Dam stability is one of the most essential geotechnical engineering challenges. Studying the structural behavior of dams during their useful life is an essential component of their safety. Terrestrial surveying network approaches are typically expensive and time-consuming. Over the last decade, the interferometric synthetic aperture radar (InSAR) method has been widely used to monitor millimeter displacements in dam crests. This research investigates the structural monitoring of the Lar Dam in Iran, using InSAR and the terrestrial surveying network technique to identify the possible failure risk of the dam. Sentinel-1A images taken from 5 February 2015 to 30 September 2019 and TerraSAR-X (09.05.2018 to 16.08.2018) images were analyzed to investigate the dam’s behavior. The InSAR results were compared with those of the terrestrial surveying network for the period of 1992 to 2019. The Sentinel-1 results implied that the dam on the left side moved over 8 mm/yr. However, the pillars to the left abutment indicated an uplift, which is consistent with the TerraSAR-X results. Also, the TerraSAR-X data indicated an 8 mm displacement over a three-month period. The terrestrial surveying showed that the largest uplift was 19.68 mm at the TB4 point on the left side and upstream of the body, while this amount was 10 mm in the interferometry analysis for the period of 2015–2020. The subsidence rate increased from the middle part toward the left abutment. The geological observations made during the ninth stage of the terrestrial surveying network indicate that there was horizontal and vertical movement over time, from 1992 to 2019. However, the results of the InSAR processing in the crown were similar to those of the terrestrial surveying network. Although different comparisons were used for the measurements, the difference in the displacement rates was reasonable, but all three methods showed the same trend in terms of uplift and displacement. Full article

Accurate estimation of forest height over a large area is beneficial to reduce the uncertainty of forest carbon sink estimation, which is of great significance to the terrestrial carbon cycle, global climate change, forest resource management, and forest-related scientific research. Forest height inversion using polarimetric interferometry synthetic aperture radar (PolInSAR) data through Random volume over ground (RVoG) models has demonstrated great potential for large-area forest height mapping. However, the wavelength and baseline length used for the PolInSAR data acquisition plays an important role during the forest height estimation procedure. In this paper, X–, C–, L–, and P–band PolInSAR datasets with four different baseline lengths were simulated and applied to explore the effects of wavelength and baseline length on forest height inversion using RVoG models. Hierarchical Bayesian models developed with a likelihood function of RVoG model were developed for estimated results uncertainty quantification and decrease. Then a similar procedure was applied in the L– and P–band airborne PolInSAR datasets with three different baselines for each band. The results showed that (1) Wavelength showed obvious effects on forest height inversion results with the RVoG model. For the simulated PolInSAR datasets, the L– and P–bands performed better than the X– and C–bands. The best performance was obtained at the P–band with a baseline combination of 10 × 4 m with an absolute error of 0.05 m and an accuracy of 97%. For the airborne PolInSAR datasets, an L–band with the longest baseline of 24 m in this study showed the best performance with R² = 0.64, RMSE = 3.32 m, and Acc. = 77.78%. (2) It is crucial to select suitable baseline lengths to obtain accurate forest height estimation results. In the four baseline combinations of simulated PolInSAR datasets, the baseline combination of 10 × 4 m both at the L– and P–bands performed best than other baseline combinations. While for the airborne PolInSAR datasets, the longest baseline in three different baselines obtained the highest accuracy at both L– and P–bands. (3) Bayesian framework is useful for estimation results uncertainty quantification and decrease. The uncertainties related to wavelength and baseline length. The uncertainties were reduced obviously at longer wavelengths and suitable baselines. Full article

Earth flows are complex gravitational events characterised by a heterogeneous displacement pattern in terms of scale, style, and orientation. As a result, their monitoring, for both knowledge and emergency purposes, represents a relevant challenge in the field of engineering geology. This paper aims to assess the capabilities, peculiarities, and limitations of different remote sensing monitoring techniques through their application to the Pietrafitta earth flow (Southern Italy). The research compared and combined data collected during the main landslide reactivations by different ground-based remote sensors such as Robotic Total Station (R-TS), Terrestrial Synthetic Aperture Radar Interferometry (T-InSAR), and Terrestrial Laser Scanner (TLS), with data being derived by satellite-based Digital Image Correlation (DIC) analysis. The comparison between R-TS and T-InSAR measurements showed that, despite their different spatial and temporal resolutions, the observed deformation trends remain approximately coherent. On the other hand, DIC analysis was able to detect a kinematic process, such as the expansion of the landslide channel, which was not detected by the other techniques used. The results suggest that, when faced with complex events, the use of a single monitoring technique may not be enough to fully observe and understand the processes taking place. Therefore, the limitations of each different technique alone can be solved by a multi-sensor monitoring approach. Full article

