Search Results (105)

Functionally graded materials (FGMs) have the potential to revolutionize the oil and gas transportation sector, due to their increased strengths and efficiencies as pipelines. Conventional pipelines frequently face serious problems such as extreme weather, pressure changes, corrosion, and stress-induced pipe bursts. By analyzing the mechanical and thermal performance of FGM-based pipes under various operating conditions, this study investigates the possibility of using them as a more reliable substitute. In the current study, the post-buckling and nonlinear vibration behaviors of pipes composed of FGMs transporting heavy crude oil were examined using a Timoshenko beam framework. The material properties of the FGM pipe were observed to change gradually across the thickness, following a power-law distribution, and were influenced by temperature variations. In this regard, two types of FGM pipes are considered: one with a metal-rich inner surface and ceramic-rich outer surface, and the other with a reverse configuration featuring metal on the outside and ceramic on the inside. The nonlinear governing equations (NGEs) describing the system’s nonlinear dynamic response were formulated by considering nonlinear strain terms through the von Kármán assumptions and employing Hamilton’s principle. These equations were then discretized using Galerkin’s method to facilitate the analytical investigation. The Runge–Kutta method was employed to address the nonlinear vibration problem. It is concluded that, compared with pipelines made from conventional materials, those constructed with FGMs exhibit enhanced thermal resistance and improved mechanical strength. Full article

Glass fiber reinforced polypropylene composite plates have gradually attracted more attention because of their repeated molding, higher toughness, higher durability, and fatigue resistance compared to glass fiber reinforced thermosetting composites. In practical engineering applications, composite plates have to undergo bending effect at different angles in corrosive environment of concrete, including bending bars from 0~90°, and stirrups of 90°, which may lead to long-term performance degradation. Therefore, it is important to evaluate the long-term performance of glass fiber reinforced polypropylene composite bending plates in an alkali environment. In the current paper, a new bending device is developed to prepare glass fiber reinforced polypropylene bending plates with the bending angles of 60° and 90°. It should be pointed out that the above two bending angles are simulated typical bending bars and stirrups, respectively. The plate is immersed in the alkali solution environment for up to 90 days for long-term exposure. Mechanical properties (tensile properties and shear properties), thermal properties (dynamic mechanical properties and thermogravimetric analysis) and micro-morphology analysis (surface morphology analysis) were systematically designed to evaluate the influence mechanism of bending angle and alkali solution immersion on the long-term mechanical properties. The results show the bending effect leads to the continuous failure of fibers, and the outer fibers break under tension, and the inner fibers buckle under compression, resulting in debonding of the fiber–matrix interface. Alkali solution (OH⁻ ions) corrode the surface of glass fiber to form soluble silicate, which is proved by the mass fraction of glass fiber decreased obviously from 79.9% to 73.65% from thermogravimetric analysis. This contributes to the highest degradation ratio of tensile strength was 71.6% (60° bending) and 65.6% (90° bending), respectively, compared to the plate with bending angles of 0°. A high curvature bending angle (such as 90°) leads to local buckling of fibers and plastic deformation of the matrix, forming microcracks and fiber–resin interface bonding at the bending area, which accelerates the chemical erosion and debonding process in the interface area, bringing about an additional maximum 10.56% degradation rate of the shear strength. In addition, the alkali immersion leads to the obvious degradation of storage modulus and thermal decomposition temperature of composite plate. Compared with the other works on the long-term mechanical properties of glass fiber reinforced polypropylene, it can be found that the long-term performance of glass fiber reinforced polypropylene composites is controlled by the corrosive media type, bending angle and immersion time. The research results will provide durability data for glass fiber reinforced polypropylene composites used in concrete as stirrups. Full article

Flexure-based linear stages have become prevalent in precision engineering; however, most designs suffer from parasitic shifts that degrade positioning accuracy. Conventional solutions to mitigate these parasitic motions often compromise support stiffness, reduce motion range, and increase structural complexity. This study presents a novel family of flexure-based rectilinear-motion stages using coupled n-RRR planar parallel mechanisms, achieving extremely low parasitic shifts while addressing the forementioned limitations. Four design variants are selected and analyzed via Finite Element Method (FEM) simulations, evaluating parasitic shifts, stroke, and support stiffness. The most precise configuration, a 4-RRR rectilinear stage having kinematic chains coupled via two Watt linkages, exhibits a lateral shift smaller than 0.258 µm and an in-plane parasitic rotation smaller than 12.6 µrad over a 12 mm stroke. Experimental validation using a POM prototype confirms the high positioning precision and support stiffness properties. In addition, a silicon prototype incorporating thermally preloaded buckling beams is investigated to reduce its translational stiffness. Experimental results show a translational stiffness reduction of 98% in the monostable configuration and 112% in the bistable configuration (i.e., negative stiffness), without support stiffness reduction. These results highlight the potential of the proposed mechanisms for a wide range of precision applications, offering a scalable and high-accuracy solution for micro- and nano-positioning systems. Full article

