Cellulose nanocrystals (CNCs) are a green resource which can produce photonic crystal films with structural colors in evaporation-induced self-assembly; CNC photonic crystal films present unique structural colors that cannot be matched by other colored materials. Recently, the mechanisms of CNC photonic crystal films with a unique liquid crystal structure were investigated to obtain homogenous, stable, and even flexible films at a large scale. To clarify the mechanism of colorful CNC photonic crystal films, we briefly summarize the recent advances from the correlations among the preparation methods, microstructures, and color properties. We first discuss the preparation process of CNCs, aiming to realize the green application of resources. Then, the behavior of CNCs in the formation of liquid crystal phases is studied, considering the influence of the CNCs’ size and shape, surface properties, and the types and concentrations of solvents. Finally, the film formation process of CNCs and the control of structural colors during the film formation are summarized, as well as the mechanisms of CNC photonic crystal films with full color. In summary, considering the above factors, obtaining reliable commercial CNC photonic crystal films requires a comprehensive consideration of the subsequent preparation processes starting from the preparation of CNCs. Full article

This study focused on utilizing cellulose nanocrystal (CNC)–polyvinyl alcohol (PVA) composite in optical sensor applications to detect high humidity conditions and determine water concentration in ethanol. We focused on the composite’s effectiveness in moisture absorption to demonstrate visual color change. We demonstrated that the different molecular weights of PVA significantly affect CNC’s chiral nematic structure and moisture absorption capability. PVA with molecular weight 88 k–97 k exhibited the disintegration of its chiral nematic structure at 30 wt%, whereas low molecular weight PVA (n~1750) showed no structural disintegration even at 100 wt% concentration when analyzed through UV-Vis spectroscopy. Further, the thermal crosslinking of the CNC-PVA composite showed no significant loss of moisture sensitivity for all molecular weights of the PVA. We observed that the addition of PVA to the sulfated CNC obtained from sulfuric acid hydrolysis did not facilitate moisture absorption significantly. A CNC-PVA sensor was developed which can detect high humidity with 2 h. of exposure time. 2,2,6,6-tetramethylpiperidin-1-piperidinyloxy oxidized CNC (TEMPO-CNC) having carboxylic functionality was also used to prepare the CNC-PVA composite films for comparing the effect of functional groups on moisture sensitivity. Finally, we demonstrated a facile method for utilizing the composite as an optical sensor to detect water concentration in ethanol efficiently; thus, it can be used in polar organic solvent dehydration applications. Full article

The investigation of functional materials derived from sustainable and eco-friendly bioresources has generated significant attention. Herein, nanocomposite films based on chiral nematic cellulose crystals (CNCs) were developed by incorporating xylose and biocompatible ZnO nanoparticles (NPs) via evaporation-induced self-assembly (EISA). The nanocomposite films exhibited iridescent color changes that corresponded to the birefringence phenomenon under polarized light, which was attributed to the formation of cholesteric structures. ZnO nanoparticles were proved to successfully adjust the helical pitches of the chiral arrangements of the CNCs, resulting in tunable optical light with shifted wavelength bands. Furthermore, the nanocomposite films showed fast humidity and ethanol stimuli response properties, exhibiting the potential of stimuli sensors of the CNC-based sustainable materials. Full article

Chiral nematic materials have been attracting attention in fields of advanced functional applications due to their unique iridescent colors and tunable helical structure. A precisely decreased pitch is of importance for construction and applications of chiral nematic materials; however, it remains a huge challenge. Herein, cellulose nanocrystal (CNC) is selected as a constructed matrix for chiral nematic films, and ferric chloride (FeCl₃) is used as a modification agent. We investigate the effects of the ferric ion loads on the helical structure and optical characteristics of iridescent film. Subsequently, the influence of ferric ions on the assembly process of CNC liquid crystal and the regulation of the structure color of self-assembled monolayers are discussed. Therefore, the CNC/FeCl₃ chiral nematic films showed a blueshifted structural color from orange to blue, which highlights a simple route to achieve the regulation of decreased pitch. Further, we have applied this CNC/FeCl₃ chiral nematic film for benzene gas detection. The sensing performance shows that the CNC/FeCl₃ chiral nematic film reacts to benzene gas, which can be merged into the nematic layer of the CNC and trigger the iron ions chelated on the CNC, consequently arousing the redshift of the reflected wavelength and the effective colorimetric transition. This CNC/FeCl₃ chiral nematic film is anticipated to boost a new gas sensing mechanism for faster and more effective in-situ qualitative investigations. Full article

