To improve the efficiency and stability of the system, this paper proposes a monolithic integrated optical path design for a cavity optomechanical accelerometer based on a 250 nm top silicon thickness silicon-on-insulator (SOI) wafer instead of readout through U-shape fiber coupling. Finite Element Analysis (FEA) and Finite-Difference Time-Domain (FDTD) methods are employed to systematically investigate the performance of key optical structures, including the resonant modes and bandgap characteristics of photonic crystal (PhC) microcavities, transmission loss of strip waveguides, coupling efficiency of tapered-lensed fiber-to-waveguide end-faces, coupling characteristics between strip waveguides and PhC waveguides, and the coupling mechanism between PhC waveguides and microcavities. Simulation results demonstrate that the designed PhC microcavity achieves a quality factor (Q-factor) of 2.26 × 10⁵ at a 1550 nm wavelength while the optimized strip waveguide exhibits a low loss of merely 0.2 dB over a 5000 μm transmission length. The strip waveguide to PhC waveguide coupling achieves 92% transmittance at the resonant frequency, corresponding to a loss below 0.4 dB. The optimized edge coupling structure exhibits a transmittance of 75.8% (loss < 1.2 dB), with a 30 μm coupling length scheme (60% transmittance, ~2.2 dB loss) ultimately selected based on process feasibility trade-offs. The total optical path system loss (input to output) is 5.4 dB. The paper confirms that the PhC waveguide–microcavity evanescent coupling method can effectively excite the target cavity mode, ensuring optomechanical coupling efficiency for the accelerometer. This research provides theoretical foundations and design guidelines for the fabrication of high-precision monolithic integrated cavity optomechanical accelerometers. Full article

An FR4-based X-band low phase noise oscillator loading an additional high-Q cavity resonator was designed in this study using substrate-integrated suspended line (SISL) technology. The additional resonator was coupled to an oscillator by the transmission line (coupling TL). The impact of the additional resonator on startup conditions, Q factor enhancement, and phase noise reduction was thoroughly investigated. Three oscillators loading an additional high-Q cavity resonator, loading an additional high-Q cavity resonator and performing partial dielectric extraction, and loading an original parallel feedback oscillator for comparison were presented. The experimental results showed that the proposed oscillator had a low phase noise of −131.79 dBc/Hz at 1 MHz offset from the carrier frequency of 10.088 GHz, and the FOM was −197.79 dBc/Hz. The phase noise was reduced by 1.66 dB through loading the additional resonator and further reduced by 1.87 dB through partially excising the substrate. To the best of our knowledge, the proposed oscillator showed the lowest phase noise and FOM compared with other all-FR4-based oscillators. The cost of fabrication was markedly reduced. The proposed oscillator also has the advantages of compact size and self-packaging properties. Full article

Objective: This study aims to critically review and synthesize the existing literature on the use of voice analysis in assessing nasal obstruction, with a particular focus on acoustic parameters. Data sources: PubMed, Scopus, Web of Science, Ovid Medline, and Science Direct. Review methods: A comprehensive literature search was conducted without any restrictions on publication year, employing Boolean search techniques. The selection and review process of the studies followed PRISMA guidelines. The inclusion criteria comprised studies with participants aged 18 years and older who had nasal obstruction evaluated using acoustic voice analysis parameters, along with objective and/or subjective methods for assessing nasal obstruction. Results: Of the 174 abstracts identified, 118 were screened after the removal of duplicates. The full texts of 37 articles were reviewed. Only 10 studies met inclusion criteria. The majority of these studies found no significant correlations between voice parameters and nasal obstruction. Among the various acoustic parameters examined, shimmer was the most consistently affected, with statistically significant changes identified in three independent studies. A smaller number of studies reported notable findings for fundamental frequency (F0) and noise-related measures such as NHR/HNR. Conclusion: This systematic review critically evaluates existing studies on the use of voice analysis for assessing and monitoring nasal obstruction and hyponasality. The current evidence remains limited, as most investigations predominantly focus on glottic sound and dysphonia, with insufficient attention to the influence of the vocal tract, particularly the nasal cavities, on voice production. A notable gap exists in the integration of advanced analytical approaches, such as machine learning, in this field. Future research should focus on the use of advanced analytical approaches to specifically extrapolate the contribution of nasal resonance to voice thus defining the specific parameters in the voice spectrogram that can give precise information on nasal obstruction. Full article

