High-strength polymer fibers such as nylon 6, nylon 6,6, and polyethylene are utilized to produce Twisted and Coiled Artificial Muscles (TCAMs) through the twisting of low-cost fibers. These artificial muscles exhibit high displacement and specific power, particularly under electrothermal actuation, which requires conductive elements. An experimental setup was developed to produce, thermally treat, and characterize commercially available nylon 6,6 fibers coated with silver. The results demonstrate that TCAMs can contract by over 15% and generate forces up to 2.5 N with minimal energy input. Key factors such as motor speed, applied load, and fiber geometry affect the overall performance. Full article

Electro-conductive films with excellent flexibility and thermal behavior have great potential in the fields of wearable electronics, artificial muscle, and soft robotics. Herein, we report a super-elastic and electro-conductive composite film with a sandwich structure. The composite film was constructed by spraying Polyvinyl alcohol (PVA) polymers onto a buckled conductive carbon nanotube-polydimethylsiloxane (CNTs-PDMS) composite film. In this system, the PVA and PDMS provide water sensing and stretchability, while the coiled CNT film offers sufficient conductivity. Notably, the composite film possesses high stretchability (205%), exceptional compression sensing ability, humility sensing ability, and remarkable electrical stability under various deformations. The produced CNT composite film exhibited deformation (bending/twisting) and high electro-heating performance (108 °C) at a low driving voltage of 2 V. The developed CNT composite film, together with its exceptional sensing and electrothermal performance, provides the material with promising prospects for practical applications in wearable electronics. Full article

In this work, the conformational behaviors of ring polyelectrolyte in tetravalent salt solutions are discussed in detail through molecular dynamics simulation. For simplification, here we have neglected the effect of the twisting interaction, although it has been well known that both bending and twisting interactions play a deterministic in the steric conformation of a semiflexible ring polymer. The salt concentration C_S and the bending energy b take a decisive role in the conformation of the ring polyelectrolyte (PE). Throughout our calculations, the b varies from b = 0 (freely joint chain) to b = 120. The salt concentration C_S changes in the range of 3.56 × 10⁻⁴ M ≤ C_S ≤ 2.49 × 10⁻¹ M. Upon the addition of salt, ring PE contracts at first, subsequently re-expands. More abundant conformations are observed for a semiflexible ring PE. For b = 10, the conformation of semiflexible ring PE shifts from the loop to two-racquet-head spindle, then it condenses into toroid, finally arranges into coil with the increase of C_S. As b increases further, four phase transitions are observed. The latter two phase transitions are different. The semiflexible ring PE experiences transformation from toroid to two racquet head spindle, finally to loop in the latter two phase transitions. Its conformation is determined by the competition among the bending energy, cation-bridge, and entropy. Combined, our findings indicate that the conformations of semiflexible ring PE can be controlled by changing the salt concentration and chain stiffness. Full article

This study investigates the performance enhancement of mandrel-coiled twisted and coiled polymer fibers with a nichrome heater (TCP_FL^NR) by coating with a solution of graphene–mesoporous carbon–nickel–polyvinyl alcohol. The coating process involved a one-pot synthesis utilizing graphene powder, Ni nanoparticles, mesoporous carbon, and PVA as a binding agent. The coating was performed by manually shaking the TCP_FL^NR and the subsequent annealing process, which results in improved thermal conductivity and actuation behavior of the TCP_FL^NR. Experimental results on a 60 mm long actuator demonstrated significant enhancements in actuation displacement and actuation strain (20% to 42%) under various loads with an input current of 0.27 A/power 2.16 W. The blocked stress is ~10 MPa under this 2.16 W power input and the maximum strain is 48% at optimum load of 1.4 MPa. The observed actuation strain correlated directly with the input power. The coated TCP_FL^NR exhibited better thermal contacts, facilitating enhanced heat transfer, and reducing power consumption by 6% to 9% compared to non-coated actuators. It was found that the nanomaterial coating helps the TCP actuator to be reliable for more than 75,000 actuation cycles at 0.1 Hz in air due to improved thermal conductivity. These findings highlight the potential for further research to optimize electrothermally operated TCP actuators and unlock advancements in this field. Full article

