To facilitate both the installation and the removal of floating offshore wind turbines (FOWTs), a novel tension-leg dual-module offshore wind turbine system has been proposed. This system primarily consists of a DTU 10 MW wind turbine (WT) module and a supporting tension-leg platform (TLP) module. Considering both mechanical and hydrodynamic coupling effects of the dual-module system, this study focuses on its dynamic responses during both the installation and the removal of the WT module under typical sea states. The effect of different installation vessel positions and key parameters of the clamping device on the dynamic response of the system during the WT module removal has been clarified. Based on the findings, preliminary recommendations are provided regarding the optimal positioning of the installation vessel and the optimal design parameters of the clamping device. Furthermore, an auxiliary sleeve has been proposed to facilitate the WT module removal. The results indicate that the application of the auxiliary sleeve can significantly improve the dynamic response of the system. The results of this study can serve as a reference for the design, installation, and removal of floating offshore wind turbines. Full article

The primary challenge in the design of offshore oscillating water column (OWC) devices lies in maintaining structural integrity throughout their operational lifespan while functioning in challenging environmental conditions. Simultaneously, it is vital for these devices to demonstrate efficiency in wave power absorption across a range of environmental scenarios pertinent to the selected installation site. The present manuscript seeks to compare two distinct mooring types for a dual-chamber OWC device to enhance its wave power efficiency. To accomplish this objective, an analysis of wave power absorption efficiency will be conducted on both a catenary mooring system and a tension-leg platform (TLP) mooring arrangement, thereby identifying the most suitable configuration. The study elucidates how OWC mooring characteristics influence wave power absorption efficiency. While the catenary mooring system exhibits two distinct resonant wave frequencies, resulting in enhanced wave power absorption at those frequencies, the TLP mooring system demonstrates superior overall wave power absorption efficiency across a broader range of wave frequencies, thus showcasing its greater potential for wave energy conversion under diverse environmental conditions. Full article

Floating offshore wind (FOW) is rapidly gaining interest due to its large potential. In this regard, it is of special interest to determine the best locations for its installation. One of the main aspects when evaluating the feasibility of a project is the levelised cost of energy (LCOE), but there are many variables to consider when calculating it for FOW, and plenty of them are hard to find when the scope is all the suitable areas worldwide. This paper presents the calculation and analysis of the global LCOE with particular focus on the best countries and territories from an economic point of view, considering four types of platforms: semi-submersible, barge, spar, and tension leg platform (TLP). The model takes into account, on the one hand, wind data, average significant wave height, and distance to shore for an accurate calculation of delivered energy to the onshore substation and, on the other hand, bathymetry, distances, and existing data from projects to find appropriate functions for each cost with regression models (e.g., manufacturing, installation, operation and maintenance (O&M), and decommissioning costs). Its results can be used to assess the potential areas around the world and identify the countries and territories with the greatest opportunities regarding FOW. The lowest LCOE values, i.e., the optimal results, correspond to areas where wind resources are more abundant and the main variables of the site affecting the costs (water depth, average significant wave height, distance to shore, and distance to port) are as low as possible. These areas include the border between Venezuela and Colombia, the Canary Islands, Peru, the border between Western Sahara and Mauritania, Egypt, and the southernmost part of Argentina, with LCOEs around 90 €/MWh. Moreover, there are many areas in the range of 100–130 €/MWh. Full article

Wave overtopping occurring in offshore wind renewable energy structures such as tension leg platforms (TLPs) or semi-submersible platforms is a phenomenon that is worth studying and preventing in order to extend the remaining useful life of the corresponding facilities. The behaviour of this phenomenon has been extensively reported for linear coastal defences like seawalls. However, no referenced study has treated the case of cylindrical structures typical of these applications to a similar extent. The aim of the present study is to define an empirical expression that portrays the relative overtopping rate over a vertical cylinder including a variety of bull-nose type mitigation structures to reduce the overtopping rate in the same fashion as for the linear structures characteristic of shoreline defences. Hydrodynamic interaction was studied by means of an experimentally validated numerical model applied to a non-impulsive regular wave regime and the results were compared with the case of a plain cylinder to evaluate the expected improvement in the overtopping performance. Four different types of parapets were added to the crest of the base cylinder, with different parapet height and horizontal extension, to see the influence of the geometry on the mitigation efficiency. Computational results confirmed the effectivity of the proposed solution in the overtopping reduction, though the singularity of each parapet geometry did not lead to an outstanding difference between the analysed options. Consequently, the resulting overtopping decrease in all the proposed geometries could be modelled by a unique specific Weibull-type function of the relative freeboard, which governed the phenomenon, showing a net reduction in comparison with the cylinder without the geometric modifications. In addition, the relationship between the reduced relative overtopping rate and the mean flow thickness over the vertical cylinder crest was studied as an alternative methodology to assess the potential damage caused by overtopping in real structures without complex volumetric measurements. The collection of computational results was fitted to a useful function, allowing for the definition of the overtopping discharge once the mean flow thickness was known. Full article

