In the context of fifth-generation (5G) communications and the dawn of sixth-generation (6G) networks, a surged societal demand on bandwidth and data rate and more stringent commercial requirements on transmission efficiency, cost, and reliability are increasingly evident and, hence, driving the maturity of reconfigurable millimeter-wave (mmW) and terahertz (THz) devices and systems, in particular, liquid crystal (LC)-based tunable solutions for delay line phase shifters (DLPSs). However, the field of LC-combined electronics has witnessed only incremental developments in the past decade. First, the tuning principle has largely been unchanged (leveraging the shape anisotropy of LC molecules in microscale and continuum mechanics in macroscale for variable polarizability). Second, LC-enabled devices’ performance has yet to be standardized (suboptimal case by case at different frequency domains). In this context, this work points out three underestimated knowledge gaps as drawn from our theoretical designs, computational simulations, and experimental prototypes, respectively. The first gap reports previously overlooked physical constraints from the analytical model of an LC-embedded coaxial DLPS. A new geometry-dielectric bound is identified. The second gap deals with the lack of consideration in the suboptimal dispersion behavior in differential delay time (DDT) and differential delay length (DDL) for LC phase-shifting devices. A new figure of merit (FoM) is proposed and defined at the V-band (60 GHz) to comprehensively evaluate the ratios of the DDT and DDL over their standard deviations across the 54 to 66 GHz spectrum. The third identified gap deals with the in-depth explanation of our recent experimental results and outlook for partial leakage attack analysis of LC phase shifters in modern eavesdropping. Full article

This paper presents the design and implementation of a D-band CMOS phase shifter based on a parallel reflective-load topology. Two phase-shifting architectures are explored, namely a 360° continuously tunable phase shifter and a 180° phase shifter combined with a phase inverter, enabling full 360° phase coverage. The circuit was simplified, and the number of bias lines was minimized to facilitate future array circuit implementation. In addition, a serial peripheral interface (SPI) circuit is implemented to simplify bias control and reduce the number of external connections during array chip packaging. Full article

Ferroelectric thin films with a high dielectric tunability (η) have great potential in electrically tunable applications, including microwave tunable devices such as phase shifters, filters, delay lines, etc. Using a modified Landau–Devonshire type thermodynamic potential, we show that the dielectric tunability η of a (001) tetragonal ferroelectric film can be analytically solved. After a survey of materials, a large η value above 60% was predicted to be achievable in a (001)-oriented tetragonal Pb(Zr_0.52Ti_0.48)O₃ (PZT) film. Experimentally, (001)-oriented PZT thin films were prepared on LaNiO₃-coated (100) SrTiO₃ substrates by using pulsed laser deposition (PLD). These films exhibited good dielectric tunability (η ~ 67.6%) measured at a small electric field E of ~250 kV/cm (corresponding to 5 volts for a 200 nm thick film). It only dropped down to ~54.2% when E was further reduced to 125 kV/cm (2.5 volts for 200 nm film). The measured dielectric tunability η as functions of the applied electric field E and measuring frequency f are discussed for a 500 nm thick PZT film, with the former well described by the theoretical η(E) curves and the latter showing a weak frequency dependence. These observations validate our integrated approach rooted in a theoretical understanding. Full article

