Search Results (31)

This study investigates the tribo-corrosion behavior of Ti6Al4V biomedical alloy, when sliding against fused filament fabrication (FFF) 3D-printed polyether ether ketone (PEEK) pins in a phosphate-buffered saline (PBS) solution. This research aims to evaluate wear mechanisms and electrochemical responses under simulated physiological conditions, providing critical insights for enhancing the durability and performance of biomedical implants. Potentiodynamic polarization tests demonstrate that the Ti6Al4V alloy possesses excellent corrosion resistance, which is further enhanced under sliding conditions compared to the test without sliding. When tested against 3D-printed PEEK, the alloy exhibits a mixed wear mechanism characterized by both abrasive and adhesive wear. Open-circuit potential (OCP) measurement of Ti6Al4V demonstrates the alloy’s superior electrochemical stability, indicating high corrosion resistance and a favorable coefficient of friction. These findings highlight the potential of 3D-printed PEEK as a viable alternative for biomedical applications, offering rapid patient-specific prototyping, tunable mechanical properties, and improved surface adaptability compared to conventional materials. Full article

This study introduced a systematic framework to develop practical design guidelines specifically for filament-based material extrusion of metals (MEX/M), an additive manufacturing (AM) process defined by ISO/ASTM 52900. MEX/M provides a cost-efficient alternative to conventional manufacturing methods, which is particularly valuable for rapid prototyping. Although AM offers significant design flexibility, the MEX/M process imposes distinct geometric and process constraints requiring targeted optimization. The research formulates and validates design guidelines tailored for the MEX/M using an austenitic steel 316L (1.4404) alloy filament. The feedstock consists of a uniform blend of 316L stainless steel powder and polymeric binder embedded within a thermoplastic matrix, extruded and deposited layer by layer. Benchmark parts were fabricated to examine geometric feasibility, such as minimum printable wall thickness, feature inclination angles, borehole precision, overhang stability, and achievable resolution of horizontal and vertical gaps. After fabrication, the as-built (green-state) components undergo a two-step thermal post-processing treatment involving binder removal (debinding), followed by sintering at elevated temperatures to reach densification. Geometric accuracy was quantitatively assessed through a 3D scan by comparing the manufactured parts to their original CAD models, allowing the identification of deformation patterns and shrinkage rates. Finally, the practical utility of the developed guidelines was demonstrated by successfully manufacturing an impeller designed according to the established geometric constraints. These design guidelines apply specifically to the machine and filament type utilized in this study. Full article

Investment casting is a precision casting technology that can produce complex shapes from various materials, particularly difficult-to-cast and difficult-to-machine metallic alloys. Meanwhile, electrical discharge machining (EDM) is a well-known technique for producing ultra-precise mechanical parts, and electrode quality is crucial. Few studies have explored how rapid prototyping (RP) pattern generation and investment casting influence the final product’s shape, dimensions, and surface roughness. This study investigates EDM electrode fabrication using investment casting and RP-generated epoxy resin patterns. We examine the effects of electrode materials (CuZn5, CuZn30, and FeCr24) on surface roughness, alongside the impact of ceramic shell thickness and RP pattern shrinkage on electrode quality. The EDM electrodes have a shrinkage of 0.8–1.9% and a surface roughness of 3.20–6.35 μm, depending on the material selections. Additionally, the probability of shell cracking decreases with increasing shell thickness, achieving stability at 16.00 mm. This research also applies investment casting electrodes to process DC53 steel. The results indicate that the surface roughness of the workpiece after EDM machining with different electrode materials is in the range of 4.71 µm to 9.88 µm. The result expands the use of investment casting in electrode fabrication, enabling the production of high-precision electrodes with complex profiles and challenging materials, potentially reducing both time and cost. Full article

