Aiming at the problem of the cement hydration shrinkage phenomenon, which occurs when cement seals downhole casing in the process of Carbon Capture, Utilization, and Storage (CCUS) technology, this paper proposes a method of sealing the casing by combining threaded casing with bismuth–tin alloy. The effect of different types of grooves (square-, trapezoidal-, and screw-threaded grooves) set on the inner surface of the casing on the gas sealing performance of the alloy plug was analyzed. And the effect of the overlay pressure on the gas sealing performance of the alloy plug during the molding process was analyzed. The experimental results show that under 0.2 MPa overlay pressure, the gas breakthrough pressure values of alloy plugs in square-threaded, screw-threaded, trapezoidal-threaded, and smooth hole casings are 5, 3.7, 2.9, and 1 MPa, respectively. When the pitch in the screw-threaded casing is half of the original, the gas breakthrough pressure value of the alloy plugs in the casing is 4.7 MPa. And after the application of 0.2 MPa overlay pressure, the gas sealing performance of the alloy plugs in the screw-threaded, trapezoidal-threaded, and light hole casings was improved by 220%, 230%, and 100%, respectively. The experimental results show that when the grooves are set on the inner surface of the casing, the gas flow path per unit length of the alloy plug-casing interface is prolonged, and the grooves increase the degree of zigzagging on the inner surface of the casing. The gas sealing performance of the alloy plugs is greatly enhanced. This research can provide theoretical support for the application of downhole Carbon Storage using Sn58Bi in casing. Full article

Ultra-high-performance concrete is widely used in bridge strengthening to improve mechanical performance and bridge durability. Interfacial bonding performance is a key factor in ensuring the effectiveness of ultra-high-performance concrete strengthening. The bending test of the UHPC–NC composite structure was carried out in this article. The effects of groove treatment type and epoxy resin bonding were considered to discuss the damage modes, load–deflection relationships, and strengths. The interfacial tensile strength of the UHPC–NC composite structure and the distribution pattern of cracks were clarified. The results of the test showed that (a) only 22.2% of the groove-treated specimens failed due to bonding surface failure, indicating that the UHPC–NC bonding surface has a high degree of reliability; (b) the strength of specimens with an epoxy adhesive interface was the lowest. It was only 21% higher than the pure normal concrete specimen, and the effective synergistic force of UHPC–NC cannot be achieved; (c) the specimens treated with a positive trapezoidal keyway exhibited the highest strength, with an increase of approximately 200% compared to the pure normal concrete specimens. The strength of bending specimens with right-angled and inverted trapezoidal grooves increased by approximately 100% compared with pure normal concrete specimens. Based on the established three-dimensional numerical model and the analysis of test results under economic and safe conditions, the positive trapezoidal keyway specimen exhibits superior interfacial bonding–tensile performances. Full article

The CERCHAR abrasivity test is a widely used index test in earth and subsurface works, delivering numerical values for abrasion that are critical to the selection of excavation tools, TBM performance or cost and project schedule estimates. The test evaluates the wear of the tip of a standardized metal pin after a scratch test on a rock surface. However, excavatability is not considered in this test. The present study presents an approach to assessing the material removal of a rock specimen due to the scratching action of a steel pin. The concept is tested for a broad range of sedimentary, metamorphic and igneous rocks. The volume of removed rock material is determined by measuring the width of the scratch groove and assuming an idealized trapezoid geometry. The CAI and volumetric removal are used to calculate the CERCHAR abrasivity ratio (CAR), and the results are in good agreement with those from the literature where specialized equipment was used. A classification scheme to estimate the excavatability of rock based on the CAI in combination with the material removal of a rock specimen is introduced. Based on the amount of material removed and the wear on the pin, an estimate can be made as to whether the excavation is likely to be economical in terms of time and material costs. The approach does not require additional testing, but rather makes use of the inherent geometry of the steel pin and the scratch groove on the rock specimen. The approach can be implemented as a complementary analysis to the existing CERCHAR test with little additional effort. Full article