The present study is concerned with the power transfer efficiency enhancement using a combination of the multi-hop node (MHN) and the Intelligent Reflecting Surface (IRS)-based passive beamforming technologies. The primary objective is to ensure a high RF-DC converter power conversion efficiency (PCE) used at the receiving end, which is difficult to achieve due to path loss and multi-path propagation. An electronically tunable reconfigurable reflectarray (RRA) designed to operate at the sub-GHz ISM band (865.5 MHz) is utilized to implement the IRS concept. Both the MHN and RRA were developed and studied in our earlier research. The RRA redirects the reflected power-carrying wave amplified by the MHN toward the intended receiver. It comprises two layers: the RF layer containing tunable phase shifters and the ground plane. Each phase shifter comprises two identical eight-shaped metal patches coupled by a pair of varactor diodes used to achieve the reflection phase tuning. The phase gradient method is used to synthesize the RRA phase profiles, ensuring different desired reflection angles. The RRA prototype, composed of 36 phase shifters, is employed in conjunction with the MHN equipped with two antennas and an amplifier. The RRA parameter optimization is accomplished by randomly varying the varactor diode voltages and measuring the corresponding received power levels until the power reflected in the desired direction is maximized. Two measurement scenarios are examined: power transmission without and with the MHN. In the first scenario, the received power is calculated and measured at several distinct beam steering angles for different distances between the Tx antenna and RRA. The same procedure is applied to different distances between the RRA and MHN in the second scenario. The effect of slight deviations in the operating frequency from the designed one (865.5 MHz) on the RRA performance is also examined. Additionally, the received power levels for both scenarios are estimated via full-wave analysis performed using the full-wave simulation software Ansys HFSS 2023 R1. A Huygens’ surface equivalence principle-based model decomposition method was developed and employed to reduce the CPU time. The calculated results are consistent with the measured ones. However, some discrepancies attributed to the adverse effect of RRA diode biasing lines, manufacturing tolerances, and imperfection of the indoor environment model are observed. Full article

A filter-free, image-reject, sub-harmonic downconverted RoF link is proposed based on a dual-polarization quadrature phase-shift keying (DP–QPSK) modulator. At the remote antenna unit, the receiving radio frequency signal is applied to the upper QPSK modulator to achieve carrier-suppressed single-sideband (CS–SSB) modulation. The local oscillator (LO) is applied to the lower QPSK modulator, achieving sub-harmonic single-sideband (SH–SSB) modulation. The I/Q mixing is realized by exploiting a two-channel photonic microwave phase shifter, which mainly consists of a modulator, two polarization controllers, and two polarizers. The image interference signal can be rejected when combing the I and Q IF signals through a 90° electrical hybrid. Because the scheme is simple and filter-free, it has a good image-reject capability over a large frequency tunable range. Moreover, due to the special SH-SSB modulation, the modulated signals are immune to the chromatic dispersion-introduced power fading effect. Last, the sub-harmonic downconverter can decrease the frequency requirement of the LO signal. Experimental results show that an image rejection ratio (IRR) greater than 50 dB can be achieved when transmitted through a 25 km single-mode fiber (SMF). Simultaneously, under different RF signals and IF signals, the IRR has no periodic power fading, only small fluctuations. Image rejection capability of the scheme for the 50-MBaud 16-QAM wideband vector signal is also verified and the demodulation of the desired IF signal with a good EVM of less than 5% is realized. Full article

Building on the fully encapsulated architecture of liquid crystal (LC) coaxial phase shifters, which leverages noise-shielding advantages for millimeter-wave wideband reconfigurable applications, this study addresses the less-explored issue of low-frequency breakdown (LFB) susceptibility in modern full-wave solvers. Specifically, it identifies the vulnerability nexus between the tuning states (driven by low-frequency bias voltages) and the constitutive elements of LC-filled coaxial phase shifters—namely, the core line, housing grounding, and radially sandwiched tunable dielectrics—operating at millimeter-wave frequencies (60 GHz WiGig), microwave (1 GHz), and far lower frequency regimes (down to 1 MHz, 1 kHz, and 1 Hz) for long-wavelength or quasi-static conditions, with specialized applications in submarine communications and geophysical exploration. For completeness, the study also investigates the device state prior to LC injection, when the cavity is air-filled. Key computational metrics, such as effective permittivity and characteristic impedance, are analyzed. The results show that at 1 kHz, deviations in effective permittivity exceed four orders of magnitude compared to 1 GHz, while characteristic impedance exhibits deviations of three orders of magnitude. More critically, in the LFB regime, theoretical benchmarks from 1 MHz to 1 kHz and 1 Hz demonstrate an exponential increase in prediction error for both effective permittivity, rising from 16.8% to 1.5 × ${10}^4$% and 1.5 × ${10}^7$%, and for characteristic impedance, escalating from 8.1% to 1.15 × ${10}^3$% and 3.9 × ${10}^4$%, respectively. Consequently, the prediction error of the differential phase shift, minimal at 60 GHz (0.16%), becomes noticeable at 1 MHz (4.39%), increases sharply to 743.88% at 1 kHz, and escalates dramatically to 2.18 × ${10}^{10}$% at 1 Hz. The findings reveal a pronounced frequency asymmetry in LFB susceptibility for the LC coaxial phase shifter biased at extremely low frequencies. Full article