The Fe-36Ni alloy, with ultra-low thermal expansion and stable properties, is essential for aerospace remote sensors and aircraft load-bearing structures, widely used in aerospace. Additive Manufacturing, an emerging rapid prototyping technology with short cycles, high efficiency, and flexibility, addresses complex structural fabrication challenges. While selective laser melting (SLM) enables complex geometry fabrication, post-process treatments (e.g., annealing-induced homogenization, thermal aging for stress relief, surface polishing) remain critical for attaining metallurgical stability in as-built components. The impact of different laser scanning speeds (500 mm/s, 1000 mm/s, 1500 mm/s, 2000 mm/s) on the microstructure and mechanical and thermal expansion properties of the Fe-36Ni alloy fabricated by selective laser melting was studied. The results indicate that all Fe-36Ni alloys predominantly exhibit the γ-phase. Interestingly, a small amount of α precipitates was also observed, which is primarily attributed to the formation of a supercooled region. Notably, at a scanning speed of 1000 mm/s, the Fe-36Ni alloy samples exhibit optimal mechanical properties, with a tensile strength of 439 MPa and an elongation of 49.0%. This improvement is primarily attributed to the enhanced molding quality and grain refinement. The minimum coefficient of thermal expansion occurs at a scanning speed of 2000 mm/s, likely due to the elevated defect density. Full article

Ti-6Al-4V is a well-known alloy for its low density and excellent corrosion resistance, making it popular in aerospace, marine, medical, and automotive applications. However, at elevated temperatures, the alloy forms oxides, leading to embrittlement. In additive manufacturing, particularly in the direct energy deposition (DED) process, which involves high temperatures, the alloy experiences oxidation. An inert gas chamber provides shielding during the process but limits the size of the manufactured components, and deposition in a vacuum chamber can alter the chemical composition of the alloy. Local shielding is a technique generally used for such applications, but it uses a high volume of shield gas, contributing to environmental contamination. This study presents a novel approach for the development and preliminary evaluation of a prototype nozzle attachment system for the additive manufacturing (AM) of Ti-6Al-4V using a direct energy deposition (DED) process in an open-air environment system. The system was designed to reduce shield gas consumption by providing conformal shielding in critical areas. This was achieved by dividing the shielding area into eight segments, with each of the eight attachments of the nozzle attachment system selectively activated to supply shield gas only where required. Four different shield gas flow rates of 20, 25, 30, and 35 SCFH were tested at three different locations under the attachment to investigate the optimal flow rate. The results proposed maintaining a baseline flow rate of 5 SCFH in all attachments and employing 60 SCFH during transitions between attachments for rapid shielding. The system maintained oxygen concentration levels below 200 PPM within 2.1 s, with an average gas consumption of 65 SCFH, underlining an 85% reduction compared to other studies. These findings highlight the potential of this system for future implementation and scalability for reactive metal depositions like Ti-6Al-4V in AM using DED processes. This study addresses the need for an effective shielding environment during deposition while minimizing the shield gas consumption. A nozzle attachment system was designed and developed to provide conformal shielding during the deposition process. Key parameters, such as the shielding flow rate, activation time, and shielding range of the nozzle attachments, were investigated. The system successfully delivered shield gas to the critical areas and provided a safe environment for deposition. Argon consumption was reduced by 85% compared to other studies in the same field, with an optimal flow rate of 25 Standard Cubic Feet per Hour (SCFH) of shielding gas used to cover all critical areas in the experiments. The effect of the laminar and turbulent flow of shield gas on the deposition path was also analyzed in this study. Full article

Additive manufacturing (AM) is a layerwise production process that creates three-dimensional objects according to a digital model. This technology has demonstrated to be a promising alternative to conventional manufacturing methods for various industrial sectors, such as aerospace, automotive, biomedical, and energy. AM offers several advantages, like design flexibility, material efficiency, functional integration, and rapid prototyping. As regards metal parts, conventional AM techniques using infrared laser sources face some limitations in processing high-reflectivity and high-conductivity materials or alloys, such as aluminum, copper, gold, and silver. These materials have low absorption of infrared radiation, which results in unstable and shallow melt pools, poor surface quality, and high porosity. To overcome these challenges, green and blue laser sources have been proposed for AM processes. This review provides an overview of the recent developments and applications of green and blue laser sources for powder bed fusion of copper and its alloys, focusing on the effects of process parameters on the melt pool dynamics, microstructure formation, and thermal and electrical properties of the fabricated parts. This review also presents the main applications of AM of copper and its alloys together with potential opportunities for future developments. Full article

