In the mosaic creation of multiple high-resolution synthetic aperture radar (SAR) images, achieving an optimal seamline in overlapping areas is crucial for seamless and visually satisfactory results. Many existing seamline generation methods are designed primarily for optical remote sensing images, but due to the differing characteristics of SAR images and optical images, applying these methods directly to SAR images poses challenges in finding the optimal seamline. In response, this paper proposes a segmentation-based optimal seamline generation (SOSG) method for SAR image mosaics. The SOSG method involves a multi-step process. First, SAR image joint segmentation is performed within the overlapping areas. Subsequently, homogeneous areas are identified based on the segmentation results. Following this, a pixel cost matrix is constructed, incorporating homogeneous areas and intensity differences. Finally, the minimum path cost from the starting pixel to the end pixel is computed using the Dijkstra algorithm to determine the optimal path. To assess the feasibility and effectiveness of the proposed method, experiments are conducted using multiple SAR images from the Chinese Gaofen-3 01 satellite as datasets. The experimental results demonstrate that the proposed method yields seamless mosaic images when compared to other methods, while delivering satisfactory outcomes. This indicates the potential of the proposed method in addressing the unique challenges posed by SAR images and enhancing the quality of SAR image mosaics. Full article

To generate an orthophoto mosaic from a collection of aerial images, the original images are first orthorectified individually using a Digital Surface Model (DSM). Then, they are stitched together along some determined seamlines to form the orthophoto mosaic. Determining appropriate seamlines is a critical process, as it affects the visual and geometric quality of the results. The stitching process can usually be done in frame-to-frame or multi-frame modes. Although the latter is more efficient, both still involve a lot of pre-processing, such as creating individual orthophotos, image registration, and overlap extraction. This paper presents a novel coarse-to-fine approach that directly determines the seamline network without such pre-processing. Our method has been specifically applied for UAV photogrammetry projects where, due to the large number of images and the corresponding overlaps, the orthophoto mosaic generation can be very challenging and time-consuming. We established the seamlines simultaneously for all the images through a two-step process. First, a DSM was generated, and a low-resolution grid was overlayed. Then, for each grid point, an optimal image was selected. Then, the grid cells are grouped into polygons based on their corresponding optimal image. Boundaries of these polygons established our seamline network. Thereafter, to generate the orthophoto mosaic, we overlayed a higher/full resolution grid on the top of the DSM, the optimal image of each point of which was quickly identified via our low-resolution polygons. In this approach, not only seamlines were automatically generated, but also were the need for the creation, registration, and overlap extraction of individual orthophotos. Our method was systematically compared with a conventional frame-to-frame (CF) technique from different aspects, including the number of double-mapped areas, discontinuities across the seamlines network, and the amount of processing time. The outcomes revealed a 46% decrease in orthophoto generation time and a notable reduction in the number of double-mapped areas, sawtooth effects, and object discontinuities within the constructed orthophoto mosaic. Full article

Seamline network generation is a crucial step in mosaicking multiple orthoimages. It determines the topological and mosaic contribution area for each orthoimage. Previous methods, such as Voronoi-based and AVOD (area Voronoi)-based, may generate mosaic holes in low-overlap and irregular orthoimage cases. This paper proposes a Voronoi centerline-based seamline network generation method to address this problem. The first step is to detect the edge vector of the valid orthoimage region; the second step is to construct a Voronoi triangle network using the edge vector points and extract the centerline of the network; the third step is to segment each orthoimage by the generated centerlines to construct the image effective mosaic polygon (EMP). The final segmented EMP is the mosaic contribution region. All EMPs are interconnected to form a seamline network. The main contribution of the proposed method is that it solves the mosaic holes in the Voronoi-based method when processing with low overlap, and it solves the limitation of the AVOD-based method polygon shape requirement, which can generate a complete mosaic in any overlap and any shape of the orthoimage. Five sets of experiments were conducted, and the results show that the proposed method surpasses the well-known state-of-the-art method and commercial software in terms of adaptability and effectiveness. Full article

