Search Results (94)

In this study, an accurate attenuation measurement system with high attenuation capability (≥100 dB) is presented, covering a broad radio frequency range from 1 GHz to 25 GHz. The system employs a dual-channel intermediate frequency (IF) substitution method, utilizing a programmable inductive voltage divider (IVD) that provides precise voltage ratios at a 1 kHz operating IF, serving as the primary attenuation standard. To ensure optimal inter-channel isolation, essential for accurate high-attenuation measurements, an optical fiber assembly, consisting of a laser diode, a wideband external electro-optic modulator, and a photodetector, is integrated between the channels. A comprehensive performance evaluation is presented, with particular emphasis on the programmable IVD calibration technique, which achieves an accuracy better than 0.001 dB across all attenuation levels, and on the role of the optical fiber assembly in enhancing isolation, demonstrating levels exceeding 120 dB across the entire frequency range. The system demonstrates measurement capabilities with expanded uncertainties (k = 2) of 0.004 dB, 0.008 dB, and 0.010 dB at attenuation levels of 20 dB, 60 dB, and 100 dB, respectively. Full article

Rain attenuation of radio waves with frequencies above 10 GHz causes a serious problem in wireless communications. For wireless systems design, highly accurate methods for estimating the magnitude of attenuation have long been studied. ITU-R recommends a calculation method for rain attenuation using R_0.01, the 1 min rainfall rate that is exceeded for 0.01% of an average year. Accordingly, an R_0.01 database suitable for this calculation has been constructed. In recent years, global warming has emerged as an important climatological issue. If the predicted rise in temperatures associated with global warming induces a significant effect on rainfall characteristics, the existing R_0.01 database will need to be revised. However, there is currently no information for quantitatively evaluating the likely long-term change in R_0.01. In our previous study, the long-term trend in annual maximum values for 1-day, 1 h, and 10 min rainfall in Japan was estimated from a large amount of meteorological data and a 95% confidence interval approach was used to identify an increasing trend of more than 10% over approximately 100 years. In this paper, we investigate the long-term trend in greater detail using non-linear approximations for three types of rainfall and adopt the Akaike Information Criterion to determine the optimal order of the non-linear approximation. The future trend of R_0.01 is then estimated based on the long-term change in annual maximum 1 h rainfall, exploiting the strong correlation between long-term average annual maximum 1 h rainfall and R_0.01. Full article

Underwater wireless communications face significant challenges due to high attenuation, turbulence, and water turbidity. Traditional methods like acoustic and radio frequency (RF) communication suffer from low data rates (<100 kbps), high latency (>1 s), and limited transmission distances (<10 km).Visible Light Communication (VLC) emerges as a promising alternative, offering high-speed data transmission (up to 5 Gbps), low latency (<1 ms), and immunity to electromagnetic interference. This paper provides an in-depth review of underwater VLC, covering fundamental principles, environmental factors (scattering, absorption), and dynamic water properties. We analyze modulation techniques, including adaptive and hybrid schemes (QAM-OFDM achieving 4.92 Gbps over 1.5 m), and demonstrate their superiority over conventional methods. Practical applications—underwater exploration, autonomous vehicle control, and environmental monitoring—are discussed alongside security challenges. Key findings highlight UVLC’s ability to overcome traditional limitations, with experimental results showing 500 Mbps over 150 m using PAM4 modulation. Future research directions include integrating quantum communication and Reconfigurable Intelligent Surfaces (RISs) to further enhance performance, with simulations projecting 40% improved spectral efficiency in turbulent conditions. Full article

