Search Results (48)

Lamb waves offer a series of desirable features for Structural Health Monitoring (SHM) applications, such as the ability to detect small defects, allowing to detect damage at early stages of its evolution. On the downside, their propagation through media with multiple geometrical features results in complicated patterns, which complicate the task of damage detection, thus hindering the realization of their full potential. This is exacerbated by the fact that numerical models for Lamb waves, which could aid in both the prediction and interpretation of such patterns, are computationally expensive. The present paper provides a flexible surrogate to rapidly evaluate the sensor response in scenarios where Lamb waves propagate in plates that include multiple features or defects. To this end, an offline–online ray tracing approach is combined with Frequency Response Functions (FRFs) and transmissibility functions. Each ray is thereby represented either by a parametrized FRFs, if the origin of the ray lies in the actuator, or by a parametrized transmissibility function, if the origin of the ray lies in a feature. By exploiting the mechanical properties of propagating waves, it is possible to minimize the number of training simulations needed for the surrogate, thus avoiding the repeated evaluation of large models. The efficiency of the surrogate is demonstrated numerically, through an example, including different types of features, in particular through holes and notches, which result in both reflection and conversion of incident waves. For most sensor locations, the surrogate achieves an error between 1% and 4%, while providing a computational speedup of three to four orders of magnitude. Full article

In this paper, we introduce an advanced AI-based solution for predicting structural damage in aircraft laminates. Our innovative approach focuses on detecting and locating fatigue damage within composite structures, thereby enhancing the assessment of aircraft health and usage. By leveraging state-of-the-art ultrasonic guided wave (UGW) inspection simulations of composite laminates integrated with piezoelectric transducers, comprehensive datasets are extracted efficiently. The signals captured by the piezoelectric sensors are utilized to engineer key features sensitive to composite structural damage, which are then used to train a deep neural network (DNN) for accurate structural damage prediction. Our findings demonstrate the significant potential of combining advanced simulation techniques with machine learning to improve the accuracy and reliability of structural health monitoring in aerospace applications. Full article

Unidirectional ultrasonic guided waves (UGWs) play a crucial role in the nondestructive testing and evaluation (NDT&E) domains, offering unique advantages in detecting material defects, evaluating structural integrity, and improving the accuracy of thickness measurements. This review paper thoroughly studies the state of the art of unidirectional UGWs before presenting a comprehensive review of the foundational mathematical principles of unidirectional UGWs, focusing on the recent advancements in their methodologies and applications. This review introduces ultrasonic guided waves and their modes before looking at mode excitability and selectivity, signal excitation, and mechanisms used to generate and receive guided waves unidirectionally. This paper outlines the applications of unidirectional UGWs to reflect their effectiveness, for instance, in measuring thickness and in identifying defects such as cracks and corrosion in pipelines, etc. The paper also studies the challenges associated with unidirectional UGW generation and utilisation, such as multi-mode and side lobes. It includes a review of the literature to mitigate these challenges. Finally, this paper highlights promising future perspectives and develops directions for the technique. This review aims to create a useful resource for researchers and practitioners to comprehend unidirectional ultrasonic guided waves’ capabilities, challenges, and prospects in NDT&E applications. Full article

This work leverages ultrasonic guided waves (UGWs) to detect and localize damage in structures using lightweight Artificial Intelligence (AI) models. It investigates the use of machine learning (ML) to train the effects of the damage on UGWs to the model. To reduce the number of trainable parameters, a physical signal processing approach is applied to the raw data before passing the data to the model. Starting from current state of the art in algorithms used for damage detection and localization, an AI-based technique is developed and validated on an experimental benchmark dataset before tiny ML implementation on a low-cost development board. A discussion of the need for a balance between the reduction in computational resources and increasing the precision of the models is also reported. It is shown that by extracting simple features of the signal, the models required to predict the damage locations can be significantly reduced in size while still having high accuracies of over 90%. In addition, it is possible to use these predictions to construct a fairly accurate heat map indicating the likely damage locations. Finally, a convenient edge/cloud visualization of the results can be achieved by simplifying the heat map. Full article

