This paper reviews the potential of Wire Arc Additive Manufacturing (WAAM) for architecture. It uniquely addresses its feasibility by evaluating existing large-scale, real-world prototypes developed to date and compiling critical gaps identified in the literature. Although previous review papers concerning WAAM for architecture exist, they focus on the technical aspects of the technology, such as the mechanical properties, defects, and process parameters. No existing review analyzes which architectural applications are being implemented nor the scale and degree prototyping accomplished for each application. WAAM, a form of metal additive manufacturing using an electric arc to melt and deposit wire, offers unique advantages for the construction industry. It allows for high deposition rates, structural integrity, and cost-efficiency using steel. However, challenges such as producing large-scale components and limited design freedom and lower resolution compared to other additive manufacturing processes remain. This review first contextualizes WAAM within the broader landscape of additive manufacturing technologies for construction and examines its proposed architectural applications, such as steel connections, columns, trusses, and bridge elements. This study emphasizes the need for real-world experimentation through large-scale prototypes to assess the practicality and scalability of WAAM in architecture. The results of this study reveal that 36 architectural projects using WAAM exist in the literature, whose application range from structural (such as beams, columns, and nodes) to nonstructural components (such as facades and ornamental elements). Based on these, a classification for WAAM in architecture is proposed: (1) stand-alone WAAM structures, (2) printed connector pieces to join standard steel parts, and (3) reinforcement for conventional steel elements using WAAM. The size of typical functional prototypes to date averages 200 × 200 × 200 mm, with exceptional cases such as the diagrid column of 2000 mm height and the MX3D Bridge, which spans over 12 m. A detailed analysis of seven projects documents the scale and development of the prototypes, functional lab configuration, and process parameters. Through this review, the current technical feasibility of WAAM in architecture is established. Full article

Steel truss–arch composite bridge systems are widely used in bridge engineering to provide sufficient space for double lanes. However, a lack of research exists on their mechanical performance throughout their lifespan, resulting in uncertainties regarding bearing capacity and the risk of bridge failure. This paper conducts a numerical study of the structural mechanical performance of a flexible arch composite bridge with steel truss beams throughout its lifespan to determine the critical components and their mechanical behavior. Critical vehicle loads are used to assess the bridge’s mechanical performance. The results show that the mechanical performance of the bridge changes significantly when the temporary piers and the bridge deck pavement are removed, substantially influencing the effects of the vehicle loads on the service life. The compressive axial force of the diagonal bar significantly increases to 33,101 kN near the supports during the two construction stages, and the axial force in the upper chord of the midspan increases by 4.1 times under a critical load. Moreover, the suspender tensions and maximum vertical displacement are probably larger than the limit of this bridge system in the service stage, and this is caused by the insufficient longitudinal bending stiffness of truss beams. Therefore, monitoring and inspection of critical members are necessary during the removal of temporary piers and bridge deck paving, and an appropriate design in steel truss beams is required to improve the life cycle assessment of this bridge system. Full article

To enhance the safety management of steel-truss-bridge construction, an evaluation method based on the improved DEMATEL–ISM was proposed to analyze the risk factors involved in such construction. Decision Making Trial and Evaluation Laboratory (DEMATEL) is a method for systematic factor analysis that utilizes graph-theory and -matrix tools, allowing for the assessment of the existence and strength of relationships between elements by analyzing the logical and direct impact relationships among various elements in a system. The distinctive feature of Interpretative Structural Modeling (ISM) is the decomposing of complex systems into several subsystems (elements) and constructing the system into a multi-level hierarchical structural model through algebraic operations. Specifically, triangular fuzzy numbers are introduced initially to improve the direct influence matrix in the DEMATEL method, thereby reducing the subjectivity of expert evaluations. The degree of influence, influenced degree, centrality degree, and causality degree of each influencing factor are determined and ranked based on the above analysis. In response to the characteristics of top-push construction, 20 key factors were selected from four aspects: “human, material, environment, and management”. The top five identified influencing factors are displacement during pushing (X10), safety-management qualification (X18), local buckling (X14), overturning of steel beams (X13), and collision with bridge piers during guide beam installation (X7). Subsequently, corresponding solutions were proposed for different influencing factors. The results of the study offer targeted measures to enhance the safety management of steel truss bridge construction and provide a reference for accident prevention. Full article

The damage identification of railway bridges poses a formidable challenge given the large variability in the environmental and operational conditions that such structures are subjected to along their lifespan. To address this challenge, this paper proposes a novel damage identification approach exploiting continuously extracted time series of autoregressive (AR) coefficients from strain data with moving train loads as highly sensitive damage features. Through a statistical pattern recognition algorithm involving data clustering and quality control charts, the proposed approach offers a set of sensor-level damage indicators with damage detection, quantification, and localization capabilities. The effectiveness of the developed approach is appraised through two case studies, involving a theoretical simply supported beam and a real-world in-operation railway bridge. The latter corresponds to the Mascarat Viaduct, a 20th century historical steel truss railway bridge that remains active in TRAM line 9 in the province of Alicante, Spain. A detailed 3D finite element model (FEM) of the viaduct was defined and experimentally validated. On this basis, an extensive synthetic dataset was constructed accounting for both environmental and operational conditions, as well as a variety of damage scenarios of increasing severity. Overall, the presented results and discussion evidence the superior performance of strain measurements over acceleration, offering great potential for unsupervised damage detection with full damage identification capabilities (detection, quantification, and localization). Full article

For enhancing the efficiency of cantilever casting construction in a bridge, a novel rhombus traveling track for a hanging basket was developed and optimized. The business-oriented software called MIDAS was applied to analyze the mechanical properties of the hanging basket with a full load and a control load. The strength and distortion of the walking mechanism are within the specified range when the maximum beam unit internal force is 149.69 MPa, which is less than the allowable stress of steel of 175 Mpa, and the anti-overturning safety factor of the hanging basket is 2.5, which meets the requirements. Through the comparative analysis of the key components and the finite element calculation, it was found that there is about a 30% redundancy in the structure performance. Therefore, further optimization of each structure was carried out, and the front elevation of the main truss of 20° was achieved. It obtained the best performance in all aspects. Full article

This paper presents a comprehensive study of the Xiangsizhou Bridge, a double-tower double-cable steel–concrete composite girder cable-stayed bridge located in Pingnan, Guangxi, China. A finite element model of the full-bridge spatial truss system was established using a dual main beam simulation of the steel–concrete composite girder. To obtain the initial reasonable bridge state, the minimum bending energy method was employed, followed by optimization of the state using the unknown load coefficient method to attain the final reasonable completion state. This paper proposes an innovative construction scheme for the erection of the main girders, which is designed to address the issue of excessive tensile stresses in the bridge deck slabs that can arise in conventional construction schemes. This scheme can save about 4 months of construction time and shorten the construction cycle of main beam erection by 60%. Furthermore, the study derived and verified a formula for the intermediate cable force during the construction process, which demonstrated its effectiveness. This study provides practical value for the design and construction of similar bridges. Full article
