This study presents the development and process integration of an alternative demoulding system for high-pressure die casting. The system is aimed at the removal of large structural castings, which are becoming increasingly popular in the industry under the terms mega- and gigacasting. The development differs from conventional systems in the fact that it completely avoids ejectors and realises the demoulding via the principle of vacuum suction cups. Preliminary tests were carried out in which various established materials for vacuum cups were initially identified and the suitability of the selected cup concept was investigated by varying influencing variables from the high-pressure die casting. These tests showed that a suction pad material combination of an elastomer with a thermal barrier and an aramid felt on the surface provides the best results under the given process boundary conditions. Based on this, a multi-segmented vacuum mask with contour adaptation to the casting to be removed was developed. This vacuum mask is used to build up the holding force between the casting and the removal device. The necessary removal force is applied via pneumatic cylinders. The functional capability of the concept and the system integration was verified by experiments on a real die-casting mould for test specimens. The shrinkage and demoulding process can be successfully modelled in the simulation and the real measured demoulding force is only approx. 15% higher than in the simulation. During demoulding in the high-pressure die-casting process, vacuums of up to 88.7% were achieved at temperatures up to 395 °C. Full article

To enhance the performance of ultra-high voltage power fittings in severe weather conditions without altering their current structure, the high-strength and toughness aluminum alloys were rationally selected to study the optimization of the die-casting process. This approach aims to improve the overall longevity and function of the power fittings in extreme climates. First of all, the propose of this study is to use the material’s strength–toughness product (STP) concept to evaluate the material stability of the power fitting impact resistance and fatigue toughness in order to determine the appropriate material selection. Secondly, the location of the mold’s sprue and gate was optimized through finite element simulation to prevent gas volume and flow defects during the casting process. This improves the material’s toughness and anti-fatigue failure characteristics of the product. Then, vacuum equipment and a vacuum valve auxiliary system were added based on the existing die-casting machine, and the mold structure was optimized to enable the vacuum die-casting process. Finally, a water-based boron nitride environmentally friendly mold release agent was used to solve demolding difficulties with an A356 aluminum alloy and improve mold lubrication and surface quality. The production of quad-bundled spacers using A356 and vacuum die casting has resulted in parts with a tensile strength of at least 250 MPa and an elongation of no less than 7%. This improvement has laid a foundation for enhancing the operational reliability of existing overhead transmission line fittings. Full article

Concrete is the most widely used building material today. The enormous amount used goes hand in hand with high material consumption and CO₂ emissions. Thus, building with concrete must be improved, becoming part of the solution on the way to climate-friendly building. Non-metallic fibres are an alternative to corrosion-sensitive steel reinforcement, and they enable the production of filigree, high-performance, structured components with low concrete cover. This article presents an alternative manufacturing method. Our thesis was that concreting under negative air pressure conditions (APC) allows the easy production of complicated, thin-walled geometries without defects or loss of mechanical properties. We firstly present the principle of the vacuum-assisted method and its technical realization. The proof of concept included the production and laboratory tests of different specimens, casted under normal and negative APC. The fine concrete’s properties were determined in flexural and compression tests. Textile-reinforced concrete was analysed in tensile and bond tests as well as in bending trials on 2.7 m long shell elements. To summarize, it can be stated that the mechanical properties achieved were comparable, independent of the manufacturing conditions. The production quality of the shell elements was improved by concreting under negative APC. Finally, an outlook is given to further improve the method. Full article

Magnesium alloys, known as a “21st-century green engineering material”, are widely used in many fields, including during the production and consumption of magnesium alloys die-casting products such as AZ91D, AM50, and AM60B. In addition, a large amount of waste is generated, which not only pollutes the environment but also wastes secondary resources. Hereby, we reported the vacuum gasification—directional condensation method, calculated the vapor pressure separation coefficient parameters, and drew the gas-liquid phase equilibrium diagram depending on the distillation temperature, condensation temperature, and system pressure for the magnesium volatilization process. The results showed that under the following conditions (distillation temperature: 1073 K, system pressure: 100 Pa, condensation temperature: 873 K, and condensation duration: 30 min), the magnesium volatilization yield could approach 93.76%, and the purity of magnesium could reach 99.98%. This research is a good theoretical and practical basis for the recovery of magnesium alloy waste using the vacuum gasification method. Full article

AlSi12(Fe), AlSi10Mg(Fe), AlSi10MnMg, and AlMg4Fe2 die-casting alloys were produced by high-pressure die casting (HPDC) and vacuum-assisted high-pressure die casting (VADC) under a vacuum level of 200 mbar. The chemical composition, hardness, gas and shrinkage porosity, and mechanical properties were analyzed. The parts under study were subjected to a T6 heat treatment. The VADC led to a decrease in the percentage of defects in the as-cast state for all the alloys, due to a reduction in the amount of gas porosities. After heat treatment, the quantity of gas and shrinkage porosities increased. The efficiency and level of vacuum used were not sufficient to improve the mechanical properties in the as-cast state. The ductility of AlSi10Mg(Fe) and AlSi10MnMg alloys was improved after heat treatment; however, the YS and UTS of AlSi10Mg(Fe) did not increase. The primary aluminum alloys presented higher elongation values than the secondary aluminum alloys due to the reduced amount of the needle-like β-Al₅FeSi phase. Full article