Ultrasonic-guided waves (UGWs) in defective pipes are subject to severe coherent noise caused by imperfect detection conditions, mode conversion, and intrinsic characteristics (dispersion and multiple modes), inducing the limited performance of anomaly imaging. To achieve the high resolution and accuracy of anomaly imaging, a multi-strategy hybrid sparse reconstruction (MHSR) method based on spatial–temporal sparse wavenumber analysis (ST-SWA) is proposed. MHSR leverages the capability of ST-SWA to extract the wavenumber dispersion curves, thereby providing a more refined and precise search space for MHSR. Furthermore, it mitigates the impact of coherent noise by conducting dispersion compensation on the reconstructed signal. The sparse compensated signals through MHSR are employed for sparse reconstruction imaging. To validate the efficacy of the proposed method, UGW testing is performed on the defective steel pipe, and the results demonstrate the significant enhancement of anomaly imaging in defect resolution and positioning accuracy. The lowest estimated errors for axial and circumferential defect positions are 10 mm and 4 mm, respectively. Full article

The multimodal and dispersive character of ultrasonic guided waves (UGW) offers the potential for non-destructive evaluation of fiber-reinforced composite (FRC) materials. In this study, a methodology for in situ stiffness assessment of FRCs using UGWs is introduced. The proposed methodology involves a comparison between measured wave speeds of the fundamental symmetric and antisymmetric guided wave modes with a pre-established dataset of UGW speeds and translation of them to corresponding stiffness properties, i.e., $ABD$-components, in an inverse manner. The dispersion relations of guided waves have been calculated using the semi-analytical finite element method. First, the performance of the proposed methodology has been assessed numerically. It has been demonstrated that each of the independent $ABD$-components of the considered laminate can be approximated with an error lower than 10.4% compared to its actual value. The extensional and bending stiffness properties can be approximated within an average error of 3.6% and 9.0%, respectively. Secondly, the performance of the proposed methodology has been assessed experimentally. This experimental assessment has been performed on a glass fiber-reinforced composite plate and the results were compared to mechanical tensile and four-point bending tests on coupons cut from the plate. Larger differences between the estimated $ABD$-components according to UGW and mechanical testing were observed. These differences were partly attributed to the variation in material properties across the test plate and the averaging of properties over the measurement area. Full article

Ultrasonic guided wave (UGW) inspection is an emerging non-destructive testing(NDT) technique for rail flaw detection, where weak UGW signals under strong noise backgrounds are difficult to detect. In this study, a UGW signal identification model based on a chaotic oscillator is established. The approach integrates the UGW response into the critical state of the Duffing system to serve as a disturbance control variable. By evaluating the system’s motion state before and after introducing the UGW response, identification of UGW signals can be realized. Thus, the parameters defining the critical state of Duffing oscillators are determined by $K_e$. Moreover, an electromagnetic transducer was specifically devised to enable unidirectional excitation for UGWs targeted at both the rail base and rail head. Experimental studies showed that the proposed methodology effectively detected and located a 0.46 mm notch at the rail base and a 1.78 mm notch at the rail head. Furthermore, $K_e$ was directly proportional to the notch size, which could be used as a quantitative index to characterize the rail flaw. Full article

The early detection of small cracks in large metal structures is a crucial requirement for the implementation of a structural health monitoring (SHM) system with a low transducers density. This work tackles the challenging problem of the early detection of submillimeter notch-type defects with a semielliptical shape and a groove at a constant width of 100 µm and 3 mm depth in a 4.1 mm thick aluminum plate. This defect is investigated with an ultrasonic guided wave (UGW) A₀ mode at 550 kHz to investigate the long range in thick metal plates. The mode selection is obtained by interdigital transducers (IDTs) designed to operate with a 5 mm central wavelength. The novel contribution is the validation of the detection by pulse-echo and pitch and catch with UGW transducers to cover a distance up to 70 cm to reduce the transducers density. The analysis of scattering from this submillimeter defect at different orientations is carried out using simulations with a Finite Element Model (FEM). The detection of the defect is obtained by comparing the scattered signals from the defect with baseline signals of the pristine laminate. Finally, the paper shows that the simulated results are in good agreement with the experimental ones, demonstrating the possible implementation in an SHM system based on the efficient propagation of an antisymmetric mode by IDTs. Full article