Additive manufacturing (AM) or 3D printing is a promising industrial technology that enables rapid prototyping of complex configurations. Powder Bed Fusion (PBF) is one of the most popular AM techniques for metallic materials. Until today, only a few metals and alloys are available for AM, e.g., titanium alloys, the most common of which is Ti-6Al-4V. After optimization of PBF parameters, with or without post processing such as heat treatment or hot isostatic pressing, the printed titanium alloy can easily reach tensile strengths of over 1100 MPa due to the quick cooling of the AM process. However, attributed to the unique features of metallurgical defects and microstructure introduced by this AM process, their fatigue strength has been low, often less than 30% of the tensile strength, especially in very-high-cycle regimes, i.e., failure life beyond 10⁷ cycles. Here, based on our group’s research on the very-high-cycle fatigue (VHCF) of additively manufactured (AMed) Ti-6Al-4V alloys, we have refined the basic quantities of porosity, metallurgical defects, and the AMed microstructure, summarized the main factors limiting their VHCF strengths, and suggested possible ways to improve VHCF performance. Full article

Additive manufacturing (AM) technologies have advanced from rapid prototyping to becoming viable manufacturing solutions, offering users both design flexibility and mechanical properties that meet ISO/ASTM standards. Powder bed fusion using a laser beam (PBF-LB), a popular additive manufacturing process (aka 3D printing), is used for the cost-effective production of high-quality products for the medical, aviation, and automotive industries. Despite the growing variety of metallic powder materials available for the PBF-LB process, there is still a need for new materials and procedures to optimize the processing parameters before implementing them into the production stage. In this study, we explored the use of a checkerboard scanning strategy to create samples of various sizes (ranging from 130 mm³ to 8000 mm³ using parameters developed for a small 125 mm³ piece). During the PBF-LB process, all samples were fabricated using Ti grade 2 and were in situ alloyed with a precisely controlled amount of oxygen (0.1–0.4% vol.) to enhance their mechanical properties using a solid solution strengthening mechanism. The samples were fabricated in three sets: I. Different sizes and orientations, II. Different scanning strategies, and III. Rods for high-cycle fatigue (HCF). For the tensile tests, micro samples were cut using WEDM, while for the HCF tests, samples were machined to eliminate the influence of surface roughness on their mechanical performance. The amount of oxygen in the fabricated samples was at least 50% higher than in raw Ti grade 2 powder. The O₂-enriched Ti produced in the PBF-LB process exhibited a tensile strength ranging from 399 ± 25 MPa to 752 ± 14 MPa, with outcomes varying based on the size of the object and the laser scanning strategy employed. The fatigue strength of PBF-LB fabricated Ti was 386 MPa, whereas the reference Ti grade 2 rod samples exhibited a fatigue strength of 312 MPa. Our study revealed that PBF-LB parameters optimized for small samples could be adapted to fabricate larger samples using checkerboard (“island”) scanning strategies. However, some additional process parameter changes are needed to reduce porosity. Full article

Microcatheters capable of active guidance have been proven to be effective and efficient solutions to interventional surgeries for cardiovascular and cerebrovascular diseases. Herein, a novel microcatheter made of two biocompatible materials, shape memory alloy (SMA) and polyethylene (PE), is proposed. It consists of a reconfigurable distal actuator and a separate polyethylene catheter. The distal actuator is created via embedding U-shape SMA wires into the PE base, and its reconfigurability is mainly dominated by the shape memory effect (SME) of SMA wires, as well as the effect of thermal mismatch between the SMA and PE base. A mathematical model was established to predict the distal actuator’s deformation, and the analytical solutions show great agreement with the finite element results. Structural optimization of such microcatheters was carried out using the verified analytical model, followed by fabrication of some typical prototypes. Experimental testing of their mechanical behaviors demonstrates the feasibility of the structural designs, and the reliability and accuracy of the mathematical model. The active microcatheter, together with the prediction model, will lay a solid foundation for rapid development and optimization of active navigation strategies for vascular interventions. Full article

