Search Results (24)

With rapid global urbanization, glass curtain wall buildings have been widely adopted due to aesthetics and natural lighting. However, during summer time, intense solar radiation leads to significant indoor heat gain, which adversely affect thermal comfort and energy efficiency. The conventional air conditioning systems are typically equipped with a cooling capacity sufficient to maintain an indoor air temperature at the design values specified in the Design standard for energy efficiency of public buildings, which fails to account for the effects of radiation temperature, potentially resulting in reduced thermal comfort and energy inefficiency. By integrating the Thermal Comfort Tool to calculate the PMV index, this study evaluates the affection of solar heat gain on indoor occupants’ thermal comfort and proposes an optimized air temperature control strategy to realize thermal comfort. Based on the dynamic air temperature strategy, an energy consumption model is developed to evaluate the affection of solar radiation on energy consumption for glass curtain wall buildings based on the PMV index. The synergistic effects of shading measures are then evaluated. This study conducts simulation analysis using an office building with a glass curtain wall located in Beijing as a case study. When accounting for radiant heat gain, a significant portion of the time (53.89%) fall outside the thermal comfort range, even when the air conditioning is set to the designated temperature. To maintain thermal comfort, the air conditioning temperature must be lowered by 1.4–3.5 °C, resulting in a 28.08% increase in energy consumption. To address this issue, this study finds that installing interior shading can reduce radiant heat gain. Under the same thermal comfort conditions, the required air temperature reduction is only 0.8–2.1 °C, leading to a 24.26% reduction in energy consumption compared to the case without interior shading. Full article

Based on the resource conservation requirements of GB/T 50378-2019 “Green Building Evaluation Standard”, this study constructed a BIM–Ecotect collaborative analysis model and proposed a “four-dimensional integration” green performance optimization method. Taking a high-rise office building in Wuhan as an example, a LOD 300-level Revit building information model was established, and a multidisciplinary collaborative analysis was achieved through gbXML data interaction. The lighting simulation results show that the average natural lighting coefficient of the office area facing south is 2.4 (the standard 85%), while in the meeting room area, due to the optimized design of the curtain wall, the average natural lighting coefficient has increased to 2.6 (the standard 92%). In terms of energy-saving renovation, a three-dimensional collaborative design strategy was adopted. Through the optimization of the envelope structure, the cooling load of the air conditioning system was reduced by 25.3%, and the heat load was reduced by 23.6% (the u value of the exterior wall was reduced by 56.3%, the SHGC of the exterior windows was reduced by 42.9%, and the thermal resistance of the roof was increased by 150%). The ventilation optimization adopts the CFD flow field reverse design, adjusting the window opening rate of the exterior windows from 15% to 20% to form a turbulent diffusion effect. Therefore, the air change rate in the office area reached 2.5 times per hour, and the CO₂ concentration decreased by up to 27.1% at most. The innovative adoption of the “composite sound insulation curtain wall” technology in acoustic environment control has increased the indoor noise compliance rate by 27 percentage points (from 65% to 92%). The above research data indicate that digital collaborative design can achieve an overall energy-saving rate of over 20% for buildings, providing a replicable technical path for enhancing the performance of green buildings. Full article

Energy-efficient, adaptive, affordable and durable curtain wall systems have always attracted great interest among the scientific and technical communities. In this regard, the purpose of this work was to conduct a comprehensive review of the issues related to energy-efficient adaptive dynamic facades, taking into account their operating loads, revealing the diversity of the studies conducted in this area. The review of the literature was carried out in three stages. For all stages, the review period was 2001–2024. In the first stage, a review of traditional curtain facade systems was conducted, which emphasized the relevance of this area, identifying a total of 4338 sources. In the second stage, a review of specific issues, such as adaptive dynamic facade systems, yielded 2838 sources, from which the 87 most suitable sources were selected. In the third stage, a review focusing on the issue of operating loads yielded 741 works, from which 43 suitable sources were selected. At the same time, pie charts reflecting the most active international scientific journals were compiled for each area. The conducted review of energy-efficient adaptive dynamic building facades, taking into account their operating loads, could provide significant assistance in further research on the specified issues. As researchers mainly focus on environmental friendliness and cost-effectiveness, they often neglect issues such as the systems’ resistance to operating loads, which represents a serious deficiency. In this regard, this review identified a gap in the research on the development of energy-efficient facades with an air layer; on this basis, the further development of adaptive facade systems is required. The review of the selected studies also showed that issues related to energy efficiency and sustainability, taking into account operational loads, have not been addressed in combination; rather, they have only been addressed individually. At the same time, this review shows that the proposed development of an adaptive system of external fencing could be relevant, both nationally and internationally, depending on the natural and climatic conditions of the territory for which the buildings are designed. Full article

