Background: Elastic image fusion (EIF) using an intraoperative CT (iCT) scan may enhance neuronavigation accuracy and compensate for brain shift. Objective: To evaluate the safety and reliability of the EIF algorithm (Virtual iMRI Cranial 4.5, Brainlab AG, Munich Germany, for the identification of residual tumour in glioblastoma surgery. Moreover, the impact of brain shift on software reliability is assessed. Methods: This ambispective study included 80 patients with a diagnosis of glioblastoma. Pre-operative MRI was elastically fused with an intraoperative CT scan (BodyTom; Samsung-Neurologica, Danvers, MA, USA) acquired at the end of the resection. Diagnostic specificity and the sensitivity of each tool was determined. The impact of brain shift on residual tumour was statistically analysed. An analysis of accuracy was performed through Target Registration Error (TRE) measurement after rigid image fusion (RIF) and EIF. A qualitative evaluation of each Virtual MRI image (VMRI) was performed. Results: VMRI identified residual tumour in 26/80 patients (32.5%), confirmed by post-operative MRI (true positive). Of these, 5 cases were left intentionally due to DES-positive responses, 8 cases underwent near maximal or subtotal resection, and 13 cases were not detected by iCT. However, in the other 27/80 cases (33.8%), VMRI reported residual tumour that was present neither on iCT nor on post-operative MRI (false positive). i-CT showed a sensitivity of 56% and specificity of 100%; VMRI demonstrated a sensitivity of 100% and specificity of 50%. Spearman correlation analysis showed a moderate correlation between pre-operative volume and VMRI tumour residual. Moreover, tumour involving insula or infiltrating more than one lobe displayed higher median values (p = 0.023) of virtual residual tumour. A statistically significant reduction towards lower TRE values after EIF was observed for test structures. Conclusions: Virtual iMRI was proven to be a feasible option to detect residual tumour. Its integration within a multimodal imaging protocol may provide neurosurgeons with intraoperatively updated imaging. Full article

Non-rigid point cloud registration holds significant importance for human body pose analysis in the fields of sports, medicine, gaming, etc. In this paper, we propose a non-rigid point cloud registration algorithm based on geodesic distance measurement, which can improve the accuracy of the registration for matching point pairs during non-rigid deformations. Firstly, a graph is constructed for two sets of point clouds using geodesic distance measurement considering that geodesic distance changes minimally during non-rigid deformation of the human body, which can preserve the point cloud matching information between corresponding points. Furthermore, a maximal clique search is employed to find combinations of matching pairs between point clouds. Finally, by driving the human body model parameters, sparse matching pairs are overlapped as much as possible to achieve non-rigid point cloud registration of the human body. The accuracy of the proposed algorithm is verified with FAUST and CAPE datasets. Full article

The challenges of point cloud registration in intelligent vehicle driving lie in the large scale, complex distribution, high noise, and strong sparsity of lidar point cloud data. This paper proposes an efficient registration algorithm for large-scale outdoor road scenes by selecting the continuous distribution of key area laser point clouds as the registration point cloud. The algorithm extracts feature descriptions of the key point cloud and introduces local geometric features of the point cloud to complete rough and fine registration under constraints of key point clouds and point cloud features. The algorithm is verified through extensive experiments under multiple scenarios, with an average registration time of 0.5831 s and an average accuracy of 0.06996 m, showing significant improvement compared to other algorithms. The algorithm is also validated through real-vehicle experiments, demonstrating strong versatility, reliability, and efficiency. This research has the potential to improve environment perception capabilities of autonomous vehicles by solving the point cloud registration problem in large outdoor scenes. Full article

