Article
Study on the Energy Loss Characteristics of Shaft Tubular Pump Device under Stall Conditions Based on the Entropy Production Method
by Dongtao Ji, Weigang Lu, Bo Xu, Lei Xu and Tao Jiang
J. Mar. Sci. Eng. 2023, 11(8), 1512; https://doi.org/10.3390/jmse11081512 - 29 Jul 2023
Cited by 2 | Viewed by 1075
Abstract
This study aimed to reveal the energy loss characteristics of each part of the shaft tubular pump device (STPD) under stall conditions. Numerical simulations were conducted by using the SST k-ω turbulence model with curvature correction, and the reliability of the simulation results [...] Read more.
This study aimed to reveal the energy loss characteristics of each part of the shaft tubular pump device (STPD) under stall conditions. Numerical simulations were conducted by using the SST k-ω turbulence model with curvature correction, and the reliability of the simulation results was verified by a model test. The entropy production method was used to evaluate and visualize the energy loss. The results show that turbulent entropy production (TEP) is the main source of energy loss in each component of the STPD, and the TEP increases significantly with the deterioration of stall. The energy loss in the impeller is mainly concentrated near the shroud and hub, while in the guide vanes it is mainly concentrated near the shroud and suction surface of the blades. In addition, with the deterioration of stall, the energy loss in the inlet of the impeller and guide vanes increases significantly. Influenced by the backflow from the impeller, there is a significant amount of energy loss at the outlet segment of the inlet passage, and the location of the high-energy-loss region is consistent with the backflow region. Affected by the flow separation vortex at the tail of the guide vanes, the energy loss in the outlet passage is mainly concentrated at the inlet segment. Full article
(This article belongs to the Section Ocean Engineering)
Show Figures

Figure 1

20 pages, 23421 KiB
Article
Study of Energy Loss Characteristics of a Shaft Tubular Pump Device Based on the Entropy Production Method
by Dongtao Ji, Weigang Lu, Bo Xu, Lei Xu and Linguang Lu
Entropy 2023, 25(7), 995; https://doi.org/10.3390/e25070995 - 29 Jun 2023
Cited by 5 | Viewed by 1353
Abstract
The unstable flow of a shaft tubular pump device (STPD) leads to energy loss, thereby reducing its efficiency. The aim of this study is to investigate the distribution pattern of energy loss in STPDs. This paper reveals that the two components with the [...] Read more.
The unstable flow of a shaft tubular pump device (STPD) leads to energy loss, thereby reducing its efficiency. The aim of this study is to investigate the distribution pattern of energy loss in STPDs. This paper reveals that the two components with the highest proportion of energy loss are the impeller and the outlet passage. Furthermore, turbulent entropy production is the primary cause of energy loss. Due to the wall effect, the energy loss in the impeller mainly occurs near the hub and shroud. Additionally, the presence of a tip leakage vortex near the shroud further contributes to the energy loss in the region near the shroud. This results in the energy loss proportion exceeding 40% in the region with a volume fraction of 14% near the shroud. In the outlet passage, the energy loss mainly occurs in the front region, with a volume fraction of 30%, and the energy loss in this part accounts for more than 65%. Finally, this study reveals the locations of the vortex in the STPD under different flow-rate conditions, and when the distribution of energy loss is visualized, it is found that the energy loss occurs high in the vortex regions. Full article
(This article belongs to the Special Issue Thermal Science and Engineering Applications)
Show Figures

Figure 1

23 pages, 16137 KiB
Article
Leakage Flow Characteristics in Blade Tip of Shaft Tubular Pump
by Zhikang Lin, Fan Yang, Jun Guo, Hongfu Jian, Shengjie Sun and Xiaoyu Jin
J. Mar. Sci. Eng. 2023, 11(6), 1139; https://doi.org/10.3390/jmse11061139 - 29 May 2023
Cited by 6 | Viewed by 1546
Abstract
The shaft tubular pump device is widely used in various water diversion projects because of its ultra-low head and large flow characteristics. Due to the tip clearance between the blade and the shroud, it is easy to cause hydraulic mechanical performance changes, induced [...] Read more.
The shaft tubular pump device is widely used in various water diversion projects because of its ultra-low head and large flow characteristics. Due to the tip clearance between the blade and the shroud, it is easy to cause hydraulic mechanical performance changes, induced vibration, and noise, which seriously affects the safe and stable operation of the pump. Steady and unsteady three-dimensional flow field numerical simulations of a shaft tubular pump device were carried out using computational fluid dynamics to investigate the impeller flow properties of the device under various flow conditions, including the tip clearance leakage flow (TCLF) and change rule of pressure pulsation. The TCLF, vortex morphology evolution, and pressure pulsation properties of the impeller tip clearance were analyzed. The results show that with an increase in the flow rate, the influence of the tip clearance size on the tip clearance flow decreases, the TCLF decreases, and the axial velocity of the water flow at the tip clearance increases. When the flow rate increases, the swirling strength of the tip leakage vortex decreases, and the distance between the tip leakage vortex and the suction surface of the blade increases. With the increase in flow rate, the pressure pulsation amplitude at the tip clearance increases first and then decreases. The focus of this study is to analyze the variation of tip clearance flow field and pressure pulsation under multiple working conditions, aiming to provide some help for improving the performance of the pump device and ensuring its safe operation. Full article
(This article belongs to the Section Ocean Engineering)
Show Figures

