously formed on the wall. Heat is transferred to the interface surface through radiation and convection and due to the phase transition of diffusing components. The mass flow to the interphase surface is determined for each diffusing component. The developed model allows for the calculation of heat transfer parameters in both steady-state and transient conditions, taking into account the formation of a multi-component condensed phase on cold walls. Full article

With the growing demand for drug products requiring lyophilization, it is essential to either expand aseptic drying capacity or improve the efficiency of existing capacity through process intensification, ensuring that resources are utilized to their full potential. In this regard, mathematical models are highly recommended to assist professionals in process optimization. To effectively utilise these models, it is also essential to develop robust techniques for determining key parameters, including the product resistance to vapour flow. Traditional experimental methods for evaluating this coefficient are time-intensive and/or require the insertion of probes into the product, which is not feasible at a manufacturing scale. This study addresses these challenges by introducing a novel deep learning framework designed to predict the mass transfer coefficient directly from Field Emission Scanning Electron Microscope images. This approach significantly streamlines the evaluation process, leveraging the high-resolution capabilities of Field Emission Scanning Electron Microscope for detailed analysis. In this work, we focus on advanced Field Emission Scanning Electron Microscope image processing, choice of strategic convolutional neural network configuration, and thorough model performance evaluation to predict the mass transfer coefficient. Given the frequent scarcity of datasets in this field, we have employed data augmentation techniques to enhance the robustness of our model. The results demonstrate good predictive accuracy (error on the interpolation test data lower than 5%), highlighting the potential of this framework to facilitate the assessment of mass transfer coefficients in freeze-dried products. Full article

In this paper, droplet vaporization dynamics in a heated bubbling fluidized bed was studied. A volatile hydrocarbon liquid jet comprising acetone was injected into a hot bubbling fluidized bed of Geldart A-type glass ballotini particles heated at 150 °C, well above the saturation temperature of acetone (56 °C). Intense interactions were observed among the evaporating droplets and hot particles during contact with the re-suspension of particles due to a release of vapour. A non-intrusive schlieren imaging method was used to track the hot air and vapour mixture plume in the freeboard region of the bed and the acetone vapour fraction therein was mapped. The jet vaporization dynamics in the bubbling fluidized bed was modelled in a Eulerian–Lagrangian CFD (computational fluid dynamics) modelling framework involving heat and mass transfer sub models. The CFD model indicated a dispersion of the vapour plume from the evaporating droplets which was qualitatively compared with the schlieren images. Further, the CFD simulation predicted a significant reduction (~60 °C) in the local bed temperature at the point of the jet injection, which was indirectly confirmed in an experiment by the presence of particle agglomerates. Full article

In nature, engineering technology and daily life, wetting phenomena are widespread and have essential roles and significance. Bionics is becoming increasingly important nowadays and exploring the mechanism that influences biomimetic surface microstructure on droplet wetting process and heat and mass transfer characteristics is becoming more meaningful. In this paper, based on photolithography technology, SU-8 photoresist was used as raw material to prepare biomimetic surfaces with microstructures in various arrangements. The research results show that the wettability of biomimetic functional surfaces can be regulated by regulating the shape and arrangement of photoresist micro-pillars. At the same time, the effects of surface microstructure configuration and roughness on the heat and mass transfer processes within the droplets were also comprehensively studied. The results show that a biomimetic surface with cylindrical micro-pillars can effectively inhibit the evaporative cooling effect of the liquid–vapour interface. This effect becomes more evident with the increase in roughness, and the interface temperature difference can be reduced by up to 18%. Similarly, the biomimetic surface with cylindrical micro-pillars can also effectively promote the evaporation rate of sessile droplets, which can be increased by about 13%. In addition, the research also shows that regardless of the structure, substrate temperature changes will significantly impact the wetting phenomenon of the biomimetic surface. This study aims to guide the optimal design of biomimetic surfaces prepared based on photoresistance. Full article

This paper presents experimental and theoretical studies of heat transfer through single- and double-glazed windows with electrical heating of the internal surfaces. Heating is achieved by applying a voltage to the low emissivity coating of the inner glass. A thermophysical model has been developed to simulate the heat transfer through these units, allowing us to determine their thermal characteristics. Experimental data are used to validate the numerical model. The resulting heat flux and temperature distributions on the external and internal surfaces of electrically heated double-glazed units are analysed. According to the results of experimental and numerical studies, it was found that the adopted electric heating scheme allows 83–85% of the heat to enter the room and 15–17% is removed to the outside. This makes it possible to increase the radiation component of the heat flow from the window to the room and improve the thermal comfort in the room. In general, this article shows that existing industrial windows with low-emissivity glass surface coating can be upgraded with simple and inexpensive modernisation, without compromising the main function of the window—efficient transmission of visible light—and create an additional (backup) heating device that can work effectively together with the existing heating system in the event of a sudden cold snap at low temperatures (below −20 °C), to prevent condensation of water vapour in the windows, and to prevent condensation on the surface of the window facade wall. Formally, a back-up (emergency) heating system is created in the room, which contributes to the energy sustainability of the building and therefore to energy security in general. Full article

