Despite the pivotal role of filtering and smoothing techniques in the preprocessing of ship maneuvering data for robust identification, persistent challenges in reconciling noise suppression with dynamic fidelity preservation have limited algorithmic advancements in recent decades. We propose an online smoothing method enhanced by the Expectation-Maximization (EM) algorithm framework that effectively extracts high-fidelity dynamic features from raw maneuvering data, thereby enhancing the fidelity of subsequent ship identification systems. Our method effectively addresses the challenges posed by heavy-tailed Student-t distributed noise and parameter uncertainty inherent in ship motion data, demonstrating robust parameter learning capabilities, even when initial ship motion system parameters deviate from real conditions. Through iterative data assimilation, the algorithm adaptively calibrates noise distribution parameters while preserving motion smoothness, achieving superior accuracy in velocity and heading estimation compared to conventional Rauch–Tung–Striebel (RTS) smoothers. By integrating parameter adaptation within the smoothing framework, the proposed method reduces motion prediction errors by 23.6% in irregular sea states, as validated using real ship motion data from autonomous navigation tests. Full article

Currently, the RANS (Reynolds-Averaged Navier–Stokes) method is widely recognized as a prevalent approach for computing ship maneuvering forces and moments. Obtaining hydrodynamic derivatives using pure RANS is time-consuming, especially with rotating propellers. A reasonable simplification of the propeller is usually necessary to improve simulation efficiency. The ITTC suggests both the discretized propeller model (DPM) and the body-force model (BFM) for RANS simulations. While BFM offers computational efficiency, it may not accurately represent large-amplitude ship maneuvers. It is quite significant to figure out how BFM affects numerical accuracy. This study compares the DPM and a very simple BFM in RANS simulations of the KCS (KRISO Container Ship), focusing on static rudder, drift, and circle motion tests. The main purpose is to check the differences between the simulated results by using the BFM and DPM. While side forces and yaw moments from both models are similar, discrepancies in longitudinal forces increase with higher rudder angles, drift angles, or turning rates. Errors in side forces and yaw moments are under 10% for both models, compared with experimental data. But BFM’s longitudinal force errors exceed 20% at large motion amplitudes, indicating reduced accuracy compared to DPM. The results of the BFM method are subject to two main sources of error. First, the lack of physical shape representation for the propeller blades leads to the absence of lather force during rotation. This in turn results in an inaccurate prediction of the interaction between the propeller blade root or blade tip leakage vortices and the rudder. Second, the limitations of the adopted model prevent it from accurately providing the thrust and torque generated by the propeller under actual operating conditions. Full article

In complex marine environments, accurate prediction of maneuvering motion is crucial for the precise control of intelligent ships. This study aims to enhance the predictive capabilities of maneuvering motion for intelligent ships in such environments. We propose a novel maneuvering motion prediction method based on Long Short-Term Memory (LSTM) and Multi-Head Attention Mechanisms (MHAM). To construct a foundational dataset, we integrate Computational Fluid Dynamics (CFD) numerical simulation technology to develop a mathematical model of actual ship maneuvering motions influenced by wind, waves, and currents. We simulate typical operating conditions to acquire relevant data. To emulate real marine environmental noise and data loss phenomena, we introduce Ornstein–Uhlenbeck (OU) noise and random occlusion noise into the data and apply the MaxAbsScaler method for dataset normalization. Subsequently, we develop a black-box model for intelligent ship maneuvering motion prediction based on LSTM networks and Multi-Head Attention Mechanisms. We conduct a comprehensive analysis and discussion of the model structure and hyperparameters, iteratively optimize the model, and compare the optimized model with standalone LSTM and MHAM approaches. Finally, we perform generalization testing on the optimized motion prediction model using test sets for zigzag and turning conditions. The results demonstrate that our proposed model significantly improves the accuracy of ship maneuvering predictions compared to standalone LSTM and MHAM algorithms and exhibits superior generalization performance. Full article