Tower fatigue and strength are crucial operational concerns of floating offshore wind turbines (FOWTs) due to the escalation of the vibration phenomena observed on these structures as compared to land-based ones. FOWT towers are excited by wave and wind polyperiodic disturbances yielding continual transient states of structural vibration that are challenging for vibration mitigation systems. Thus, the paper investigates a novel implementation of nonlinear optimal-based vibration control solutions for the full-scale, tension leg platform (TLP)-based, NREL 5MW wind turbine tower-nacelle model with a 10-ton tuned vibration absorber (TVA), equipped with a magnetorheological (MR) damper, located at the nacelle. The structure is subjected to excessive wave and wind excitations, considering floating platform motions derived from model experiments in a wave tank. The MR damper operates simultaneously with an electromagnetic force actuator (forming a hybrid TVA) or independently (a semiactive TVA). The study includes both actuators’ nonlinearities and dynamics, whereby the former are embedded in the Hamilton-principle-based nonlinear control solutions. The TVA is tuned either to the NREL 5MW tower-nacelle 1st bending mode frequency (TVA-TN) or to the TLP surge frequency (TVA-TLP). The optimal control task was redeveloped concerning the TVA stroke and transient vibration minimisation, including the implementation of the protected structure’s acceleration and relative displacement terms, as well as the nonzero velocity term in the quality index. The regarded model is embedded in a MATLAB/Simulink environment. On the basis of the obtained results, the TVA-TN solution is by far superior to the TVA-TLP one. All the regarded TVA-TN solutions provide a tower deflection safety factor of ca. 2, while reference systems without any vibration reduction solutions or with a passive TVA-TLP are at risk of tower structural failure as well as the hybrid TVA-TLP system. The obtained TVA stroke reductions of 25.7%/22.0% coincide with 3.6%/10.3% maximum tower deflection reductions for the semiactive/hybrid TVA-TN case (respectively) with regard to the previously developed approaches. Moreover, these reductions are obtained due to the sole control algorithm enhancement; thus, no additional resources are necessary, while this attainment is accompanied by a reduction in the required MR damper force. The lowest obtained TVA stroke amplitude of 1.66 m is guaranteed by the newly introduced semiactive control. Its hybrid equivalent ensures 8% lower primary structure deflection amplitude and reduced nacelle acceleration levels thanks to the utilisation of the force actuator of the relatively low power (ca. 6 kW); the trade-off is an increased TVA stroke amplitude of 2.19 m, which, however, is the lowest among all the tested hybrid solutions. The analysed reference passive TVA systems, along with a modified ground-hook hybrid solution, can hardly be implemented in the nacelle (especially along the demanding side–side direction). The latter, being the well-proven hybrid solution for steady-state tower deflection minimisation, yielded unsatisfactory results. The achievements of the study may be used for an effective design of a full-scale vibration reduction system for the TLP-based floating wind turbine structure. Full article

To address the unstable motion of a tension leg platform (TLP) for floating wind turbines in various sea conditions, an improved method of incorporating a tuned liquid multi-column damper (TLMCD) into the TLP foundation is proposed. In order to evaluate the control effect of TLMCD on the motion response of the floating foundation, a multiphase flow solver based on a viscous flow CFD method and overlapping grid technique is applied to model the coupled multi-body dynamics interaction problem involving liquid tanks, waves, and a spring mooring system. This method has been proven to accurately capture the high-frequency motions of the structure and account for complex viscous interferences affecting the geometric motions. Additionally, the volume of fluid (VOF) method and the first-order linear superposition method are used to model the focused wave, enabling a simulation of the effects of transient wave loads on the floating foundation. The results show that the tuned damping effect of TLMCD on the TLP is mainly in the pitch motion, with the maximum pitch amplitude control volume ratio of TLMCD reaching up to 86% and the maximum surge amplitude control volume ratio of TLMCD reaching up to 25.2% under the operating conditions. These findings highlight the potential for additional research on and implementation of TLMCD technology. Full article