Amplitude equalizers play an important role in microwave transmission systems, and their performance can directly improve the signal transmission quality. Nowadays, the miniaturized equalizer is in good need of a highly integrated radio frequency (RF) front end. In this paper, a wafer-level amplitude equalizer based on an integrated passive device (IPD) process is proposed. Moreover, the equalizer circuit containing two resonance points within the transmission frequency band is also proposed. The amplitude equalizer operates at the center frequency of 3.88 GHz, with two resonance points of 2.9 GHz and 5.2 GHz; the minimum insertion loss is 1.17 dB, the maximum attenuation is 4 dB, and the in-band voltage standing wave ratio (VSWR) is less than 1.6:1. All the measured results are in good agreement with the designed results. The size of the proposed equalizer is 0.8 mm × 0.65 mm × 0.1 mm (0.011λ × 0.008λ × 0.001λ), which shows great potential in the miniaturization application of the RF microsystem. Furthermore, the new equalizer circuit with two resonance points is especially suitable for wavy in-band transmission. Full article

The technology of anti-informational interference is a research hotspot in radio detectors. According to the workflow of first interception and then interference for the jammer, improving low interception can fundamentally improve the anti-jamming ability of the radio detector. Airspace low interception is one of the most promising research directions. FDA-MIMO technology holds significant potential for application in this field. Therefore, this paper investigates the design principle of an FDA-MIMO radio detector with low beam entropy. From the perspectives of information acquisition and countermeasure, the spatial low interception of a radio detector is defined by beam entropy. In this paper, the power peak point and drop point are set in a relatively close range ($\Delta r$), ensuring the rapid attenuation of beam amplitude over short distances. Consequently, the design principle of the FDA-MIMO low interception point beam based on the array frequency offset setting formula is obtained, and the optimal beam convergence is realized. Simulation results show that the half-power beam widths of FDA-MIMO point-like beams are 1 m in the distance dimension and 9 degrees in the beamwidth dimension, with a beam entropy of 11. Compared with other classical frequency offset setting methods, the proposed method demonstrates significantly superior beam performance, particularly in terms of low intercept characteristics. The design principle proposed in this paper provides theoretical support for the low intercept beam design of the FDA-MIMO radio detector, thereby reducing the probability of jammers acquiring signal parameters and enhancing both the low intercept performance and anti-jamming capabilities of the radio detector. Full article

The rapid advancement of terahertz (THz) communication systems has positioned this technology as a key enabler for next-generation telecommunication networks, including 6G, secure communications, and hybrid wireless-optical systems. This review comprehensively analyzes THz communication, emphasizing its integration with free-space optical (FSO) systems to overcome conventional bandwidth limitations. While THz-FSO technology promises ultra-high data rates, it is significantly affected by atmospheric absorption, particularly absorption beyond 500 GHz, where the attenuation exceeds 100 dB/km, which severely limits its transmission range. However, the presence of a lower-loss transmission window at 680 GHz provides an opportunity for optimized THz-FSO communication. This paper explores recent developments in high-power THz sources, such as quantum cascade lasers, photonic mixers, and free-electron lasers, which facilitate the attainment of ultra-high data rates. Additionally, adaptive optics, machine learning-based beam alignment, and low-loss materials are examined as potential solutions to mitigating signal degradation due to atmospheric absorption. The integration of THz-FSO systems with optical and radio frequency (RF) technologies is assessed within the framework of software-defined networking (SDN) and multi-band adaptive communication, enhancing their reliability and range. Furthermore, this review discusses emerging applications such as self-driving systems in 6G networks, ultra-low latency communication, holographic telepresence, and inter-satellite links. Future research directions include the use of artificial intelligence for network optimization, creating energy-efficient system designs, and quantum encryption to obtain secure THz communications. Despite the severe constraints imposed by atmospheric attenuation, the technology’s power efficiency, and the materials that are used, THz-FSO technology is promising for the field of ultra-fast and secure next-generation networks. Addressing these limitations through hybrid optical-THz architectures, AI-driven adaptation, and advanced waveguides will be critical for the full realization of THz-FSO communication in modern telecommunication infrastructures. Full article

