Search Results (8)

Search Parameters:
Keywords = solder pin

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
11 pages, 4311 KiB
Article
Electrically Tunable Metasurface for Multi-Polarized Reflection
by Bing Li, Yunhan Wang, Chunan Wang and Shiqi Liu
Remote Sens. 2025, 17(4), 700; https://doi.org/10.3390/rs17040700 - 18 Feb 2025
Viewed by 702
Abstract
Most electromagnetic metasurfaces only control a single property of electromagnetic waves, such as the phase, amplitude, polarization or frequency, leading to a shortage in capacity and security in communication and a decrease in radar imaging efficiency. By switching the states of four PIN [...] Read more.
Most electromagnetic metasurfaces only control a single property of electromagnetic waves, such as the phase, amplitude, polarization or frequency, leading to a shortage in capacity and security in communication and a decrease in radar imaging efficiency. By switching the states of four PIN diodes soldered between adjacent resonant arms, cross-polarization and co-polarization reflected waves both with a 1-bit phase can be implemented. The simulation results demonstrate that the proposed metasurface operates within a frequency band of 5.7 GHz to 5.88 GHz, covering ISM 5.8 GHz. Within its operational frequency range, in the cross-polarization reflection case, the losses of the 1-bit phase reflected wave are from 1 dB to 1.5 dB, with a high polarization conversion rate exceeding 91% and even reaching 99%. For the co-polarization reflection case, the losses of the 1-bit reflected wave are from 0.3 dB to 2 dB, and the polarization conversion is almost 100%. The phase difference of the reflected wave in both cases can be realized as about 180°, which satisfies the 1-bit phase requirement for building a good property of beam steering. Upon constructing a 10 × 10 small array, the cross-polarized reflection beam can be steered within the range of elevation angle from 0° to 45° and the elevation angle from 0° to 30° in the co-polarized reflection case. Full article
Show Figures

Graphical abstract

29 pages, 4580 KiB
Article
Determination of the Contact Resistance of Planar Contacts: Electrically Conductive Adhesives in Battery Cell Connections
by Philipp Jocher, Michael K. Kick, Manuel Rubio Gomez, Adrian V. Himmelreich, Alena Gruendl, Edgar Hoover, Michael F. Zaeh and Andreas Jossen
Batteries 2023, 9(9), 443; https://doi.org/10.3390/batteries9090443 - 29 Aug 2023
Cited by 3 | Viewed by 5543
Abstract
This study presents a method to analyze the electrical resistance of planar contacts. The method can determine whether the contact resistance of the joint exhibits linear or non-linear behavior. By analyzing the current distribution over a planar contact, it can be determined whether [...] Read more.
This study presents a method to analyze the electrical resistance of planar contacts. The method can determine whether the contact resistance of the joint exhibits linear or non-linear behavior. By analyzing the current distribution over a planar contact, it can be determined whether an area-based contact resistance is justified or if other parameters define the contact resistance. Additionally, a quantitative evaluation of the factors that affect the measurement accuracy, including the positioning, the measurement equipment used, and the influence of the current injection on the sense pin was conducted. Based on these findings, the electrical contact resistance and the mechanical ultimate tensile force of a silver-filled epoxy-based adhesive are analyzed and discussed. The layer thickness and the lap joint length were varied. Overall, the investigated adhesive shows a low contact resistance and high mechanical strength of the same magnitude as that of well-established joining techniques, such as welding, press connections, and soldering. In addition to evaluating the mechanical and electrical properties, the electric conductive adhesive underwent an economic assessment. This analysis revealed that the material costs of the adhesive significantly contribute to the overall connection costs. Consequently, the effective costs in mass production are higher than those associated with laser beam welding. Full article
(This article belongs to the Section Battery Modelling, Simulation, Management and Application)
Show Figures

Figure 1

20 pages, 33103 KiB
Article
The Reliability of the Complex Components under Temperature Cycling, Random Vibration, and Combined Loading for Airborne Applications
by Hao Cui, Wenchao Tian, Hanyang Xu, Heng Wang, Jiabo Huang, Chunxi Peng and Zhiqiang Chen
Crystals 2023, 13(3), 473; https://doi.org/10.3390/cryst13030473 - 9 Mar 2023
Cited by 11 | Viewed by 3020
Abstract
The electronic devices suffer great vibration and temperature fluctuation in an airborne environment, which has been always a big challenge for reliability design. In this paper, the reliability of the complex electronic components for airborne applications under a thermal cycling test, random vibration [...] Read more.
The electronic devices suffer great vibration and temperature fluctuation in an airborne environment, which has been always a big challenge for reliability design. In this paper, the reliability of the complex electronic components for airborne applications under a thermal cycling test, random vibration and combined loading has been investigated by experiment tests and finite element simulation. The fatigue life and failure location under different loadings have been compared and discussed, respectively. The results indicated that the combined fatigue life was much shorter than a single-factor experiment. The failed solder joints mostly appeared at the interface between the solder and the copper pad on the component side and the location was at the corner for all three harsh environment tests. Nevertheless, several differences could be observed. For temperature cycling, all the specimens failed due to the increase in daisy chain resistance rather than the open circuit for the combined loading test. That is because the degeneration of the solder caused by temperature variation led to lower stress levels and fatigue life. Moreover, the pins fractured at the welding regions have been observed. The modified Coffin—Manson model, Miner’s linear fatigue damage criterion and Steinberg’s model and rapid life-prediction approach were used to predict the fatigue life under temperature cycling, random vibration and combined loading, respectively. With these methods, the accurate numerical models could be developed and validated by experiment results. Thanks to the simulation, the design time could be effectively shortened and the weak point could be determined. Full article
Show Figures

