Oxygen (O₂) uptake by cells and tissues is a critical indicator of metabolic demand, changes in microenvironment, and pathophysiology. O₂ uptake from the atmosphere accounts for virtually all the O₂ consumption in the avascular cornea; however, a detailed spatiotemporal profile of corneal O₂ uptake (COU) remains undetermined. Here, we used a non-invasive self-referencing optical fiber O₂ sensor—the scanning micro-optrode technique (SMOT)—to report the O₂ partial pressure and flux variations at the ocular surface of rodents and non-human primates. In vivo spatial mapping in mice revealed a distinct COU, characterized by a centripetal gradient with a significantly higher O₂ influx at the limbus and conjunctiva regions than at the center of the cornea. This regional COU profile was reproduced ex vivo in freshly enucleated eyes. The centripetal gradient was conserved across the following species analyzed: mice, rats, and rhesus monkeys. In vivo temporal mapping in mice showed a significant increase in the O₂ flux in the limbus in the evening compared to other times. Altogether, the data unveiled a conserved centripetal COU profile, which may be associated with the limbal epithelial stem cells residing at the intersection of the limbus and conjunctiva. These physiological observations will serve as a useful baseline for comparative studies with contact lens wear, ocular disease, diabetes, etc. Moreover, the sensor may be applied to understand the responses of the cornea and other tissues to various insults, drugs, or changes in the environment. Full article

In this work, an optical fiber sensor based on the localized surface plasmon resonance (LSPR) phenomenon has been designed for the detection of two different chemical species (mercury and hydrogen peroxide) by using Layer-by-Layer Embedding (LbL-E) as a nanofabrication technique. In the first step, silver nanoparticles (AgNPs) and gold nanoparticles (AuNPs) have been synthesized by using a chemical protocol as a function of the strict control of three main parameters, which were polyelectrolyte concentration, a loading agent, and a reducing agent. In the second step, their incorporation into nanometric thin films have been demonstrated as a function of the number of bilayers, which shows two well-located absorption peaks associated to their LSPR in the visible region at 420 nm (AgNPs) and 530 nm (AuNPs). Finally, both plasmonic peaks provide a stable real-time reference measurement, which can be extracted from the spectral response of the optical fiber sensor, which shows a specific sensing mechanism as a function of the analyte of study. Full article

Water management is a critical mission required to protect the water resources that is essential in diverse industrial applications. Amongst a variety of parameters such as level (or depth), temperature, conductivity, turbidity, and pH, the water level is the most fundamental one that needs to be monitored on a real-time basis for securing the water management system. This paper presents an overview of water level monitoring technologies based on optical fiber sensor (OFS) networks. Firstly, we introduce and compare the passive distributed and quasi-distributed (discrete) sensor networks with the recent achievements summarized. The performance (i.e., sensing range and resolution) of the OFS networks can be enhanced through diverse multiplexing techniques based on wavelength, time, coherence, space, etc. Especially, the dense wavelength division multiplexing (DWDM)-based sensor network provides remote sensing (where its reach can be extended to >40 km) with high scalability in terms of the channel number that determines the spatial resolution. We review the operation principle and characteristics of the DWDM-based OFS network with full theoretical and experimental analysis being provided. Furthermore, the key system functions and considerations (such as the link protection from physical damages, self-referencing, management of sensing units, and so on) are discussed that could be a guideline on the design process of the passive OFS network. Full article

A sensing configuration for the real-time monitoring, detection, and quantification of dissolved carbon dioxide (dCO₂) was developed for aquaculture and other applications in freshwater and saline water. A chemical sensing membrane, based on a colorimetric indicator, is combined with multimode optical fiber and a dual wavelength light-emitting diode (LED) to measure the dCO₂-induced absorbance changes in a self-referenced ratiometric scheme. The detection and processing were achieved with an embeded solution having a mini spectrometer and microcontroller. For optrode calibration, chemical standard solutions using sodium carbonate in acid media were used. Preliminary results in a laboratory environment showed sensitivity for small added amounts of CO₂ (0.25 mg·L⁻¹). Accuracy and response time were not affected by the type of solution, while precision was affected by salinity. Calibration in freshwater showed a limit of detection (LOD) and a limit of quantification (LOQ) of 1.23 and 1.87 mg·L⁻¹, respectively. Results in saline water (2.5%) showed a LOD and LOQ of 1.05 and 1.16 mg·L⁻¹, respectively. Generally, performance was improved when moving from fresh to saline water. Studies on the dynamics of dissolved CO₂ in a recirculating shallow raceway system (SRS+RAS) prototype showed higher precision than the tested commercial sensor. The new sensor is a compact and robust device, and unlike other sensors used in aquaculture, stirring is not required for correct and fast detection. Tests performed showed that this new sensor has a fast accurate detection as well as a strong potential for assessing dCO₂ dynamics in aquaculture applications. Full article