Unmanned Aerial Vehicles (UAVs) are integral to the development of smart city infrastructures, enabling essential services such as real-time surveillance, urban traffic regulation, and cooperative environmental monitoring. UAV-to-UAV communication networks, despite their adaptability, have significant limits stemming from onboard battery constraints, inclement weather, and variable flight trajectories. This work presents a thorough examination of energy and spectral efficiency in UAV-to-UAV communication over four frequency bands: 2.4 GHz, 5.8 GHz, 28 GHz, and 60 GHz. Our MATLAB R2023a simulations include classical free-space path loss, Rayleigh/Rician fading, and real-time mobility profiles, accommodating varied heights (up to 500 m), flight velocities (reaching 15 m/s), and fluctuations in the path loss exponent. Low-frequency bands (e.g., 2.4 GHz) exhibit up to 50% reduced path loss compared to higher mmWave bands for distances exceeding several hundred meters. Energy efficiency (${\eta }_e$) is evaluated by contrasting throughput with total power consumption, indicating that 2.4 GHz initiates at around 0.15 bits/Joule (decreasing to 0.02 bits/Joule after 10 s), whereas 28 GHz and 60 GHz demonstrate markedly worse ${\eta }_e$ (as low as ${10}^{-3}$–${10}^{-4}\mathrm{bits}/\mathrm{Joule}$), resulting from increased path loss and oxygen absorption. Similarly, sub-6 GHz spectral efficiency can attain $4\times {10}^{-12}\mathrm{bps}/\mathrm{Hz}$ in near-line-of-sight scenarios, whereas 60 GHz lines encounter significant attenuation at distances above 200–300 m without sophisticated beamforming techniques. Polynomial-fitting methods indicate that the projected ${\eta }_e$ diverges from actual performance by less than 5% after 10 s of flight, highlighting the feasibility of machine-learning-based techniques for real-time power regulation, beam steering, or multi-band switching. While mmWave UAV communication can provide significant capacity enhancements (100–500 MHz bandwidth), energy efficiency deteriorates markedly without meticulous flight planning or adaptive protocols. We thus advocate using multi-band radios, adaptive modulation, and trajectory optimisation to equilibrate power consumption, ensure connection stability, and meet high data-rate requirements in densely populated, dynamic urban settings. Full article

This study investigates the impact of rain-induced attenuation on cross-polarization discrimination (XPD) in Earth–space satellite links operating at millimeter-wave frequencies in Pretoria, South Africa. The traditional method of computing XPD employs a constant annual mean rain height and annual mean co-polar attenuation (CPA) over a certain location. This research utilized seasonal rain height data obtained from a recent study and the latest ITU-R P.618-14 guidelines, to compute and analyze XPD variations across six selected frequencies (11.7 GHz to 35 GHz) for different percentages of time exceedance in Pretoria. The study reveals significant seasonal dependencies of rain heights, with XPD reaching its maximum during winter due to lower rain height, and lower rain-induced attenuation and its minimum during summer, characterized by intense convective rainfall and maximum rain height. For instance, the estimated XPD for a 35 GHz signal at 0.01% of the time in the summer, spring, winter, and autumn are 13, 14, 15, and 14 dB, respectively. This implies that radio signals suffer severe attenuation caused by low XPD in the summer. The relationship between CPA and XPD highlights the need for increased XPD margins at higher frequencies to mitigate signal degradation caused by rain depolarization. Practical recommendations include the adoption of adaptive modulation and coding schemes to maintain link reliability during adverse weather conditions, particularly in summer. This research highlights the significance of incorporating frequency-dependent parameters and rain height variability in XPD estimation to enhance the design of satellite communication systems, ensuring optimized performance and reliable operation in a tropical climate. Full article

