The trade-off between resolution and contrast is a transcendental problem in optical imaging, spanning from artistic photography to technoscientific applications. To the latter, Fourier-optics-based filters, such as the 4f system, are well-known for their image-enhancement properties, removing high spatial frequencies from an optically Fourier-transformed light signal through simple aperture adjustment. Nonetheless, assessing the contrast–resolution balance in optical imaging remains a challenging task, often requiring complex mathematical treatment and controlled laboratory conditions to match theoretical predictions. With that in mind, we propose a simple yet robust analytical technique to determine the optimal aperture in a 4f imaging system for static and quasi-static objects. Our technique employs the mathematical formalism of the H-theorem, enabling us to directly access the information of an imaged object. By varying the aperture at the Fourier plane of the 4f system, we have empirically found an optimal aperture region where the imaging entropy is maximum, given that the object is fitted to the imaged area. At that region, the image is lit and well-resolved, and no further aperture decrease improves that, as information of the whole assembly (object plus imaging system) is maximum. With that analysis, we have also been able to investigate how the imperfections in an object affect the entropy during its imaging. Despite its simplicity, our technique is generally applicable and passable for automation, making it interesting for many imaging-based optical devices. Full article

The article discusses the design, fabrication, and experimental evaluation of a large-area vertical grating coupler (VGC) enabling simultaneous coupling of multiple input optical beams. The presented VCG was fabricated by direct nanoimprinting of a grating pattern in a non-hardened SiO_X:TiO_Y waveguide (WG) film. The WG film was deposited on a glass substrate using a combination of the sol–gel method and the dip-coating technique. The fabrication process allowed precise control of the waveguide film thickness and refractive index, as well as the VGC geometry. The relevance of the process was proved by a demonstration of optical coupling of multiple quasi-parallel input beams via the VGC to the WG layer. To make this possible, a dedicated optical coupling system was designed, including a polymer microlens array and optical fiber array positioned in a V-groove. This opens promising perspectives on using the proposed structure for the fabrication of low-cost multichannel optical sensor chips, as highlighted in the article’s final section. Full article

Three-dimensional (3D) photolithography has found wide applications in microelectronics, optoelectronics, biomedicine, etc. Traditionally, it requires repetitive exposure and developing cycles. Meanwhile, a laser direct writing (LDW) system with a digital micromirror device (DMD) enables high-speed maskless lithography with programmable doses. In this paper, we propose a quasi-3D digitized photolithography via LDW with a DMD to remove multiple developing cycles from the process. This approach quantizes the dose of the 3D geometry and stores it in a grayscale image. And the entire dose distribution can be formed by overlapping the exposures with sliced binary dose maps from the above grayscale dose map. In the image slicing algorithm, a modified Golomb coding is introduced to make full use of the highest available exposure intensity. Both 1D multi-step patterns and diffractive optical devices (DOEs) have been fabricated to verify its feasibility. This type of digitized quasi-3D photolithography can be applied to fabricating DOEs, microlens arrays (MLAs), micro-refractive optical elements (μROEs), etc., and 3D molds for micro-embossing/nano-imprinting. Full article

MWC 342 (V1972 Cyg) was discovered nearly 90 years ago as an early-type emission-line star. It was among the first hot stars whose strong infrared excess was detected in the early 1970s. Several mostly short-term photometric and spectroscopic studies resulted in contradictory conclusions about the nature and evolutionary status of MWC 342. It has been classified as a pre-main-sequence Herbig Be star, an evolved suspected binary system, and a long-period variable star. Suggestions on the nature of the secondary component to this B0/B1 primary included a cool M-type giant and an X-ray source. We collected medium- and high-resolution optical spectra of MWC 342 taken in 1994–2024 as well as optical photometric data taken in 1986–2024. Analysis of these data shows strong variations in the object’s brightness and spectral line properties at various time scales, but no strictly periodic phenomena have been found. Inparticular, such a long-term dataset allowed us to reveal the optical brightness variations over a nearly 20-year-long quasi-period, as well as their anti-correlation with the H$\alpha$ emission-line strength. Also, we did not confirm the presence of He ii emission lines and absorption lines of the star’s atmosphere that were suspected in previously published studies. Full article

