Search Results (66)

In cold-region rock engineering, freeze–thaw cycle-induced crack propagation in fractured rock masses serves as a major cause of disasters such as slope instability. Existing studies primarily focus on the influence of individual fissure parameters, yet lack a systematic analysis of the crack propagation mechanisms under the coupled action of multiple parameters. To address this, we establish three groups of slope models with different rock bridge distances (d), rock bridge angles (α), and fissure angles (β) based on the PFC2D discrete element method. Frost heave loads are simulated by incorporating the volumetric expansion during water–ice phase change. The Parallel Bond Model (PBM) is used to capture the mechanical behavior between particles and the bond fracture process. This reveals the crack evolution laws under freeze–thaw cycles. The results show that, at a short rock bridge distance of d = 60 m, stress concentrates in the fracture zone. This easily leads to the rapid penetration of main cracks and triggers sudden instability. At a long rock bridge distance where d ≥ 100 m, the degree of stress concentration decreases. Meanwhile, the stress distribution range expands, promoting multiple crack initiation points and the development of branch cracks. The number of cracks increases as the rock bridge distance grows. In cases where the rock bridge angle is α ≤ 60°, stress is more likely to concentrate in the fracture zone. The crack propagation exhibits strong synergy, easily forming a penetration surface. When α = 75°, the stress concentration areas become dispersed and their distribution range expands. Cracks initiate earliest at this angle, with the largest number of cracks forming. Cumulative damage is significant under this condition. When the fissure angle is β = 60°, stress concentration areas gather around the fissures. Their distribution range expands, making cracks easier to propagate. Crack propagation becomes more dispersed in this case. When β = 30°, the main crack rapidly penetrates due to stress concentration, inhibiting the development of branch cracks, and the number of cracks is the smallest after freeze–thaw cycles. When β = 75°, the freeze–thaw stress dispersion leads to insufficient driving force, and the number of cracks is 623. The research findings provide a theoretical foundation for assessing freeze–thaw damage in fractured rock masses of cold regions and for guiding engineering stability control from a multi-parameter perspective. Full article

Grouting reinforcement is a pivotal approach to enhancing the integrity and load-bearing capacity of fractures in surrounding rock. In this study, standard limestone specimens were fractured through uniaxial compression. Then, the specimens were reinforced with grouting, using ultrafine cement paste containing varying mass fractions of enhancers and a grouting apparatus developed by the authors. After the specimens were cured under standard conditions for 28 days, CT scanning technology was used to investigate the microstructure and grouting effect characteristics of grouted bodies containing different mass fractions of enhancers from a mesoscopic perspective. Then, uniaxial compression tests were conducted on those grouted specimens. The experimental results revealed that the content of the enhancer significantly affected the post-peak characteristics, mechanical parameters, and failure modes of the grouted specimens. When the content of the enhancer increased from 2.50 wt.% to 15.00 wt.%, the uniaxial compressive strength of the grouted specimens exhibited a positive correlation with the enhancer content, with the maximum improvement rate reaching 18.10% compared to the residual strength. However, when the enhancer content ranged from 15.00 wt.% to 20.00 wt.%, the uniaxial compressive strength was negatively correlated with the enhancer content. At an enhancer content of 15.00 wt.%, the overall stability of the grouted specimens was optimal, with all mechanical parameters reaching their maximum values. Utilizing three-dimensional CT scanning and reconstruction technology, it was observed that when the enhancer content was less than 15.00 wt.%, the cracks were concentrated in the limestone matrix rather than in the grouted solid in the edge regions of grouted specimens. However, in the whole specimens, the cracks in the grouted solid exceeded that in the limestone matrix. Conversely, when the enhancer content was greater than 17.50 wt.%, the grouted solid was predominantly distributed within the edge fissures of the specimens, while the internal regions exhibited a lower volume fraction of the grouted solid. In this scenario, the volume fraction of the grouted solid in the specimens was significantly lower than that of the fissures. Full article