Dams are essential structures in the growth of a region due to their ability to store large amounts of water and manage it for different social activities, mainly for human consumption. The study of the structural behavior of dams during their useful life is a fundamental factor for their safety. In terms of structural monitoring, classic terrestrial techniques are usually costly and require much time. Interferometric synthetic aperture radar (InSAR) technology through the persistent scatterer interferometry (PSI) technique has been widely applied to measure millimeter displacements of a dam crest. In this context, this paper presents an investigation about the structural monitoring of the crest of the Sanalona dam in Mexico, applying two geodetic satellite techniques and mathematical modeling to extract the risk of the dam–reservoir system. The applicability of the InSAR technique for monitoring radial displacements in dams is evaluated and compared with both GPS systems and an analytical model based on the finite element method (FEM). The radial displacements of the Sanalona dam follow a seasonal pattern derived from the reservoir level, reaching maximum radial magnitudes close to 13 mm in November when the rainy season ends. GPS recorded and FEM simulated maximum displacements of 7.3 and 6.7 mm, respectively. InSAR derived radial displacements, and the reservoir water level presented a high similarity with a correlation index equal to 0.8. In addition, it was found that the Sanalona dam presents the greatest deformation in the central zone of the crest. On the other hand, based on the reliability analysis, the probability of failure values lower than 8.3 × ${10}^{-2}$ was obtained when the reservoir level was maximum, which means that the radial displacements did not exceed the limit states of the dam–reservoir system in the evaluated period. Finally, the extracted values of the probability of failure demonstrated that the Sanalona dam does not represent a considerable risk to society. Full article

SAR tomography (TomoSAR) extends SAR interferometry (InSAR) to image a complex 3D scene with multiple scatterers within the same SAR cell. The phase calibration method and the super-resolution reconstruction method play a crucial role in 3D TomoSAR imaging from multi-baseline SAR stacks, and they both influence the accuracy of the 3D SAR tomographic imaging results. This paper presents a systematic processing method for 3D SAR tomography imaging. Moreover, with the newly released TanDEM-X 12 m DEM, this study proposes a new phase calibration method based on SAR InSAR and DEM error estimation with the super-resolution reconstruction compressive sensing (CS) method for 3D TomoSAR imaging using COSMO-SkyMed Spaceborne SAR data. The test, fieldwork, and results validation were executed at Zipingpu Dam, Dujiangyan, Sichuan, China. After processing, the 1 m resolution TomoSAR elevation extraction results were obtained. Against the terrestrial Lidar ‘truth’ data, the elevation results were shown to have an accuracy of 0.25 ± 1.04 m and a RMSE of 1.07 m in the dam area. The results and their subsequent validation demonstrate that the X band data using the CS method are not suitable for forest structure reconstruction, but are fit for purpose for the elevation extraction of manufactured facilities including buildings in the urban area. Full article

Terrestrial Radar Interferometry (TRI) is a measurement technique capable of measuring displacements with high temporal resolution at high accuracy. Current implementations of TRI use large and/or movable antennas for generating two-dimensional displacement maps. Multiple Input Multiple Output Synthetic Aperture Radar (MIMO-SAR) systems are an emerging alternative. As they have no moving parts, they are more easily deployable and cost-effective. These features suggest the potential usage of MIMO-SAR interferometry for structural health monitoring (SHM) supplementing classical geodetic and mechanical measurement systems. The effects impacting the performance of MIMO-SAR systems are, however, not yet sufficiently well understood for practical applications. In this paper, we present an experimental investigation of a MIMO-SAR system originally devised for automotive sensing, and assess its capabilities for deformation monitoring. The acquisitions generated for these investigations feature a 180${}^{\circ }$ Field-of-View (FOV), distances of up to 60 m and a temporal sampling rate of up to 400 Hz. Experiments include static and dynamic setups carried out in a lab-environment and under more challenging meteorological conditions featuring sunshine, fog, and cloud-cover. The experiments highlight the capabilities and limitations of the radar, while allowing quantification of the measurement uncertainties, whose sources and impacts we discuss. We demonstrate that, under sufficiently stable meteorological conditions with humidity variations smaller than 1%, displacements as low as 25 μm can be detected reliably. Detecting displacements occurring over longer time frames is limited by the uncertainty induced by changes in the refractive index. Full article