Vortex beams characterized by helical phase wavefronts enable innovative explorations of optical and physical interactions. This work experimentally realizes longitudinally polarized vortices with arbitrary topological charges in terahertz (THz) frequencies using a silicon ring resonator integrated with a second-order diffraction grating. The implemented configuration enables flexible topological charge manipulation in longitudinally polarized electric fields through the excitation of quasi-transverse-magnetic (TM) waveguide modes with different frequencies. By employing a terahertz near-field measurement system, the spatial intensity patterns and phase characteristics of emitted waves are quantitatively analyzed via a precision probe. This strategy shows promising potential for applications in particle manipulation techniques and advanced imaging technologies. Full article

Aircraft mechanical maintenance involves high loads, repetitive movements, and awkward postures, significantly increasing the risk of work-related musculoskeletal disorders (WMSDs). Traditional static evaluation methods based on posture analysis fail to capture the complexity and dynamic nature of these tasks, limiting their applicability in maintenance settings. To address this limitation, this study introduces a novel quantitative WMSD risk assessment model that leverages 3D motion data collected through an optical motion capture system. The model evaluates dynamic human postures and employs an inverse trigonometric function algorithm to quantify the loading effects on working joints. Experimental validation was conducted through quasi-real-life scenarios to ensure the model’s reliability and applicability. The findings demonstrate that the proposed methodology provides both innovative and practical advantages, overcoming the constraints of conventional assessment techniques. Specifically, it enables precise quantification of physical task loads and enhances occupational injury risk assessments. The model is particularly valuable in physically demanding industries, such as aircraft maintenance, where accurate workload and fatigue monitoring are essential. By facilitating real-time ergonomic analysis, this approach allows managers to monitor worker health, optimize task schedules, and mitigate excessive fatigue and injury risks, ultimately improving both efficiency and workplace safety. Full article

This review paper explores the Riccati-type pseudo-potential formulation applied to the quasi-integrable sine-Gordon, KdV, and NLS models. The proposed framework provides a unified methodology for analyzing quasi-integrability properties across various integrable systems, including deformations of the sine-Gordon, Bullough–Dodd, Toda, KdV, pKdV, NLS, and SUSY sine-Gordon models. Key findings include the emergence of infinite towers of anomalous conservation laws within the Riccati-type approach and the identification of exact non-local conservation laws in the linear formulations of deformed models. As modified integrable models play a crucial role in diverse fields of nonlinear physics—such as Bose–Einstein condensation, superconductivity, gravity models, optics, and soliton turbulence—these results may have far-reaching applications. Full article

This study examines the surf and swash zone dynamics of a microtidal, low-energy, dissipative beach in Kos Island, Greece, using high-frequency optical monitoring with a Beach Optical Monitoring System (BOMS) and in situ wave measurements during the winter period. Increased wave heights induced the offshore migration of the wave-breaking zone with significant alongshore variability; however, no triggering of NOM (Net Offshore Movement) behavior was verified, while occasional rhythmic patterns were observed in the breaking location under moderate wave conditions. Shoreline dynamics showed transient erosional episodes coupled with elevated run-up excursions, yet the shoreline showed signs of recovery, suggesting a quasi-equilibrium state. Run-up energy spectra were consistently dominated by lower frequencies than those of incoming waves under both low- and high-energy conditions. This behavior is attributed to the nearshore sandbars acting as low-pass filters, dissipating high-frequency wave energy and allowing for lower-frequency motions to dominate run-up processes. A widely used empirical wave run-up predictor corresponded well with the video observations, confirming its applicability to low-energy dissipative beaches. These results underscore the role of submerged sandbars in regulating wave energy dissipation and stabilizing beach morphology under low-to-moderate wave conditions. Full article