The morphology of the contact surface between cast-in-place engineering structures and soil is generally random. Previous research focusing on the shear mechanical properties of soil–concrete interfaces has predominantly concentrated on the role of interface roughness by constructing regular concrete surface types, largely neglecting the potential impact of the roughness morphology (i.e., the morphology of the concrete surface). In this study, concrete blocks with the same interface roughness and different roughness morphologies were constructed based on the sand-cone method, including random rough surface, triangular groove surface, rectangular groove surface, trapezoid groove surface, and semicircular groove surface. A series of direct shear tests were conducted on the rough and smooth sand–concrete interfaces, as well as on natural sand. Through these tests, we examined the shear mechanical behavior and strength of the sand–concrete interfaces, and analyzed the underlying shear mechanisms. The results showed that: (i) the interface morphology had little effect on the variation in the shear stress–displacement curve of sand–concrete interfaces, and it had a significant influence on the shear strength of the interfaces; (ii) under the same normal stress, the shear strength of the sand–concrete interfaces with a random rough surface was the greatest, followed by the triangular groove surface, while the shear strength of the rectangular groove surface proved the lowest; (iii) the shear strength of the sand–concrete interfaces with the same roughness was affected by the size of the contact area between the concrete plane and the sand, that is, a larger contact area correlated with a decrease in shear strength. It can be concluded that the shear strength value of a sand–concrete surface with the triangular groove is the closest to the shear strength of a random rough interface. By gaining a deep understanding of the effects of different contact surface morphologies on shear strength and shear behavior, significant insights can be provided for optimizing engineering design and enhancing engineering performance. Full article

Inspired by pigeon feathers, the drag-reducing contribution of spanwise grooves was studied. Surface topography of the wing feather was scanned by an instrument of white light interference. Three types of grooves of triangle, rectangle, and trapezoid were adopted based on the unsymmetric microstructures found on the feather surface. Numerical simulations were conducted to analyze drag-reducing mechanisms. According to the simulation results, the rectangular groove reduced the wall shear stress more efficiently but with greater additional pressure drag, while the triangular groove was the opposite. For the trapezoidal groove similar to the feather structure, drag reduction was the best out of the three. Wind tunnel experiments for the trapezoidal groove were performed by using a cylindrical model and large-area plate. Drag reduction was confirmed from the cylindrical model at a series of velocities from 15 m/s to 90 m/s (about 16% at velocity of 30 m/s and about 8.5% at velocity of 60 m/s). Drag reduction was also obtained from the plate model at a velocity range of 30 m/s to 75 m/s (about 19% at the velocity of 60 m/s), which worked for a wide range of velocity and was more meaningful for the application. Full article

The falling film flow characteristics of a liquid on the surface of corrugated sheet packing are crucial for its mass transfer performance in various industrial applications. In this study, a falling film flow experiment with laser-induced fluorescence technology was conducted to validate the flow characteristics of a falling film simulated using computational fluid dynamics (CFD). The influences of Reynolds number (Re) and the packing structure on flow characteristics were analyzed with quantitative film thickness and wetted area obtained through three-dimensional simulation. The results show that the CFD model can accurately predict the liquid falling–film flow behavior and calculate the characteristic parameters. For sinusoidal corrugated sheets, when Re reaches 500, the groove flow changes into a rivulet flow along the adjacent ripples and the wetted area is at its largest, about 0.022 m². However, relative to the geometric area of the corrugated sheet, the wetted area can only reach 20% of the surface area, and the overall wetting performance is still poor. Triangular and trapezoidal corrugated sheets were further proposed and proved to improve the wetting area compared with the sinusoidal sheet, with maximum increases of 23% and 9%, respectively. On this basis, extensive research was carried out on the corrugation angle. The results show that a triangular corrugated sheet with a 75° corrugated angle was more conducive to the flow of the liquid film, and the wetted area was 38.8% of the surface area. Full article

In this study, we reported experimental results of a water droplet falling on trapezoidal grooved surfaces of heated silicon wafers with the groove width varied from 20 μm to 640 μm and the depth from 20 μm to 40 μm. Based on the observation of droplet dynamics captured by high-speed camera, we found that on the denser grooved surface, the maximum spreading diameter of the droplet perpendicular to the groove direction was smaller than that on the sparser grooved surface with the same groove depth. The residence time of the droplet on the denser grooved surface was shorter than that on the sparser grooved surface. The Leidenfrost point increased 50 °C with the groove width varied from 20 μm to 640 μm and decreased 10 °C when the depth was changed from 20 μm to 40 μm, which were higher than that on the smooth surface. Due to the deformation of the droplet during the droplet dynamics, it was difficult to calculate the heat transfer by measuring the droplet volume reduction rate. Based on the convective heat transfer from the grooved surface to the droplet, a Leidenfrost point model was developed. The results calculated by the model are in agreement with the experimental data. Full article