A continuously steerable beam patch antenna array employing a classical phase shifter based on GaN HEMTs is presented. Here, the GaN HEMTs are used as varactor diodes to achieve the tunability purpose. By controlling the DC bias of these varactors from −2 V to 2 V, the proposed array antenna can provide continuous beam steering from 0° to +25° in the azimuth plane at 41.20 GHz, while achieving a low side-lobe level and good impedance matching performances. Using GaN HEMTs as varactors to achieve beam steering capability has never been tried before to the best of our knowledge. The measurement results agree well with the simulation results and validate the effectiveness of the proposed beam steering based on GaN technology. This proposed phased array antenna will find numerous applications within future wireless communications systems, especially for millimeter-wave applications. Full article

The paper presents a novel small-footprint varactor diode-based reconfigurable reflectarray (RRA) design and investigates its power reflection efficiency theoretically and experimentally in a real-life indoor environment. The surface is designed to operate at 865.5 MHz and is intended for simultaneous use with other wireless power transfer (WPT) efficiency-improving techniques that have been recently reported in the literature. To the best of the authors’ knowledge, no RRA intended to improve the performance of antenna-based WPT systems operating in the sub-GHz range has been designed and studied both theoretically and experimentally so far. The proposed RRA is a two-layer structure. The top layer contains electronically tunable phase shifters for the local phase control of an incoming electromagnetic wave, while the other one is fully covered by metal to reduce the phase shifter size and RRA’s backscattering. Each phase shifter is a pair of diode-loaded 8-shaped metallic patches. Extensive numerical studies are conducted to ascertain a suitable set of RRA unit cell parameters that ensure both adequate phase agility and reflection uniformity for a given varactor parameter. The RRA design parameter finding procedure followed in this paper comprises several steps. First, the phase and amplitude responses of a virtual infinite double periodic RRA are computed using full-wave solver Ansys HFSS. Once the design parameters are found for a given set of physical constraints, the phase curve of the corresponding finite array is retrieved to estimate the side lobe level due to the finiteness of the RRA aperture. Then, a diode reactance combination is found for several different RRA reflection angles, and the corresponding RRA radiation pattern is computed. The numerical results show that the side lobe level and the deviation of the peak reflected power angles from the desired ones are more sensitive to the reflection coefficient magnitude uniformity than to the phase agility. Furthermore, it is found that for scanning angles less than 50°, satisfactory reflection efficiency can be achieved by using the classical reactance profile synthesis approach employing the generalized geometrical optics (GGO) approximation, which is in accord with the findings of other studies. Additionally, for large reflection angles, an alternative synthesis approach relying on the Floquet mode amplitude optimization is utilized to verify the maximum achievable efficiency of the proposed RRA at large angles. A prototype consisting of 36 elements is fabricated and measured to verify the proposed reflectarray design experimentally. The initial diode voltage combination is found by applying the GGO-based phase profile synthesis method to the experimentally obtained phase curve. Then, the voltage combination is optimized in real time based on power measurement. Finally, the radiation pattern of the prototype is acquired using a pair of identical 4-director printed Yagi antennas with a gain of 9.17 dBi and compared with the simulated. The calculated results are consistent with the measured ones. However, some discrepancies attributed to the adverse effects of biasing lines are observed. Full article