Objective: Respiratory movements are a significant factor that may hinder the use of image navigation systems during minimally invasive procedures used to destroy focal lesions in the liver. This article aims to present a method of estimating the displacement of the target point due to respiratory movements during the procedure, working in real time. Method: The real-time method using skin markers and non-rigid registration algorithms has been implemented and tested for various classes of transformation. The method was validated using clinical data from 21 patients diagnosed with liver tumors. For each patient, each marker was treated as a target and the remaining markers as target position predictors, resulting in 162 configurations and 1095 respiratory cycles analyzed. In addition, the possibility of estimating the respiratory phase signal directly from intraoperative US images and the possibility of synchronization with the 4D CT respiratory sequence are also presented, based on ten patients. Results: The median value of the target registration error (TRE) was 3.47 for the non-rigid registration method using the combination of rigid transformation and elastic body spline curves, and an adaptation of the assessing quality using image registration circuits (AQUIRC) method. The average maximum distance was 3.4 (minimum: 1.6, maximum 6.8) mm. Conclusions: The proposed method obtained promising real-time TRE values. It also allowed for the estimation of the TRE at a given geometric margin level to determine the estimated target position. Directions for further quantitative research and the practical possibility of combining both methods are also presented. Full article

Entire surface point clouds in complex objects cannot be captured in a single direction by using noncontact measurement methods, such as machine vision; therefore, different direction point clouds should be obtained and registered. However, high efficiency and precision are crucial for registration methods when dealing with huge number of point clouds. To solve this problem, an improved registration algorithm based on double threshold feature extraction and distance disparity matrix (DDM) is proposed in this study. Firstly, feature points are extracted with double thresholds using normal vectors and curvature to reduce the number of points. Secondly, a fast point feature histogram is established to describe the feature points and obtain the initial corresponding point pairs. Thirdly, obviously wrong corresponding point pairs are eliminated as much as possible by analysing the Euclidean invariant features of rigid body transformation combined with the DDM algorithm. Finally, the sample consensus initial alignment and the iterative closest point algorithms are used to complete the registration. Experimental results show that the proposed algorithm can quickly process large data point clouds and achieve efficient and precise matching of target objects. It can be used to improve the efficiency and precision of registration in distributed or mobile 3D measurement systems. Full article

The intelligent road is an important component of the intelligent vehicle infrastructure cooperative system, the latest development of intelligent transportation systems. As an advanced sensor, Light Detection and Ranging (LiDAR) has gradually been used to collect high-resolution micro-traffic data on the roadside of intelligent roads. Furthermore, a fusion of multiple LiDARs has become a current hot spot to extend the data collection range and improve detection accuracy. This paper focuses on point cloud registration in a complex traffic environment and proposes a three-dimensional (3D) registration method based on traffic signs and prior knowledge of traffic scenes. Traffic signs with their reflective films are used as reference targets to register 3D point cloud data from roadside LiDARs. The proposed method consists of a vertical registration and a horizontal registration. For the vertical registration, we propose a panel rotation algorithm to rotate the initial point cloud to register it vertically, converting the 3D point cloud registration into a two-dimensional (2D) rigid body transformation. For the vertical registration, our system registers traffic signs from different LiDARs. Our method has been verified in some actual scenarios. Compared with previous methods, the proposed method is automatic and does not need to search reference targets manually. Furthermore, it is suitable for actual engineering use and can be applied to sparse point cloud data from LiDAR with few beams, realizing point cloud registration of large disparity. Full article

In 3D reconstruction applications, an important issue is the matching of point clouds corresponding to different perspectives of a particular object or scene, which is addressed by the use of variants of the Iterative Closest Point (ICP) algorithm. In this work, we introduce a cloud-partitioning strategy for improved registration and compare it to other relevant approaches by using both time and quality of pose correction. Quality is assessed from a rotation metric and also by the root mean square error (RMSE) computed over the points of the source cloud and the corresponding closest ones in the corrected target point cloud. A wide and plural set of experimentation scenarios was used to test the algorithm and assess its generalization, revealing that our cloud-partitioning approach can provide a very good match in both indoor and outdoor scenes, even when the data suffer from noisy measurements or when the data size of the source and target models differ significantly. Furthermore, in most of the scenarios analyzed, registration with the proposed technique was achieved in shorter time than those from the literature. Full article

