In the drum mixing of particulate polymers, segregation may occur. By measuring the mixing status in real time, it is possible to implement corrective measures to prevent separation and improve the efficiency of the process. This study aims to develop and validate a real-time vision system designed to monitor the mixing process of polymeric particles in a rotary drum mixer, employing a novel centroid-based model for determining the mixing index. The proposed centroid-based model is capable of addressing the radial particle segregation issue without the need for extra image-processing procedures like image subdivision or pixel randomization. This innovative approach greatly improves computational efficiency by processing over 68 image frames per second. The new processing method is 2.8 times faster than the gray-level co-occurrence matrix method and 21.6 times faster than the Lacey index approach. This significantly improves real-time monitoring capabilities and enables real-time image processing using only affordable single-board computers and webcams. The proposed vision-based system for monitoring rotary drum mixing has undergone validation via cross-validation using discrete element method simulations, ensuring its accuracy and reliability. Full article

The production of catalysts such as zeolites is a complex multiscale and multi-step process. Various material properties, such as particle size or moisture content, as well as operating parameters—e.g., temperature or amount and composition of input material flows—significantly affect the outcome of each process step, and hence determine the properties of the final product. Therefore, the design and optimization of such processes is a complex task, which can be greatly facilitated with the help of numerical simulations. This contribution presents a modeling framework for the dynamic flowsheet simulation of a zeolite production sequence consisting of four stages: precipitation in a batch reactor; concentration and washing in a block of centrifuges; formation of droplets and drying in a spray dryer; and burning organic residues in a chain of rotary kilns. Various techniques and methods were used to develop the applied models. For the synthesis in the reactor, a multistage strategy was used, comprising discrete element method simulations, data-driven surrogate modeling, and population balance modeling. The concentration and washing stage consisted of several multicompartment decanter centrifuges alternating with water mixers. The drying is described by a co–current spray dryer model developed by applying a two-dimensional population balance approach. For the rotary kilns, a multi-compartment model was used, which describes the gas–solid reaction in the counter–current solids and gas flows. Full article

This paper presents a mathematical model of the heat and mass transfer processes for a rotary-spray honey dehydrator with a heat pump and a closed air circuit. An analytical calculation model, based on the energy balance equations of the dehydrator and heat pump, was used to model the transient dehydration process of honey in a dehydrator. The presented article includes a different approach to modelling both the dryer and the heat pump assisting the drying process. The novel quality of this study lies in the use of original equations to determine the heat and mass transfer coefficients between honey and air and using an actual model of a cooling unit to model the honey dehydration process. The experimentally verified calculation algorithm enables an analysis of the effects of air flow rate, mixer rotation speed, and cooling unit power on the efficiency of the drying process. The dehydrator calculation model was used to minimize the drying time by selecting the optimal evaporative temperature values of the cooling unit. For fixed mixer speed and air flow rates, optimal values of evaporation temperatures allow for 8–13% reduction in honey drying time and an increase in the specific moisture extraction rate (SMER) by 4–32%. Full article

Unit operations (UO) are mostly used in non-ferrous extractive metallurgy (NFEM) and usually separated into three categories: (1) hydrometallurgy (leaching under atmospheric and high pressure conditions, mixing of solution with gas and mechanical parts, neutralization of solution, precipitation and cementation of metals from solution aiming purification, and compound productions during crystallization), (2) pyrometallurgy (roasting, smelting, refining), and (3) electrometallurgy (aqueous electrolysis and molten salt electrolysis). The high demand for critical metals, such as rare earth elements (REE), indium, scandium, and gallium raises the need for an advance in understanding of the UO in NFEM. The aimed metal is first transferred from ores and concentrates to a solution using a selective dissolution (leaching or dry digestion) under an atmospheric pressure below 1 bar at 100 °C in an agitating glass reactor and under a high pressure (40–50 bar) at high temperatures (below 270 °C) in an autoclave and tubular reactor. The purification of the obtained solution was performed using neutralization agents such as sodium hydroxide and calcium carbonate or more selective precipitation agents such as sodium carbonate and oxalic acid. The separation of metals is possible using liquid (water solution)/liquid (organic phase) extraction (solvent extraction (SX) in mixer-settler) and solid-liquid filtration in chamber filter-press under pressure until 5 bar. Crystallization is the process by which a metallic compound is converted from a liquid into a crystalline state via a supersaturated solution. The final step is metal production using different methods (aqueous electrolysis for basic metals such as copper, zinc, silver, and molten salt electrolysis for REE and aluminum). Advanced processes, such as ultrasonic spray pyrolysis, microwave assisted leaching, and can be combined with reduction processes in order to produce metallic powders. Some preparation for the leaching process is performed via a roasting process in a rotary furnace, where the sulfidic ore was first oxidized in an oxidic form which is a suitable for the metal transfer to water solution. UO in extractive metallurgy of REE can be successfully used not only for the metal wining from primary materials, but also for its recovery from secondary materials. Full article

Scant attention has been given to understanding the impact of creaming stability on the final structure of semi-sweet biscuits, an aspect that has traditionally concerned the biscuit industry. Accordingly, the aim of this study was to analyze the influence of the creaming phase stability on the quality attributes of rotary-molded biscuits. Doughs were formulated with 10.2% of fat (wet basis) and 16.3% of sucrose (w.b.), using two sucrose particle sizes, which were either added directly or after dilution in water at different concentrations. Additionally, the creaming phase was prepared using either a low-shear or a high-shear mixer. The results show that an aqueous-phase migration occurred when the creaming was blended in a low-shear mixer, when using either powdered sucrose or granular sucrose diluted in water at a high concentration. The phase separation was inhibited with the high-shear mixer, which provided a stable creaming. Notwithstanding the variation in creaming stability, no differences were observed in hardness, aeration, sweetness, color and noise intensity. Additionally, the micro-CT analysis revealed that biscuits had a similar microstructure (air porosity and thickness of biscuit walls) when they were prepared with either an unstable or a stable creaming phase. Consequently, creaming stability does not seem to affect the structure and the most relevant sensory attributes of rotary-molded biscuits under this set of experimental conditions, which are representative of those used by the industry for this product category. Full article

The mixing process in a mechanically agitated vessel is a widespread phenomenon which plays an important role among industrial processes. In that process, one of the crucial parameters, the mixing efficiency, depends on a large number of geometrical factors, as well as process parameters and complex interactions between the phases which are still not well understood. In the last decade, large progress has been made in optimisation, construction and numerical and experimental analysis of mechanically agitated vessels. In this review, the current state in this field has been presented. It shows that advanced computational fluid dynamic techniques for multiphase flow analysis with reactions and modern experimental techniques can be used with success to analyse in detail mixing features in liquid-liquid, gas-liquid, solid-liquid and in more than two-phase flows. The objective is to show the most important research recently carried out. Full article

This paper presents an innovative mixing technology for centrifugal microfluidic platforms actuated using a specially designed flyball governor. The multilayer microfluidic disc was fabricated using a polydimethylsiloxane (PDMS) replica molding process with a soft lithography technique. The operational principle is based on the interaction between the elastic covering membrane and an actuator pin installed on the flyball governor system. The flyball governor was used as the transducer to convert the rotary motion into a reciprocating linear motion of the pin pressing against the covering membrane of the mixer chamber. When the rotation speed of the microfluidic disc was periodically altered, the mixing chamber was compressed and released accordingly. In this way, enhanced active mixing can be achieved with much better efficiency in comparison with diffusive mixing. Full article