Figure 1

13 pages, 10556 KiB
Article
Applicability Evaluation of Nano-Al2O3 Modified Sn-Ag-Cu Solder in High-Density Electronic Packaging Subjected to Thermal Cycling
by Jie Wu, Guoqiang Huang, Yiping Wu, Xiwu Huang, Rui Yu, Xuqi Yang, Guangyao Chen, Cheelong Tan, Zhihao Yu, Huabin Sun and Yong Xu
Crystals 2022, 12(12), 1736; https://doi.org/10.3390/cryst12121736 - 1 Dec 2022
Cited by 3 | Viewed by 1947
Abstract
Recently, 3D packaging has been regarded as an important technical means to continue Moore’s Law. However, excessive stacking will increase the longitudinal dimension, and one chip with high-density bondings packaging is still needed. Thus, it naturally places higher demand on thermal cycling reliability [...] Read more.
Recently, 3D packaging has been regarded as an important technical means to continue Moore’s Law. However, excessive stacking will increase the longitudinal dimension, and one chip with high-density bondings packaging is still needed. Thus, it naturally places higher demand on thermal cycling reliability due to the decreased joint size to satisfy high-density packaging. In this work, the nano-Al2O3 (1 wt.%) modified Sn-1 wt.% Ag-0.5 wt.% Cu low-Ag solder was applied as a solder sample to evaluate the associated thermal cycling reliability. The investigated results revealed that the nano-Al2O3 modified solder did present enhanced thermal cycling reliability, as evidenced by the delayed microstructure coarsening and the inhibited atom inter-diffusion at interface caused by the adsorption of nano-Al2O3 on grain surfaces, and the resultant pinning effect. Worthy of note is that the potential of the newly developed nano-Al2O3 modified solder for high-density packaging applications (e.g., BGA, QFN, and CCGA) was evaluated based on the Finite Element Modeling. Full article
(This article belongs to the Special Issue Advances in Metal Matrix Composites)
Show Figures

Figure 1

11 pages, 2724 KiB
Article
Measuring the Positions of the Solder Pins of Electrical Connectors from the Side
by Wei-chen Lee and Kuan-Chuan Huang
Appl. Sci. 2022, 12(17), 8772; https://doi.org/10.3390/app12178772 - 31 Aug 2022
Cited by 2 | Viewed by 2068
Abstract
In the electronics industry, it is common to measure the positions of the solder pins of electrical connectors from the bottom using the automated optical inspection (AOI) technique. However, the pins’ surfaces facing the camera of the AOI system may generate image noises, [...] Read more.
In the electronics industry, it is common to measure the positions of the solder pins of electrical connectors from the bottom using the automated optical inspection (AOI) technique. However, the pins’ surfaces facing the camera of the AOI system may generate image noises, leading to inaccurate measurement results. The objective of the paper is to develop a machine vision system with an algorithm to measure the pin position from the side. Two images must be captured in different view directions so that the algorithm can use the information on the images to calculate the positions of the pins. Comparing the results obtained using the proposed method and those obtained using a 2D vision measuring machine to measure the positions from the bottom, we found that the maximum difference in the results was 0.03 mm. The technique presented in the paper can provide an alternative solution for measuring the positions of the solder pins of electrical connectors or similar components if measurement from the bottom is not feasible. Full article
(This article belongs to the Section Robotics and Automation)
Show Figures

