Conventional stator–magnet moving−iron transverse−flux linear oscillatory machines (CSMTLOMs) are widely applied in directly−drive reciprocating devices due to the merits of easy fabrication and robust mover. However, in order to keep the mover vibrating at a certain resonance frequency to save the energy and enlarge the output power, they still suffer from a higher requirement on spring stiffness due to their thick and heavy mover core, which would also narrow the frequency band with a high power factor due to the large inertial energy storage of the heavy mover. Hence, to reduce the mover core weight to reduce the demand of the spring and improve the operation performance, an improved linear oscillatory machine featured by a spoke−type interior permanent magnet inner stator (ISMTLOM) is proposed. Benefiting from its separated two stators, the tangential flux in the radial plane can return through the inner stator core, so that the yoke of the mover core can be eliminated directly. Then, to analytically investigate the influence of the special axial local saturation effect, the segmental equivalent magnetic circuit (EMC) model of the ISMTLOM is established, wherein a saturation coefficient is introduced to quantitatively consider the local saturation effect on the output force. Consequently, several important size parameters are optimally selected when keeping the same outer diameter and copper loss as that of the CSMTLOM. Afterward, the three−dimension finite element algorithm (3D FEA) is adopted for the electromagnetic performance validation and comparison. Finally, it is found that the nonlinear segmental EMC corrected by the saturation coefficient can quickly predict the output force more accurately within the wide load range, and benefiting from the topology improvement, the ISMTLOM has the merits over the CSMTLOM in its smoother output force, much lighter mover core, and less demand of mechanical spring stiffness, whilst preserving the similar output force density. Full article

This paper delves into the knowledge of transverse flux linear induction motors using three-dimensional finite element simulation tools. Original linear induction motors have a useful magnetic flux perpendicular to the movement. We propose some geometric changes to improve the main magnetic circuit of the machine and to ensure simultaneous operation between longitudinal and transverse magnetic fluxes. To obtain the main parameters of the equivalent electrical circuit in a steady state, we propose two steps. Firstly, replicate the classic indirect tests used in rotating machines. This represents a significant advantage since it allows several models to be experimentally tested to obtain the values of electrical parameters. Secondly, use the data from these tests to solve a particular system of equations using numerical methods. The solution provides the electrical elements necessary to generate the equivalent circuit proposed by the authors. A quantitative analysis of the main electrical parameters is also carried out, confirming the advantages of the changes introduced. With them, a significant improvement in thrust force is obtained, especially in stationary conditions and low speeds. Finally, we study, in detail, a set of specific phenomena of linear machines using two parameters: the secondary equivalent air gap and the secondary equivalent conductivity. Full article

It is critical in the metal continuous casting process to estimate the temperature evolution of the casted section along the machine from the meniscus (the point where liquid metal is poured) to the cutting machine, where the product is cut to commercial length. A convenient approximated model to achieve this goal with a feasible computational effort, particularly in the case of large sections, is the so-called travelling slice: the transversal section of casted product is subjected to different thermal boundary conditions (e.g., thermal flux, radiation, convection) that are found during the movement at constant speed from meniscus to the end of machine. In this work, the results obtained with the approximated travelling slice model are analyzed in the favorable case of an axisymmetric section. In this case, the reference model is 2D, whereas the travelling slice model degenerates in a simple 1D model. Three different casted shapes were investigated, rounds with diameters of 200 mm, 850 mm, and 1200 mm, spanning from traditional to only recently adopted product diameter sizes. To properly test the validity of the travelling slice model, other casting speeds were considered, even outside the industrial range. Results demonstrate the advantage of using the travelling slice, particularly the much lower computational cost without sacrificing precision, even at low casting speed and large dimensions. Full article

The cogging machine is a new design of a machine with permanent magnets, which combines the advantages of a machine with transverse flux (TFM), eliminating its disadvantages. The biggest advantage of TFM machines is their high torque density, which varies with the design parameters. The developed machine retains these advantages while simplifying the construction of the stator core, which is the biggest disadvantage of TFM machines. This article presents the results of an analysis of the power density of the developed cogging machine as a function of a number of pole pairs and the basic design parameters. Analyses were carried out on the basis of the derived analytical equations, which make the generated torque depend on the construction parameters. Thanks to the derived dependencies, one can easily examine the effects of modifying the machine structure. The results presented in the article prove that the developed design of the cogging machine is competitive in relation to machines with permanent magnets existing on the market. Full article