Maneuvering motion prediction is central to the control and operation of ships, and the application of machine learning algorithms in this field is increasingly prevalent. However, challenges such as extensive training time, complex parameter tuning processes, and heavy reliance on mathematical models pose substantial obstacles to their application. To address these challenges, this paper proposes an LSTM-based modeling algorithm. First, a maneuvering motion model based on a real USV model was constructed, and typical operating conditions were simulated to obtain data. The Ornstein–Uhlenbeck process and the Hidden Markov Model were applied to the simulation data to generate noise and random data loss, respectively, thereby constructing a sample set that reflects real experiment characteristics. The sample data were then pre-processed for training, employing the MaxAbsScaler strategy for data normalization, Kalman filtering and RRF for data smoothing and noise reduction, and Lagrange interpolation for data resampling to enhance the robustness of the training data. Subsequently, based on the USV maneuvering motion model, an LSTM-based black-box motion prediction model was established. An in-depth comparative analysis and discussion of the model’s network structure and parameters were conducted, followed by the training of the ship maneuvering motion model using the optimized LSTM model. Generalization tests were then performed on a generalization set under Zigzag and turning conditions to validate the accuracy and generalization performance of the prediction model. Full article

The autonomous operation of a device or a system is one of the many vital tasks that need to be achieved in many areas of industry. This is also true for maritime transport. This paper introduces an approach developed in order to achieve the autonomous operation of a ship in a port. A safe trajectory was calculated with the use of the Ant Colony Optimization (ACO) algorithm. The ship motion control was based on two controllers: the master overriding trajectory controller (OTC) and the slave low speed controller based on the Linear Matrix Inequalities (LMI) method. The control object was the model of a Very Large Crude Carrier Blue Lady. The results of our simulation tests, which show the safe trajectories calculated by the ACO algorithm and executed by the ship using the designed controllers (OTC and LMI), are presented in this paper. The results present maneuvers executed by the Blue Lady ship when at port. The area where the tests were conducted is located in the Ship Handling, Research and Training Center of the Foundation for Shipping Safety and Environmental Protection on the Lake Silm in Kamionka, Poland. Full article

With the continuous increase in ship size combined with the generally slower increase in the sizes of waterways, the need for the prediction of ship maneuvering in shallow waterways continues to attract attention from the international scientific community. Ship behavior in shallow water is relevant in seabed effects that result in changing the hydrodynamic forces acting on a ship. In this study, the maneuvering characteristics of a container ship with four degrees of freedom in shallow water are analyzed. The Reynolds-Averaged Navier Stokes approach in Ansys Fluent code is used to produce the maneuvering coefficients through the simulations of forward running, static drift, static heel, circular motion, the combined motions, and the pure roll motion of the KRISO container ship. The maneuvering characteristics of the ship are estimated for evaluating the ship behaviors in shallow-water conditions. The obtained results show that the roll has a significant decrease and the ship’s turning diameter has a significant increase when the ship operates in a shallow waterway. The predicted maneuvering characteristics of the ship are in good agreement with those of free-running model tests, indicating that the numerical simulation based on the Computational Fluid Dynamics method has good capability to predict the maneuvering derivatives and the four-DOF ship maneuvering motion in shallow water as well. Full article

To predict the maneuverability of a dual full rotary propulsion ship quickly and accurately, the integrated computational fluid dynamics (CFD) and mathematical model approach is performed to simulate the ship turning and zigzag tests, which are then compared and validated against a full-scale trial carried out under actual sea conditions. Initially, the RANS equations are solved, employing the Volume of Fluid (VOF) method to capture the free water surface, while a numerical simulation of the captive model test is conducted using the rigid body motion module. Secondly, hydrodynamic derivatives for the MMG model are obtained from the CFD simulations and empirical formula. Lastly, a four-degree-of-freedom mathematical model group (MMG) maneuvering model is proposed for the dual full rotary propulsion ship, incorporating full-scale simulations of turning and zigzag tests followed by a full-scale trial for comparative validation. The results indicate that the proposed method has a high accuracy in predicting the maneuverability of dual full-rotary propulsion ships, with an average error of less than 10% from the full-scale trial data (and within 5% for the tactical diameters in particular) in spite of the influence of environmental factors such as wind and waves. It provides experience in predicting the maneuverability of a full-scale ship during the ship design stage. Full article