Offshore floating wind foundations supporting a large wind turbine require a large yard facility or significant facility upgrades for their fabrication. To overcome the cost increase associated with facility upgrades, an innovative lightweight modular floating foundation is developed. The foundation comprises multiple modules to enable their assembly on water, offering many benefits and expanding fabrication options for a reduction in the overall cost of the platform. In this paper, the foundation modules and their assembly are briefly described, and an analysis of the platform’s dynamic responses is presented. The modular foundation includes a modular and lightweight tension leg platform (TLP) called “MarsVAWT” which supports a Darrieus 10 MW vertical axis wind turbine (VAWT). The platform is moored with highly pretensioned wire rope tendons. The responses of the platform are analyzed in the time domain in a semi-coupled manner under the turbine operating and parked conditions for an offshore site in the US Northeast. The tower base shear forces and bending moments increase considerably with the combination of wind and waves, compared to those with wind only. The tendon tensions on the weatherside in the operating condition at high wind speeds are comparable to the values of the 50-year extreme (parked). The tendon tension increases are highly correlated to the platform pitch, as well as the horizontal and vertical velocities and vertical acceleration at the tendon porch. The modular platform performances and tendon designs are confirmed to comply with industry standards and practices. Full article

In this study, a numerical simulation was conducted to investigate the non-linear physical phenomena of a tension leg platform (TLP) of a 15-MW-class floating offshore wind turbine (FOWT). Computational fluid dynamics was employed as the numerical tool, and a deforming mesh technique was used to describe the moving body. To examine the non-linear physical phenomena, an irregular wave was generated with a focus on head sea conditions. The springing and ringing responses were calculated from the numerical simulation results, and the relations between the motions and dynamic tensions of the 15-MW-class FOWT TLP were investigated. From the irregular wave impact simulation, it was found that the springing response via the wave sum frequencies and the ringing response occurred at approximately three times the wave peak frequency. Additionally, whipping simulations were conducted under a focused wave. The results show that the response in pitch resonance frequency was caused by the wave impact. The numerical results of this study could be used as fundamental data for FOWT TLP design. Full article

An assessment is made of the stress distribution and the hydrodynamic response of the preliminary structural design of the tension leg platform of a 10 MW wind turbine. The platform supporting a 10 MW turbine is modelled and analysed by the finite element method. The stress distribution of the platform is determined in still water with the turbine at above-rated conditions, and the response of the tension leg platform is estimated in the time domain. The results of the time domain analysis show reasonable agreement between the present results and the available data. To check the design stiffener dimensions, span, and spacing against stress distribution, classification societies’ recommendations are used. The results of the stress distribution analysis indicate that the critical locations of the platform are the interaction of the lower columns with the upper columns and the connection of the tower of the turbine. Full article

Renewable energy resources such as offshore wind and wave energy are environmentally friendly and omnipresent. A hybrid offshore wind-wave energy system produces a more sustainable form of energy that is not only eco-friendly but also economical and efficient as compared to use of individual resources. The objective of this paper is to give a detailed review of co-generation technologies for hybrid offshore wind and wave energy. The proposed area of this review paper is based on the power conversions techniques, response coupling, control schemes for co-generation and complimentary generation, and colocation and integrated conversion systems. This paper aims to offer a systematic review to cover recent research and development of novel hybrid offshore wind-wave energy (HOWWE) systems. The current hybrid wind-wave energy structures lack efficiency due to their design and AC-DC-AC power conversion that need to be improved by applying an advanced control strategy. Thus, using different power conversion techniques and control system methodologies, the HOWWE structure can be improved and will be transferrable to the other hybrid models such as hybrid solar and wind energy. The state-of-the-art HOWWE systems are reviewed. Critical analysis of each method is performed to evaluate the best possible combination for development of a HOWWE system. Full article