Figure 1

16 pages, 8413 KiB
Article
Comparison of the Hydraulic Performance and Pressure Pulsation Characteristics of Shaft Tubular Pump Device under Multiple Working Conditions
by Dongtao Ji, Weigang Lu, Lei Xu and Linguang Lu
J. Mar. Sci. Eng. 2022, 10(6), 750; https://doi.org/10.3390/jmse10060750 - 30 May 2022
Cited by 4 | Viewed by 1791
Abstract
For pumping station projects in plain areas, shaft tubular pump devices are often used due to the low head. In actual operation, the common working range of the pump device is generally 0.8 Qbep~1.2 Qbep. Therefore, it is of [...] Read more.
For pumping station projects in plain areas, shaft tubular pump devices are often used due to the low head. In actual operation, the common working range of the pump device is generally 0.8 Qbep~1.2 Qbep. Therefore, it is of great significance to study the hydraulic performance and pressure pulsation characteristics of the pump device in the working range. In this study, the hydraulic performance of a shaft pump device was tested by a model test, and the internal flow and pressure pulsation characteristics were analyzed by numerical simulation. The results obtained from the model test and numerical simulation were in general agreement, indicating that the numerical results were reliable. The results show that the inlet passage has a good flow pattern in the working range, which may offer a favorable flow state for the impeller. When Q = 0.8 Qbep, the flow in the impeller and guide vane was chaotic, the guide vane had a poor adjustment function on flow direction, and the flow in the outlet passage presented in a spiral motion. When Q = 1.0 and 1.2 Qbep, the flow in the impeller and guide vane was ordered, and the spiral flow in the outlet passage improved. In the working range, the pressure pulsation was similar. The main frequency at the impeller inlet and outlet was consistent with the blade passing frequency. For the same flow rate condition, the amplitude rose from hub to shroud and declined from impeller inlet to outlet. In addition, the amplitude decreased with an increasing flow rate. Full article
(This article belongs to the Section Ocean Engineering)
Show Figures

Figure 1

13 pages, 5436 KiB
Article
Comparison of Energy Performance of Shaft Tubular Pump Device at Two Guide Vane Inlet Angles
by Lei Xu, Fusheng Lv, Feifan Li, Dongtao Ji, Wei Shi, Weigang Lu and Linguang Lu
Processes 2022, 10(6), 1054; https://doi.org/10.3390/pr10061054 - 25 May 2022
Cited by 6 | Viewed by 2110
Abstract
In order to improve the pump device efficiency of the frequent operating condition of the extra-low head pumping station, the energy performance of the front-positioned shaft tubular pump device at two guide vane inlet angles has been researched. Based on the function of [...] Read more.
In order to improve the pump device efficiency of the frequent operating condition of the extra-low head pumping station, the energy performance of the front-positioned shaft tubular pump device at two guide vane inlet angles has been researched. Based on the function of the guide vane in the pump device, the guide vane blades are divided into three parts: the inlet section, the middle section, and the outlet section. Combining numerical simulation and model tests, the energy performance of the pump device with the inlet section angle adjusted to 0° and −12° were studied and compared, respectively. The research results indicate that the inlet section angle of the guide vane has a significant effect on the energy performance of the pump device. When the guide vane inlet section is adjusted clockwise, the pump device efficiency of the optimal operating point—while the efficiency of the pump device at a low head and large discharge that deviate from the optimal operating point—will be improved. The farther the working condition deviates from the optimal operating point, the greater the influence. Within the scope of the working conditions studied in this paper, the pump device efficiency of the optimal operating point is reduced by about 2%, and the pump device efficiency in the low head and high flow conditions is increased by 5% at the maximum. Adjusting the inlet section angle of the guide vane, the flow pattern in the guide vane will be improved, and the hydraulic loss of the guide vane will be decreased, thus the pump device efficiency is increased. The numerical calculation results of the energy performance agree with the model test results; the maximum error of the pump device efficiency is less than 7%. Adjusting the angle of the inlet section of the guide vane has great significance to the hydraulic design and engineering application of the extra-low head pump device. Full article
Show Figures