With advancements in photoelectric technology and computer image processing technology, the visual measurement method based on point clouds is gradually being applied to the 3D measurement of large workpieces. Point cloud registration is a key step in 3D measurement, and its registration accuracy directly affects the accuracy of 3D measurements. In this study, we designed a novel MPCR-Net for multiple partial point cloud registration networks. First, an ideal point cloud was extracted from the CAD model of the workpiece and used as the global template. Next, a deep neural network was used to search for the corresponding point groups between each partial point cloud and the global template point cloud. Then, the rigid body transformation matrix was learned according to these correspondence point groups to realize the registration of each partial point cloud. Finally, the iterative closest point algorithm was used to optimize the registration results to obtain the final point cloud model of the workpiece. We conducted point cloud registration experiments on untrained models and actual workpieces, and by comparing them with existing point cloud registration methods, we verified that the MPCR-Net could improve the accuracy and robustness of the 3D point cloud registration. Full article

Traditional feature matching methods of optical and synthetic aperture radar (SAR) used gradient are sensitive to non-linear radiation distortions (NRD) and the rotation between two images. To address this problem, this study presents a novel approach to solving the rigid body rotation problem by a two-step process. The first step proposes a deep learning neural network named RotNET to predict the rotation relationship between two images. The second step uses a local feature descriptor based on the Gaussian pyramid named Gaussian pyramid features of oriented gradients (GPOG) to match two images. The RotNET uses a neural network to analyze the gradient histogram of the two images to derive the rotation relationship between optical and SAR images. Subsequently, GPOG is depicted a keypoint by using the histogram of Gaussian pyramid to make one-cell block structure which is simpler and more stable than HOG structure-based descriptors. Finally, this paper designs experiments to prove that the gradient histogram of the optical and SAR images can reflect the rotation relationship and the RotNET can correctly predict them. The similarity map test and the image registration results obtained on experiments show that GPOG descriptor is robust to SAR speckle noise and NRD. Full article

The performance of marker-based, six degrees of freedom (6DOF) pose measuring systems is investigated. For instruments in this class, the pose is derived from locations of a few three-dimensional (3D) points. For such configurations to be used, the rigid-body condition—which requires that the distance between any two points must be fixed, regardless of orientation and position of the configuration—must be satisfied. This report introduces metrics that gauge the deviation from the rigid-body condition. The use of these metrics is demonstrated on the problem of reducing robot localization error in assembly applications. Experiments with two different systems used to reduce the localization error of the same industrial robot yielded two conflicting outcomes. The data acquired with one system led to substantial reduction in both position and orientation error of the robot, while the data acquired with a second system led to comparable reduction in the position error only. The difference is attributed to differences between metrics used to characterize the two systems. Full article

Iterative closest point (ICP) is a method commonly used to perform scan-matching and registration. To be a simple and robust algorithm, it is still computationally expensive, and it has been regarded as having a crucial challenge especially in a real-time application as used for the simultaneous localization and mapping (SLAM) problem. For these reasons, this paper presents a new method for the acceleration of ICP with an assisted intensity. Unlike the conventional ICP, this method is proposed to reduce the computational cost and avoid divergences. An initial transformation guess is computed with an assisted intensity for their relative rigid-body transformation. Moreover, a target function is proposed to determine the best initial transformation guess based on the statistic of their spatial distances and intensity residuals. Additionally, this method is also proposed to reduce the iteration number. The Anderson acceleration is utilized for increasing the iteration speed which has better ability than the Picard iteration procedure. The proposed algorithm is operated in real time with a single core central processing unit (CPU) thread. Hence, it is suitable for the robot which has limited computation resources. To validate the novelty, this proposed method is evaluated on the SEMANTIC3D.NET benchmark dataset. According to comparative results, the proposed method is declared as having better accuracy and robustness than the conventional ICP methods. Full article