This paper presents a prototype of a low-cost two-phase axial-gap transverse flux generator, in which the magnetic and electric circuits have been made of reused materials, and the stator housing has been manufactured by 3D printing of plastic. Therefore, this work presents as a novelty the combination of the novel transverse flux topology and two challenging trends in electrical machines manufacturing, such as reusing of components and additive manufacturing. Axial-gap transverse flux machines potentially enable the combination of two of the main advantages of axial flux machines and transverse flux machines, i.e., short axial length and a high number of poles. The two-phase arrangement with shared air gap is of great interest in order to reduce further the axial length while avoiding the use of magnetic materials in the rotor, such as iron or soft magnetic composites. However, the equivalent air gap might be large, with significant leakage and fringing effects as the magnetic flux closes through the air. Therefore, in this paper the accuracy of the analytical equations and the magnetic equivalent circuit is firstly investigated. The two-phase axial-gap transverse flux machine is prone to misalignment between phases and rotor imbalances that alter the air gap length, so these effects have been included in the simulations with the finite element method. Experimental tests have been conducted throughout the investigation, from the prototype characterization to the steady-state operation, both with no load and with resistive loads. Full article

The magnetic properties of magnetic cores are essential for the design of electrical machines, and consequently appropriate mathematical modeling is needed. Usually, the design and analysis of electrical machines consider only the one-dimensional (1D) magnetic properties of core materials, i.e., the relationship of magnetic flux density (B) versus magnetic field strength (H), and their associated power loss under 1D magnetization, in which the B and H are constrained in the same orientation. Some studies have also been performed with the two-dimensional (2D) magnetizations in which the B and H are vectorial, rotating on a plane, and they may not be in the same direction. It has been discovered that the 2D rotational property is very different from its 1D alternating counterpart. However, the magnetic fields in an electrical machine, in particular claw pole and transverse flux machines, are naturally three-dimensional (3D), and the B and H vectors are rotational and may not lie on the same plane. It can be expected that the 3D vectorial property might be different from its 2D or 1D counterpart, and hence it should be investigated for the interests of both academic research and engineering application. This paper targets at a general summary about the magnetic material characterization with 3D vectorial magnetization, and their application prospect in electrical machine design and analysis. Full article

Laser powder bed fusion (L-PBF) was used to produce stator half-shells of a transverse flux machine from pure iron (99.9% Fe). In order to reduce iron losses in the bulk components, radially extending slits with a nominal width of 150 and 300 µm, respectively, were integrated during manufacturing. The components were subjected to a suitable heat treatment. In addition to a microscopic examination of the slit quality, the iron losses were also measured using both a commercial and a self-developed measurement setup. The investigations showed the iron losses can be reduced by up to 49% due to the integrated slits and the heat treatment. Full article

3-dimensional (3D) flux machines accommodate many design and analysis challenges. Transverse flux machines (TFMs) are mostly useful for low speed, high torque applications but in this research a fault tolerant transverse flux alternator with segmented stator has been prototyped and several important design and manufacturing challenges have been thoroughly investigated as different scenarios. The proposed machine consists of axially separated, 4-single phase to achieve low speed power of 40 Watts at 400 revolutions/minute (rpm). In addition, the machine must achieve several high-speed specifications at 15,000 rpm. It is demonstrated that the proposed TFM could be an alternative to more conventional radial flux machines in aerospace as validated within the paper. However, the necessity of stator segmentation and the use of soft magnetic composites for the proposed 3D flux machine lead to many important design and optimization considerations. Therefore, this paper investigates the manufacturing and material uncertainties in a TFM for an aerospace application. The results indicate that transverse flux alternator might be an option as an aerospace alternator but the peak performance of the prototype machine is still far from the 3D models investigated using finite element electromagnetic simulations. Full article

Multiple techniques continue to be simultaneously utilized in the condition monitoring and fault detection of electric machines, as there is still no single technique that provides an all-round solution to fault finding in these machines. Having various machine fault-detection techniques is useful in allowing the ability to combine two or more in a manner that will provide a more comprehensive application-dependent condition-monitoring solution; especially, given the increasing role these machines are expected to play in man’s transition to a more sustainable environment, where many more electric machines will be required. This paper presents a novel non-invasive optical fiber using a stray flux technique for the condition monitoring and fault detection of induction machines. A giant magnetostrictive transducer, made of terfenol-D, was bonded onto a fiber Bragg grating, to form a composite FBG-T sensor, which utilizes the machines’ stray flux to determine the internal condition of the machine. Three machine conditions were investigated: healthy, broken rotor, and short circuit inter-turn fault. A tri-axial auto-data-logging flux meter was used to obtain stray magnetic flux measurements, and the numerical results obtained with LabView were analyzed in MATLAB. The optimal positioning and sensitivity of the FBG-T sensor were found to be transverse and 19.3810 pm/μT, respectively. The experimental results showed that the FBG-T sensor accurately distinguished each of the three machine conditions using a different order of magnitude of Bragg wavelength shifts, with the most severe fault reaching wavelength shifts of hundreds of picometres (pm) compared to the healthy and broken rotor conditions, which were in the low-to-mid-hundred and high-hundred picometre (pm) range, respectively. A fast Fourier transform (FFT) analysis, performed on the measured stray flux, revealed that the spectral content of the stray flux affected the magnetostrictive behavior of the magnetic dipoles of the terfenol-D transducer, which translated into strain on the fiber gratings. Full article