Based on the theory of optical sensing, we propose a high-precision plasmonic refractive index nanosensor, which consists of a symmetric rectangular waveguide and a circular ring containing a rectangular cavity. The designed novel tunable micro-resonant circular cavity filter based on surface plasmon excitations is able to confine light to sub-wavelength dimensions. The data show that different geometrical factors have different effects on sensing, with the geometry of the rectangular cavity and the radius of the circular ring being the key factors affecting the Fano resonance. Furthermore, the resonance bifurcation enables the structure to achieve a tunable dual Fano resonance system. The structure was tuned to obtain optimal sensitivity (S) and figure of merit values up to 3066 nm/RIU and 78. The designed structure has excellent sensing performance with sensitivities of 0.4767 nm·(mg/d${\mathrm{L}}^{-1}$) and 0.6 nm·(mg/d${\mathrm{L}}^{-1}$) in detecting Na⁺ and K⁺ concentrations in the electrolyte solution, respectively, and can be easily achieved by the spectrometer. The wavelength accuracy of 0.001 nm can be easily achieved by a spectrum analyzer, which has a broad application prospect in the field of optical integration. Full article

High-density polyethylene (HDPE) pipes are widely used in urban natural gas pipeline systems due to their excellent mechanical and chemical properties. However, welding joints are critical weak points in these pipelines, and defects, such as cold welding—caused by reduced temperature or/and insufficient pressure—pose significant safety risks. Traditional non-destructive testing (NDT) methods face challenges in detecting cold welding defects due to the polymer’s complex structure and characteristics. This study presents a microwave-based NDT system for detecting cold welding defects in thermal fusion welds of HDPE pipes. The system uses a focusing antenna with a resonant cavity, connected to a vector network analyzer (VNA), to measure changes in microwave parameters caused by cold welding defects in thermal fusion welds. Experiments conducted on HDPE pipes welded at different temperatures demonstrated the system’s effectiveness in identifying areas with a lack of fusion. Mechanical and microstructural analyses, including tensile tests and scanning electron microscopy (SEM), confirmed that cold welding defects lead to reduced mechanical properties and lower material density. The proposed microwave NDT method offers a sensitive, efficient approach for detecting cold welds in HDPE pipelines, enhancing pipeline integrity and safety. Full article

Span-wise homogeneous supersonic cavity flows display complicated structures due to shear layer breakdown, flow acoustic resonance, and even non-linear hydrodynamic-acoustic interactions. In practical applications, such as aircraft bays, the cavity is of finite width and has doors, both of which introduce distinctive phenomena that couple with the shear layer at the cavity lip, further modulating shear layer bifurcations and tonal mechanisms. In particular, asymmetric states manifest as ‘tornado’ vortices with significant practical consequences on the design and operation. Both inward- and outward-facing leading-wedge doors, resulting in leading edge shocks directed into and away from the cavity, are examined at select opening angles ranging from $22.5°$ to $90°$ (fully open) at Mach 1.6. The computational approach utilizes the Reynolds-Averaged Navier–Stokes equations with a one-equation model and is augmented by experimental observations of cavity floor pressure and surface oil-flow patterns. For the no-doors configuration, the asymmetric results are consistent with a long-time series DDES simulation, previously validated with two experimental databases. When fully open, outer wedge doors (OWD) yield an asymmetric flow, while inner wedge doors (IWD) display only mildly asymmetric behavior. At lower door angles (partially closed cavity), both types of doors display a successive bifurcation of the shear layer, ultimately resulting in a symmetric flow. IWD tend to promote symmetry for all angles observed, with the shear layer experiencing a pitchfork bifurcation at the ‘critical angle’ ($67.5°$). This is also true for the OWD at the ‘critical angle’ ($45°$), though an entirely different symmetric flow field is established. The first observation of pitchfork bifurcations (‘critical angle’) for the IWD is at $67.5°$ and for the OWD, $45°$, complementing experimental observations. The back wall signature of the bifurcated shear layer (impingement preference) was found to be indicative of the 3D cavity dynamics and may be used to establish a correspondence between 3D cavity dynamics and the shear layer. Below the critical angle, the symmetric flow field is comprised of counter-rotating vortex pairs at the front and back wall corners. The existence of a critical angle and the process of door opening versus closing indicate the possibility of hysteresis, a preliminary discussion of which is presented. Full article