The behaviour of bubbles in cavitation and boiling processes is determined by the thermodynamic parameters of the two-phase medium and the intensity of heat and mass transfer, which affect the final dynamic effects. In this review, we analyse the influences of these factors on bubble behaviour, as described in existing mathematical models. In particular, we analyse the physical processes that govern bubble behaviour, the influence of mass transfer, vapor and liquid temperature, vapour, and liquid pressure on the inertial and dynamic stages of development. In conclusion, we summarize the problems associated with modelling, the accuracy of numerical predictions, and propose directions for further research. Full article

In the field of convective drying, several models have been proposed by different research groups, both theoretical and empirical. However, research on theoretical mathematical models has been superficial and needs to be extended. Empirical models present difficulties in their implementation in other research. It is suggested that further research should focus on obtaining models adaptable to different species and environmental conditions. The aim of this work was to analyse the current state of research on the drying process and mass transfer. It is concluded that drying is a mathematically complex process that must be modelled with differentiated equations in two stages: constant drying rate stage and decreasing drying rate stage. The modelling of the constant drying phase can be based on the convective mass transfer equation, although the prediction of the coefficient with analogies to heat transfer has deviations in biomass. Modelling of the variable rate drying phase should focus on the variation of water diffusivity in porous materials or vapour permeability as a function of material moisture and temperature. A database of homogenised equations particularised for each material needs to be generated to predict drying rates and times under predetermined convection conditions. This represents a scientific challenge and suggests that research in drying kinetics still needs development. Full article

Experiments on specimen cooling dynamics and possible film boiling around a body are very important in various industrial applications, such as nucleate boiling, to decrease drag reduction or achieve better surface properties in coating technologies. The objective of this study was to investigate the interaction between the heat transfer processes and cooling dynamics of a sample in different boundary conditions. This article presents new experimental data on specimens coated with Al–TiO₂ film and Leidenfrost phenomenon (LP) formation on the film’s surface. Furthermore, this manuscript presents numerical heat and mass transfer parameter results. The comparative analysis of new experiments on Al–TiO₂ film specimens and other coatings such as polished aluminium, Al–MgO, Al–MgH₂ and Al–TiH₂ provides further detail on oxide and hydride materials. In the experimental cooling dynamics experiments, specimens were heated up to 450 °C, while the sub-cooling water temperatures were 14*‒20 °C (room temperature), 40 °C and 60 °C. The specimens’ cooling dynamics were calculated by applying Newton’s cooling law, and heat transfer was estimated by calculating the heat flux $q$ transferred from the specimens’ surface and the Bi parameter. The metadata results from the performed experiments were used to numerically model the cooling dynamics curves for different material specimens. Approximated polynomial equations are proposed for the polished aluminium, Al–TiO₂, Al–MgO, Al–MgH₂ and Al–TiH₂ materials. The provided comparative analysis makes it possible to see the differences between oxides and hydrides and to choose materials for practical application in the industrial sector. The presented results could also be used in software packages to model heat transfer processes. Full article

The possibility of directly growing carbon nanofibers (CNFs) and carbon nanotubes (CNTs) on half-Heusler alloys by Chemical Vapour Deposition (CVD) is investigated for the first time, without using additional catalysts, since the half-Heusler alloys per se may function as catalytic substrates, according to the findings of the current study. As a carbon source, acetylene is used in the temperature range of 700–750 °C. The n-type half-Heusler compound ${\left({\mathrm{Z}\mathrm{r}}_{0.4}{\mathrm{T}\mathrm{i}}_{0.6}\right)}_{0.33}{\mathrm{N}\mathrm{i}}_{0.33}{\left({\mathrm{S}\mathrm{n}}_{0.98}{\mathrm{S}\mathrm{b}}_{0.02}\right)}_{0.33}$ is utilized as the catalytic substrate. At first, a computational model is developed for the CVD reactor, aiming to optimize the experimental process design and setup. The experimental process conditions are simulated to investigate the reactive species concentrations within the reactor chamber and the activation of certain reactions. SEM analysis confirms the growth of CNFs with diameters ranging from 450 nm to 1 μm. Raman spectroscopy implies that the formed carbon structures resemble CNFs rather than CNTs, and that amorphous carbon also co-exists in the deposited samples. From the characterization results, it may be concluded that a short reaction time and a low acetylene flow rate lead to the formation of a uniform CNF coating on the surface of half-Heusler alloys. The purpose of depositing carbon nanostructures onto half-Heusler alloys is to improve the current transfer, generated from these thermoelectric compounds, by forming a conductive coating on their surface. Full article