The urgent need for timely and accurate precipitation estimations in the face of ongoing climate change and the increasing frequency and/or intensity of extreme weather events underscores the necessity for innovative approaches. Recently, several studies have focused on estimating the precipitation rate through induced attenuation of radio frequency (RF) signals, which are abundant in modern communication systems. Most research has concentrated on frequencies exceeding 10 GHz, as attenuation at lower frequencies is minimal, posing measurement challenges. This study aims to confront this limitation by introducing a high-precision experimental setup capable of detecting this subtle attenuation at frequencies under 10 GHz. The setup includes a transmitter and receiver optimized for operation at 2.07, 4.63, and 6.22 GHz, where minimal worldwide research exists. A power resolution below 10⁻⁵ dB in preliminary measurements demonstrated its effectiveness in quantifying signal attenuation due to precipitation across the specified frequencies. Moreover, a strong power law relationship was observed between signal attenuation and precipitation rate for all three frequencies, while, as expected, the higher the frequency, the more pronounced the signal attenuation was. Full article

Background: Indoor Positioning Systems (IPS) have gained increasing relevance in logistics, offering solutions for safety enhancement, intralogistics management, and material flow control across various environments such as industrial facilities, offices, hospitals, and supermarkets. This study aims to evaluate IPS technologies’ performance and applicability to guide practitioners in selecting systems suited to specific contexts. Methods: The study systematically reviews key IPS technologies, positioning methods, data types, filtering methods, and hybrid technologies, alongside real-world examples of IPS applications in various testing environments. Results: Our findings reveal that radio-based technologies, such as Radio Frequency Identification (RFID), Ultra-wideband (UWB), Wi-Fi, and Bluetooth (BLE), are the most commonly used, with UWB offering the highest accuracy in industrial settings. Geometric methods, particularly multilateration, proved to be the most effective for positioning and are supported by advanced filtering techniques like the Extended Kalman Filter and machine learning models such as Convolutional Neural Networks. Overall, hybrid approaches that integrate multiple technologies demonstrated enhanced accuracy and reliability, effectively mitigating environmental interferences and signal attenuation. Conclusions: The study provides valuable insights for logistics practitioners, emphasizing the importance of selecting IPS technologies suited to specific operational contexts, where precision and reliability are critical to operational success. Full article

This paper presents a three-channel reconfigurable step attenuator based on radio frequency (RF) microelectromechanical system (MEMS) switches, in response to the current issues of high insertion loss and low attenuation accuracy of attenuators. The coplanar waveguide (CPW), cross-shaped power dividers, RF MEMS switches, and π-type attenuation resistor networks are designed as a basic unit of the attenuator. The attenuator implemented attenuation of 0~30 dB at 5 dB intervals in the frequency range of 1~25 GHz through two basic units. The results show that the insertion loss is less than 1.41 dB, the attenuation accuracy is better than 2.48 dB, and the geometric size is 2.4 mm × 4.0 mm × 0.7 mm. The attenuator can be applied to numerous fields such as radar, satellites, aerospace, electronic communication, and so on. Full article

In recent years, the need for reliable signal transmission in forested areas has increasingly grown, and the past few decades have witnessed significant developments in related research. With the emergence of smart forestry and precision forestry, understanding the science behind enhancing signal reliability in forests—specifically, studying the patterns and models of radio wave attenuation in these environments—has become crucial. To this end, we conducted a comprehensive review based on bibliometrics to summarize and construct the existing academic literature, revealing current research trends and hotspots. Utilizing bibliometric techniques, we analyzed the literature on radio wave attenuation in forests to summarize and evaluate previous studies. Our analysis indicates that empirical models (67%), hybrid models (21%), and equivalent models (12%) are the three main research clusters in this field. We observed that studies on radio attenuation are more prevalent in urban and artificial forests, while there is a scarcity of research in complex conditions like tropical rainforests and extreme weather; studies are more focused on UHF, VHF, and SHF frequency bands, with lesser attention given to other bands. Previous research has not adequately considered the impact of seasonal factors on signal attenuation patterns nor the influence of forest working environments. Full article