An external power build-up cavity of a line-narrowed 407-nm laser diode for Raman gas analysis was demonstrated to possess good gas detection capabilities. By employing an ordinary laser diode without anti-reflection coating or and a bandpass interference filter in an external cavity resonance, the laser linewidth was narrowed by resonant optical feedback, and tens of watts of external cavity power were built up. The coupling mechanism between the semiconductor laser and the external cavity are discussed, as well as the noise background in the experimental results. The Raman spectrum of ambient air was analyzed, achieving a methane detection limit of 1 ppm. Full article

The quality of life (QoL) perception has been studied in neurological diseases; however, there is limited information linking brain morphological characteristics, QoL, and cognition. Human behavior and perception are associated with specific brain areas that interact through diffuse electrochemical networking. We used magnetic resonance imaging (MRI) to analyze the brain region volume (BRV) correlation with the scores of Rand’s 36-item Short Form Survey (SF-36) and cognitive domains (memory and dementia status). We analyzed data from 420 adult participants in the Maracaibo Aging Study (MAS). Principal component analysis with oblimin axis rotation was used to gather redundant information from brain parcels and SF-36 domains. Canonical correlation was used to analyze the relationships between SF-36 domains and BRV (adjusted for intracranial cavity), as well as sex, age, education, obesity, and hypertension. The average age (±SD) of subjects was 56 ± 11.5 years; 71% were female; 39% were obese; 12% had diabetes, 52% hypertension, and 7% dementia. No sex-related differences were found in memory and orientation scores, but women had lower QoL scores. The 1st and 2nd canonical correlation roots support the association of SF-36 domains (except social functioning and role emotional) and total brain volume, frontal lobe volume, frontal pole, lateral orbital lobe, cerebellar, and entorhinal areas. Other variables, including age, dementia, memory score, and systolic blood pressure, had a significant influence. The results of this study demonstrate significant correlations between BRV and SF-36 components, adjusted for covariates. The frontal lobe and insula were associated with the mental health component; the lateral-orbital frontal lobe and entorhinal area were correlated with the physical component. Full article

Hydrocephalus is a frequently observed congenital malformation of the central nervous system in domestic animals; however, its occurrence in wild species remains underreported. This study documents a clinical case of congenital hydrocephalus in a red fox cub (Vulpes vulpes) admitted to the “Visul Luanei” Wildlife Rehabilitation Center. The individual exhibited neurological deficits characterized by depressed mental status, incoordination, dromomania, behavior changes, and blindness. Diagnostic imaging, including radiography and magnetic resonance imaging (MRI), revealed a domed cranial morphology and severe dilation of the ventricular system. Notably, the lateral ventricles were markedly enlarged, with the absence of the septum pellucidum, resulting in a unified ventricular cavity. During electroencephalography (EEG) performed under general anesthesia, a high voltage and low frequency, predominantly featuring delta waves background activity was observed on all traces. Due to the poor prognosis and lack of clinical improvement, euthanasia was performed. This case contributes to the limited knowledge regarding central nervous system malformations in wild canids and underscores the need for further research on congenital neurological disorders in wildlife species. Full article

In this study, a terahertz microfluidic multi-band sensor was designed. Unlike previous microfluidic absorption sensors that rely on dipole resonance, the proposed sensor uses a physical mechanism for absorption by exciting higher-order lattice resonances in microfluidic structures. With a Fabry–Perot cavity, the sensor can form an absorption peak with a high quality factor (Q) and narrow full width at half maximum (FWHM). A high Q value and a narrow FWHM are valuable in the field of sensing and provide strong support for high-precision sensing. On this basis, the sensing performance of the device was investigated. The simulation results clearly show that the absorption sensor has ultra-high sensitivity, which reaches 400 GHz/Refractive Index Unit (RIU). In addition, the sensor generates three absorption peaks, overcoming the limitations of a single frequency band in a composite resonance mode and multidimensional frequency response, which has potential application value in the field of volatile organic compound (VOC) sensing. Full article

The Polish Free-Electron Laser (PolFEL), which is currently under construction in the National Centre for Nuclear Research in Świerk near Warsaw, will comprise an electron gun and from four to six cryomodules, each accommodating two nine-cell TESLA RF superconducting resonant cavities. To cool the superconducting resonant cavities, the cryomodules will be supplied with superfluid helium at a temperature of 2 K. Other requirements regarding the cooling power of PolFEL result from the need to cool the power couplers for the accelerating cryomodules (5 K) and thermal shields, which limit the heat inleaks due to radiation (40–80 K). The machine will utilize several thermodynamic states of helium, including two-phase superfluid helium, supercritical helium, and low-pressure helium vapours. Supercritical helium will be supplied from a cryoplant by a cryogenic distribution system (CDS)—transfer line and valve boxes—where it will be thermodynamically transformed into a superfluid state. This article presents the architecture of the CDS, discusses several design solutions that could have been decided on with the use of second law analysis, and presents the design methodology of the chosen CDS elements. Full article