This study was conducted to survey the level of technification of quail sheds in Brazil. Data from 25 quail farms (5 in each Brazilian region) were collected by image analysis of videos available on the Internet. The analyzed variables were farm location, degree of technological adoption in quail sheds, housing conditions, structural conditions, wall conditions, and thermal comfort equipment. The data were subjected to descriptive analysis, and differences were assessed using the chi-squared test (p < 0.10). It was found that curtain walls were the most used system for air entry and renewal in quail sheds. Fan systems were present in only 12% of sheds, and evaporative cooling systems (or air conditioning) were observed in 4% of sheds, exclusively on large farms. Internal insulation was used in 20.83% of farms. In conclusion, Brazilian quail sheds have a low degree of technification; about 90% do not use implements such as ceiling, ventilation, and cooling systems. These conditions make it difficult to control environmental variables within quail sheds, impairing thermal comfort and, consequently, animal welfare and quail productivity. Full article

Recommendations on the selection of air curtains and the calculation of their parameters for livestock premises in cattle management farms are made. The air curtain functioning principle is analyzed from the air jet theory point of view. The block diagram and modular design of air curtains with a variable air jet direction vector and with controlled slit width are designed. Laboratory tests of the newly designed air curtain structure are performed in accordance with the microclimate requirements for the cattle management farm premises. Based on the experimental results, the major air curtain parameters are calculated for the range from 10° to 60° of angle α between the direction of the air jet outward from the air curtain slit and aperture plane, and for the air curtain slit width b₀ in the range from 0.05 m to 0.15 m with the account of the wind speed V_w variations. Calculated values for amounts of energy that have to be consumed to ensure the required air jet velocity, in the output from the air curtain, and those for the quantity of thermal energy required to heat the air supplied to the air curtain, depending on the angle α and on the slit width b₀, can be helpful for selecting the power capacity of both the air curtain fan and electric heater. A block diagram of the air curtain control for cattle management farm premises is designed, enabling automatic control of the airflow rate, the angle of the air jet output from the air curtain slit, and the temperature of the heated air supplied to the air curtain, considering particular climate conditions. According to the preliminary estimate, applications of the newly designed air curtain will make it possible to reduce the energy consumed to maintain the required microclimate conditions in cattle management premises by 10% to 15% in the cold period. Full article

People are spending more and more of their lives indoors, making thermal comfort and air quality essential factors for their health and well-being. The use of natural elements within indoor spaces can improve the indoor environment and air quality, but can also bring multiple health and well-being, psychological, cognitive, and behavioral benefits due to its biophilic effect. Indoor vertical greenery strategy in buildings can give these benefits to the building occupants. In this study, a prototype of a living green curtain is assessed to evaluate the benefits that may derive when used as a shading device. The analysis evaluated the performance of the green curtain prototype compared to the other two scenarios, no curtains (control module) and external blind. Temperature, relative humidity, air quality, and solar radiation were measured in the indoor environment. Results indicate that the green curtain module was cooler by 0–4 °C than the control module during the peak solar radiation hours, and the difference even reached up to 8 °C on hotter days. Due to the evapotranspiration effect, the green curtain recorded the highest daily average relative humidity of 67%. This study demonstrates the potential ability of a green curtain to improve air quality and thermal comfort. Full article

Large public buildings (LPBs) are the main energy consumers in cities, and the air conditioning system contributes a large part. Supply air allocation by partition can avoid excessive regulation of the system. In spatially interconnected LPBs, thermal coupling relationships exist between different subzones. The convective heat transfer to the non-occupied zone increases the actual cooling/heating capacity of the air conditioning area. This paper applies the air curtain as an airflow barrier indoors, and the air curtain grid system (ACGS) is created by the combined operation of multiple air curtains, which aims to reduce the convective heat exchange between adjacent subzones. The computational fluid dynamics (CFD) model is established and simulated. The main conclusions are as follows: (1) For the scenarios addressed in this paper, the combination of a 60° diffuser air supply angle and 2 m/s air curtain velocity can reduce the convective load from the adjacent space by more than 50%. (2) It is recommended to install incomplete air curtains indoors, and a 50% air curtain coverage ratio can reduce 52% of the heat exchange. (3) The mathematical model of air infiltration/exfiltration under the combined operation of multiple air curtains is established and verified in ACGS. This paper provides a new approach to the air conditioning partition control of LPBs. Full article