This paper describes the design of a hybrid coupler with a continuously variable output phase difference. This is achieved by using reconfigurable transmission lines with electrically tunable lengths controlled by two biasing voltages through varactor diodes placed across the coupler branches. The design of the coupler is based on the quadrature hybrid structure for the case where the output phase difference is 90° and on the asymmetric structure for the other cases. The proposed coupler can achieve a tunable output phase difference from 52° to 128°, while keeping a coupling coefficient of −3 dB (± 0.5 dB) over the entire desired frequency band. To validate the simulated results, a prototype working at 3.5 GHz was fabricated and tested. The measurement results show good correspondence with the simulation results, especially when the output phase difference is 90°, while a phase mismatch of less than 7° was observed for the other cases. The presented coupler would be a great asset for antenna feeding arrays, especially the Butler matrix. Full article

This work demystifies the role that packaging boundary conditions (both physically and electromagnetically) can play in a nematic liquid crystal (NLC)-based inverted microstrip (IMS) phase shifter device operating at the 60 GHz band (from 54 GHz to 66 GHz). Most notably, the air box radiating boundary and perfect electric conductor (PEC) enclosing boundary are numerically examined and compared statistically for convergence, scattering parameters, and phase-shift-to-insertion-loss ratio, i.e., figure-of-merit (FoM). Notably, the simulated phase tunability of the radiating air box boundary structure is 8.26°/cm higher than that of the encased (enclosed) PEC boundary structure at 60 GHz. However, the maximum insertion loss of the encased PEC structure is 0.47 dB smaller compared to that of the radiant air box boundary structure. This results in an FoM increase of 29.26°/dB at the enclosed PEC limit (relative to the less-than-optimal airbox radiation limit). Arguably, the NLC-filled IMS phase shifter device packaging with metals fully enclosed (in addition to the default ground plane) enhances the symmetry of the structure, both in the geometry and the materials system. In electromagnetic parlance, it contributes to a more homogenously distributed electric field and a more stable monomodal transmission environment with mitigated radiation and noise. Practically, the addition of the enclosure to the well-established NLC-IMS planar fabrication techniques provides a feasible manufacturing (assembling) solution to acquire the reasonably comparable performance advantage exhibited by non-planar structures, e.g., a fully enclosed strip line and rectangular coaxial line, which are technically demanding to manufacture with NLC. Full article

In this paper, a novel 2D Nolen beamforming phased array with 3D scanning capability to achieve high channel capacity is presented for multiple-input multiple-output (MIMO) Internet-of-Things (IoT) applications. The proposed 2D beamforming phased array is designed by stacking a fundamental building block consisting of a 3 × 3 tunable Nolen matrix, which applies a small number of phase shifters with a small tunning range and reduces the complexity of the beam-steering control mechanism. Each 3 × 3 tunable Nolen matrix can achieve a full 360° range of progressive phase delay by exciting all three input ports, and nine individual radiation beams can be generated and continuously steered on azimuth and elevation planes by stacking up three tunable Nolen matrix in horizontal and three in vertical to maximize signal-to-noise ratio (SNR) in the corresponding spatial directions. To validate the proposed design, the simulations have been conducted on the circuit network and assessed in a fading channel environment. The simulation results agree well with the theoretical analysis, which demonstrates the capability of the proposed 2D Nolen beamforming phased array to realize high channel capacity in MIMO-enabled IoT communications. Full article

This work proposes and examines the feasibility of next-generation 0.3 THz phase shifters realized with liquid crystals (LCs) as tunable dielectrics coaxially filled in the transmission line. The classic coaxial transmission line topology is robust to electromagnetic interference and environmental noise, but is susceptible to higher-order modes from microwave to millimeter-wave towards terahertz (THz) wavelength ranges, which impedes the low-insertion-loss phase-shifting functionality. This work thus focuses primarily on the suppression of the risky higher-order modes, particularly the first emerging ${\mathrm{T}\mathrm{E}}_{11}$ mode impacting the dielectric loss and metal losses in diverse manners. Based on impedance matching baselines at diverse tuning states of LCs, this work analytically derives and models two design geometries; i.e., design 1 for the coaxial geometry matched at the isotopically referenced state of LC for 50 Ω, and design 2 for geometry matched at the saturated bias of LC with the maximally achievable permittivity. The Figure-of-Merit for design 1 and design 2 reports as 35.15°/dB and 34.73°/dB per unit length, respectively. We also propose a constitutive power analysis method for understanding the loss consumed by constitutive materials. Notably, for the 0.3 THz design, the isotropic LC state results in an LC dielectric loss of 63.5% of the total input power (assuming 100%), which becomes the primary constraint on achieving low-loss THz operations. The substantial difference in the LC dielectric loss between the isotropic LC state and saturated bias state for the 0.3 THz design (35.76% variation) as compared to that of our past 60 GHz design (13.5% variation) indicates that the LC dielectric loss’s escalating role is further enhanced with the rise in frequency, which is more pronounced than the conductor losses. Overall, the results from analytical and finite-element optimization in this work shape the direction and feasibility of the unconventional THz coaxial phase shifting technology with LCs, actioned as continuously tunable dielectrics. Full article