The article presents a concept for a new design of the well-known Transverse Flux Machine (TFM) made with the use of a flat core used in classical electrical machines. The proposed design was first analytically verified and was subsequently verified using the finite element method, which fully corroborated the results. The simulations show that a set of three single-phase TFM machines with slotted flat rotor yokes generates a torque over three times greater than that of an induction motor and twice as large as Fractional Slot Concentrated Winding—Permanent Magnet Synchronous Machines (FSCW-PMSM). The performed comparative calculations confirmed that the torque generated by machines operating on principles similar to TFM can generate a torque much greater than those currently in common use. Full article

High torque and power density are unique merits of transverse flux machines (TFMs). TFMs are particularly suitable for use in direct-drive systems, that is, those power systems with no gearbox between the electric machine and the prime mover or load. Variable speed wind turbines and in-wheel traction seem to be great-potential applications for TFMs. Nevertheless, the cogging torque, efficiency, power factor and manufacturing of TFMs should still be improved. In this paper, a comprehensive review of TFMs topologies and design is made, dealing with TFM applications, topologies, operation, design and modeling. Full article

Oriented steel has higher permeability and lower losses in the direction of orientation (the rolling direction) than non-oriented steel. However, in the transverse direction, oriented steel typically has lower permeability and higher losses. The strategic use of oriented steel in a modular Permanent Magnet Synchronous Machine (PMSM) stator can improve machine performance, particularly when compared to a machine designed with non-oriented steel, by increasing both torque and efficiency. Typically, steel manufacturers provide magnetic properties only in the rolling and transverse directions. Furthermore, in modern Finite Element Analysis (FEA) software, the magnetic properties between the rolling and transverse directions are interpolated using an intrinsic mathematical model. However, this interpolation method has proven to be inaccurate; to resolve this issue, an improved model was proposed in the literature. This model requires the magnetic properties of the oriented steel in between the rolling and transverse directions. Therefore, a procedure for extracting the magnetic properties of oriented steel is required. The objective of this work is to propose a method of determining the magnetic properties of oriented steel beyond just the oriented and transverse directions. In this method, flux-injecting probes, also known as sensors, are used to inject and control the flux density in an oriented steel segmented stator in order to extract the properties of the oriented steel. These extracted properties are then used to model an oriented steel modular stator PMSM. The machine’s average torque and core losses are compared with conventional, non-modular, non-oriented steel stator PMSM, and modular, non-oriented steel stator PMSM. It is shown that both the average torque and the core loss of the oriented steel modular stator PMSM have better performance at the selected number of segments than either of the two non-oriented steel stators. Full article

This paper presents analysis and study of the single-phase transverse-flux machine. The finite element method results of the machine are compared with the laboratory measurements to confirm the accuracy of the computer model. This computer model is then used to investigate the effect of the machine’s geometry on its output characteristics. Parametric analysis of the machine is carried out to find the optimal air-gap diameter at which the cogging torque of the machine is minimal. In addition, the influence of the coil cross-section on the torque and output power characteristics of the machine is investigated and discussed. Full article

This paper presents the manufacturing challenges of a transverse flux alternator for an aerospace application. For fault tolerance, four independent isolated phases are required to deliver a specific power at low speeds, whilst at over speed, there is a strict limit on the short circuit current. A transverse flux machine (TFM) was selected due to its high inductance combined with the modular nature of separate phases lending itself to fault tolerance. The stator consists of pressed soft magnetic composite (SMC) segments. The authors explore the electromagnetic, mechanical, and assembly design challenges of the machine. It is shown that mechanical design aspects of the segments are of equal importance to the electromagnetic design and optimization. Simple design choices have allowed the same component to be used as all the stator segments, despite the requirement of a 90° electrical phase difference between phases and a tooth offset of 180° electrical within each phase. Full article

The article presents an original method for numerical determination of the value of magnetic co-energy of a transverse construction motor. The aim of the developed method is initial determination of the co-energy value for the analyzed structure in the function of rotor rotation angle. The main requirement set to the presented method was the lowest possible complexity of the process computation, lack of the necessity to apply costly dedicated software, as well as creating construction 3D models. These requirements were met by applying specific cross-section/development of the analyzed machine geometry, as well as application of specific boundary conditions, which enabled reduction of the analyzed problem to solving a Poisson equation in 2D. The calculations were done with the Finite Element Method. Full article