This study establishes a numerical simulation model based on heat and mass transfer theory to reflect the variations in temperature and humidity conditions within a tunnel. It analyzes the impact of high-temperature fissure water, humid porous media, and drainage methods on the temperature and humidity distribution in a tunnel. The results indicate the following: (1) When the area of the humid porous media increases from 150 m² to 300 m², the relative humidity (RH) of the air in the tunnel rises from 52.7% to 55.8%, but the impact on air temperature (T_a) is minimal. (2) The heating and humidification effects of hot water in a drainage ditch on the airflow cannot be overlooked. Meanwhile, the hot water transfers heat to the surrounding rock, with heat transfer predominantly driven by the surrounding rock convection. Compared to a drainage pipe, the heat transfer amount increases by 44.9%, and RH rises by 9.3%. (3) For every increase of 5 °C in water temperature (water volume of 90 m³/h), the ventilation outlet T_a linearly increases by 0.15 °C, and the rate of increase in RH accelerates with rising water temperature. (4) Covering a drainage ditch with a cover plate can reduce RH by 12.3%, while spraying a 10 cm insulation layer on the tunnel walls can significantly lower T_a by 0.66 °C. These findings provide a potential solution for the application of insulation materials in reducing the thermal hazards of deep high temperatures. Full article

Anchored surrounding rock is prone to large nonlinear deformation and instability failure under dynamic disturbances. The fissures and defects within the surrounding rock make the rock mass’s bearing characteristics and deformation instability behavior increasingly complex. To investigate the effect of the fissure angle on the dynamic mechanical response of the anchored body, a dynamic loading model of the anchored, fissured surrounding rock unit body was established based on the finite difference–discrete element coupling method. The main conclusions are as follows: Compared to the indoor test results, this numerical model can accurately simulate the dynamic response characteristics of the unit body. As the fissure angle increased, the dynamic strength, failure strain, and dynamic elastic modulus of the specimen generally decreased and then increased, with a critical angle at approximately 45°. Compared to 0°, when the fissure angle was 45°, the dynamic strength, failure strain, and dynamic elastic modulus decreased by 17.08%, 15.48%, and 9.11%, respectively. Additionally, the evolution process of cracks and fragments shows that the larger the fissure angle, the more likely cracks are to develop along the initial fissure direction, which then triggers the formation of tensile cracks in other regions. Increasing the fissure angle causes the specimen to rupture earlier, making the main rupture plane more directional. Full article

In order to investigate the effect of fissure inclination on the mechanical properties, deformation, and crack evolution of the surrounding rock in the roadway, uniaxial compression experiments were conducted on sandstone-like materials with prefabricated fissures. The high-speed camera and DIC (digital image correlation) method were employed to analyze the strain distribution and the crack evolution of the specimen. The results demonstrated that the presence of fissures reduces the stress for crack initiation, with intact specimens producing new cracks from about 75% of peak strength and fissured specimens producing new cracks from 50% to 60% of peak strength. The fissure reduced the strength and elastic modulus of the specimen while increasing the strain. The fissure inclination of 45° exhibited the most significant changes compared to the intact specimen. The peak strength and elastic modulus decreased by 54.52% and 35.95%, respectively, and the strain increased by 151.42%. The intact specimen and specimen with 90° inclination are mainly distributed with the shear crack, tensile crack, and far-field crack, which are mainly tensile–tension damage; specimens with 0~75° inclination are mainly distributed with the wing crack, anti-wing crack, oblique secondary crack, and coplanar secondary crack, which are mainly shear slip damage. The direction of the extension of cracks is related to the fissure inclination. For specimens with 0° inclination, the new cracks mainly propagate in the direction perpendicular to the fissure; for specimens with 30° and 45° inclinations, the new cracks mainly propagate in the direction parallel and perpendicular to the fissure; for specimens with 60° and 75° inclinations, the new cracks propagate in the direction parallel to the fissure; and for specimens with 90° inclination, the new cracks propagate in the direction parallel to the fissure. Full article

