Semitransparent perovskite solar cells (PSCs) that possess a high-power conversion efficiency (PCE) and high average visible light transmittance (AVT) can be employed in applications such as photovoltaic windows. In this study, a bifacial modification comprising a buried layer of [4-(3,6-Dimethyl-9H-carbazol-9-yl) butyl] phosphonic acid (Me-4PACz) and a surface passivator of 2-(2-Thienyl) ethylamine hydroiodide (2-TEAI) was proposed to enhance device performance. When the concentrations of Me-4PACz and 2-TEAI were 0.3 mg/mL and 3 mg/mL, opaque PSCs with a 1.57 eV perovskite absorber achieved a PCE of 22.62% (with a V_OC of 1.18 V) and retained 88% of their original value after being stored in air for 1000 h. By substituting a metal electrode with an indium zinc oxide electrode, the resulting semitransparent PSCs showed a PCE of over 20% and an AVT of 9.45%. It was, therefore, suggested that the synergistic effect of Me-4PACz and 2-TEAI improved the crystal quality of perovskites and the carrier transport in devices. When employing an absorber with a wider bandgap (1.67 eV), the corresponding PSC obtained a higher AVT of 20.71% and maintained a PCE of 18.73%; these values show that a superior overall performance is observed compared to that in similar studies. This work is conductive to the future application of semitransparent PSCs. Full article

Despite the huge progress achieved in the optimization of perovskite solar cell (PSC) performance, stability remains a limiting factor for technological commercialization. Here, a study on the photovoltaic, structural and morphological stability of semi-transparent formamidinium lead bromide-based PSCs is presented. This work focuses on the positive role of 2D nanoscale layer passivation, induced by perovskite surface treatment with a mixture of iso-Pentylammonium chloride (ISO) and neo-Pentylammonium chloride (NEO). In situ X-ray diffraction (XRD) is applied in combination with atomic force microscopy (AFM), and the results are correlated to the devices’ photovoltaic performances. The superior power conversion efficiency and overall stability of the ISO-NEO system is evidenced, as compared to the un-passivated device, under illumination in air. Furthermore, the role of the ISO-NEO treatments in increasing the morpho-structural stability is clarified as follows: a bulk effect resulting in a protective role against the loss in crystallinity of the perovskite 3D phase (observed only for the un-passivated device) and an interface effect, being the observed 2D phase crystallinity loss spatially localized at the interface with the 3D phase where a higher concentration of defects is expected. Importantly, the complete stability of the device is achieved with the passivated ISO-NEO-encapsulated device, allowing us to exclude the intrinsic degradation effects. Full article

This research addresses the need for enhanced thermal management in building-integrated photovoltaic systems, specifically focusing on semi-transparent PV panels based on luminescent solar concentrator (LSC) technology. In pursuit of optimal thermal regulation, the cooling effect of a paraffin PCM was investigated via finite element simulations developed with COMSOL Multiphysics. The PCM was thermally coupled with the PV cells situated in the frame of a south-facing window. Due to the seasonal difference between winter and summer, the PCM latent heat capacity and melting temperature were optimized to ensure the maximum nominal operating cell temperature (NOCT) reduction during summer months. PCM latent heat capacities equivalent to 120 kJ/kg, 180 kJ/kg, and 240 kJ/kg have been investigated, whereas for the melting temperature a range from 20 °C to 42 °C was spanned. The combination of higher latent heat and 36 °C melting point showed the most significant thermal benefits, by reducing the NOCT from 42 °C to 36 °C, which led to an 11.80% increase in power output across the whole PV window. Considering the same latent heat, the other melting temperature resulted in more moderate benefits, namely an enhancement of 7.88% and 3.94%, for 38 °C and 40 °C, respectively. The lower latent heat capacities resulted in an NOCT reduction that ranged between 2.7 °C and 5.3 °C, according to the associated melting point. These results testify that the presented solution could significantly enhance energy production in semi-transparent PV applications based on LSC panels. Full article

Amid the shift away from fossil fuels, third-generation perovskite solar cells (PSCs) have become pivotal due to their high efficiency and low production costs. This review concentrates on semi-transparent perovskite solar cells (ST-PSCs), highlighting their power conversion efficiency (PCE) and average visible transmittance (AVT). We address strategies to optimize ST-PSC performance, tackling inherent challenges, such as optical losses from reflection, parasitic absorption, and thermalization loss, which impact the operational efficiency under variable environmental conditions. ST-PSCs are distinguished by their lightweight, flexible, and translucent properties, allowing for diverse applications in urban building integration, agricultural greenhouses, and wearable technology. These cells integrate seamlessly into various settings, enhancing energy harnessing without compromising on aesthetic or structural elements. However, the scalability of ST-PSCs involves challenges related to stability and efficiency in large-scale deployments. The tropical urban landscape of Singapore provides a unique case study for ST-PSC application, blending architectural aesthetics with high solar irradiance to optimize energy efficiency. While the potential for ST-PSCs to contribute to sustainable urban development is immense, significant technological hurdles must be overcome to realize their full potential. Continued advancements in material science and engineering are essential to address these challenges, ensuring the scalability and long-term deployment of ST-PSCs in global energy solutions. Full article