Fire safety is one of the critical concerns for the design and construction of modular structures. The lack of understanding of cavity fire spread in modular construction could create variations in the fire performance of structural members. This study aimed to assess the impact of cavity fire spread in modular buildings initiated by a room fire using validated fire dynamics and structural numerical models. A comprehensive parametric study was conducted to identify critical thermal conditions affecting adjacent structural members under plausible cavity fire scenarios. The identified critical cavity fire thermal conditions were used to examine the structural performance of cold-formed steel intermediate column specimens while varying geometric configurations, material properties, and boundary conditions. The results highlighted two distinct phases of restrained thermal expansion and lateral deformations under material yielding and buckling, resulting in the loss of structural integrity. The restrained thermal expansion significantly increased axial/restraint forces, reaching up to 155% of the initial load. This behavior decreased axial load capacity by 2.4% to 35% of the ambient capacity. Further, the study identifies a requirement for designing the intermediate columns and the connected intermodular connections for increased design action equivalent to 56% of the service load. Full article

This work aims to study the compressive buckling and consequent blowup of jointed concrete pavements due to thermal rise. For this purpose, a simple and effective mixed FEM, originally introduced for performing static and buckling analyses of beams on elastic supports, is extended for performing a preliminary study of jointed concrete pavements. An elastic Euler–Bernoulli beam in frictionless and bilateral contact with an elastic support is considered. Three different elastic support models are assumed, namely a Winkler support, an elastic half-space (3D), and half-plane (2D). The transversal pavement joint or crack is modeled employing a hinge at the beam midpoint with nil rotational stiffness. Numerical tests are performed by determining critical loads and the corresponding modal shapes, with particular attention to the first minimum critical load related to pavement blowup. From a theoretical point of view, the results show that minimum critical loads converge to existing results in the case of Winkler support, whereas new results are obtained in the case of the 2D and 3D support types. Associated modal shapes have maximum upward displacements at the beam midpoint. The second and subsequent critical loads, together with the corresponding sinusoidal modal shapes, converge to existing results. From a practical point of view, minimum critical loads represent a lower bound for estimating axial forces due to thermal variation causing jointed pavement blowup. Full article

Square steel tube (SST) columns are widely applied, and fire resistance is a critical issue in its design. Current research on the fire resistance of the SST column predominantly assumes that it is uniformly exposed to fire, ignoring the thermal insulation of the surrounding walls under actual fire conditions. The heat transfer and mechanical finite element model (FEM) for SST columns embedded in walls under an ISO 834 standard fire are established in this study, and the accuracy of the FEM is verified by existing experimental results. Subsequently, the wall effect on the temperature distribution and fire resistance of the SST columns exposed to fire is analyzed, the stress mechanisms of the SST column embedded in walls is investigated and further parametric analyses are performed. The results show that, for SST columns embedded in walls, the temperature rise rate of the wall-embedded region is significantly reduced, and the fire resistance is improved by 25.3% compared with the case of uniform exposure to fire. Under two fire conditions, the SST columns exhibit compressive bending failure, and when considering the wall effect, the uneven temperature distribution induces material strength eccentricity, causing the buckling direction to deviate toward the wall-thickness direction. Reducing the fire-resistive coating thickness of the wall-embedded region can mitigate the uneven stress distribution, thereby lowering construction costs while concurrently preserving fire resistance. Increasing the steel tube thickness can significantly improve the fire resistance, but the high steel strength and slenderness ratio result in the accelerated failure of the SST column when exposed to fire. Full article

This study investigates the buckling performance of built-up cold-formed steel (CFS) columns, with a focus on how different thermal exposures and cooling strategies influence their susceptibility to various failure mechanisms. Addressing the gap in the literature on the fire behavior of mild steel (MS)-based CFS columns, the research aims to provide new insights. Compression tests were conducted on MS-based CFS column specimens after they were exposed to fire, to assess their post-fire buckling strength. The columns were subjected to controlled fire conditions following standardized protocols and then allowed to cool to room temperature. The study examined axial load-bearing capacity and deformation characteristics under elevated temperatures. To improve fire resistance, protective coatings—gypsum, perlite, and vermiculite—were applied to certain specimens before testing, and their performance was compared to that of uncoated specimens. A comprehensive finite element analysis (FEA) was also performed to model the structural response under different thermal and cooling scenarios, providing a detailed comparison of the coating effectiveness, which was validated against experimental results. The findings revealed significant variations in axial strength and failure mechanisms based on the type of fire-resistant coating used, as well as the heating and cooling durations. Among the coated specimens, those treated with perlite showed the best performance. For example, the air-cooled perlite-coated column (MBC2AC) retained a load capacity of 277.9 kN after 60 min of heating, a reduction of only 6.0% compared to the unheated reference section (MBREF). This performance was superior to that of the gypsum-coated (MBC1AC) and vermiculite-coated (MBC3AC) specimens, which showed reductions of 3.6% and 7.9% more, respectively. These results highlight the potential of perlite coatings to enhance the fire resistance of CFS columns, offering valuable insights for structural fire design. Full article