A methodology of mathematical testing is proposed for a ship with twin azimuth thrusters based on numerical calculations. An unmanned surface vessel (USV) powered by two azimuth thrusters is considered, which is a model-scale configuration. The Ship Maneuvering Mathematical Model Group (MMG) model is introduced to describe forces on the hull and propellers. A set of captive tests (planar motion mechanism (PMM) and open-water tests) were simulated using STAR-CCM+ (16.06.008-R8) software to obtain hull hydrodynamic derivatives and azimuth thruster hydrodynamic coefficients. A maneuvering test of the model-scale ship with two azimuth thrusters is built based on numerical results, and numerical results are compared with the model-scale experimental data to validate the feasibility of numerical methods. The findings show that the usability of the developed mathematical test in predicting the maneuvering ability of ships with two azimuth thrusters is confirmed through numerical calculations. Full article

During escort and convoy operations, icebreakers are often required to maneuver to open up channels or adjust routes due to the prevalence of ice floe conditions in Arctic routes. This study aimed to investigate the global ice load characteristics of the maneuvering captive motions, including constant turning motion, pure yaw motion, and pure sway motion, of the icebreaker Xue Long, using a combination of the discrete element method (DEM) and drag model. First, the method was verified using simulating Araon model tests from the Korea Institute of Ocean Science and Technology (KIOST). In addition, the maneuvering captive motions of the Xue Long model were simulated at varying turning radii, drift angles, and sway and yaw periods, which are typical but currently poorly studied maneuvering motions. Overall, the results of the study showed that the method is able to reproduce the coupling effect of the ship–ice–water system by considering ship–ice interaction and ice resistance, where the mean deviation and maximum deviation of ice resistance are 9.45% and 13.3%, respectively. The influences of the turning radius, drift angle, and sway and yaw period on the ice resistance and transverse force characteristics were studied and analyzed via ship–ice interactions. The present study provides a prediction tool for the assessment of ship maneuvering performance to assist the hull line development and model testing of icebreakers. Full article

A mathematical model for predicting the maneuvering motion of a ship is constructed, using a planing craft with dual waterjet propulsion as the object of study. This model is based on the standard approach of the MMG (Maneuvering Modeling Group) and uses the Runge–Kutta algorithm to solve the differential equations. For the simulation of the turning and Z-shape maneuvering motion, the RANS equation is first solved using the program STAR-CCM + and then the PMM motion of the hull is simulated using the overlapping grid approach to derive the hydrodynamic derivative. The established method for predicting the ship’s maneuverability is feasible, as shown by the calculated results, which agree well with those obtained using data from the sea trials. This method was used to simulate the rudder rotation and Z-shape motion of the planing craft at medium and high speeds to predict the maneuverability index. Full article

Among the 6 degrees of freedom (6-DoF), excessive roll motion is the most dangerous cause of ships capsizing. However, when analyzing the maneuverability of surface ships, the roll components have usually been ignored. It is widely known that the influence of roll moment becomes significant for surface ships with low GM (metacentric height) and high speed. This paper examines the pure roll test for several surface ships to assess the roll-related hydrodynamic derivatives of added mass and damping in maneuvering. The objective ships are the KRISO Container Ship (KCS), David Taylor Model Basin (DTMB), Office of Naval Research Tumblehome (ONRT), and Delft 372 catamaran, where the DTMB and ONRT ships are equipped with complementary bilge keels as damping devices and have a small GM, which the Delft 372 catamaran does not have. The flow during pure roll is analyzed by the Computational Fluid Dynamics (CFD) simulation method that allows the complex flow around ships to be captured, especially when the bilge keel and skeg are considered. The results indicate that the roll moment is greatest in the catamaran. Since the roll moments of the DTMB and ONRT are larger than that of the KCS, bilge keels and surface shape also contribute to increasing roll damping moment. In addition, a comparison of the damping derivatives due to roll rate with results obtained from another method indicates that CFD simulation is capable of accurately predicting the roll-related derivatives, which is difficult to perform by the experiment method. Full article