Semitransparent organic solar cells (ST-OSCs) have garnered more interest and stand out as promising candidates for next-generation solar energy harvesters with their unique advantages. However, challenges remain for the advancement of colorful ST-OSCs, such as enhancing the light absorption and transmittance without considerable power conversion efficiency (PCE) losses. Herein, an optical analysis of silver (Ag) electrodes and one-dimensional photonic crystals (1DPCs) was conducted by simulations, revealing the presence of optical Tamm states (OTSs) at the interface of Ag/1DPCs. Furthermore, the spectral and electrical properties were fine-tuned by modulating the OTSs through theoretical simulations, utilizing PM6:Y6 as the active layer. The structural parameters of the ST-OSCs were optimized, including the Ag layer thickness, the central wavelength of 1DPCs, the first WO₃ layer thickness, and the pair number of WO₃/LiF. The optimization resulted in the successful development of blue, violet-blue, and red ST-OSC devices, which exhibited transmittance peak intensities ranging from 31.5% to 37.9% and PCE losses between 1.5% and 5.2%. Notably, the blue device exhibited a peak intensity of 37.0% and a PCE of 15.24%, with only a 1.5% loss in efficiency. This research presents an innovative approach to enhancing the performance of ST-OSCs, achieving a balance between high transparency and high efficiency. Full article

In the dynamic field of photovoltaic technology, the pursuit of efficiency and sustainability has led to continuous novelty, shaping the landscape of solar energy solutions. One of the key elements affecting the efficiency of photovoltaic cells of II^nd and III^rd generation is the presence of transparent conductive oxide (TCO) layers, which are key elements impacting the efficiency and durability of solar panels, especially for DSSC, CdTe, CIGS (copper indium gallium diselenide) or organic, perovskite and quantum dots. TCO with low electrical resistance, high mobility, and high transmittance in the VIS–NIR region is particularly important in DSSC, CIGS, and CdTe solar cells, working as a window and electron transporting layer. This layer must form an ohmic contact with the adjacent layers, typically the buffer layer (such as CdS or ZnS), to ensure efficient charge collection Furthermore it ensures protection against oxidation and moisture, which is especially important when transporting the active cell structure to further process steps such as lamination, which ensures the final seal. Transparent conductive oxide layers, which typically consist of materials such as indium tin oxide (ITO) or alternatives such as fluorine-doped tin oxide (FTO), serve dual purposes in photovoltaic applications. Primarily located as the topmost layer of solar cells, TCOs play a key role in transmitting sunlight while facilitating the efficient collection and transport of generated electrical charges. This complex balance between transparency and conductivity highlights the strategic importance of TCO layers in maximizing the performance and durability of photovoltaic systems. As the global demand for clean energy increases and the photovoltaic industry rapidly develops, understanding the differential contribution of TCO layers becomes particularly important in the context of using PV modules as building-integrated elements (BIPV). The use of transparent or semi-transparent modules allows the use of building glazing, including windows and skylights. In addition, considering the dominant position of the Asian market in the production of cells and modules based on silicon, the European market is intensifying work aimed at finding a competitive PV technology. In this context, thin-film, organic modules may prove competitive. For this purpose, in this work, we focused on the electrical parameters of two different thicknesses of a transparent FTO layer. First, the influence of the FTO layer thickness on the transmittance over a wide range was verified. Next, the chemical composition was determined, and key electrical parameters, including carrier mobility, resistivity, and the Hall coefficient, were determined. Full article

Perovskite/silicon tandem solar cells are of great interest due to their potential for breaking the Shockley-Queisser limit of single-junction silicon solar cells. Perovskite solar cells are widely used as the top subcells in perovskite/silicon tandem solar cells due to their high efficiency and lower fabrication cost. Herein, we review the semi-transparent perovskite solar cell in terms of the mechanisms of their translucent structure, transparent electrodes, charge transport layer, and component modification. In addition, recent progress in the research and development of 4T perovskite/silicon tandem solar cells is summarized, with emphasis on the influence of perovskite structure and silicon cells on the progress of tandem solar cells. Finally, we discuss the challenges associated with 4T perovskite/silicon tandem solar cells and suggest directions for the development of perovskite/silicon commercialization. Full article