Structural coloration has become a fascinating field of research, inspiring scientists and engineers to explore the vibrant colors observed in nature and develop bio-inspired photonic structures for various applications. Cellulose-based materials derived from plant fibers offer a promising platform for mimicking natural photonic structures. Their abundance, renewability, and versatility in form and structure make them ideal for engineering specific optical properties. Self-assembly techniques enable the creation of ordered, periodic structures at the nanoscale by manipulating the interactions between cellulose fibers through chemical modification or physical manipulation. Alternatively, additive manufacturing techniques like 3D printing and nanoimprint lithography can directly fabricate desired structures. By em-ulating natural photonic structures, cellulose-based materials hold immense potential for applications such as colorimetric sensors, optoelectronic devices, camouflage, and decorative materials. However, further research is needed to fully com-prehend and control their optical properties, as well as develop cost-effective and scalable manufacturing processes. This article presents a comprehensive review of the fundaments behind natural structural colors exhibited by living organisms and their bio-inspired artificial counterparts. Emphasis is placed on understanding the underlying mechanisms, strategies for tunability, and potential applications of these photonic nanostructures, with special focus on the utilization of cellulose nanocrystals (CNCs) for fabricating photonic materials with visible structural color. The challenges and future prospects of these materials are also discussed, highlighting the potential for advancements to unlock the full potential of cellulose-based materials with structural color. Full article

The charge plays an important role in cellulose nanocrystal (CNC) self-assembly to form liquid crystal structures, which has rarely been systematically explored. In this work, a novel technique combining atomic force microscopy force and atomistic molecular dynamics simulations was addressed for the first time to systematically investigate the differences in the CNC self-assembly caused by external positive and negative charges at the microscopic level, wherein sodium polyacrylate (PAAS) and chitosan oligosaccharides (COS) were used as external positive and negative charge additives, respectively. The results show that although the two additives both make the color of CNC films shift blue and eventually disappear, their regulatory mechanisms are, respectively, related to the extrusion of CNC particles by PAAS and the reduction in CNC surface charge by COS. The two effects both decreased the spacing between CNC particles and further increased the cross angle of CNC stacking arrangement, which finally led to the color variations. Moreover, the disappearance of color was proved to be due to the kinetic arrest of CNC suspensions before forming chiral nematic structure with the addition of PAAS and COS. This work provides an updated theoretical basis for the detailed disclosure of the CNC self-assembly mechanism. Full article

Balancing physicochemical properties and sensory properties is one of the key points in expanding edible packaging applications. The work consisted of two parts, one was to investigate the effects of cellulose nanocrystals (CNC) on the packaging-related properties of whey protein isolate films with natural colorants (curcumin, phycocyanin, and lycopene) under freeze-thaw (FT) conditions; the other was to test oral tactility and visual sensory properties of the edible films and their overall acceptability in packed ice cream. FT treatment reduced the mechanical strength and moisture content and increased the water vapor permeability of the films, as water-phase transformation not only disrupted hydrogen bonds but also the film network structure through physical stress. The oral tactility produced by CNC and the visual effect produced by colorants could affect participants’ preference for edible films. This study provides a good reference for the consumer-driven product development of packaged low-temperature products. Full article

Through self-assembly, environmentally friendly cellulose nanocrystals (CNCs) can form films with a photonic crystal structure whose pitch size can be adjusted in a variety of ways at the fabrication stage. Moreover, the films exhibit response performance to multiple stimuli, which offers extensive applications. Poly(ethylene glycol) (PEG) and CNCs combine to form a smaller chiral nematic domain that develops a solid film with a uniform spiral structure when slowly dried. By changing the composition of CNCs and PEG, flexible and flat photonic composite films with uniform structural colors from blue to red are prepared. Benefiting from the change in pitch size by insertion and detachment of water molecules into the chiral nematic structure, CNCs films and CNC-PEG composite films exhibit a reversible structural color change in response to different humidity. In addition, the chiral nematic films formed by the combination of glycerol and CNCs have a reversible stimulation response to hydrochloric acid gas. Similarly, adjusting the ratio of glycerol can control the pitch size of the films and, thus, the reflective color. In summary, the pitch size of the photonic crystal structure of the films can be precisely tuned by regulating the additive ratio, and the two prepared films have reversible responses to humidity and hydrochloric acid gas, respectively. The CNC-based films show promise in the application of colorimetric biosensors. Full article

The aim of this study was to produce innovative edible films and coatings with various combinations of materials, in order to achieve the best possible resulting properties. More specifically, the effect of cellulose nanocrystals (CNC) or beta-cyclodextrin (CD) addition to chitosan (CH) films and the development of composite CH–CNC–CD films were investigated. According to the results, most properties of both CH–CNC and CH–CD edible films were improved. The viscosity of the solutions was decreased up to 50% while the surface tension was minimally changed even at high levels of CNC or CD addition. Furthermore, oxygen and water vapor permeability of the CH–CNC and the CH–CD edible films was decreased, whereas transparency and heterogeneity were increased. On the other hand, the study of the composite CH–CNC–CD films, showed that CNC improved viscosity, supporting thus the coating procedure. Moreover, CNC led to more stable structures with enhanced mechanical properties. Finally, CD mostly contributed to the improvement of the optical properties (lighter color and increased transparency). Full article