Figure 1

12 pages, 2621 KiB
Article
Experiment on Influence of Blade Angle on Hydraulic Characteristics of the Shaft Tubular Pumping Device
by Kaihua Cheng, Songbai Li, Li Cheng, Tao Sun, Bowen Zhang and Weixuan Jiao
Processes 2022, 10(3), 590; https://doi.org/10.3390/pr10030590 - 17 Mar 2022
Cited by 11 | Viewed by 2474
Abstract
In order to understand the influence of blade angle on the hydraulic characteristics of a shaft tubular pumping device, the energy characteristics, cavitation characteristics, runaway characteristics, and pressure pulsation of the tubular pumping device under different blade angles were studied by a model [...] Read more.
In order to understand the influence of blade angle on the hydraulic characteristics of a shaft tubular pumping device, the energy characteristics, cavitation characteristics, runaway characteristics, and pressure pulsation of the tubular pumping device under different blade angles were studied by a model test. Comparing the efficiency of the best efficiency point of the pumping device under different blade angles, it can be seen that when the blade angle is +4°, the efficiency of the best efficiency point of the pumping device is the lowest, 74.10%. When the blade angle is −4°, the efficiency of the best efficiency point of the pumping device is the highest, 79.75%. Comparing the cavitation characteristics of the pumping device under different blade angles, it can be seen that when the blade angle is −4°, the overall cavitation performance of the pumping device is the best. When the design head point is deviated, the NPSHav (Net positive suction head available) of the pump will increase. At the same blade angle, the runaway speed increases with the increase in head. The runaway speed of the prototype pump decreases with the increase in blade angle. When the blade angle is −6°, the runaway speed of the prototype pump is the largest, which is not conducive to the safe operation of the pumping station. When the blade angle is −4°, the variation law of pressure pulsation is small, and there is no abnormal pulsation. The tubular pumping device has satisfactory hydraulic performance, high efficiency, cavitation, and runaway characteristics. Therefore, the shaft tubular pumping device has wide application prospects under ultra-low head, and we recommend prioritizing it in low-head pumping stations. Full article
(This article belongs to the Special Issue Design and Optimization Method of Pumps)
Show Figures

Figure 1

20 pages, 73855 KiB
Article
Influence of Blade Angle Deviation on the Hydraulic Performance and Structural Characteristics of S-Type Front Shaft Extension Tubular Pump Device
by Lijian Shi, Changxin Wu, Li Wang, Tian Xu, Yuhang Jiang, Yao Chai and Jun Zhu
Processes 2022, 10(2), 328; https://doi.org/10.3390/pr10020328 - 8 Feb 2022
Cited by 7 | Viewed by 2253
Abstract
When the axial-flow pump is running, the blade angle is not fully adjusted or there are errors in the manufacture of the blades, which will lead to inconsistent blade placement angles during operation, and which will reduce the efficiency of the axial-flow pump. [...] Read more.
When the axial-flow pump is running, the blade angle is not fully adjusted or there are errors in the manufacture of the blades, which will lead to inconsistent blade placement angles during operation, and which will reduce the efficiency of the axial-flow pump. This paper uses the research methods of numerical simulation and model experiments to analyze the hydraulic performance and impeller structure characteristics of each flow components under different schemes when the angles of each blade of the S-type front shaft extension tubular pump device are inconsistent. The research phenomenon is that the guide vane greatly recovers the flow velocity circulation at the impeller outlet, reduces the hydraulic loss of guide vane, and widens the best efficiency range with an increase in guide vane blade angle. When the blade angle deviation occurs, the flow field of each blade channel affects each other, and the maximum decrease in the best efficiency is up to 7.78%, mainly due to the increased hydraulic loss in the outlet channel. The blade angle deviation will also affect the maximum equivalent stress and maximum deformation of the impeller, which is more obvious in large flow conditions. Inconsistent blade angles seriously affect the operating efficiency of the water pump and water pump device, and make the structural characteristics of the impeller worse. Full article
(This article belongs to the Special Issue Design and Optimization Method of Pumps)
Show Figures