In this paper, a new socially assistive robot (SARs) called HBS-1.2 is presented, which uses 6-ply twisted and coiled polymer (TCP) artificial muscles in its hand to perform physical tasks. The utilization of 6-ply TCP artificial muscles in a humanoid robot hand is a pioneering advancement, offering cost effective, lightweight, and compact solution for SARs. The robot is designed to provide safer human–robot interaction (HRI) while performing physical tasks. The paper explains the procedures for fabrication and testing of the 6-ply TCP artificial muscles, along with improving the actuation response by using a Proportional-Integral-Derivative (PID) control method. Notably, the robot successfully performed a vision-based pick and place experiment, showing its potential for use in homecare and other settings to assist patients who suffer from neurological diseases like Alzheimer’s disease. The study also found an optimal light intensity range between 34 to 108 lumens/m², which ensures minimal variation in calculated distance with 95% confidence intervals for robust performance from the vison system. The findings of this study have important implications for the development of affordable and accessible robotic systems to support elderly patients with dementia, and future research should focus on further improving the use of TCP actuators in robotics. Full article

A soft actuator is an essential component in a soft robot that enables it to perform complex movements by combining different fundamental motion modes. One type of soft actuator that has received significant attention is the twisted and coiled polymer artificial muscle (TCP actuator). Despite many recent advancements in TCP actuator research, its use as an extensile actuator is less common in the literature. This works introduces the concept of using TCP actuators as thermal-driven extensile actuators for robotics applications. The low-profile actuator can be easily fabricated to offer two unique deformation capabilities. Results from the characterization indicate that extensile actuators, made with various rod diameters and under different load conditions, display remarkable elongation deformation. Additionally, a proof-of-concept soft-earthworm robot was developed to showcase the potential application of the extensile actuator and to demonstrate the benefits of combining different types of motion modes. Full article

The soft robot is a new type of robot with strong adaptability, good pliability, and high flexibility. Today, it is widely used in the fields of bioengineering, disaster rescue, industrial production, medical services, exploration, and surveying. In this paper, the typical driven methods, 3D printing technologies, applications, the existed problems, and the development prospects for soft robots are summarized comprehensively. Firstly, the driven methods and materials of the soft robot are introduced, including fluid driven, smart materials driven, chemical reaction driven, a twisted and coiled polymer actuator, and so on. Secondly, the basic principles and characteristics of mainstream 3D printing technologies for soft materials are introduced, including FDM, DIW, IP, SLA, SLS, and so on. Then, current applications of soft robots, such as bionic structures, gripping operations, and medical rehabilitation are described. Finally, the problems existing in the development of soft robots, such as the shortage of 3D printable soft materials, efficient and effective manufacturing of soft robots, shortage of smart soft materials, efficient use of energy, the realization of complex motion forms of soft robot, control action accuracy and actual kinematic modeling are summarized. Based on the above, some suggestions are put forward pertinently, and the future development and applications of the soft robot are prospected. Full article

Twisted and coiled polymer (TCP) artificial muscles can exhibit unidirectional actuation similar to skeletal muscles. This paper presents a TCP driven artificial musculoskeletal actuation module that can be used in soft robots. This module can contract in the axis direction, and the contraction displacement and force can be controlled easily. The main body of the actuation module consists of TCP muscles and leaf springs, and the deformation of the module is actuated by the TCP muscles. A prototype was made to test the performance of the module. The design and experimental results of the module are presented. The module can provide contraction motion. Results show that the module can provide a contraction force of 0.7 N with displacement of approximately 6.8 mm at 120 °C when exposed to electrical power of 24 V. The proposed artificial musculoskeletal actuation module can potentially be applied in biomimetic robots and the aerospace field. Full article

To achieve high durability and excellent mechanical performances of cementitious materials, research on fiber-reinforced cementitious composites (FRCC) containing various fibers has been actively conducted. On the other hand, in robotics and other fields, research on artificial muscles using Twisted and Coiled Polymer Actuator (TCPA), which have similar functions to human muscle fibers, has attracted much attention. In this study, use of this TCPA as a reinforcing fiber in high performance FRCC (HPFRCC) was proposed. The employed TCPA has a structure of coiled nylon fibers with wrapping stainless-steel fibers. The effect of the TCPA and its shrinkage motion on the crack dispersion properties of HPFRCC was investigated. The experimental results showed that the strain-hardening with multiple cracks in HPFRCC continued up to more than 7% of the ultimate strain when the TCPA was electrically stimulated to shrinkage motion. This information indicates that the TCPA has high potential to further improve HPFRCC performance. Full article