Drag reduction of riblets is one of the most important problems in drag reduction of non-smooth surfaces. In the past two decades, the use of riblets arranged along the flow direction to reduce frictional resistance has received considerable attention. In this paper, we study the plates with the triangular concave grooves, triangular protrusion riblets, trapezoidal concave grooves, trapezoidal protrusion riblets, and circular concave grooves. The numerical simulation method is used to calculate five kinds of plates with grooves and riblets under multiple working conditions. The results showed that the plates with grooves and riblets generated vortices inside the grooves, which separated the incoming flow from the wall surface, and by increasing the thickness of the boundary layer, greatly reducing the average velocity gradient of the wall surface, compared with the smooth flat plate, the friction resistance is reduced. But, lateral riblets and grooves cause additional pressure resistance, which is one order of magnitude higher than the friction resistance. Then, the triangular concave grooves are arranged on the suction and pressure sides of the NACA0012 airfoil, respectively. We calculated the aerodynamic parameters of the both airfoils, and the standard NACA0012 airfoil from the −8° attack angle to their respective stall attack angles. The results showed that the NACA0012 airfoil with triangular concave grooves on the suction side reduced the aerodynamic characteristics of the standard NACA0012 at a small angle of attack, but the stall angle of attack of the standard NACA0012 airfoil was improved, because the grooves ensure that some gas can flow normally on the suction side and delay the separation of the boundary layer. The NACA0012 airfoil with triangular concave grooves on the pressure side did not effectively improve the aerodynamic characteristics: lift–drag ratio decreased and stall angle of attack decreased, but it can increase the lift slightly. Full article

The condition of working surfaces of ploughshares used in two soils with different granulometric condition (one containing large portion of coarse fractions and one containing increased portion of fine fractions) was evaluated. The soil cultivated for the research was characterised by high moisture content. In the tests, divided ploughshares were used, composed of separate parts: a share-points and a trapezoidal part. The aim of the research was to determine, on the grounds of scanning microscopy of working surfaces and their roughness measurements, wear processes occurring during operation of the ploughshare. It was found from the scanning photography that the main mechanism for material wear in soils containing an increased portion of coarse grains was microcutting and grooving, but in soils containing increased portion of fine fractions, microcutting dominated. Surface roughness of ploughshares used in soil with increased portion of coarse grains was higher than that of ploughshares working in soil with higher portion of fine fractions. It was found by statistical analysis that in soil with an increased portion of coarse grains, values of the parameters Ra (arithmetical mean deviation of the assessed profile), Rt (maximum height of the profile), Rv (maximum valley depth) and Rp (maximum peak height), most often occurring on ploughshare rake face, were 1.13, 10.50, 7.60, 2.74 µm respectively and, in soil with an increased portion of fine fractions, these values were 0.80, 6.86, 4.78 and 2.32 µm respectively. On working surfaces of ploughshares operating in both types of soil, higher values Rv in relation to Rp were found. In average, ratio of these parameters for ploughshares in both soils was ca. 2.7. This indicated that microcutting and scratching occurred in the process of material wear of a ploughshare. Full article

This study provides an overview regarding enhancement of an air-cooled heat sink applicable for electronic cooling subject to cross-flow forced convection. Some novel designs and associated problems in air-cooled heat sinks are discussed, including the drawback of adding surfaces, utilization of porous surfaces such as metal foam or carbon foam, problems and suitable applicable range of highly interrupted surfaces (louver or slit) and longitudinal vortex generator. Though the metal foam may accommodate significant surface area, it is comparatively ineffective for air-cooling application due to its much lower fin efficiency, and this shortcoming can be improved by integrating with solid fin. For highly dense fin spacing (e.g., <1.0 mm), cannelure or grooved surface may be a better choice, and fin structure with periodic contraction and expansion may not be suitable for it introduces additional pressure drop penalty. The partial bypass concept, which manipulates a larger temperature difference at the trailing part of heat sink, can be implemented to significantly reduce the pressure drop. Through some certain niche operation, t the thermal resistance of the partial bypass heat sink may be superior to the conventional heat sink. The trapezoid fin surface featuring easier manufacturing and a smaller weight is shown to have competitive performance against traditional rectangular fin geometry. The IPFM (Interleaved Parallelogram Fin Module) design which combines two different geometrical fins with the odd number fins being rectangular shape, and parallelogram shape in even fin numbers, shows 8%–12% less surface than conventional design but still offers a lower thermal resistance than the conventional rectangular heat sink in lower flowrate operation. The cross-cut design shows appreciable improvements as compared to the conventional plate fin design especially in high velocity regime and the single cross-cut heat sinks are superior to multiple cross-cut heat sinks. Full article