The development of semitransparent CdS/CdTe ultrathin solar cells has been delayed as a result of the activation annealing to which the device must be subjected, which may involve problems such as the sublimation of ultrathin films and the diffusion of Cd and S at the interface. In this work, CdS/CdTe ultrathin devices on soda-lime glass/SnO₂:F/ZnO substrates were obtained by RF magnetron sputtering. CdS/CdTe ultrathin heterostructures were obtained with the following thicknesses for the CdS thin film: 70, 110, and 135 nm. The CdTe thickness film was kept constant at 620 nm. Subsequently, activation annealing with CdCl₂ was carried out at 400 °C. Surface characterization was performed by scanning electron microscopy, which indicated that the CdCl₂ annealing tripled the CdTe thin films’ grain size. Raman characterization showed that CdS thin films deposited by RF sputtering present the first, the second, and the third longitudinal optical modes, indicating the good crystallinity of the CdS thin films. The study showed that the photovoltaic properties of the CdS/CdTe ultrathin devices improved as the CdS thicknesses decreased. Full article

The tandem solar cell presents a potential solution to surpass the Shockley–Queisser limit observed in single-junction solar cells. However, creating a tandem device that is both cost-effective and highly efficient poses a significant challenge. In this study, we present proof of concept for a four-terminal (4T) tandem solar cell utilizing a wide bandgap (1.6–1.8 eV) perovskite top cell and a narrow bandgap (1.2 eV) antimony selenide (Sb₂Se₃) bottom cell. Using a one-dimensional (1D) solar cell capacitance simulator (SCAPS), our calculations indicate the feasibility of this architecture, projecting a simulated device performance of 23% for the perovskite/Sb₂Se₃ 4T tandem device. To validate this, we fabricated two wide bandgap semitransparent perovskite cells with bandgaps of 1.6 eV and 1.77 eV, respectively. These were then mechanically stacked with a narrow bandgap antimony selenide (1.2 eV) to create a tandem structure, resulting in experimental efficiencies exceeding 15%. The obtained results demonstrate promising device performance, showcasing the potential of combining perovskite top cells with the emerging, earth-abundant antimony selenide thin film solar technology to enhance overall device efficiency. Full article

The increasing energy demands of the global community can be met with solar energy. Solution-processed organic solar cells have seen great progress in power conversion efficiencies (PCEs). Semitransparent organic solar cells (ST-OSCs) have made enormous progress in recent years and have been considered one of the most promising solar cell technologies for applications in building-integrated windows, agricultural greenhouses, and wearable energy resources. Therefore, through the synergistic efforts of transparent electrodes, engineering in near-infrared photoabsorbent materials, and device engineering, high-performance ST-OSCs have developed, and PCE and average visible transmittance reach over 10% and 40%, respectively. In this review, we present the recent progress in photoabsorbent material engineering and strategies for enhancing the performance of ST-OSCs to help researchers gain a better understanding of structure–property–performance relationships. To conclude, new design concepts in material engineering and outlook are proposed to facilitate the further development of high-performance ST-OSCs. Full article

The luminous transmittance and the color rendering index of daylight through semitransparent photovoltaic glazing are essential parameters for visual comfort indoors, and they must be considered for different absorber materials that were traditionally developed for opaque solar cells, such as those of the chalcopyrite type. With this aim, various chalcopyrite compounds (CuInSe₂, CuInS₂ and CuGaS₂) were prepared by means of evaporation and then measured to obtain their optical absorption spectra. These experimental data are used here to calculate the solar absorptance (α_S), luminous transmittance (τ_L) and color rendering index (R_a) as a function of the chalcopyrite film thickness. The comparative analysis of the different factors indicates that 70 nm thick CuInSe₂ is optimal to guarantee excellent visual comfort (τ_L = 50% and R_a = 93%) while absorbing as much solar irradiance (α_S = 37%) as 130 nm thick CuInS₂ or 900 nm thick CuGaS₂. The second option (130 nm thick CuInS₂) is also considered good (τ_L = 40% and R_a = 80%), but for CuGaS₂, the thickness should be kept below 250 nm in order to obtain a suitable color rendering R_a ≥ 60%. Full article