Intensity-based optical fiber sensors are one of the most studied sensor approaches thanks to their simplicity and low cost. Nevertheless, their main issue is their lack of robustness since any light source fluctuation, or unexpected optical setup variation is directly transferred to the output signal, which, significantly reduces their reliability. In this work, a simple and robust hydrogen peroxide (H₂O₂) optical fiber sensor is proposed based on the Localized Surface Plasmon Resonance (LSPR) sensitivity of silver and gold metallic nanoparticles. The precise and robust detection of H₂O₂ concentrations in the ppm range is very interesting for the scientific community, as it is a pathological precursor in a wide variety of damage mechanisms where its presence can be used to diagnose important diseases such as Parkinson’s disease, diabetes, asthma, or even Alzheimer’s disease). In this work, the sensing principle is based the oxidation of the silver nanoparticles due the action of the hydrogen peroxide, and consequently the reduction of the efficiency of the plasmonic coupling. At the same time, gold nanoparticles show a high chemical stability, and therefore provide a stable LSPR absorption band. This provides a stable real-time reference that can be extracted from the spectral response of the optical fiber sensor, giving a reliable reading of the hydrogen peroxide concentration. Full article

We proposed a refractive index (RI) sensor employing two twisted tapered plastic optical fibers (POFs). The tapered POFs were fabricated by a heating and drawing method and were twisted around each other to form a coupled structure. The sensor consisted of two input ports, a twisted region, and two output ports. The tapered POF could make the light couple from one POF to the other easily. The twisted tapered POFs could constitute a self-referencing sensor, and by monitoring the changes of the coupling ratio, the variations of the external medium RIs could be measured. The RI sensing performances for the sensors with different fiber diameters and twisted region lengths were studied. The sensitivities of 1700%/RIU and −3496%/RIU in the RI ranges of 1.37–1.41 and 1.41–1.44 were obtained, respectively. The sensor is a low-cost solution for liquid RI measurement, which has the features of simple structure and easy fabrication. Full article

This work bridges the gap between the remote interrogation of multiple optical sensors and the advantages of using inherently biocompatible low-cost polymer optical fiber (POF)-based photonic sensing. A novel hybrid sensor network combining both silica fiber Bragg gratings (FBG) and polymer FBGs (POFBG) is analyzed. The topology is compatible with WDM networks so multiple remote sensors can be addressed providing high scalability. A central monitoring unit with virtual data processing is implemented, which could be remotely located up to units of km away. The feasibility of the proposed solution for potential medical environments and biomedical applications is shown. Full article

A self-referencing, intensity-based fiber optic sensor (FOS) is proposed and demonstrated. The theoretical analysis for the proposed design is given, and the validity of the theoretical analysis is confirmed via experiments. We define the measurement parameter, X, and the calibration factor, β, to find the transfer function, , of the intensity-based FOS head. The self-referencing and multipoint sensing characteristics of the proposed system are validated by showing the measured and relative error versus the optical power attenuation of the sensor head for four cases: optical source fluctuation, various remote sensing point distances, fiber Bragg gratings (FBGs) with different characteristics, and multiple sensor heads with cascade and/or parallel forms. The power-budget analysis and limitations of the measurement rates are discussed, and the measurement results of fiber-reinforced plastic (FRP) coupon strain using the proposed FOS are given as an actual measurement. The proposed FOS has several benefits, including a self-referencing characteristic, the flexibility to determine FBGs, and a simple structure in terms of the number of devices and measuring procedure. Full article

In this work a radio-frequency self-referencing WDM intensity-based fiber-optic sensor operating in reflective configuration and using virtual instrumentation is presented. The use of virtual delay lines at the reception stage, along with novel flexible self-referencing techniques, and using a single frequency, avoids all-optical or electrical-based delay lines approaches. This solution preserves the self-referencing and performance characteristics of the proposed WDM-based optical sensing topology, and leads to a more compact solution with higher flexibility for the multiple interrogation of remote sensing points in a sensor network. Results are presented for a displacement sensor demonstrating the concept feasibility. Full article

We present two configurations of an amplified fiber-optic-based corrosion sensor using the optical time domain reflectometry (OTDR) technique as the interrogation method. The sensor system is multipoint, self-referenced, has no moving parts and can measure the corrosion rate several kilometers away from the OTDR equipment. The first OTDR monitoring system employs a remotely pumped in-line EDFA and it is used to evaluate the increase in system reach compared to a non-amplified configuration. The other amplified monitoring system uses an EDFA in booster configuration and we perform corrosion measurements and evaluations of system sensitivity to amplifier gain variations. Our experimental results obtained under controlled laboratory conditions show the advantages of the amplified system in terms of longer system reach with better spatial resolution, and also that the corrosion measurements obtained from our system are not sensitive to 3 dB gain variations. Full article

A novel self-referencing fiber optic intensity sensor based on bending losses of a partially polished polymer optical fiber (POF) coupler is presented. The coupling ratio (K) depends on the external liquid in which the sensor is immersed. It is possible to distinguish between different liquids and to detect their presence. Experimental results for the most usual liquids found in industry, like water and oil, are given. K value increases up to 10% from the nominal value depending on the liquid. Sensor temperature dependence has also been studied for a range from 25 ºC (environmental condition) to 50 ºC. Any sector requiring liquid level measurements in flammable atmospheres can benefit from this intrinsically safe technology. Full article