The frequency and buckling characteristics of functional gradient (FG) beams with asymmetric material distribution in the temperature field are analyzed in this paper. Generally, the asymmetrical material distribution of FG beams results in a non-zero neutral axis and non-zero thermal moment. However, some previous studies adopted the treatment of homogeneous beams in which the neutral axis and thermal moment were set as zero. To this end, a comprehensive FG beam model with thermal effect is developed based on the absolute nodal coordinate formulation, in which Euler–Bernoulli beam theory, Lagrangian strain, exact curvature, thermally induced strain, and neutral axis position are considered. For the convenience of comparisons, the presented model can be simplified into three models which do not consider the neutral axis or thermal moment. The numerical results indicate that the influence of the neutral axis on the thermal axial force is minimal while that on the thermal moment is significant. In the case of the high temperature difference, frequency, critical temperature difference, unstable state, and the buckling type of the FG beams are misjudged when the neutral axis or thermal moment is ignored. Full article

The present work was carried out as part of the PRIN 2022JCS2CN project “CoolGal”, which aims to design and manufacture a beryllium target cooled by Galinstan (a liquid metal alloy at room temperature) for the production of neutrons using energetic protons. The objective of the present work is to thermo-structurally design a beam window that encloses the environment in which the target is housed. The window consists of a Havar disk, the thickness of which must be minimized to absorb the least amount of proton beam power, while its diameter must be sufficient to avoid excessive beam loss. The window will then be embedded around its perimeter and will have to withstand two load conditions, applied individually: A mechanical load, due to the atmospheric pressure of 0.11 MPa during vacuuming, and a thermal load, due to heating during irradiation with the proton beam. Once a first-version window geometry was defined, a static structural finite element analysis (FEA) was carried out by activating geometric nonlinearities to assess the structural integrity of the window under mechanical loading. After that, a static thermal–mechanical FEA analysis was carried out to assess the structural integrity of the window under thermal loading. Given the compressive stress state induced by thermal loading and the slenderness of the window itself, a nonlinear buckling structural FEA analysis was also performed. Full article

Power transformers are vital for maintaining the reliability and stability of electrical systems. However, their vulnerability to faults, such as partial discharges and winding deformation, poses significant operational risks. Advanced diagnostic techniques are essential for timely fault detection and predictive maintenance. This study investigates the application of machine learning (ML) techniques in transformer fault detection using Frequency Response Analysis (FRA) data. The study aims to evaluate the effectiveness of various ML models, the impact of frequency variations, and the contribution of numerical indices to fault classification accuracy. FRA data, comprising 50 to 70 measurements per transformer, were segmented into eight frequency bands (20 kHz to 12 MHz). A systematic approach utilizing a confusion matrix was applied to classify faults such as partial discharges and winding deformation. The performance of ML models, including Decision Trees and Subspace KNN, was assessed in terms of classification accuracy. Machine learning models achieved fault classification accuracies ranging from 80% to 100% across eight frequency bands (20 kHz to 12 MHz). Decision Tree models excelled in detecting insulation faults, achieving 100% accuracy for faults such as thermal aging (Class A), electrical stress (Class B), and moisture ingress (Class C). Subspace KNN models demonstrated strong performance for core-related faults, with classification accuracies of 100% for core displacement (Class B) and core buckling (Class C), but they faced challenges with lamination deformation, achieving 75% accuracy. Contamination-related faults exhibited a 100% False Negative Rate (FNR), indicating a need for model refinement. Fault detection was consistent across frequency bands, with key diagnostic markers at 7.6 MHz, 8.25 MHz, and 8.7 MHz providing high diagnostic value. Machine learning integration into FRA-based diagnostics enhances the accuracy and reliability of transformer fault detection. While current results are promising, future research should focus on deep learning approaches and enhanced feature extraction to address challenges such as data scarcity and fault diversity. Full article

The present work aims to carry out free vibration and buckling analysis of functionally graded hybrid reinforced laminated composite plates under thermal conditions. Finite element-based solutions are presented within the framework of recently proposed higher-order zigzag theory. Different variations of concentration of graphene platelets and fibers within the plate across its thickness are considered. First, the plate polymer is assumed to be reinforced using graphene platelets and then with fibers. The multiscale material properties of hybrid reinforced plates are obtained using the Halpin–Tsai micromechanical model. The nature of the distribution of graphene platelets and fibers across the thickness of the plate widely governs the free vibration behavior of functionally graded hybrid reinforced composite plates. The number of layers and shape factors also affect the free vibration behavior of functionally graded hybrid reinforced composite plates. Full article