Nowadays the use of remote monitoring sensors is a standard practice in landslide characterization and monitoring. In the last decades, technologies such as LiDAR, terrestrial and satellite SAR interferometry (InSAR) and photogrammetry demonstrated a great potential for rock slope assessment while limited studies and applications are still available for ArcSAR Interferometry, Gigapixel imaging and Acoustic sensing. Taking advantage of the facilities located at the Poggio Baldi Landslide Natural Laboratory, an intensive monitoring campaign was carried out on May 2019 using simultaneously the HYDRA-G ArcSAR for radar monitoring, the Gigapan robotic system equipped with a DSLR camera for photo-monitoring purposes and the DUO Smart Noise Monitor for acoustic measurements. The aim of this study was to evaluate the potential of each monitoring sensor and to investigate the ongoing gravitational processes at the Poggio Baldi landslide. Analysis of multi-temporal Gigapixel-images revealed the occurrence of 84 failures of various sizes between 14–17 May 2019. This allowed us to understand the short-term evolution of the rock cliff that is characterized by several impulsive rockfall events and continuous debris production. Radar displacement maps revealed a constant movement of the debris talus at the toe of the main rock scarp, while acoustic records proved the capability of this technique to identify rockfall events as well as their spectral content in a narrow range of frequencies between 200 Hz to 1000 Hz. This work demonstrates the great potential of the combined use of a variety of remote sensors to achieve high spatial and temporal resolution data in the field of landslide characterization and monitoring. Full article

The coupled effects of climate change, sea-level rise, and land sinking in estuaries/alluvial plains prone to inundation and flooding mean that reliable estimation of land movements/subsidence is becoming more crucial. During the last few decades, land subsidence has been monitored by precise and continuous geodetic measurements either from space or using terrestrial techniques. Among them, the Persistent Scaterrer Interferometry (PSInSAR) technique is used on the entire Belgian territory to detect, map and interpret the identified ground movements observed since 1992. Here the research focuses on one of the biggest cities in Belgium that became the second European harbour with giant docks and the deepening of the Scheldt river allowing the navigation of the largest container vessels. The areas along the embankments of the Scheldt river and the harbour facilities are associated to Holocene fluviatile deposits overlain by recent landfills. These sedimentary deposits and human-made landfills are affected by important and ongoing land subsidence phenomena. The land subsidence process is highlighted by an annual average Line of Sight (LOS) velocity of about −3.4 mm/year during the years 1992–2001 (ERS1/2 datasets), followed by an annual average LOS velocity of about −2.71 mm/year and −2.11 mm/year, respectively, during the years 2003–2010 (ENVISAT) and 2016–2019 (Sentinel 1A). The Synthetic Aperture Radar (SAR) imagery data indicate a progressive decrease in the average annual velocities on a global scale independently of important local variations in different districts along the Scheldt river. On the contrary, the city centre and the old historic centre of Antwerp are not affected by negative LOS velocities, indicating stable ground conditions. A geological interpretation of this difference in settlement behaviour between the different areas is provided. Full article

Mass movements represent a serious threat to the stability of human structures and infrastructures, and cause loss of lives and severe damages to human properties every year worldwide. Built structures located on potentially unstable slopes are susceptible to deformations due to the displacement of the ground that at worst can lead to total destruction. Synthetic aperture radar (SAR) data acquired by Sentinel-1 satellites and processed by multi-temporal interferometric SAR (MT-InSAR) techniques can measure centimeter to millimeter-level displacement with weekly to monthly updates, characterizing long-term large-scale behavior of the buildings and slopes. However, the spatial resolution and short wavelength weaken the performance of Sentinel-1 in recognizing features (i.e., single buildings) inside image pixels and maintaining the coherence in mountainous vegetated areas. We have proposed and applied a methodology that combines Sentinel-1 interferometry with ground-based geomatics techniques, i.e., global navigation satellite system (GNSS), terrestrial laser scanning (TLS) and terrestrial structure from motion photogrammetry (SfM), for fully assessing building deformations on a slope located in the north-eastern Italian pre-Alps. GNSS allows verifying the ground deformation estimated by MT-InSAR and provides a reference system for the TLS and SfM measurements, while TLS and SfM allow the behavior of buildings located in the investigated slope to be monitored in great detail. The obtained results show that damaged buildings are located in the most unstable sectors of the slope, but there is no direct relationship between the rate of ground deformation of these sectors and the temporal evolution of damages to a single building, indicating that mass movements cause the displacement of blocks of buildings and each of them reacts differently according to its structural properties. This work shows the capability of MT-InSAR, GNSS, TLS and SfM in monitoring both buildings and geological processes that affect their stability, which plays a key role in geohazard analysis and assessment. Full article