Machine learning techniques such as deep learning have already been successfully applied in Structural Health Monitoring (SHM) for damage localization using Ultrasonic Guided Waves (UGW) at various temperatures. However, a common issue arises due to the time-consuming nature of collecting guided wave measurements at different temperatures, resulting in an insufficient amount of training data. Since SHM systems are predominantly employed in sensitive structures, there is a significant interest in utilizing methods and algorithms that are transparent and comprehensible. In this study, a method is presented to augment feature data by generating a large number of training features from a relatively limited set of measurements. In addition, robustness to environmental changes, e.g., temperature fluctuations, is improved. This is achieved by utilizing a known temperature compensation method called temperature scaling to determine the function of signal features as a function of temperature. These functions can then be used for data generation. To gain a better understanding of how the damage localization predictions are made, a known explainable neural network (XANN) architecture is employed and trained with the generated data. The trained XANN model was then used to examine and validate the artificially generated signal features and to improve the augmentation process. The presented method demonstrates a significant increase in the number of training data points. Furthermore, the use of the XANN architecture as a predictor model enables a deeper interpretation of the prediction methods employed by the network. Full article

High-density polyethylene (HDPE) pipes are becoming increasingly popular, being used in various fields, such as construction, marine, petroleum, water transfer, process water, methane gas collection, oil and gas gathering, gas distribution systems, mining, acid and wet gas lines, offshore oil and gas and in nuclear power plants. Higher-order guided Lamb wave (UGW) modes can be used to detect various defects in complex structures. We will apply this methodology to one of the types of plastic—the structure of high-density polyethylene (HDPE). However, the excitation of UGW modes faces numerous challenges, especially when there is a need to identify which mode is excited. It is essential to note that, in the higher frequency range, multiple different higher-order modes can usually be excited. This can make it difficult to determine which modes have actually been excited. The objective of this research was to successfully excite and receive various higher-order UGW modes in high-density polyethylene structures using both ultrasonic single-element transducers and a phased array. Theoretical calculations were performed using a variety of methods: semi-analytical finite element (SAFE) method, 2D spatial–temporal spectrum analysis and finite element modeling (FEM). The results obtained from both measurements and simulations clearly demonstrate the possibility of efficiently exciting and receiving different Lamb wave modes possessing different phase velocities. Full article

This paper describes, for the first time, the application of an Elastodynamic Boundary Element Method (BEM) in Laplace Domain for the Structural Health Monitoring (SHM) of poly-crystalline materials. The study focuses on Ultrasonic Guided Wave (UGW) propagation and investigates the wave–material interactions at micro-scale. The study aims to investigate the interaction of UGWs with assessing micro-structural features such as grain size, morphology, degradation, and flaws. Numerical simulations of the most common micro-structural features demonstrate the accuracy and validity of the proposed method. Particular attention is paid to the study of porosity and its influence on material macro-properties. Different crystal morphologies such as cubic, rhombic, and truncated octahedral are considered. The detection of voids based on the changes in the amplitude and Time of Arrival (ToA) of the backscattered signal is investigated. The study also considers inter-granular cracks, which cause laceration, and examines flaw position/orientation, length, and distance from a specific reference. Furthermore, a framework is proposed for generating Probability of Detection (PoD) curves using numerical simulations. Experimental tests in pristine conditions are shown to be in good agreement with the numerical simulations in terms of ToA, signal amplitude, and wave velocity. The numerical simulations provide insights into wave propagation and wave–material interactions, including different types of defects at the micro-scale. Overall, the BEM and UGW methods are shown to be effective tools for better understanding micro-structural features and their influence on the macro-structural properties of poly-crystalline materials. Full article