Figure 1

16 pages, 3054 KiB
Article
Study on the Comparison of the Hydraulic Performance and Pressure Pulsation Characteristics of a Shaft Front-Positioned and a Shaft Rear-Positioned Tubular Pump Devices
by Dongtao Ji, Weigang Lu, Linguang Lu, Lei Xu, Jun Liu, Wei Shi and Guohao Huang
J. Mar. Sci. Eng. 2022, 10(1), 8; https://doi.org/10.3390/jmse10010008 - 22 Dec 2021
Cited by 13 | Viewed by 2791
Abstract
The shaft front-positioned tubular pump device has been widely used in practical engineering, but the shaft rear-positioned pump device is rarely used due to its low efficiency. To investigate the effect of the shaft position on the performance of a tubular pump device, [...] Read more.
The shaft front-positioned tubular pump device has been widely used in practical engineering, but the shaft rear-positioned pump device is rarely used due to its low efficiency. To investigate the effect of the shaft position on the performance of a tubular pump device, the optimized shaft front-positioned and shaft rear-positioned pump devices were compared and studied. Both tubular pump devices adopt a TJ04-ZL-06 pump model. Three dimensional steady and unsteady numerical simulations combined with model tests were used to compare the difference of two pump devices. Meanwhile, three groups of pressure monitoring points were set at different positions of the pump device to collect pressure information and pressure pulsation was analyzed. The results show that, the highest efficiency of the shaft front and rear positioned pump device are 81.78% and 80.26%, respectively. The hydraulic performance of the two inlet passages is excellent, and the hydraulic loss is close to each other. Therefore, the hydraulic performance of the pump device depends mainly on the hydraulic performance of the outlet passage. The shaft is set in the outlet passage, which will increase the hydraulic loss and reduce efficiency. Under design conditions, the pressure pulsation amplitude at the impeller inlet is the largest, and the pressure pulsation amplitude increases from the hub to the shroud. The pressure pulsation amplitude of the shaft rear-positioned pump device is larger than that of the shaft front-positioned pump device. The pressure pulsation at the impeller inlet and outlet is greatly affected by the number of blades, and the main frequency is three times the RF. This study can provide practical and effective guidance for the design and optimization of the shaft front-positioned and rear-positioned tubular pump devices, which has theoretical value and application value. Full article
(This article belongs to the Section Ocean Engineering)
Show Figures

Figure 1

16 pages, 7487 KiB
Article
Energy Characteristics of Full Tubular Pump Device with Different Backflow Clearances Based on Entropy Production
by Fan Meng, Yanjun Li and Ji Pei
Appl. Sci. 2021, 11(8), 3376; https://doi.org/10.3390/app11083376 - 9 Apr 2021
Cited by 17 | Viewed by 1913
Abstract
In this study, the entropy theory was used as the evaluation standard of energy dissipation, and the effect of backflow clearance (the gap between motor rotor and motor shell) on energy characteristics of a full tubular pump was investigated by 3D unsteady flow [...] Read more.
In this study, the entropy theory was used as the evaluation standard of energy dissipation, and the effect of backflow clearance (the gap between motor rotor and motor shell) on energy characteristics of a full tubular pump was investigated by 3D unsteady flow simulation. The calculated results validated through testing shows that backflow clearance produces additional head loss and the rotation of the motor rotor requires more shaft power. The additional energy losses lead to a significant decline in the efficiency of tubular pump device. Under design conditions, the total dissipation of backflow clearance, rear guide vane, and outlet passage decreases with the increase of clearance radius, but that of the impeller decreases first and then rises with the increase of clearance radius. In addition, the increase of the clearance radius leads to disorderly flow pattern in the impeller. The total dissipation rate on the impeller suction side and near the impeller inlet increases with the increase of backflow clearance radius, but that on the impeller suction side decreases with the increase of backflow clearance radius. The total dissipation rate of the suction side of the guide vane and the wall of the outlet passage decreases with the increase of backflow clearance radius. This work can provide an intuitive analysis of the energy dissipation caused by backflow clearance and reference for engineering applications of full tubular pump. Full article
(This article belongs to the Section Energy Science and Technology)
Show Figures

Figure 1