Fibrous materials are often used in the manufacturing of fire protection devices such as fire curtains. Their optimization and improved performance is still a topic of interest. The present work aims to develop and test a new combination of fibers arranged in various 2D and 3D patterns with coatings. For this purpose, basalt fibers were added into a glass fiber fabric, and wires of a shape memory material (SMM) were inserted into the fabric to create air pockets induced by temperature. In fire curtains, the base structure is a 2D basket pattern, and all combinations were tested with and without a waterborne polyurethane (WPU) coating with inorganic materials. Three different tests were selected to characterize the thermal behavior: fire resistance, ignitability, and smoke production. Fiberglass proved to be the best material to provide thermal resistance in fire curtains, with the outer surface temperature of the fabric below 650 °C at the end of the tests. The SMM wires provided good protection during the initial stages of the test, but a combination of excessive deformation and reduced strength of the fabric resulted in a sudden failure of the structure. Basalt fibers contribute to a reduction of smoke production. It was observed an improvement of up to 10% in the thermal capacity between 1MIX2 (glass fibers fabric with coating, MIX2) and the best commercial curtain evaluated, Commercial3 (glass and steel fibers fabric with coating). Full article

Post-occupancy evaluations of buildings help us understand the effectiveness of building designs. Most of such evaluations focus on the overall building performance and on the indoor air environment, and few focus on individual technologies. In this paper, we report a user experience-based evaluation on multiple green technologies applied in a high-rise building constructed 17 years ago. These technologies include a circular building design, innovative floor plans, a corridor-type, double-skin facade with cavity shading, and three-dimensional greening design. Data were obtained through a questionnaire for the building occupants and on-site measurements of environmental variables. The results show that the occupants were most satisfied with the three-dimensional greening, natural lighting and ventilation in the public spaces, and the sound and thermal environment of the rooms with the double facade. They were not satisfied with room ventilation, solar shading, or lighting adjustment provided by the double facade. In addition, the aesthetic appearance of the circular building was not recognized by the occupants, who appeared to pay more attention to its space efficiency than the external appearance. This was true especially for older occupants. The users expressed a strong demand for outdoor leisure spaces and green vegetation. However, the practicality and functionality of three-dimensional greening, along with the interference of the glass curtain wall on vegetation growth, calls for more attention to the design. The female occupants were found to be more sensitive to the thermal and acoustic environment. Based on these results, we provide recommendations on the maintenance of the building and the future design of these measures. Full article

In buildings with the solar heat collection/insulation energy-saving window (SHC/IESW), when the insulation device is placed at night in winter, a double-wall structure façade (DSF) is formed between the glass and the insulation curtain, and the existence of air inlet and outlet leads to cold air penetration. In this paper, the Nusselt number (Nu) correlation and convective heat transfer coefficient (CHTC) of the cavity in SHC/IESW were calculated through an experiment combined with a theoretical analysis. Then, numerical simulation was performed on the fluid dynamics and thermal characteristics caused by air convection in an asymmetrically heated cavity under uniform heat flow conditions, to optimize the SHC/IESW structure and analyze its heat transfer mechanism to solve the problem of convection heat transfer between plates under cold air infiltration. Using the calculation formulas obtained from the experiment, the heat transfer coefficient of SHC/IESW is 1.71 W·m⁻²·K⁻¹. The numerical simulation results showed that with the increase of air layer thickness, the outlet temperature, the average air velocity of the cavity, and the surface temperature of thermal insulation curtain all decrease; with the increase of inlet width, the outlet temperature and the surface temperature of thermal insulation curtain decreases significantly, while the average air velocity of cavity increases. It can help to weaken the convective heat transfer in the cavity and thus, reduce the total heat transfer coefficient to 1.28 W·m⁻²·K⁻¹ when the air layer thickness is 12 mm and the inlet width is 1 mm. Full article

High-temperature particle receivers are being developed to achieve temperatures in excess of 700 °C for advanced power cycles and solar thermochemical processes. This paper describes designs and features of a falling particle receiver system that has been evaluated and tested at the National Solar Thermal Test Facility at Sandia National Laboratories. These advanced designs are intended to reduce heat losses and increase the thermal efficiency. Novel features include aperture covers, active air flow, particle flow obstructions, and optimized receiver shapes that minimize advective heat losses, increase particle curtain opacity and uniformity, and reduce cavity wall temperatures. Control systems are implemented in recent on-sun tests to maintain a desired particle outlet temperature using an automated closed-loop proportional–integral–derivative controller. These tests demonstrate the ability to achieve and maintain particle outlet temperatures approaching 800 °C with efficiencies between 60 and 90%, depending on incident power, mass flow, and environmental conditions. Lessons learned regarding the testing of design features and overall receiver operation are also presented. Full article

In the context of energy conservation and sustainable development, building design should take into account the energy efficiency criteria by using renewable energy sources. Double-skin facades (DSF) represent innovative energy-efficient techniques that have gained increasing interest worldwide. The present study reports the results of an experimental campaign performed on a full-scale double-skin façade using the in-situ measurement methodology. The thermodynamic behavior of the façade is studied under real exterior climatic conditions in Romania in hot and cold seasons, and performance indicators in terms of pre-heating efficiency and dynamic insulation efficiency were determined. Three summer periods are analyzed corresponding to the outdoor air curtain scenario for three ventilation modes in naturally or mechanically ventilated single-story DSF. Results revealed that the third ventilation scenario, which combines horizontal and vertical openings, gives the best efficiency of 71.3% in the double skin façade functioning. During the cold season, the channel façade behaved like a thermal buffer between the building and the exterior air, ensuring the thermal energy for partial or integral heating of the building. Full article