The automotive industry is undergoing a rapid evolution to meet today’s challenges; therefore, continuous innovation and product development are needed. Validation tests on prototypes play a crucial role in moving new components into industrial production. There is also a pressing need for faster prototyping processes. In this context, rapid sand casting (RSC), based on additive manufacturing technology, offers a promising solution for a quick production of sand molds. While this technology is already employed in the industry, the need to deepen the general understanding of its impact on the casting properties is still a relevant item. In this study, different geometries of automotive prototypes made of aluminum EN AC 42100-T6 alloy were experimentally analyzed. Microstructural examinations, tensile tests, and fractography and porosity analyses were conducted. The findings demonstrate the considerable potential of RSC, giving, in general, high mechanical properties. A comparative analysis with prototypes produced through traditional sand casting revealed similar results, with RSC exhibiting superior yield strength and stress at brake. However, both technologies revealed a reduced elongation percentage, as expected. Future efforts will focus on standardizing the RSC process to enhance ductility levels. Full article

Achieving lightweight, high-strength, and biocompatible composites is a crucial objective in the field of tissue engineering. Intricate porous metallic structures, such as lattices, scaffolds, or triply periodic minimal surfaces (TPMSs), created via the selective laser melting (SLM) technique, are utilized as load-bearing matrices for filled ceramics. The primary metal alloys in this category are titanium-based Ti6Al4V and iron-based 316L, which can have either a uniform cell or a gradient structure. Well-known ceramics used in biomaterial applications include titanium dioxide (TiO₂), zirconium dioxide (ZrO₂), aluminum oxide (Al₂O₃), hydroxyapatite (HA), wollastonite (W), and tricalcium phosphate (TCP). To fill the structures fabricated by SLM, an appropriate ceramic is employed through the spark plasma sintering (SPS) method, making them suitable for in vitro or in vivo applications following minor post-processing. The combined SLM-SPS approach offers advantages, such as rapid design and prototyping, as well as assured densification and consolidation, although challenges persist in terms of large-scale structure and molding design. The individual or combined application of SLM and SPS processes can be implemented based on the specific requirements for fabricated sample size, shape complexity, densification, and mass productivity. This flexibility is a notable advantage offered by the combined processes of SLM and SPS. The present article provides an overview of metal–ceramic composites produced through SLM-SPS techniques. Mg-W-HA demonstrates promise for load-bearing biomedical applications, while Cu-TiO₂-Ag exhibits potential for virucidal activities. Moreover, a functionally graded lattice (FGL) structure, either in radial or longitudinal directions, offers enhanced advantages by allowing adjustability and control over porosity, roughness, strength, and material proportions within the composite. Full article

Metal-fused filament fabrication (MF3), which is a variation of the conventional fused filament fabrication (FFF), has recently gained interest due to its distinctive process flexibility and rapid prototyping capability to produce metallic parts. With respect to the additive manufacturing (AM) of aluminum alloys, most efforts have been centered on laser powder bed fusion technologies, with limited activities focused on binder-based processes due to challenges in the sintering of aluminum powders. With respect to MF3, one challenge for fabricating metallic components is the appropriate selection of a binder mixture, enabling the extrusion of a filament with high metallic volume content. In this paper, a mixture of biodegradable aliphatic polyester thermoplastic is used as a binder phase to act as the carrier for AlSi10Mg alloy powders. Full article