Image mosaicking which is a process of constructing multiple orthoimages into a single seamless composite orthoimage, is one of the key steps for the production of large-scale digital orthophoto maps (DOM). Seamline determination is one of the most difficult technologies in the automatic mosaicking of orthoimages. The seamlines that follow the centerlines of roads where no significant differences exist are beneficial to improve the quality of image mosaicking. Based on this idea, this paper proposes a novel method of seamline determination based on road probability map from the D-LinkNet neural network for urban image mosaicking. This method optimizes the seamlines at both the semantic and pixel level as follows. First, the road probability map is obtained with the D-LinkNet neural network and related post processing. Second, the preferred road areas (PRAs) are determined by binarizing the road probability map of the overlapping area in the left and right image. The PRAs are the priority areas in which the seamlines cross. Finally, the final seamlines are determined by Dijkstra’s shortest path algorithm implemented with binary min-heap at the pixel level. The experimental results of three group data sets show the advantages of the proposed method. Compared with two previous methods, the seamlines obtained by the proposed method pass through the less obvious objects and mainly follow the roads. In terms of the computational efficiency, the proposed method also has a high efficiency. Full article

To generate an orthoimage product, mosaicking is a necessary process, and seam-based mosaicking of orthoimages is popular. However, many of these methods only focus on the generation of seamlines between two adjacent orthoimages, so the final generated mosaicking image depends on the order of compositing. To address this shortcoming, this paper presents an initial seamline network generation method based on improved seeded region growing. The basis of this method is the use of raster data rather than vector calculation, which is used with the area Voronoi diagrams with overlap (AVDO)-based method. First, the effective area of each image and overlap regions between adjacent images are determined. Then, the improved seeded region growing algorithm obtains the seamlines of each overlap region. The main improvement is that the boundary lines of overlap regions, rather than individual points, are chosen as seeds of the seeded region growing algorithm. These seeds grow simultaneously until growing regions overlap. The generated separatrix of growing regions is regarded as the seamline in the overlap region. At the same time, the cut result of the image’s effective area is obtained. After that, these generated cut images are intersected to generate the effective mosaic polygon (EMP) of the image. Finally, all generated EMPs are vectorized to form the initial seamline network. In this way, the proposed method can process any kind of overlap region, and the final generated seamline network has no relation to the order of the image compositing. The experimental results demonstrate that the presented method is feasible and can achieve higher accuracy than the previous AVDO-based method. Full article

This paper presents a novel method of seamline determination for remote sensing image mosaicking. A two-level optimization strategy is applied to determine the seamline. Object-level optimization is executed firstly. Background regions (BRs) and obvious regions (ORs) are extracted based on the results of parametric kernel graph cuts (PKGC) segmentation. The global cost map which consists of color difference, a multi-scale morphological gradient (MSMG) constraint, and texture difference is weighted by BRs. Finally, the seamline is determined in the weighted cost from the start point to the end point. Dijkstra’s shortest path algorithm is adopted for pixel-level optimization to determine the positions of seamline. Meanwhile, a new seamline optimization strategy is proposed for image mosaicking with multi-image overlapping regions. The experimental results show the better performance than the conventional method based on mean-shift segmentation. Seamlines based on the proposed method bypass the obvious objects and take less time in execution. This new method is efficient and superior for seamline determination in remote sensing image mosaicking. Full article

Intelligent seamline selection for image mosaicking is an area of active research in the fields of massive data processing, computer vision, photogrammetry and remote sensing. In mosaicking applications for digital orthophoto maps (DOMs), the visual transition in mosaics is mainly caused by differences in positioning accuracy, image tone and relief displacement of high ground objects between overlapping DOMs. Among these three factors, relief displacement, which prevents the seamless mosaicking of images, is relatively more difficult to address. To minimize visual discontinuities, many optimization algorithms have been studied for the automatic selection of seamlines to avoid high ground objects. Thus, a new automatic seamline selection algorithm using a digital surface model (DSM) is proposed. The main idea of this algorithm is to guide a seamline toward a low area on the basis of the elevation information in a DSM. Given that the elevation of a DSM is not completely synchronous with a DOM, a new model, called the orthoimage elevation synchronous model (OESM), is derived and introduced. OESM can accurately reflect the elevation information for each DOM unit. Through the morphological processing of the OESM data in the overlapping area, an initial path network is obtained for seamline selection. Subsequently, a cost function is defined on the basis of several measurements, and Dijkstra’s algorithm is adopted to determine the least-cost path from the initial network. Finally, the proposed algorithm is employed for automatic seamline network construction; the effective mosaic polygon of each image is determined, and a seamless mosaic is generated. The experiments with three different datasets indicate that the proposed method meets the requirements for seamline network construction. In comparative trials, the generated seamlines pass through fewer ground objects with low time consumption. Full article