On February 14th, 2018, in the North-Western sector of the Municipality of Rome (Central Italy), in the framework of an excavation for building construction, a portion of a piling wall piling wall collapsed in an already densely urbanized area. Soil behind the collapsed piling wall slipped inside the excavation site dragging seven cars parked on one side of the road running parallel to the piling wall and affecting some residential buildings located on the opposite side of the road. Fortunately, no injuries were counted but the 22 families living in the buildings next to the damaged wall were evacuated. Following the piling wall collapse, the Civil Protection of Rome, thanks to the technical support of the Research Centre on Geological Risks (CERI) of the Sapienza University of Rome, started a continuous monitoring of the affected area through remote sensing techniques. In the first hours following the collapse, a Terrestrial Synthetic Aperture Radar Interferometer (TInSAR) and a terrestrial laser scanner (TLS) were installed with the aim to control the evolution of the process, to support the local authority to manage the associated residual risk, and to ensure the safety of workers during emergency operations. In this paper we discuss some of the results obtained by the monitoring of the involved area. Thanks to the comparisons between different surveys and the reconstruction of the pre-event geometries, the total volume involved in the failure was estimated around 850 m³. In addition, through the analysis of data acquired by the 18 multi-temporal TLS scans and the three and a half months of continuous TInSAR monitoring, the movement involving a portion of the filling material used for stabilization works was observed and described. Such movement, reaching a total displacement of about 270–300 mm, was monitored and reported in real time. Full article

Monitoring environmental hazards, owing to natural and anthropogenic causes, is an important issue, which requires proper data, models, and cross-validation of the results. The geodetic satellite missions, for example, the Gravity Recovery and Climate Experiment (GRACE) and Sentinel-1, are very useful in this respect. GRACE missions are dedicated to modeling the temporal variations of the Earth’s gravity field and mass transportation in the Earth’s surface, whereas Sentinel-1 collects synthetic aperture radar (SAR) data, which enables us to measure the ground movements accurately. Extraction of large volumes of water and oil decreases the reservoir pressure and form compaction and, consequently, land subsidence occurs, which can be analyzed by both GRACE and Sentinel-1 data. In this paper, large-scale groundwater storage (GWS) changes are studied using the GRACE monthly gravity field models together with different hydrological models over the major oil reservoirs in Sudan, that is, Heglig, Bamboo, Neem, Diffra, and Unity-area oil fields. Then, we correlate the results with the available oil wells production data for the period of 2003–2012. In addition, using the only freely available Sentinel-1 data, collected between November 2015 and April 2019, the ground surface deformation associated with this oil and water depletion is studied. Owing to the lack of terrestrial geodetic monitoring data in Sudan, the use of GRACE and Sentinel-1 satellite data is very valuable to monitor water and oil storage changes and their associated land subsidence over our region of interest. Our results show that there is a significant correlation between the GRACE-based GWS anomalies (ΔGWS) and extracted oil and water volumes. The trend of ΔGWS changes due to water and oil depletion ranged from –18.5 ± 6.3 to –6.2 ± 1.3 mm/year using the CSR GRACE monthly solutions and the best tested hydrological model in this study. Moreover, our Sentinel-1 SAR data analysis using the persistent scatterer interferometry (PSI) method shows a high rate of subsidence, that is, –24.5 ± 0.85, –23.8 ± 0.96, –14.2 ± 0.85, and –6 ± 0.88 mm/year over Heglig, Neem, Diffra, and Unity-area oil fields, respectively. The results of this study can help us to control the integrity and safety of operations and infrastructure in that region, as well as to study the groundwater/oil storage behavior. Full article