The radius of the failure area after a blasting fracture process of burnt rock is affected by joint fissures, does not conform to the existing theoretical calculation formula and the distribution law of the failure area also changes. The fracture area is large, and the fracture extension and expansion area are small. Therefore, in order to describe the damage of blasting to a fractured rock mass more objectively and accurately, on the basis of summarizing the previous research results, a damage variable was introduced to characterize the initial crushing degree of the fractured rock mass, and the corresponding rock failure criterion was used to derive the calculation formula of a blasting crushing circle and fracture circle radius of burnt rock with different charge structures. The results show that the blasting failure zone of fractured rock mass with different charge structures was not only related to the radius of the blast hole and the explosive and rock properties, but also had a strong relationship with the initial damage degree of the rock mass. Taking an open-pit coal mine in Xinjiang as an example, the radius of the fracture zone with different charge structures was obtained by using the obtained calculation formula, and it was applied to the determination of row spacing and hole spacing. Full article

A rock mass is mainly subjected to a high internal pressure load in the lined rock cavern (LRC) for compressed air energy storage (CAES). However, under the action of long-term cyclic loading and unloading, the mechanical properties of a rock mass will deteriorate, affecting the long-term stability of the cavern. The fissures in the rock mass will expand and generate new cracks, causing varying degrees of damage to the rock mass. Most of the existing studies are based on the test data of complete rock samples and the fissures in the rock mass are ignored. In this paper, the strain equivalence principle is used to couple the initial damage variable caused by the fissures and the fatigue damage variable of a rock mass to obtain the damage variable of a rock mass under cyclic stress. Then, based on the ANSYS 17.0 platform, the ANSYS Parametric Design Language (APDL) is used to program the rock mass elastic modulus evolution equation, and a calculation program of the rock mass damage model is secondarily developed. The calculation program is verified by a cyclic loading and unloading model test. It is applied to the construction project of underground LRC for CAES in Northwest China. The calculation results show that the vertical radial displacement of the rock mass is 8.39 mm after the 100th cycle, which is a little larger than the 7.53 mm after the first cycle. The plastic zone of the rock mass is enlarged by 4.71 m², about 11.49% for 100 cycles compared to the first cycle. Our calculation results can guide the design and calculation of the LRC, which is beneficial to the promotion of the CAES technology. Full article

Understanding the dynamics of damaged rock masses and the evolution of internal fractures is beneficial to the construction of deep engineering projects. Dynamic tests on damaged granite were carried out using a split Hopkinson device which can apply a confining pressure. A group of damaged granites was CT-scanned and three-dimensional reconstructed using Avizo 2020.1 software. The results indicate that with increasing damage, the peak stress and peak modulus of the damaged granite decrease, while the peak strain increases. When the initial damage is consistent, all three parameters increase with the increasing confining pressure. Confining pressure alters the number and development direction of internal fissures in granite. Higher confining pressure results in fewer fissures, with their development direction shifting more towards the center of the sample and becoming straighter. The total volume of fissures within the rock samples, the volume of through fissures, and the maximum length of the fissures are decreasing with the increase in the confining pressure. In addition, the three-dimensional fractal dimension and the internal damage also decreased continuously with the increase in the confining pressure. This research provides valuable theoretical guidance for supporting and constructing surrounding rock in deep engineering projects. Full article

When mineral resources are extracted using underground mining methods in hilly regions, landslides or slope failures can be induced frequently. In this study, slope collapse disasters in mountain mining areas were analyzed. The model test and numerical simulation of the slope impacted by repeated mining were carried out. The crack evolution and failure process were analyzed to reveal the instability mechanism. The results show that the rock mass would topple to the inside of the slope first, when the subsidence of overlying rock was induced by the mining of the upper coal seam. When repeated mining was performed in the lower coal seam, the mining induced macro-cracks that could connect with natural fissures, inducing the outward displacement of the slope. Then, the rock mass at the foot of the slope has to bear the upper load, which is also squeezed out by the collapsed rock mass, forming the potential slip zone. Finally, the instability is caused by the shear slip of the slope toe rock mass. Therefore, the instability evolution of the slope under underground repeated mining disturbance can be divided into four stages as follows: roof caving and overlaying rock subsidence, joint rock toppling, fracture penetration, and slope toe shearing and slope slipping. Full article