Near-unstable cavities hold promise for reducing thermal noise in next-generation gravitational wave detectors and for enhancing light–matter interactions in quantum electrodynamics. However, operating close to the edge of geometrical stability presents significant challenges, including increased coupling to higher-order modes and heightened sensitivity to small cavity length changes and mirror imperfections. This study employs Finesse v3 simulations to systematically investigate the modal behavior of a plano-concave cavity as it approaches instability, incorporating measured mirror surface defects and anisotropic curvature to replicate realistic conditions. The simulations highlight the degradation of beam purity and control signals as the cavity approaches instability. By validating the simulations against experimental data, we confirm Finesse’s reliability for modeling cavities while identifying critical limitations in regimes close to the edge of stability. These findings provide essential guidance for optimizing cavity designs in future gravitational wave detectors, balancing performance gains against the challenges of operating at the stability edge. Full article

This paper presents a carbon monoxide (CO) detection mechanism achieved through further improvement of the sensing antenna based on hybrid spoof localized surface plasmons (SLSPs) and cavity resonance. Unlike conventional approaches relying on chemical reactions or photoelectric effects, the all-metal configuration detects dielectric variations through microwave-regime resonance frequency shifts, enabling CO/air differentiation with theoretically enhanced robustness and environmental adaptability. The designed system achieves measured figures of merit (FoMs) of 183.2 RIU⁻¹, resolving gases with dielectric contrast below 0.1%. Experimental validation successfully discriminated CO (ε_r = 1.00262) from air (ε_r = 1.00054) under standard atmospheric pressure at 18 °C. Full article

The experimental and computational characterization of a cold model prototype designed to test the electromagnetic properties of a new RFQ (Radio-Frequency Quadrupole) cavity is reported. This cavity is intended to be an essential part of a compact, high-gradient proton accelerator for medical purposes. The RFQ’s design employs a novel RF power-coupler injection solution. One common way to couple the RF power in proton RFQs has been the use of loop-couplers inserted into the mid-section of the RFQ’s lobe sections. This technique has been demonstrated to be reliable and effective but introduces a significant perturbation into the lobe that can be more noticeable when dealing with compact structures. We propose a RF injection scheme that uses direct transition from a coaxial cable to the RFQ by connecting the inner coaxial conductor to the RFQ vane body. As a consequence, the lobe geometry is not perturbed, and the transversal electrical fields are directly excited through the vanes. Moreover, by using a pair of such couplers connected to opposite vanes at a given transversal plane of the RFQ, it is also possible to excite the desired quadrupolar TE210 modes while avoiding the excitation of dipolar TE110 modes. The resonances corresponding to different RFQ modes have been characterized, and the dependence of the amplitude of the modes on the relative phase of the field injected through the RF power ports has been demonstrated both by measurements and simulations. Full article

Optically pumped gas terahertz (THz) lasers (OPGTLs) as reliable sources of THz radiation have been extensively utilized within THz application areas. In this paper, a substrate-free metal mesh coupler based on the metasurfaces principle was designed for continuous wave OPGTL, which is suitable for the Fabry–Perot (FP) THz resonator. The parameters of substrate-free metal mesh are calculated by the Ulrich equivalent circuit model, and the influence of metal mesh period and linewidth on its transmittance is analyzed quantitatively. Taking the THz laser with the 118.8 µm of CH₃OH optically pumped by the 9.6 µm CO₂ laser line for instance, two kinds of metal mesh were devised as input and output couplers of the resonator, and the transmittance and reflectance of the metal meshes are verified by the finite-difference time-domain (FDTD) method. Furthermore, the transmitted and reflected light fields of the FP resonant cavity metal mesh mirrors were simulated by using the FDTD method under the vertical incidence of both pump light and THz waves. Validation of the optical field characteristics of the substrate-free metal meshes confirmed their suitability as ideal input and output coupling cavity mirrors for FP resonant cavities in optically pumped gas THz lasers. Full article