Herein, we demonstrate a facile technique for the fabrication of one-dimensional indium antimonide (InSb) nanowires using anodic aluminium oxide (AAO) template-assisted vacuum die-casting method. The filling mechanism of the vacuum die-casting process is investigated on varying AAO pore structures through different electrolytes. It is found that the anodizing electrolytes play a vital role in nanowire growth and structure formation. The as-obtained InSb nanowires from the dissolution process show a degree of high crystallinity, homogeneity, and uniformity throughout their structure. The TEM and XRD results elucidated the InSb zinc-blende crystal structure and preferential orientation along the c-axis direction. The thermoelectric characteristics of InSb nanowires were measured with a four-electrode system, and their resistivity, Seebeck coefficient, power factor, thermal conductivity, and ZT have been evaluated. Further, surface-modified nanowires using the reactive-ion etching technique showed a 50% increase in thermoelectric performance. Full article

Zr-based amorphous alloy is a new energetic material that has been closely monitored and extensively studied for the design of highly effective shaped charge warheads in recent years. In order to accurately determine the motion parameters of shaped charge jets during the detonation-driven formation process of Zr-based amorphous alloy liners, we prepared conical ZrCuNiAlAg liners by vacuum die casting and supercooled liquid high-rheological-rate formation processes. Based on jet-formation numerical simulation, pulsed X-ray imaging and copper foil target velocity measuring tests were conducted to identify the variation trend of the jet velocity of Zr-based amorphous alloy liners with time. The jet velocities at typical moments in the free flight stage were verified. The research results showed that Zr-based amorphous alloy liners could produce solid jets, whose velocity was in gradient descent from the head to the tail, and that the jet’s head velocity peaked at 12 μs and then slowly decreased with time. The average velocities measured by the X-ray imaging and copper foil target tests were 6913 m/s and 7177 m/s, respectively, and both of them were in good agreement with the simulation results, verifying the accuracy of the numerical simulation model for jet formation. The formation processes of shaped charge liners were found to affect the mechanical properties of the material and thus, the jet’s formation process and motion parameters. The Zr-based amorphous alloy liner formed by the supercooled liquid-phase high-rheological-rate formation process exhibited a jet velocity 6.5% higher than that formed by the vacuum die casting process. Full article

With the rise in the demand for eco-friendly and electric vehicles, welding and heat treatment are becoming very important to meet the necessary weight reduction, complexity, and high functionality of die castings. Pore-free (PF) die casting is an effective process that enables heat treatment and welding due to low gas porosities. Indeed, this process affords castings of low gas porosity, similar to those attained by high-vacuum die casting. In this study, we compared the gas porosities of different castings fabricated by PF die casting using varied injected oxygen amounts. The castings were all subjected to T6 heat treatment and analyzed by computed tomography (CT) to compare their microstructure and mechanical properties before and after T6 heat treatment. The results revealed that with the increasing injected oxygen amount, the gas porosity of the specimens decreased while their mechanical properties increased. In particular, the gas porosity was the lowest at 1.26 L. Moreover, the 1.26 L specimen displayed the best tensile strength, yield strength, and elongation results. Finally, Weibull distribution analysis revealed that the tensile strength and elongation repeatability and reproducibility increased with increasing injected oxygen amount. Full article

Graphene oxide (GO) has been a prized material for fabricating separation membranes due to its immense potential and unique chemistry. Despite the academic focus on GO, the adoption of GO membranes in industry remains elusive. One of the challenges at hand for commercializing GO membranes lies with large-scale production techniques. Fortunately, emerging studies have acknowledged this issue, where many have aimed to deliver insights into scalable approaches showing potential to be employed in the commercial domain. The current review highlights eight physical methods for GO membrane fabrication. Based on batch-unit or continuous fabrication, we have further classified the techniques into five small-scale (vacuum filtration, pressure-assisted filtration, spin coating, dip coating, drop-casting) and three large-scale (spray coating, bar/doctor blade coating, slot die coating) approaches. The continuous nature of the large-scale approach implies that the GO membranes prepared by this method are less restricted by the equipment’s dimensions but rather the availability of the material, whereas membranes yielded by small-scale methods are predominately limited by the size of the fabrication device. The current review aims to serve as an initial reference to provide a technical overview of preparing GO membranes. We further aim to shift the focus of the audience towards scalable processes and their prospect, which will facilitate the commercialization of GO membranes. Full article

An integrated precipitation and strengthening model, incorporating the effect of precipitate morphology on precipitation kinetics and yield strength, is developed based on a modified Kampmann–Wagner numerical (KWN) framework with a precipitate shape factor. The optimized model was used to predict the yield strength of Al-Si-Mg-Mn casting alloys produced by vacuum high pressure die casting at various aged (T6) conditions. The solid solution strengthening contribution of Mn, which is a common alloying element to avoid die soldering, was included in the model to increase the prediction accuracy. The experimental results and simulations show good agreement and the model is capable of reliably predicting yield strength of aluminum die castings after T6 heat treatment, providing a useful tool to tailor heat treatment for a variety of applications. Full article