It has been extensively reported that cellulose nanocrystals (CNCs) can represent structural colors due to their unique chiral-nematic self-assembly. However, the application of this remarkable structure does need further investigation. It has been challenging to keep the selective reflection band (SRB) resulting from the CNC structure in the visible spectrum. Herein, composition of CNC colloidal suspensions with polyethylene glycol (PEG) and glycerol (Gly) have been studied to develop humidity-responsive sensors in the form of coatings and films. The fabricated samples were characterized for their mechanical properties, optical properties, water uptake capacity, water contact angle, and surface roughness. Additionally, the chemical structure of the samples was studied with FTIR spectroscopy. The produced humidity indicators on microbial glass slides were maintained and tested in a different relative humidity range from 20% to 98% with a different color response from blue to red, respectively. The color change of the humidity sensors was reversible for several cycles. It should be noted that the color change can be detected easily by the naked eye. The water uptake test showed that pure CNC and CNC/Gly had the lowest (34%) and highest (83%) water absorption levels. The mechanical tests for CNC/PEG composites showed the highest tensile strength (40.22 MPa). Moreover, microstructural characterizations confirmed the CNC pitch formation in all the samples. Addition of the fillers increased the CNC pitch, resulting in a mesoporous film formation. These produced humidity sensors are promising candidates in food and drug packaging due to their biodegradability, biocompatibility, and cost-effectiveness. Full article

Evaporation-induced-self-assembly is widely used to produce chiral cellulose nanocrystal (CNC) free-standing films reflecting left-handed polarized light. Research on supported chiral CNC films is rather scarce. The reflection and/or transmission of unpolarized light are the most common optical techniques used to characterize the selective reflection of CNC films whereas the use of techniques to quantify chiral properties is limited. Here, the fabrication of chiral CNC films supported on glass substrates by a shear-coating method, as well as a full characterization of their polarization properties, are reported. Optical chirality is evidenced in films, showing a brilliant blue structural color when viewed through a left-handed polarizer and darkness through a right-handed polarizer. Mueller-matrix data in the reflection and transmission modes are used to quantitatively characterize the structural origin of color in the films. The quantification of the linear and circular birefringence, as well as circular dichroism, is performed by analytical inversion of the Mueller matrix data in the transmission mode and regression analysis using Tellegen constitutive equations. The equivalence of the two methods to quantify the structural chirality in CNC films is demonstrated. The swelling of films in water and kinetics during drying is studied by reflection spectroscopy. Full article

As an important functional material in food industry, intelligent packaging films can bring great convenience for consumers in the field of food preservation and freshness detection. Herein, we fabricated pH-sensing films employing hydroxypropyl guar (HPG), 1-butyl-3-methylimidazolium chloride (BmimCl), and anthocyanin (Anth). Besides, the effects of adding cellulose nanocrystals (CNC) into the composite films upon the films’ structures and physicochemical properties are elucidated. The addition of CNC promoted more compact film structures. Moreover, CNC dramatically improved several properties of the pH-sensing films, including the distinguishability of their color changes, sensitivity to pH, permeability to oxygen and water vapor, solvent resistance, durability, and low-temperature resistance. These results expand the application range of pH-sensing films containing CNC in the fields of food freshness detection and intelligent packaging. Full article

The lyotropic cholesteric liquid crystal phase developed by suspensions of cellulose nanocrystals (CNCs) has come increasingly into focus from numerous directions over the last few years. In part, this is because CNC suspensions are sustainably produced aqueous suspensions of a fully bio-derived nanomaterial with attractive properties. Equally important is the interesting and useful behavior exhibited by solid CNC films, created by drying a cholesteric-forming suspension. However, the pathway along which these films are realized, starting from a CNC suspension that may have low enough concentration to be fully isotropic, is more complex than often appreciated, leading to reproducibility problems and confusion. Addressing a broad audience of physicists, chemists, materials scientists and engineers, this Review focuses primarily on the physics and physical chemistry of CNC suspensions and the process of drying them. The ambition is to explain rather than to repeat, hence we spend more time than usual on the meanings and relevance of the key colloid and liquid crystal science concepts that must be mastered in order to understand the behavior of CNC suspensions, and we present some interesting analyses, arguments and data for the first time. We go through the development of cholesteric nuclei (tactoids) from the isotropic phase and their potential impact on the final dry films; the spontaneous CNC fractionation that takes place in the phase coexistence window; the kinetic arrest that sets in when the CNC mass fraction reaches ∼10 wt.%, preserving the cholesteric helical order until the film has dried; the ’coffee-ring effect’ active prior to kinetic arrest, often ruining the uniformity in the produced films; and the compression of the helix during the final water evaporation, giving rise to visible structural color in the films. Full article