This work serves as the first simulation investigation to tackle the liquid crystal (LC)-filled coaxially structured continuously variable phase shifter at 60 GHz, wherein the LCs act as single tunable dielectrics fully occupying the millimeter-wave (mmW) power transmitted (i.e., free of leakage or interference). Impedance and effective dielectric constant computations are settled, followed by the quantification of the interplay between the dielectric thickness and the dielectric constant (Dk) for a controlled 50 Ω impedance. Geometry’s aspect ratio (AR) effects are exploited for the coaxially accommodating topology filled with mmW-tailored LCs with an operatable Dk range of 2.754 (isotropic state) to 3.3 (saturated bias state). In addition to the proposed structure’s noise-free advantages, a novel figure of merit (FoM) enhancement method based on Dk-selection-based impedance matching is proposed. The optimum FoM design by simulation exhibits a 0–180.19° continuously variable phase shift with a maximum insertion loss of 1.75871 dB, i.e., a simulated FoM of 102.46°/dB when the LC-filled coaxial geometry is 50 Ω and matched with the Dk of 2.8, corresponding to the dielectric thickness of 0.34876 mm and line length of 15.92 mm. The envisioned device fabrication and assembly processes are free of the conventional polyimide alignment agent and the related thermal and electrical concerns. Significant cost reduction and yield improvement can hence be envisaged. The topology can also serve as a test structure for broadband characterizations of LC materials and new electro-optical effects. Full article

In this article, a tunable RF sensor is presented for the measurement of dielectric materials (liquids and solids) based on a metamaterial resonator. The proposed novel configuration sensor has a microstrip line-loaded metamaterial resonator with tunable characteristics by utilizing a single varactor diode in the series of the resonator. CST Microwave studio is employed for 3D simulations of the tunable sensor, and the desired performance is attained by optimizing various structural parameters to enhance the transmission coefficient ($S_{21}$ magnitude) notch depth performance. The proposed RF sensor can be tuned in L and S-bands using the varactor diode biasing voltage range of 0–20 V. To validate the performance of the sensor, the proposed design has been simulated, fabricated, and tested for the dielectric characterization of different solid and liquid materials. Material testing is performed in the bandwidth of 1354 MHz by incorporating a single metamaterial resonator-based sensor. Agilent’s Network Analyzer is used for measuring the S-parameters of the proposed sensor topology under loaded and unloaded conditions. Simulated and measured S-parameter results correspond substantially in the 1.79 to 3.15 GHz frequency band during the testing of the fabricated sensor. This novel tunable resonator design has various applications in modulators, phase shifters, and filters as well as in biosensors for liquid materials. Full article

In this work, an enhanced tunable microwave phase shifter is presented. The phase shifter consists of three short circuited stubs and a tapered line. The stubs are connected to graphene pads. Graphene’s tunable conductivity is varied by a DC voltage. This in turn causes a reactance variation at the input of the tapered line, which causes a phase variation. The physical parameters of the stubs are optimized for a maximum reactance variation by the help of analytical models, circuit and full wave simulations. Measurements of an optimized prototype are performed and a dynamic phase variation of ${59}^{\circ }$ is obtained with an amplitude variation of less than 1 dB. Full article