The absolute pressure strongly affects the porosity and mechanical properties of castings produced by vacuum high-pressure die casting (V-HPDC) technology. The pore size, quantity and distribution of AlSi₉Cu₃ samples under three absolute pressures were evaluated by X-ray tomography and optical and electron microscopy. The paper presents an elaboration the stress concentration mechanism of pores affecting the tensile properties. According to a mathematical analysis of a sample under uniaxial stress, the greater the radius of the pore, the higher the stress value is at the pore perimeter. When the absolute pressure drops from 1013 mbar to 100 mbar, the porosity decreases from 6.8% to 2.8%, and the pore number and mean size decreases. In tensile tests, the pore sizes of the fracture surface decrease with decreasing absolute pressure, and the pore distribution becomes uniform. The tensile properties and extensibility of the sample are improved, and the microscopic fracture surface of the sample changes from cleavage fracture to quasi-cleavage fracture. The number, size and distribution of pores in die casting collectively affect the properties of the sample. Large-size or complex pores or pores with concentrated distributions produce large stress concentrations, decreasing the strength of the metal. Full article

Al–Si–Mg based alloys can provide high strength and ductility to satisfy the increasing demands of thin wall castings for automotive applications. This study has investigated the effects of T6 heat-treatment on the microstructures, the local mechanical properties of alloy phases and the fracture behavior of high vacuum die-cast AlSiMgMn alloys using in-situ scanning electron microscopy (SEM) in combination with nano-indentation testing. The microstructures of the alloys at as-cast and T6 treated conditions were compared and analyzed. It is found that the T6 heat treatment plays different roles in affecting the hardness and the Young’s modulus of alloy phases. This study also found that the T6 heat treatment would influence the failure modes of the alloys. The mechanisms of crack propagation in the as-cast and T6 treated alloys were also analyzed and discussed. Full article

The quench sensitivities of an AlSi10Mg alloy in permanent mold (PM) and high-pressure vacuum die (HPVD) castings were investigated with time–temperature–transformation and time–temperature–property diagrams using an interrupted quench technique. The quench-sensitive temperature range of the HPVD casting sample is 275–450 °C, and its nose temperature is 375 °C. The quench-sensitive range of the PM casting sample is 255–430 °C, and the nose temperature is 350 °C. The mechanical strength versus the cooling rate in both casting samples were predicted via a quench factor analysis and verified experimentally. The critical cooling rate of the HPVD casting sample is 20 °C/s whereas it is 17 °C/s for the PM casting sample. With a shorter critical time, higher nose temperature, and higher critical cooling rate, the HPVD casting sample exhibits a higher quench sensitivity than the PM casting sample. The differences in the quench sensitivities of the AlSi10Mg alloy due to the different casting processes is explained via the different precipitation behavior. At the nose temperature, coarse β-Mg₂Si precipitates mainly precipitate along the grain boundaries in the HPVD casting sample, whereas rod-like β-Mg₂Si precipitates distribute in the aluminum matrix in the PM casting. Full article

Forming complex geometries using the casting process is a big challenge for bulk metallic glasses (BMGs), because of a lack of time of the window for shaping under the required high cooling rate. In this work, we open an approach named the “entire process vacuum high pressure die casting” (EPV-HPDC), which delivers the ability to fill die with molten metal in milliseconds, and create solidification under high pressure. Based on this process, various Zr-based BMGs were prepared by using industrial grade raw material. The results indicate that the EPV-HPDC process is feasible to produce a glassy structure for most Zr-based BMGs, with a size of 3 mm × 10 mm and with a high strength. In addition, it has been found that EPV-HPDC process allows complex industrial BMG parts, some of which are hard to be formed by any other metal processes, to be net shaped precisely. The BMG components prepared by the EVP-HPDC process possess the advantages of dimensional accuracy, efficiency, and cost compared with the ones formed by other methods. The EVP-HPDC process paves the way for the large-scale application of BMGs. Full article

The aim of this work is to study the microstructure of four high entropy alloys (HEAs) produced by large scale vacuum die casting. Al₄₀Cu₁₅Mn₅Ni₅Si₂₀Zn₁₅, Al₄₅Cu₁₅Mn₅Fe₅Si₅Ti₅Zn₂₀, Al₃₅Cu₅Fe₅Mn₅Si₃₀V₁₀Zr₁₀, and Al₅₀Ca₅Cu₅Ni₁₀Si₂₀Ti₁₀ alloys formed a mixture of different structures, containing intermetallic compound (IC) and solid solution (SS) phases. The phases observed in the casting alloys were compared with the equilibrium phases predicted by Thermo-Calc. The measured densities varied from 3.33 g/cm⁻³ to 5.07 g/cm⁻³ and microhardness from 437 Hv to 887 Hv. Thus, the microhardness and estimated strength/density ratios are significantly higher than other lightweight high entropy alloys (LWHEAs). Full article
