Repeated mining of shallow-buried close-distance coal seams can disturb the fractured strata remaining in the goaf of the upper coal seam. Under gully terrain, mining disturbance is coupled with surface-relief effects, which may reactivate the overburden structure and induce dynamic strata-pressure behavior. In particular, when the working face advances across gullies, the change in surface slope alters the spatial distribution of roof load, while lower-seam extraction further disturbs the fractured rock mass formed by upper-seam mining, increasing the risk of severe strata-pressure behavior and support-crushing accidents. Taking the cross-ditch mining of the 2
−2 and 3
−1 coal seams in Anshan Coal Mine as the research object, this study integrates field geological investigation, theoretical calculation, physical similarity simulation, and field engineering verification to analyze overburden structural evolution, key-stratum breaking characteristics, and support-load variation under gully terrain. The results show that gully landforms generate obvious nonuniform loading above the working face. During upslope advance, the roof load gradually increases from the goaf side to the solid-coal side, causing tensile stress concentration at the fixed end of the key stratum and accelerating rock-stratum failure. A cantilever rock-beam mechanical model subjected to parabolic nonuniform loading was established, and the maximum breaking interval of the key stratum was calculated as 24.09 m. With increasing gully slope angle, the load gradient intensifies, the rock-beam breaking interval decreases, and the risk of overburden instability increases. Physical similarity simulation indicates that, when the 2
−2 coal seam working face passes through the 45° steep-slope section, the fractured overburden is more likely to form a stepped rock-beam structure, accompanied by slope rotation, stepped surface subsidence, and a sharp increase in support pressure. Under the 30° gentle-slope condition, The lateral confinement effect is stronger, roof movement is more gradual, and support-pressure fluctuation is reduced. During subsequent extraction of the lower 3
−1 coal seam, repeated mining disturbance reactivates the overlying goaf structure, and the upper stepped rock beam and lower hinged rock beam couple to form a double composite structure. When the fracture lines of the upper and lower key strata are staggered, the instability load of the upper structure is mainly buffered by caved gangue and interburden strata. The calculated support resistance in the asynchronous breaking stage is 8248.04 kN, which agrees well with the field-measured value of 8273 kN. When the fracture lines tend to coincide and synchronous breaking occurs, the unstable load of the upper key block is transferred downward and superimposed on the structural load of the lower key block, increasing the required support resistance to 15,165.55 kN, far exceeding the rated working resistance of the ZY9200/15/29 hydraulic support. Sensitivity analysis indicates that gully slope angle is the dominant factor affecting support resistance. As the slope angle increases from 30° to 60°, the support resistance increases from 13,228.65 kN to 18,278.43 kN, and the normalized support-resistance index increases from 0.872 to 1.205. Therefore, synchronous breaking of double key strata is the main mechanical cause of sudden support-load increase and support-crushing risk during cross-ditch mining of shallow-buried close-distance coal seams. The results can provide a basis for hydraulic support selection, roof weakening, weighting-interval control, and dynamic strata-pressure prevention under similar conditions.