The tension legs are the essential parts of the tension legs platform-type (TLP-type) floating offshore wind turbine (FOWT) against the extra buoyancy of FOWT. Therefore, the TLP-type FOWT will face the risk of tension leg failure. However, there are seldom analyses on the hydrodynamic response and tension leg failure performance of FOWT with inclined tension legs. In this paper, a hydrodynamic model was established using three-dimensional hydrodynamic theory and applied in the motion response and tension analyses of FOWT with conventional and new tension leg arrangements on Moses. The influence of draft and tension leg arrangement on the performance of FOWT with inclined tension legs were studied. The optimum draft was the height of the column and lower tensions were obtained for the new tension leg arrangement. Moreover, the tension leg failure performance of FOWT with inclined tension legs was evaluated under different failure conditions. The results illustrated that the FOWT with the new tension leg arrangement can still operate safely after one tension leg fails. Full article

This paper defines a methodology for the economic feasibility analysis of a floating offshore wind farm composed of tensioned leg platforms, which are part of the EU ARCWIND research project. In this context, the phases and subphases of its life-cycle process are considered to deal with aspects such as bathymetry, characteristics of the platforms, distance from the farm to shore, distance from the farm to port and offshore wind speed. All the costs and other external parameters such as capital cost, electric tariff, interest rate, percentage of financing and corporate tax have been analysed to calculate the internal rate of return, net present value, discounted pay-back period and levelized cost of energy of the farm. This work studies a farm composed of TLP offshore wind platforms designed by CENTEC and located at Ribadeo in Spain. Results indicate the costs and the economic feasibility of this platform for deep waters. They indicate that the platform is economically feasible for the location selected. Full article

To verify that inclined tension legs can improve the stability of the tension leg platform, this paper established the dynamic equation of a tension leg platform (TLP) under marine environmental loads by using the modified Morrison equation considering the influence of ocean currents on wave forces. Additionally, the velocity and acceleration of random wave water particles were simulated via the JONSWAP spectrum. In addition, a three-dimensional model of a tension leg platform with inclined tension legs was established by AQWA, and its dynamic responses under variable survival conditions were compared and analyzed. The results showed that the surge and heave were more sensitive to the sea current, while the pitch was more sensitive to the wind. There is a significant difference in tendon tensions between the atypical TLP with inclined tension legs established in this study and the typical International Ship and Offshore Structures Committee (ISSC) TLP. Full article

The open-source code DualSPHysics, based on the Smoothed Particle Hydrodynamics method for solving fluid mechanics problems, defines a complete numerical environment for simulating the interaction of floating structures with ocean waves, and includes external libraries to simulate kinematic- and dynamic-type restrictions. In this work, a full validation of the SPH framework using experimental data available for an experimental test campaign on a 1:37-scale floating offshore wind turbine tension-leg platform (TLP) is presented. The first set of validation cases includes a surge decay test, to assess the quality of the fluid–solid interaction, and regular wave tests, which stimulate the mooring system to a large extent. During this phase, tendons (tension legs) that are simulated by MoorDyn${}^{+}$ are validated. Spectral comparison shows that the model is able to capture the surge and pitch dynamic amplification that occurs around the resonant fundamental mode of vibration. This work concludes with a numerical investigation that estimates the response of TLP under extreme events defined using multiple realizations of irregular sea states; the results suggest that the tendon loads are sensitive to the sea-state realization, providing maximum tendon peak forces in a range of ±10% about the mean. Furthermore, it is shown that the load pattern that forms from considering the relative position of the tendons to the incident wave direction leads to higher forces (≈20%). Full article

A new type of tension leg platform (TLP) connected to a series of buoys (Serbuoys-TLP) has been proven to effectively suppress the surge response of the platform during wave conditions. However, in the complex marine environment, it is more relevant to study its motion response to the action of waves and currents. Considering the tension tendon as a lumped mass model, a DUTMST 2.0 time-domain simulation program was written, based on MATLAB, which can accurately calculate the surge response of the Serbuoys-TLP under wave–current coupling conditions. The suppression efficiency of the Serbuoys-TLP on the surge response was analyzed under different current velocities and wave parameters, and the results showed that the suppression efficiency by the Serbuoys-TLP of surges was higher under the action of waves and currents compared with the action of waves. In addition, the surge response of the platform under the two conditions of wave–current combination and wave–current coupling was also investigated, where wave–current coupling considers the effect of the current’s velocity on the wave period, while the wave–current combination does not consider it, which means that the wave and current are linearly superimposed. The results show that the surge response of the platform will be overestimated without considering the coupling effect of waves and currents. The effect of wave–current coupling has a greater impact on the surge response of the Serbuoys-TLP than that of conventional TLP. Therefore, in the design of new floating structures, the motion performance in response to the effect of wave–current coupling should be paid full attention. Full article