Creating and maintaining the microclimate in livestock buildings is associated with numerous engineering and technical challenges. Together with adequate feeding, the microclimate determines the health, reproductive ability, and production potential of the animals (obtaining a maximum amount of high-quality products). One of the deciding steps in improving the parameters of microclimate, i.e., temperature and humidity in agricultural facilities, particularly in livestock buildings, is to develop reliable and highly efficient air curtains in the vestibules. The objective of the manuscript is to investigate the parameters of the microclimate in livestock buildings using the air curtain, supported by automation and ICT technologies for rational operating modes. The presented theoretical and experimental studies on improving the microclimate parameters in livestock buildings were carried out using an innovative air curtain system. Its power is calculated based on the dimensions of the room, and the flow rate of warm air near the floor level is three times lower than at the installation site. The use of air curtains reduces consumption of thermal energy needed to maintain an optimal microclimate for livestock by 10–15%. Furthermore, the use of an automated digital control system maintains an optimal microclimate in the building. The developed energy-saving system for creating an optimal micro-climate in livestock buildings using air curtains was tested in a pigsty of the Research and Training Farm “Vorzel” of the National University of Life and Environmental Sciences of Ukraine, located in the Kiev region. The developed automated microclimate system using air curtains significantly improves the microclimate parameters and significantly reduces power consumption. The system can be further developed by adding remote control based on the Internet of Things (IoT) technology. Full article

To host the 2022 FIFA World Cup, Qatar is facing the greatest challenge in balancing the energy consumptions for cooling the stadiums and the thermal comfort for both players and spectators. Previous studies have not considered using a combined configuration of air curtain and roof cooling supply slot in stadiums to prevent the infiltration of outside hot air and reduce the cooling system’s energy consumption. This paper presents a Computational Fluid Dynamics (CFD) study of thermal and wind modeling around a baseline stadium and simulates the cooling scenarios of air curtains and roof cooling along with the energy consumption estimations for the World Cup matches using Building Energy Simulation (BES). Sensitivity analysis of different supply speeds and supply temperatures of air curtain gates and roof cooling was carried out, and the results showed that scenario six, which provides supply air of 25 m/s and 20 m/s at the roof and air curtain gates with a supply temperature of 10 °C, demonstrates optimal thermal performances on both the spectator tiers and the pitch. Compared with the baseline stadium performance, the average reductions in temperature on the pitch and spectator tiers under scenario six could reach 15 °C and 14.6 °C. The reductions in the Predicted Percentage of Dissatisfied values for the upper and lower tiers as well as the pitch were 63%, 74%, and 78%. In terms of the estimated energy consumptions, scenario six would consume electric energy per match at a rate of 25.5 MWh compared with 22.8 MWh for one of the stadiums in the 2010 South Africa World Cup and 42.0 MWh for the 2006 Germany World Cup. Future research is recommended to explore the influence of supply angle on air curtain gates and roof cooling supply slots’ performances. Full article

This article describes the characteristics of one type of sealing system used in warm edge glazing units and analyses the possible causes of damage. Attention was focused on the performance of the dual seal, PIB/silicone system. This type of glazing is widely used for modern curtain walls and roofs of office buildings and shopping centres. Study was focused on PIB displacement defects, which affects both the appearance and thermal performance of the curtain wall system. Wide-ranging field surveys were conducted to examine the problems identified in some office buildings. The information gathered in this way was used to identify the critical areas and causes of seal displacement in the analysed insulating glass units (IGUs). Laboratory tests were conducted on PIB and silicone seals retrieved from the removed defective units. The properties of these materials were determined and used to evaluate the applied edge sealing system and build a representative numerical model. Due to the problems encountered in deriving accurate analytical formulas, finite element (FE) approximation was used as a problem solving tool. The generated FE model and strain analysis were the key parts to obtaining a true representation of the actual behaviour of IGUs subjected to various environmental loads, taking into account the influence of the air cavity. Results of computer simulations and laboratory tests were compared for model validation. The effect of changes in ambient pressure was examined, showing the development of tensile strains in the silicone and PIB, which can lead to debonding. The greatest principal strains occur at the silicone/butyl rubber interface and this location should be considered to be the most susceptible to failure. The observations are summarised in the final conclusions. Additionally, as field study showed, after ten years in service, the percentage of damaged units is considerable. More frequent IGUs inspection should cover both appearance and thermal imaging to detect unsealed panels. From the standpoint of both durability and appearance, dual silicone/PIB should be phased out in favour of modern seal systems. Full article