Ultrasonic guided waves (UGWs) in water-filled pipes are subject to more severe dispersion and attenuation than vacant pipes, posing significant challenges for defect identification and localization. To this end, a novel sparse signal decomposition method called orthogonal matching pursuit based on dispersion and multi-mode (DMOMP) was proposed, which utilizes the second-order asymptotic solution of dispersion curves and the conversion characteristics of asymmetric UGWs in the defect contact stage to reconstruct the dispersive signals and converts the time-domain dispersive signals to distance-domain non-dispersive signals by dispersion compensated time-distance mapping. The synthesized simulation results indicate that DMOMP not only exhibits higher reconstruction accuracy compared to OMP, but also reveals more accurate and stable mode recognition and localization compared to DOMP, which only considers the dispersion under perturbation and noise. In addition, the UGW testing experimental results of water-filled pipes verify the effectiveness of DMOMP, the localization accuracies of three feature signals (defct 1, defct 2 and end echo) with DMOMP are 99.10%, 98.72% and 98.36%, respectively, and the average localization accuracy of DMOMP is as high as 98.73%. Full article

This paper describes a study that focuses on assessing the influence of composites with different thicknesses (2 mm, 4 mm, and 9 mm) on embedded ultrasonic guided waves (UGWs) under varying temperatures. The study also demonstrates the effectiveness of these embedded sensors in identifying damage. A novel cut-out method that included an embedded diagnostic layer and phased-array lead zirconate titanate (PZT) transducers, created using the ink-jet printing technique in the manufacturing process was employed. The research then focused on studying the behavior of UGWs under varying temperatures for each composite panel. This analysis aimed to understand how temperature variations affected the propagation of guided waves in thick composites. Finally, artificial damage on the surface and impact damage were introduced, both embedded and surface-mounted PZT transducers were used to detect and locate these damages in different thickness composite panels. The results of damage localization indicated that the embedded PZT transducers were more sensitive than the surface-mounted transducers in locating the damage in thick composites. Full article

Ultrasonic guided waves (UGW) are widely used in structural health monitoring (SHM) systems due to the sensitivity of their propagation mechanisms to local material changes, i.e., those induced by damage. Post-processing of the signals gathered by piezoelectric sensors, typically used for both the excitation and the sensing of UGW, is a fundamental step to extract all the peculiar features that can be related to both damage location and severity. This research probes the efficacy of machine learning (ML) models in discerning damage location (R-Classification) and size (S-Classification). Seven supervised ML classifiers were examined: Ensemble-Subspace K-Nearest Neighbors (KNN), Ensemble-Bagged Trees, KNN-Fine, Ensemble-Boosted Trees, Support Vector Machine (SVM), Linear Discriminant, and SVM-Quadratic. The experimental dataset comprised measurements from varied reversible damage configurations on a composite panel, represented by wooden cuboids of single and three different sizes. Signal noise was minimized by performing a low-pass filter, and sequence forward selection-aided feature selection. The optimized ensemble classifier proved to be the most precise for R-Classification (95.83% accuracy), while Ensemble-Subspace KNN excelled in S-Classification (98.1% accuracy). This method offers accurate, efficient damage diagnosis and classification in composite structures, promising potential applications in aerospace, automotive, and civil engineering sectors. Full article

This research utilizes Ultrasonic Guided Waves (UGW) to inspect corrosion-type defects in steel pipe walls, providing a solution for hard-to-reach areas typically inaccessible by traditional non-destructive testing (NDT) methods. Fundamental helical UGW modes are used, allowing the detection of defects anywhere on the pipe’s circumference using a limited number of transducers and measurements on the upper side of the pipe. Finite element (FE) modeling and experiments investigated generating and receiving UGW helical waves and their propagation through varying corrosion-type defects. Defect detection is based on phase delay differences in the helical wave’s signal amplitude peaks between defective and defect-free regions. Phase delay variations were noted for the different depths and spatial dimensions of the defects. These results highlight the phase delay method’s potential for NDT pipeline inspection. Full article