High-strength, low-alloy (HSLA) steel has attracted much attention in the manufacturing industry because of its good combination of high strength and toughness, low cost, and good formability. Wire and arc additive manufacturing (WAAM) technology can realize the rapid prototyping of HSLA steel parts. This study investigated a 26-layer HSLA steel component fabricated with the WAAM technique. The microstructure of the deposited wall of ER120S-G is mainly acicular ferrite, and there are longitudinal, preferentially growing dendrites along the deposition direction. With the deposition height accumulation, the top sample’s interlayer temperature increases and the amount of acicular ferrite in the microstructure decreases, while the amount of quasi-polygonal ferrite, Widmanstatten ferrite increases. The changes in microhardness were consistent with the corresponding microstructure gradients: the microhardness of the top sample showed a decreasing trend along the deposition direction, while the microhardness of the middle sample was uniform and stable. The present work shows that the mechanical properties of HSLA steel parts deposited using WAAM technology have good strength and toughness. The microstructure gradient of the sample along the deposition direction did not lead to a significant difference in the tensile strength of the sample at different heights. On the contrary, the ductility of the longitudinal sample is slightly lower than that of the transverse sample, indicating some anisotropy in the deposited sample, which is related to the directional growth of grains along the direction of heat flow. From the current work, the thin wall of HSLA steel prepared with the WAAM process has good mechanical properties, which indicates that it is feasible to replace the traditional processing method with the WAAM process to rapidly manufacture an HSLA steel structure meeting the performance requirements. Full article

Turbomolecular pumps (TMPs), boasting advantageous high pumping rates, stability, and cleanliness, have been widely used in the semiconductor and photoelectric industries. In the aviation industry, the lightweight rotors of turbomolecular pumps can enhance the performance of generators. With technological advancements and increased industrial performance demands, various designs for turbomolecular pump rotors utilizing twisted and curved blade surfaces have been proposed. This increase in complexity runs parallel with machining difficulties. Contact and noncontact reverse engineering equipment was used to reconstruct a computer-aided design (CAD) model of turbomolecular pump rotors. The machining of thin and long blades, cutting tool arrangement, and toolpath was planned. Postprocessing was used to convert the toolpath into numerical control (NC) programming codes, which were combined with solid model cutting simulation software to verify the efficacy of the generated machining NC program for turbomolecular pump rotors. A five-axis horizontal machining center (CK type) with aluminum alloy AL6061-T6 was used to conduct actual machining tests measuring the efficiency of the machining methods. The rapid prototyping (RP) blocks can be creatively used as a jig and stuffed between the blades to suppress the chatter problem during processing, and the roughness of the surface of the blades can be reduced from 4.4 μm to 1.3 μm. The processed rotor can meet the flow test requirements, and the overall research can be used as a reference for the industry. Full article

This work investigated the feasibility of using a miniaturised non-standard tensile specimen to predict the post-necking behaviour of the materials manufactured via a rapid alloy prototyping (RAP) approach. The experimental work focused on the determination of the Lankford coefficients (r-value) of dual-phase 800 (DP800) steel and the digital image correlation (DIC) for some cases, which were used to help calibrate the damage model parameters of DP800 steel. The three-dimensional numerical simulations focused on the influence of the size effect (aspect ratio, AR) on the post-necking behaviour, such as the strain/stress/triaxiality evolutions, fracture angles, and necking mode transitions. The modelling showed that although a good correlation can be found between the predicted and experimentally observed ultimate tensile strength (UTS) and total elongation. The standard tensile specimen with a gauge length of 80 mm exhibited a fracture angle of ∼55°, whereas the smaller miniaturised non-standard specimens with low ARs exhibited fractures perpendicular to the loading direction. This shows that care must be taken when comparing the post-necking behaviour of small-scale tensile tests, such as those completed as a part of a RAP approach, to the post-necking behaviours of standard full-size test specimens. However, the modelling work showed that this behaviour is well represented, demonstrating a transition between the fracture angles of the samples between 2.5 and 5. This provides more confidence in understanding the post-necking behaviour of small-scale tensile tests. Full article