Propeller modeling in virtual captive model tests is crucial to the prediction accuracy of ship maneuvering motion. In the present study, the Computational Fluid Dynamics (CFD) method with two propeller modeling methods, Sliding Mesh (SM) and Multiple Reference Frames (MRF), was used to simulate the captive model tests for a KVLCC2 tanker model. The virtual captive model tests, including for resistance, self-propulsion, rudder force, oblique towing, circular motion, oblique towing and steady turning tests with rudder angle, were conducted by solving the Reynolds-averaged Navier–Stokes (RANS) equations. The computed hydrodynamic forces, hydrodynamic derivatives, and hull-propeller-rudder interaction coefficients were validated against the available captive model test data and the CFD results obtained by a Body Force (BF) method in the literature. Then the standard turning circle and zig-zag maneuvers were simulated by using the MMG (Maneuvering Modeling Group) model with the computed hydrodynamic derivatives and hull-propeller-rudder interaction coefficients, and the results were validated against available free-running model test data. The most satisfactory agreement in terms of the ship hydrodynamic forces and maneuvering parameters and the most accurate rudder normal force were obtained by the SM method rather than by the MRF or the BF methods, while the lateral forces and yaw moments obtained by the SM and the MRF methods were all in good agreement with the model test data. Full article

With active research being conducted on maritime autonomous surface ships, it is becoming increasingly necessary to ensure the safety of unmanned surface vehicles (USVs). In this context, a key task is to correct their paths to avoid obstacles. This paper proposes a reactive collision avoidance algorithm to ensure the safety of USVs against obstacles. A global map is represented using a Gaussian mixture model, formulated using the expectation–maximization algorithm. Motion primitives are used to predict collision events and modify the USV’s trajectory. In addition, a controller for the target vessel is designed. Mapping is performed to demonstrate that the USV can implement the necessary avoidance maneuvers to prevent collisions with obstacles. The proposed method is validated by conducting collision avoidance simulations and autonomous navigation field tests with a small-scale autonomous surface vehicle (ASV) platform. Results indicate that the ASV can successfully avoid obstacles while following its trajectory. Full article

In level ice, the maneuvering motion of icebreakers has a major influence on the global ice loads of the hull. This study researched the influences of the drift angle and turning radius on the ice loads of the icebreaker Xue Long through a partial numerical method based on the linear superposition theory of ice loads. First, with reference to the Araon model tests performed by the Korea Research Institute of Ships and Ocean Engineering (KRISO), numerical simulations of Araon’s direct motion were carried out at different speeds, and the average deviation between numerical results and model test results was about 13.8%. Meanwhile, the icebreaking process and modes were analyzed and discussed, compared with a model test and a full-scale ship trial. Next, the maneuvering captive motions of oblique and constant radius were simulated to study the characteristics of ice loads under different drift angles and turning radii. Compared with the maneuvering motion model tests in the ice tank of Tianjin University and the Institute for Ocean Technology of the National Research Council of Canada (NRC/IOT), the numerical results had good agreement with the model test results in terms of the variation trend of ice loads and ice–hull interaction, and the influences of drift angle and turning radius on ice resistance and transverse force, which have a certain reference value for sailing performance research and the design of the hull form of icebreaker ships, are discussed. Full article

This paper explores a fast and efficient method for identifying and modeling ship maneuvering motion, and conducts a comprehensive experiment. Through the ship maneuvering test, the dynamics interaction between ship and the environment is obtained. Then, the LWL (Locally Weighted Learning algorithm) underlying architecture is constructed by sparse Gaussian Process to reduce the data requirements of LWL-based ship maneuvering motion modeling and to improve the performance for LWL. On this basis, a non-parametric model of ship maneuvering motion is established based on the locally weighted sparse Gaussian Process, and the traditional mathematical model of ship maneuvering motion is replaced by the generative model. This generative model considers the hydrodynamic effects of ships, and reduces the sensitivity of local weighted learning to sample data. In addition, matrix operations are transferred to the auxiliary platform to optimize the calculation performance of the method. Finally, the simulation results of ship maneuvering motion indicate that this method has the characteristics of efficiency, rapidity and universality, and its accuracy conforms to engineering practice. Full article