Twisted and coiled polymer (TCP) actuators are becoming increasingly prevalent in soft robotic fields due to their powerful and hysteresis-free stroke, large specific work density, and ease of fabrication. This paper presents a soft crawling robot with spike-inspired robot feet which can deform and crawl like an inchworm. The robot mainly consists of two leaf springs, connection part, robot feet, and two TCP actuators. A system level model of a soft crawling robot is presented for flexible and effective locomotion. Such a model can offer high-efficiency design and flexible locomotion of the crawling robot. Results show that the soft crawling robot can move at a speed of 0.275 mm/s when TCP is powered at 24 V. Full article

In this paper, we proposed a novel light-driven polymer actuator that could produce remotely controllable tensile stroke in response to near infrared (NIR) light. The light-driven polymer actuator was composed of a twisted and coiled nylon-6 fiber (TCN) and a thin poly(3,4-ethylenedioxythiophene) doped with p-toluenesulfonate (PEDOT-Tos) layer. By adopting dip-coating methodology with thermal polymerization process, we constructed a thin and uniform PEDOT-Tos layer on the surface of the three-dimensional TCN structure. Thanks to the PEDOT-Tos layer with excellent NIR light absorption characteristic, the NIR light illumination via a small LEDs array allowed the multiple PEDOT-Tos coated TCN actuators to be photo-thermally heated to a fairly consistent temperature and to simultaneously produce a contractile strain that could be modulated as high as 8.7% with light power. The actuation performance was reversible without any significant hysteresis and highly durable during 3000 cyclic operations via repetitive control of the LEDs. Together with its simple structure and facile fabrication, the light-driven actuator can lead to technical advances in artificial muscles due to its attractive benefits from remote controllability without complex coupled instruments and electromagnetic interference. Full article

Twisted coiled actuators (TCAs) are a type of soft actuator made from polymer fibres such as nylon sewing thread. As they provide motion in a compact, lightweight, and flexible package, they provide a solution to the actuation of wearable mechatronic devices for motion assistance. Their limitation is that they provide low total force, requiring them to actuate in parallel with multiple units. Previous literature has shown that the force and stroke production can be improved by incorporating them into fabric meshes. A fabric mesh could also improve the contraction efficiency, strain rate, and user comfort. Therefore, this study focused on measuring these performance metrics for a set of TCAs embedded into a woven fabric mesh. The experimental results show that the stroke of the actuators scaled linearly with the number of activated TCAs, achieving a maximum applied force of 11.28 N, a maximum stroke of 12.23%, and an efficiency of 1.8%. Additionally, two control methods were developed and evaluated, resulting in low overshoot and steady-state error. These results indicate that the designed actuators are viable for use in wearable mechatronic devices, since they can scale to meet different requirements, while being able to be accurately controlled with minimal additional components. Full article

Twisted and coiled polymer (TCP) can generate large stroke and output high power density, making it a promising artificial muscle. Thermally induced muscles fabricated from nylon or other polymer fibers can be used in robotic, biomedical devices, and energy-harvesting equipment. While fibers with different shapes and materials have different optimal process parameters. Understanding mechanisms of TCP forming and the impact of process parameters is critical to explore stronger, more powerful artificial muscles. In this paper, an elastic-rod-theory-based model was established for capturing the quantitative relationship between tensile actuation and fabrication load. Further experimental results agree with model calculation and TCP muscles used in our research reaches maximum stroke of 52.6%, strain up to 9.8 MPa, and power density of 211.89 J/kg. Full article

A twisted and coiled polymer actuator (TCPA) is a novel soft actuator. TCPA is fabricated by twisting nylon fibers. The TCPA extends and contracts by heating and cooling. By applying conductive nylon fibers to the actuator, the electroactive TCPA can be driven by the Joule heating of the applied voltage. It has noteworthy properties such as a high power/mass ratio, large deformation, and low hysteresis. By applying conductive nylon fibers to the actuator, it can be driven by the electrical input. From these properties, many soft robots using the electroactive TCPA have been demonstrated, such as robotic hands, locomotion robots, robot skins, biomimetic robots, and so on. In this paper, to realize a simple controller design, an internal model control based on the identified model is applied. The applied controller can be designed easily without experience in parameter-tuning based on controls theory. The validity of the applied method is investigated through experiments. Full article