Figure 1

12 pages, 5455 KiB
Article
Eco-Friendly Lead-Free Solder Paste Printing via Laser-Induced Forward Transfer for the Assembly of Ultra-Fine Pitch Electronic Components
by Marina Makrygianni, Filimon Zacharatos, Kostas Andritsos, Ioannis Theodorakos, Dimitris Reppas, Nikolaos Oikonomidis, Christos Spandonidis and Ioanna Zergioti
Materials 2021, 14(12), 3353; https://doi.org/10.3390/ma14123353 - 17 Jun 2021
Cited by 9 | Viewed by 3485
Abstract
Current challenges in printed circuit board (PCB) assembly require high-resolution deposition of ultra-fine pitch components (<0.3 mm and <60 μm respectively), high throughput and compatibility with flexible substrates, which are poorly met by the conventional deposition techniques (e.g., stencil printing). Laser-Induced Forward Transfer [...] Read more.
Current challenges in printed circuit board (PCB) assembly require high-resolution deposition of ultra-fine pitch components (<0.3 mm and <60 μm respectively), high throughput and compatibility with flexible substrates, which are poorly met by the conventional deposition techniques (e.g., stencil printing). Laser-Induced Forward Transfer (LIFT) constitutes an excellent alternative for assembly of electronic components: it is fully compatible with lead-free soldering materials and offers high-resolution printing of solder paste bumps (<60 μm) and throughput (up to 10,000 pads/s). In this work, the laser-process conditions which allow control over the transfer of solder paste bumps and arrays, with form factors in line with the features of fine pitch PCBs, are investigated. The study of solder paste as a function of donor/receiver gap confirmed that controllable printing of bumps containing many microparticles is feasible for a gap < 100 μm from a donor layer thickness set at 100 and 150 μm. The transfer of solder bumps with resolution < 100 μm and solder micropatterns on different substrates, including PCB and silver pads, have been achieved. Finally, the successful operation of a LED interconnected to a pin connector bonded to a laser-printed solder micro-pattern was demonstrated. Full article
(This article belongs to the Special Issue Materials Light Life)
Show Figures

Figure 1

11 pages, 3897 KiB
Article
Transient Numerical Modelling of the Pin-in-Paste Technology
by Tareq Ibrahim Al-Ma'aiteh, Oliver Krammer and Balázs Illés
Appl. Sci. 2021, 11(10), 4670; https://doi.org/10.3390/app11104670 - 19 May 2021
Cited by 5 | Viewed by 5959
Abstract
The pin-in-paste technology is an advancing soldering technology for assembling complex electronic products, which include both surface-mounted and through-hole components. A computational fluid dynamics model was established to investigate the stencil printing step of this technology, where the hole-filling by the solder pastes [...] Read more.
The pin-in-paste technology is an advancing soldering technology for assembling complex electronic products, which include both surface-mounted and through-hole components. A computational fluid dynamics model was established to investigate the stencil printing step of this technology, where the hole-filling by the solder pastes is the most critical factor for acquiring reliable solder joints. The geometry of the transient numeric model included the printing squeegee, the stencil, and the through-holes of a printed circuit board with different geometries and arrangements. A two-phase fluid model (solder paste + air) was applied, utilizing the Volume of Fluid method (VoF). The rheological properties of the solder paste were addressed by an exhaustive viscosity model. It was found that the set of through-holes affected the flow-field and yielded a decrease in the hole-filling if they were arranged in parallel with the travelling direction of the printing squeegee. Similar disturbance on the flow-field was found for oblong-shaped through-holes if they were arranged in parallel with the squeegee movement. The findings imply that the arrangement of a set of through-holes and the orientation of oblong-shaped through-holes should be optimized even in the early design phase of electronic products and during the set of assembly processes. The soldering failures in pin-in-paste technology can be reduced by these early design-phase considerations, and the first-pass yield of electronic soldering technologies can be enhanced. Full article
(This article belongs to the Section Electrical, Electronics and Communications Engineering)
Show Figures

Figure 1

17 pages, 5007 KiB
Article
Development of Heat Transfer Surface Area Enhancements: A Test Facility for New Heat Exchanger Designs
by Hannes Fugmann, Paolo Di Lauro, Aniket Sawant and Lena Schnabel
Energies 2018, 11(5), 1322; https://doi.org/10.3390/en11051322 - 22 May 2018
Cited by 14 | Viewed by 7451
Abstract
Enhancing the heat transfer surface by usage of cellular metal structures, such as foams or wire structures, might allow enlarging the surface area, increasing the heat transfer coefficients, decreasing the material utilization, and enabling the flexibility of different geometrical dimensions. However their manufacturing [...] Read more.
Enhancing the heat transfer surface by usage of cellular metal structures, such as foams or wire structures, might allow enlarging the surface area, increasing the heat transfer coefficients, decreasing the material utilization, and enabling the flexibility of different geometrical dimensions. However their manufacturing and assembling in a large heat exchanger for performance testing and optimizing can be costly. Therefore a test rig was constructed for experimental characterization of heat transfer surface area enhancements. Heat exchanger samples with dimensions in the centimeter range can be measured. The fluid flow and heat transfer features of a micro pin fin wire structure made from copper by soft-soldering were experimentally characterized under steady-state forced air convection. The results are compared to performance characteristics of louvered fins. Heat transfer coefficients of the pin fins are twice as high as for the louvered fins. The relative expanded uncertainty of the Nusselt number is ±7%. Full article
(This article belongs to the Section I: Energy Fundamentals and Conversion)
Show Figures

Figure 1