The coupled effects of climate change and land sinking make deltas and coastal areas prone to inundation and flooding, meaning that reliable estimation of land subsidence is becoming crucial. Commonly, land subsidence is monitored by accurate continuous and discrete measurements collected by terrestrial and space geodetic techniques, such as Global Navigation Satellite System (GNSS), Interferometry Synthetic Aperture Radar (InSAR), and high precision leveling. In particular, GNSS, which includes the Global Positioning System (GPS), provides geospatial positioning with global coverage, then used for deriving local displacements through time. These site-positioning time series usually exhibit a linear trend plus seasonal oscillations of annual and semi-annual periods. Although the periodic components observed in the geodetic signal affect the velocity estimate, studies dealing with the prediction and prevention of risks associated with subsidence focus mainly on the permanent component. Periodic components are simply removed from the original dataset by statistical analyses not based on the underlying physical mechanisms. Here, we propose a systematic approach for detecting the physical mechanisms that better explain the permanent and periodic components of subsidence observed in the geodetic time series. It consists of three steps involving a component recognition phase, based on statistical and spectral analyses of geodetic time series, a source selection phase, based on their comparison with data of different nature (e.g., geological, hydro-meteorological, hydrogeological records), and a source validation step, where the selected sources are validated through physically-based models. The application of the proposed procedure to the Codigoro area (Po River Delta, Northern Italy), historically affected by land subsidence, allowed for an accurate estimation of the subsidence rate over the period 2009–2017. Significant differences turn out in the retrieved subsidence velocities by using or not periodic trends obtained by physically based models. Full article

Ground-based synthetic aperture radar interferometry (GB-InSAR) is a valuable tool for deformation monitoring. The 2D interferograms obtained by GB-InSAR can be integrated with a 3D terrain model to visually and accurately locate deformed areas. The process has been preliminarily realized by geometric mapping assisted by terrestrial laser scanning (TLS). However, due to the line-of-sight (LOS) deformation monitoring, shadow and layover often occur in topographically rugged areas, which makes it difficult to distinguish the deformed points on the slope between the ones on the pavement. The extant resampling and interpolation method, which is designed for solving the scale difference between the point cloud and radar pixels, does not consider the local scattering characteristics difference of slope. The scattering difference information of road surface and slope surface in the terrain model is deeply weakened. We propose a differentiated method with integrated GB-InSAR and terrain surface point cloud. Local geometric and scattering characteristics of the slope were extracted, which account for pavement and slope differentiating. The geometric model is based on a GB-InSAR system with linear repeated-pass and the topographic point cloud relative observation geometry. The scattering model is based on k-nearest neighbor (KNN) points in small patches varies as radar micro-wave incident angle changes. Simulation and a field experiment were conducted in an open-pit mine. The results show that the proposed method effectively distinguishes pavement and slope surface deformation and the abnormal area boundary is partially relieved. Full article

The integration of data from different sources can be very helpful in understanding the mechanism, the geometry, the kinematic, and the area affected by complex instabilities, especially when the available geotechnical information is limited. In this work, the suitability of different techniques for the study of a deep-seated landslide affecting a bridge in Alcoy (Spain) is evaluated. This infrastructure presents such severe damage that has rendered the bridge unusable, which prevents normal access to an important industrial area. Differential SAR Interferometry (DInSAR) and terrestrial Light Detection and Ranging (LiDAR) remote sensing techniques have been combined with ground displacement monitoring techniques, such as inclinometers and conventional geological and geotechnical investigation, electrical-seismic tomography, damage, and topographic surveys, to determine the boundaries, mechanism, and kinematics of the landslide. The successful case study that is illustrated in this work highlights the potential and the need for integrating multi-source data for the optimal management of complex landslides and the effective design of remedial measurements. Full article

This paper presents a practical framework for urban bridge damage detection and analysis by using three key techniques: terrestrial laser scanning (TLS), ground-based microwave interferometry, and permanent scatterer interferometry synthetic aperture radar (PS-InSAR). The proposed framework was tested on the Beishatan Bridge in Beijing, China. Firstly, a Digital Surface Model (DSM) of the lower surface of the bridge was constructed based on the point cloud generated by using TLS to obtain the potential damage area. Secondly, the dynamic time-series displacement of the potential damage area was acquired by ground-based microwave interferometry, and the Extreme-Point Symmetric Mode Decomposition (ESMD) method was applied to detect damages by the use of signal decomposition and instantaneous frequency calculation. Lastly, the PS-InSAR technique was applied to obtain the surface deformation around Beishatan Bridge by using COSMO-SkyMed images with a ground resolution of 3 m × 3 m, and finally, we analyzed the causes of bridge damage. The experimental results showed that the proposed framework can effectively obtain the potential damage area of the bridge by the DSM from the point cloud by TLS and further judge whether the bridge was damaged by the ESMD method, based on the time-series displacement data. The results also showed that the subway shield construction may be the reason for damage to Beishatan Bridge. Full article