C-arm cone-beam computed tomography (CBCT) has been used recently to acquire images of the human knee joint under weight-bearing conditions to assess knee joint health under load. However, involuntary patient motion during image acquisition leads to severe motion artifacts in the subsequent reconstructions. The state-of-the-art uses fiducial markers placed on the patient’s knee to compensate for the induced motion artifacts. The placement of markers is time consuming, tedious, and requires user experience, to guarantee reliable motion estimates. To overcome these drawbacks, we recently investigated whether range imaging would allow to track, estimate, and compensate for patient motion using a range camera. We argue that the dense surface information observed by the camera could reveal more information than only a few surface points of the marker-based method. However, the integration of range-imaging with CBCT involves flexibility, such as where to position the camera and what algorithm to align the data with. In this work, three dimensional rigid body motion is estimated for synthetic data acquired with two different range camera trajectories: a static position on the ground and a dynamic position on the C-arm. Motion estimation is evaluated using two different types of point cloud registration algorithms: a pair wise Iterative Closest Point algorithm as well as a probabilistic group wise method. We compare the reconstruction results and the estimated motion signals with the ground truth and the current reference standard, a marker-based approach. To this end, we qualitatively and quantitatively assess image quality. The latter is evaluated using the Structural Similarity (SSIM). We achieved results comparable to the marker-based approach, which highlights the potential of both point set registration methods, for accurately recovering patient motion. The SSIM improved from 0.94 to 0.99 and 0.97 using the static and the dynamic camera trajectory, respectively. Accurate recovery of patient motion resulted in remarkable reduction in motion artifacts in the CBCT reconstructions, which is promising for future work with real data. Full article

This paper presents a new approach for the registration of airborne LiDAR point clouds by finding and matching corresponding linear plane features. Linear plane features are a type of common feature in an urban area and are convenient for obtaining feature parameters from point clouds. Using such linear feature parameters, the 3D rigid body coordination transformation model is adopted to register the point clouds from different trajectories. The approach is composed of three steps. In the first step, an OpenStreetMap-aided method is applied to select simply-structured roof pairs as the corresponding roof facets for the registration. In the second step, the normal vectors of the selected roof facets are calculated and input into an over-determined observation system to estimate the registration parameters. In the third step, the registration is be carried out by using these parameters. A case dataset with a two trajectory point cloud was selected to verify the proposed method. To evaluate the accuracy of the point cloud after registration, 40 checkpoints were manually selected; the results of the evaluation show that the general accuracy is 0.96 m, which is approximately 1.6 times the point cloud resolution. Furthermore, two overlap zones were selected to measure the surface-difference between the two trajectories. According to the analysis results, the average surface-distance is approximately 0.045–0.129 m. Full article

We propose a generative framework for 3D human pose estimation that is able to operate on both individual point sets and sequential depth data. We formulate human pose estimation as a point set registration problem, where we propose three new approaches to address several major technical challenges in this research. First, we integrate two registration techniques that have a complementary nature to cope with non-rigid and articulated deformations of the human body under a variety of poses. This unique combination allows us to handle point sets of complex body motion and large pose variation without any initial conditions, as required by most existing approaches. Second, we introduce an efficient pose tracking strategy to deal with sequential depth data, where the major challenge is the incomplete data due to self-occlusions and view changes. We introduce a visible point extraction method to initialize a new template for the current frame from the previous frame, which effectively reduces the ambiguity and uncertainty during registration. Third, to support robust and stable pose tracking, we develop a segment volume validation technique to detect tracking failures and to re-initialize pose registration if needed. The experimental results on both benchmark 3D laser scan and depth datasets demonstrate the effectiveness of the proposed framework when compared with state-of-the-art algorithms. Full article

Here an inertial sensor-based monitoring system for measuring and analyzing upper limb movements is presented. The final goal is the integration of this motion-tracking device within a portable rehabilitation system for brain injury patients. A set of four inertial sensors mounted on a special garment worn by the patient provides the quaternions representing the patient upper limb’s orientation in space. A kinematic model is built to estimate 3D upper limb motion for accurate therapeutic evaluation. The human upper limb is represented as a kinematic chain of rigid bodies with three joints and six degrees of freedom. Validation of the system has been performed by co-registration of movements with a commercial optoelectronic tracking system. Successful results are shown that exhibit a high correlation among signals provided by both devices and obtained at the Institut Guttmann Neurorehabilitation Hospital. Full article