With economic development and coal resource exploitation, the area of mined-out zones is expanding continuously. The traditional waste disposal methods no longer meet the current demands, making it urgent to evaluate and reuse the surface stability of these mined-out zones. Surface residual deformation is a process where voids and fissures within the mined-out zones are gradually filled and compacted, affecting the overlying rock structure. Additionally, groundwater significantly impacts the strength of the overlying rock, leading to increased subsidence. Therefore, predicting surface residual deformation while considering the effects of groundwater is crucial for forecasting surface deformation and assessing stability in mined-out zones. This study, taking into account the characteristics of subsidence zones and the impact of groundwater on the compaction of fractured rock masses, uses equivalent mining height and probability integral methods to develop a predictive model for surface residual deformation incorporating groundwater effects. Predictions for the study area show that groundwater exacerbates surface residual deformation, with various deformation values ranging from 33.8% to 51.9%. The surface stability categories are divided into stable and essentially stable regions based on the residual deformation’s impact on the working face. This model fully considers the influence of groundwater on residual deformation in mined-out zones, refining existing mining subsidence theories, addressing deformation issues caused by adverse groundwater factors, and providing a theoretical basis for predicting residual deformation and evaluating stability in mined-out zones, promoting the sustainable development of land and environmental resources in mining areas. Full article

The technological requirements for mining are becoming more and more complex as underground coal mining depth increases. The issue that the concentration of mining stress causes an increase in the degree of rock fracture formation in the stope is one of them, and it has a significant impact on the mine’s production safety and efficiency. Using a pseudo-triaxial compression experimental platform, the effects of confining pressure on the strength, deformation, and fracture propagation route of fractured sandy mudstone were investigated in order to explore the mechanical characteristics of fractured rock mass. The findings demonstrate that the stress and strain curves of split sandy mudstone vary from those of intact specimens in that they are stepped and have several stress decreases. High frequency and low energy levels are released by fractured sandy mudstone, while high frequency and low energy levels are released by unbroken rock. The strength of sandy mudstone is less sensitive to confining pressure when prefabricated fissures are present. Specimens with fractures have a roughly 80% reduction in shear strength while confining pressure remains constant. The fracture propagation route of the intact rock is parallel to the section where the highest shear stress is found, whereas the fracture propagation path of the fractured sandy mudstone progressively expands from the constructed fracture tip to the specimen border. The degree of fracture development in fractured sandy mudstone is greater under the same stress mechanism, and the rock breaks more readily. Full article

In nature, rock masses often exhibit fissures, and varying external forces lead to different rates of loading on fissured rock masses. By studying the influence of the loading rate on the mechanical properties of fractured rock mass and AE characteristic parameters, it can provide a theoretical basis for the safety and stability prediction of engineering rock mass. To investigate the influence of loading rates on fissured rock masses, this study utilizes surrogate rock specimens resembling actual rock bodies and prefabricates two fissures. By conducting uniaxial compression acoustic emission tests at different loading rates, the study explores changes in their mechanical properties and acoustic emission characteristic parameters. Research findings indicate the following: (1) Prefabricated fissures adversely affect the stability of specimens, resulting in lower strength compared to intact specimens. Under the same fissure inclination angle, peak strength, elastic modulus, and loading rate exhibit a positive correlation. When the fissure inclination angle varies from 0° to 60° under the same loading rate, the peak strength of specimens generally follows a “V”-shaped trend, decreasing initially and then increasing, with the minimum peak strength observed at α = 30°. (2) Prefabricated fissure specimens primarily develop tensile cracks during loading, gradually transitioning to shear cracks, ultimately leading to shear failure. (3) The variation patterns of AE (acoustic emission) characteristic parameters under the influence of loading rate differ: AE event count, AE energy, and cumulative AE energy show a positive correlation with loading rate, while cumulative AE event count gradually decreases with increasing loading rate. (4) AE characteristic parameters exhibit good correlation with the stress–strain curve and can be divided into four stages. The changes in AE characteristic parameters correspond to the changes in the stress–strain curve. With increasing loading rate, AE signals in the first three stages gradually stabilize, focusing more on the fourth stage, namely the post-peak stage, where the specimens typically experience maximum AE signals accompanying final failure. Full article