In the present work, an insight on the morpho/structural properties of semitransparent organic devices for buildings’ integrated photovoltaics is presented, and issues related to interface and bulk stability are addressed. The organic photovoltaic (OPV) cells under investigation are characterized by a blend of PM6:Y6 as a photo-active layer, a ZnO ETL (electron transporting layer), a HTL (hole transporting layer) of HTL-X and a transparent electrode composed by Ag nanowires (AgNWs). The devices’ active nanomaterials, processed as thin films, and their mutual nanoscale interfaces are investigated by a combination of in situ Energy Dispersive X-ray Reflectometry (EDXR) and ex situ Atomic Force Microscopy (AFM), X-ray Diffraction (XRD) and micro-Raman spectroscopy. In order to discriminate among diverse concomitant aging pathways potentially occurring upon working conditions, the effects of different stress factors were investigated: light and temperature. Evidence is gained of an essential structural stability, although an increased roughness at the ZnO/PM6:Y6 interface is deduced by EDXR measurements. On the contrary, an overall stability of the system subjected to thermal stress in the dark was observed, which is a clear indication of the photo-induced origin of the observed degradation phenomenon. Micro-Raman spectroscopy brings light on the origin of such effect, evidencing a photo-oxidation process of the active material in the device, using hygroscopic organic HTL, during continuous illumination in ambient moisture conditions. The process may be also triggered by a photocatalytic role of the ZnO layer. Therefore, an alternative configuration is proposed, where the hygroscopic HTL-X is replaced by the inorganic compound MoOx. The results show that such alternative configuration is stable under light stress (solar simulator), suggesting that the use of Molybdenum Oxide, limiting the photo-oxidation of the bulk PM6:Y6 active material, can prevent the cell from degradation. Full article

The rapid development of photovoltaic technology has driven the search for novel materials that can improve the cost-effectiveness and efficiency of solar cells. Organic semiconductors offer unique optical tunability and transparency, allowing customization for the absorption of specific optical spectra like near-infrared radiation. Through the molecular engineering of electron donors and acceptors, these materials can be optimized for targeted optical selectivity. This adaptability enables the development of efficient energy-harvesting devices tailored for specific spectral regions. Consequently, organic semiconductors present a promising avenue for specialized applications such as semi-transparent organic solar cells. This review offers a detailed summary of the latest developments in novel organic semiconductor materials, focusing on design principles and synthesis of materials in the context of semi-transparent organic solar cells. Optimization of molecular architecture, photovoltaic performance, and the optoelectronic properties of these materials has been explored, highlighting their potential for next-generation solar energy conversion. Full article

Recently, metal halide perovskite-based top cells have shown significant potential for use in inexpensive and high-performance tandem solar cells. In state-of-the-art p-i-n perovskite/Si tandem devices, atomic-layer-deposited SnO₂ has been widely used as a buffer layer in the top cells because it enables conformal, pinhole-free, and highly transparent buffer layer formation. In this work, the effects of various electrical properties of SnO₂ and C60 layers on the carrier transport characteristics and the performance of the final devices were investigated using a numerical simulation method, which was established based on real experimental data to increase the validity of the model. It was found that the band alignment at the SnO₂/C60 interface does, indeed, have a significant impact on the electron transport. In addition, as a general design rule, it was suggested that at first, the conduction band offset (CBO) between C60 and SnO₂ should be chosen so as not to be too negative. However, even in a case in which this CBO condition is not met, we would still have the means to improve the electron transport characteristics by increasing the doping density of at least one of the two layers of C60 and/or SnO₂, which would enhance the built-in potential across the perovskite layer and the electron extraction at the C60/SnO₂ interface. Full article

In this study, we explore the potential of a blended material comprising ${\mathrm{CsPbI}}_3$:${\mathrm{EuCl}}_3$ perovskite and Gig-Lox ${\mathrm{TiO}}_2$, a unique transparent spongy material known for its multi-branched porous structure, for application in solar cells. The inclusion of ${\mathrm{EuCl}}_3$ in ${\mathrm{CsPbI}}_3$ serves to stabilize the photoactive $\mathrm{\gamma }$-phase with a bandgap of 1.75 eV, making it suitable for solar energy conversion in tandem solar cells. Our study applies X-ray-based techniques to investigate the structural properties and interfacial behavior within this blended material, in comparison with a reference perovskite layer deposited on glass. In addition, Spectroscopic ellipsometry is complemented with density functional theory calculations and photoluminescence measurements to elucidate the absorption and radiative emission properties of the blend. Notably, our findings reveal a significant quenching of photoluminescence within the blended material, underscoring the pivotal role of the distributed interfaces in facilitating efficient carrier injection from the ${\mathrm{CsPbI}}_3$:${\mathrm{EuCl}}_3$ perovskite into the Gig-Lox ${\mathrm{TiO}}_2$ sponge. These findings pave the way for the application of the blend as an Electron Transport Layer (ETL) in semi-transparent perovskite solar cells for tandem and building integrated photovoltaics. Full article