Though the transition from disposable to reusable surgical gowns holds substantial promise, successful implementation faces challenges. This study investigated tactile and thermophysiological comfort in surgical reusable gowns, comparing them with their disposable counterparts. Parameters such as surface roughness, compression, heat flux, and material rigidity were tested using a Fabric Touch Tester. Additionally, the water vapour permeability and static charge of the gowns were assessed. Thermophysiological comfort of the gowns was evaluated by measuring the temperature and relative humidity (RH) on test subjects during wear trials where they were engaged in an activity that mimics a surgeon’s performance. Skin temperature was monitored using iButton sensors and a thermal camera, and the impact on heart rate during the task was analysed. Following each test, participants provided subjective feedback through a questionnaire. The results indicated that reusable gowns boasted a smoother texture, translating to reduced friction on the skin and better heat transfer compared to the disposable fabrics, as indicated using FTT. They also exhibited higher water vapour permeability compared to their disposable counterparts. The wear trials revealed minimal differences in comfort between disposable and reusable gowns. While performing the activity, an increase in body temperature led to decreased RH, yet this rise did not adversely affect subject comfort, as validated using heart rate and questionnaire survey data. From a comfort point of view, switching from disposable to reusable gowns would not have drawbacks, meaning hospitals should be able to switch provided logistics and costs can be managed. Full article

This study aims to provide condensation heat transfer coefficients of R600a (isobutane) refrigerant under mass fluxes between 50 and 98 kg/m²·s at saturation temperatures of 35 °C, 40 °C and 45 °C. Additionally, experiments are conducted with varying inlet vapour quality to understand its effect on the condensation heat transfer measurement. An aluminium multiport microchannel with a hydraulic diameter ($D_h$) of 0.399 mm is used, where a plexiglass cover is mounted on the top of the microchannels to observe the flow conditions. A 1D heat transfer through the aluminium block is assumed, and heat flux through the refrigerant to the coolant is measured to obtain condensation heat transfer coefficients of R600a. The results showed that decreasing saturation temperature and increasing vapour quality increase the condensation heat transfer coefficient. Increasing refrigerant mass flux increases the heat transfer coefficient up to a specific mass flux. It is observed that the effect of inlet vapour quality becomes significant as introduced quality decreases due to increasing fluctuation. Full article

Near-stoichiometric lithium tantalate (NSLT) wafers with different Li contents were prepared by vapour transfer equilibrium (VTE) method and fabricated into surface acoustic wave filters. The temperature coefficient of frequency, insertion loss, and bandwidth of the surface acoustic wave filters were tested using a special chip test bench and a network analyzer. The results show that the temperature coefficient of frequency shows a trend of first decreasing and then increasing with the increase in Li content, and the temperature stability of the surface acoustic wave filters is best when the Li content is 49.75%. It is also found that the surface acoustic wave filter fabricated from NSLT wafers has 21.18% lower temperature coefficient of frequency, 7.3% lower insertion loss, and 2.8% lower bandwidth than those fabricated from congruent lithium tantalate wafers. Therefore, NSLT crystals are more suitable for applications in acoustic devices, providing a new idea for performance enhancement of 5G communication devices. Full article

Pulsed laser deposition (PLD) is a simple and extremely versatile technique to grow thin films and nanomaterials from a wide variety of materials. Compared to traditional fabrication methods, PLD is a clean physical vapour deposition approach that avoids complicated chemical reactions and by-products, achieving a precise stochiometric transfer of the target material onto the substrate and providing control over the film thickness. Halide perovskite materials have attracted extensive attention due to their excellent photoelectric and photovoltaic properties. In this paper, we present an overview of the fundamental and practical aspects of PLD. The properties and preparation methods of the halide perovskite materials are briefly discussed. Finally, we will elaborate on recent research on the preparation of perovskite solar cells by PLD, summarize the advantages and disadvantages of the PLD preparation, and prospect the all-vacuum PLD-grown solar cells in a full solar cell structure. Full article