An asymptotic analytical method is proposed to study the thermal post-buckling behaviors of fiber-reinforced composite (FRC)-laminated beams with geometric imperfections employing a modified zig-zag beam model. The beam model satisfied the discontinuity of the shear deformation at the interlayer interfaces and the stress boundary conditions on the upper and lower surfaces. Each imperfection was assumed to possess the same shape as the buckling mode, and the in-plane boundary conditions were presumed to be immovable. A two-step perturbation method was used to solve the nonlinear governing equations and obtain the equilibrium path. Subsequently, the initial defect sensitivity of the post-buckling behaviors was analyzed. The existence of the bifurcation-type equilibrium path for perfect beams is discussed in depth. Load–deflection curves for beams with various boundary conditions and ply modes were plotted to illustrate these findings. The effects of the slenderness ratio, elastic modulus ratio, thermal expansion coefficient ratio, ply modes, and supported boundaries on the buckling and post-buckling behaviors were also investigated. The numerical results indicate that the slenderness ratio significantly influences the critical buckling temperature, with thicker beams exhibiting higher buckling resistance. The elastic modulus ratio also plays a crucial role, with higher ratios leading to increased buckling strength. Additionally, the thermal expansion coefficient ratio affects the post-buckling load-bearing capacity, with lower ratios resulting in greater stability. Full article

The buckling-like mechanical behavior of functionally graded graphene platelet-reinforced composite (FG-GPLRC) structures is increasingly attracting research attention. However, buckling behavior has previously been studied separately as thermal buckling and mechanical buckling. In this context, this study investigates the buckling behavior of FG-GPLRC plates under combined thermal and mechanical loads. The coupled buckling problem is formulated according to the minimum potential energy theorem using first-order shear deformation theory (FSDT). In addition, the problem is approximated by the 2-D natural element method (NEM), and the resulting coupled eigen matrix equations are derived to compute the critical buckling temperature rise (CBTR) and the mechanical buckling load. The developed numerical method can solve thermal, mechanical, and coupled thermo-mechanical buckling problems, and its reliability is examined through convergence and benchmark tests. Using the developed numerical method, the buckling behavior of FG-GPLRC plates under thermal and mechanical buckling loads is examined in depth with respect to the key parameters. In addition, a comparison with functionally graded CNT-reinforced composite (FG-CNTRC) plates is also presented. Full article

The structure of thermoset composite laminated plates is made by stacking layers of plies with different fiber orientations. Similarly, the stiffened panel structure is assembled from components with varying ply configurations, resulting in thermal residual stresses and processing-induced deformations (PIDs) during manufacturing. To mitigate the residual stresses caused by the geometric features of corner structures and the mismatch between the stiffener-skin ply orientations, which lead to PIDs in composite-stiffened panels, this study proposes a multi-objective stacking optimization strategy based on an improved adaptive genetic algorithm (IAGA). The viscoelastic constitutive model was employed to describe the modulus variation during the curing process to ensure computational accuracy. In this study, the IAGA was proposed to optimize the ply-stacking sequence of L-shaped stiffeners in composite laminated structures. The results demonstrate a reduction in the spring-in angle to 0.12°, a 50% improvement compared to symmetric balanced stacking designs, while the buckling eigenvalues were improved by 20%. Additionally, the IAGA outperformed the traditional non-dominated sorting genetic algorithm (NSGA), achieving a threefold increase in the Pareto solution diversity under identical constraints and reducing the convergence time by 70%. These findings validate the effectiveness of asymmetric ply design and provide a robust framework for enhancing the structural performance and manufacturability of composite laminates. Full article

In this study, the solution of the buckling problem of axially loaded laminated cylindrical shells consisting of functionally graded (FG) nanocomposites in elastic and thermal environments is presented within extended first-order shear deformation theory (FOST) for the first time. The effective material properties and thermal expansion coefficients of nanocomposites in the layers are computed using the extended rule of mixture method and molecular dynamics simulation techniques. The governing relations and equations for laminated cylindrical shells consisting of FG nanocomposites on the two-parameter elastic foundation and in thermal environments are mathematically modeled and solved to find the expression for the axial buckling load. The numerical results of the current analytical approach agree well with the existing literature results obtained using a different methodology. Finally, some new results and interpretations are provided by investigating the influences of different parameters such as elastic foundations, thermal environments, FG nanocomposite models, shear stress, and stacking sequences on the axial buckling load. Full article