The physical model test is an effective method to study the bearing behavior of digging hold foundations due to its low cost and clear boundary conditions. Here, similar materials of rocks were configured and employed to study the bearing capacity and failure model of digging hold foundations in rock ground. Firstly, sixteen groups of material proportion schemes were employed to make similar materials of rocks, and the effects of four mix parameters were analyzed. Then, similar materials of rocks were employed to perform the uplift tests of digging hold foundations. The results show that the mass ratio of fine particles and aggregate has the greatest influence on the density and internal friction angle, while the cement moisture content has the greatest influence on the cohesion and compressive strength of similar materials of rocks. During the pull-out process of the digging hold foundation, the radial cracks radiate outward from the circumferential cracks, which is different from those in the field test because the ground is small and uniform without fissures inside. The foundation drives the surrounding similar materials to be pulled up as a whole with a certain failure angle, which increases from 35.7° to 42.5° as the internal friction angle decreases from 56° to 41°. In addition, the ratio between the equivalent shear strength in Chinese Code and uniaxial compressive strength falls in the range of 0.027–0.05. Full article

The mechanical properties of frozen fissured rock masses are crucial considerations for engineering in frozen earth. However, there has been little research on the mechanical properties of frozen fissured sandstone, including its strength, deformation, and geometric parameters. In this study, sandstone samples with three open en echelon fissures were observed using high-speed photography and acoustic emissions during uniaxial compression tests. The aim was to investigate sandstone’s strength, deformability, and failure process in order to elucidate the effects of freezing on its mechanical properties. In the frozen-saturated and dried states, the uniaxial compression strength (UCS) initially decreases and then increases with an increase in fissure inclination angle. Conversely, the UCS of samples in the saturated state continuously increases. The UCS follows a decreasing trend, as follows: frozen-saturated state > dried state > saturated state. The initial crack angle decreases as the fissure inclination increases in all states, irrespective of temperature and moisture conditions. However, the initial crack stress and time show an increasing trend. The uniaxial compression strength (UCS) of frozen fissured sandstone is influenced by four mechanisms: (1) ice provides support to the rock under compression, (2) ice fills microcracks, (3) unfrozen water films act as a cementing agent under tension or shearing loads, and (4) frost damage leads to softening of the rock. Full article

China is renowned for its extensive underground engineering projects and the complex geological and hydrological conditions it faces. Grouting treatment technology is widely employed in deep-buried mines and tunnels, where grouting parameters such as materials, pressure, volume, and hole arrangement significantly impact the effectiveness of grouting. This review paper comprehensively examines current research on grouting materials, theories, experiments, and numerical simulations. It summarizes the various factors that must be considered during the grouting process of fissures and explores the diffusion mechanisms of grout under their influence. Furthermore, further research is needed on the mechanisms and treatment methods for poor grouting in rock masses, the distribution patterns of fissures, optimization methods for grouting parameters, and grout quality assessment techniques. Future research should focus on developing more efficient experimental methods with higher accuracy levels while advancing grouting technologies. Establishing comprehensive and accurate rock mass models along with improving monitoring capabilities are also crucial aspects to consider. Therefore, studying the diffusion mechanisms of grout in fissured rock masses is of significant importance for the practical operation of underground engineering projects. Full article