Unmanned aerial vehicles (UAVs) are extensively employed in pursuit, rescue missions, and agricultural applications. These operations necessitate substantial data and video transmission, requiring significant spectral resources. The unlicensed millimeter wave (mmWave) spectrum, especially in the 60 GHz frequency band, offers promising potential for UAV communications. However, WiGig users are the incumbent users of the 60 GHz unlicensed spectrum. Therefore, to ensure fair coexistence between UAV-based new radio-unlicensed (NR-U) users and WiGig users, unlicensed spectrum-sharing strategies need to be meticulously designed. Due to the beam directionality of the NR-U system, traditional listen-before-talk (LBT) spectrum sensing strategies are no longer effective in NR-U/WiGig systems. To address this, we propose a new cooperative unlicensed spectrum sensing strategy based on mmWave beamforming direction. In this strategy, UAV and WiGig users cooperatively sense the unlicensed spectrum and jointly decide on the access strategy. Our analysis shows that the proposed strategy effectively resolves the hidden and exposed node problems associated with traditional LBT strategies. Furthermore, we consider the sensitivity of mmWave to obstacles and analyze the effects of these obstacles on the spectrum-sharing sensing scheme. We examine the unlicensed spectrum access probability and network throughput under blockage scenarios. Simulation results indicate that although obstacles can attenuate the signal, they positively impact unlicensed spectrum sensing. The presence of obstacles can increase spectrum access probability by about 60% and improve system capacity by about 70%. Full article

Although RFID(radio frequency identification) tags do not require a direct line of sight, their operational range is often characterized as being limited. Indeed, in the case of passive RFID tags, the interrogating signal from the transmitter needs to reach the tag’s radio transponder and trigger a nearly omnidirectional scattered signal to be harvested by the receiver. This two-way (from Tx to the tag and back to Rx) channel exhibits increased attenuation not only due to the doubled distance (in case Tx and Rx are collocated) but also to the uncontrolled (i.e., unfocused) backscattering. In the work at hand, we propose a way to control the backscattered radiation and focus the produced beam towards the direction of the reader (the Tx-Rx device). Indeed, one can utilize the concept of retrodirective arrays to immediately control the direction of departure of the backscatter link, maximizing the scattered power towards the reader and thus delivering an increase in the operational range of the tag. This of course means that in this case, the tag should be equipped with a minimum of two element radiators. Thus, retrodirective RFID array tags are introduced in the current work to increase the operating range with minimal costs and levels of complexity since 90° hybrids are used to achieve proper backscattering. To evaluate the proposed passive tag array, performance aspects are addressed. Specifically, we examine the Bit Error Rate with respect to the Signal to Noise Ratio for the retrodirective tag, the one antenna, the broadside, and the spatial diversity array. The results prove that the proposed tag allows for a significant increase in the operational range. Full article

Piezoelectric c-axis oriented zinc oxide (ZnO) thin films, from 1.8 up to 6.6 µm thick, have been grown by the radio frequency magnetron sputtering technique onto fused silica substrates. A delay line consisting of two interdigital transducers (IDTs) with wavelength λ = 80 µm was photolithographically implemented onto the surface of the ZnO layers. Due to the IDTs’ split-finger configuration and metallization ratio (0.5), the propagation of the fundamental, third, and ninth harmonic Rayleigh waves is excited; also, three leaky surface acoustic waves (SAWs) were detected travelling at a velocity close to that of the longitudinal bulk wave in SiO₂. The acoustic waves’ propagation in ZnO/fused silica was simulated by using the 2D finite-element method (FEM) technique to identify the nature of the experimentally detected waves. It turned out that, in addition to the fundamental and harmonic Rayleigh waves, high-frequency leaky surface waves are also excited by the harmonic wavelengths; such modes are identified as Sezawa waves under the cut-off, hereafter named leaky Sezawa (LS). The velocities of all the modes was found to be in good agreement with the theoretically calculated values. The existence of a low-loss region in the attenuation vs. layer thickness curve for the Sezawa wave below the cut-off was theoretically predicted and experimentally assessed. Full article