To achieve laminates with constant bending stiffness to match the high precision requirement of optical systems made of carbon fiber reinforced plastic (CFRP), a new method, the normalized direction factor of bending stiffness (NDFBS), is proposed based on the normalized geometric factor of bending stiffness. Using NDFBS and its variance (VNDFBS), we investigate two common stacking patterns, I and II ([(θ₁)_m/(θ₂)_m/…/(θ_p)_m]_S and [(θ₁/θ₂/…/θ_p)_m]_S) and our proposed new stacking pattern, Pattern III ([(θ₁/θ₂/…/θ_p)_S]_m) based on the initial quasi-isotropic laminates, [θ₁/θ₂/…/θ_p]. The bending stiffness of the stacking sequence [(45/−45/0/90)_S]₂ tends to be more uniform than that of [45/−45/0/90]_2S, and the order of uniformity in bending stiffness of other stacking sequences is [(60/0/−60)_S]₄ > [60/0/−60]_4S > [(60/0/−60)_S]₂ > [60/0/−60]_2S. Both theoretical deviations and experimental observations confirm that as the cycle number m increased, the uniformity in bending stiffness is improved gradually, except for that of Pattern I. As the cycle number increased, the speed of Pattern III approaching the constant bending stiffness was faster than that of Patterns I and II_. Notably, to achieve a nearly identical uniformity in bending stiffness, only the square root of the cycle number of Pattern II was enough for Pattern III. Based on the same initial laminate and cycle number, Pattern III exhibited more uniform bending stiffness and strength, which are appropriate for precision optical components that require dimensional stability, such as space mirrors. Full article

Pole-zero maps and Bode plots are commonly utilized in control systems and the study of natural phenomena to visualize their origins and behavior. In this paper, these graphical methods are applied to investigate the behavior of cavity variations, ΔL, in a low-finesse Fabry–Pérot interferometer subjected to external perturbations. Both graphical representations are analyzed in the s-plane. The study is theoretically performed, and the theory is corroborated by developing three numerical experiments where small displacements were applied. Based on the theoretical and numerical results, the cavity length variations, $\Delta L$, can be studied on the s-plane applying the pole-zero maps and Bode plots. The two methods, including the theory and the experiments, are in agreement. Considering the theoretical and graphical results, pole-zero maps and Bode plots can be applied on the signal demodulation of optical interferometers and quasi-distributed sensors where local sensors are interferometers. Full article

This article discusses the design of a high-performance quasi-optical mode converter for the $T{E}_{33,12}$ mode at 210 GHz. The conversion process is challenging due to a caustic-to-cavity radius ratio of approximately 0.41. The mode converter employs an optimized dimpled wall launcher, analyzed using coupling mode theory with twenty-five coupled modes, compared to the usual nine modes and optimized reflector systems, to effectively address the conversion challenge.Electromagnetic field analysis within the launcher wall was optimized using MATLAB R2021b. The radiation fields from the launcher were analyzed in free space using Gaussian optics and vector diffraction theory. The mirror system consists of a quasi-elliptical mirror, an elliptical mirror, and phase-corrected parabolic mirrors. Following phase correction, the output window achieved a scalar Gaussian mode content of 99.0% and a vector Gaussian mode content of 97.4%. Full article

Topological photonic sensors have emerged as a breakthrough in modern optical sensing by integrating topological protection and light confinement mechanisms such as topological states, quasi-bound states in the continuum (quasi-BICs), and Tamm plasmon polaritons (TPPs). These devices exhibit exceptional sensitivity and high-Q resonances, making them ideal for high-precision environmental monitoring, biomedical diagnostics, and industrial sensing applications. This review explores the foundational physics and diverse sensor architectures, from refractive index sensors and biosensors to gas and thermal sensors, emphasizing their working principles and performance metrics. We further examine the challenges of achieving ultrahigh-Q operation in practical devices, limitations in multiparameter sensing, and design complexity. We propose physics-driven solutions to overcome these barriers, such as integrating Weyl semimetals, graphene-based heterostructures, and non-Hermitian photonic systems. This comparative study highlights the transformative impact of topological photonic sensors in achieving ultra-sensitive detection across multiple fields. Full article

Phase transformations induced by short optical pulses are mainstream in studies on the dynamics of cooperative electronic states. We present a semiphenomenological modeling of spatiotemporal effects expected when optical excitons are intricate with the order parameter such as in, e.g., organic compounds with neutral-ionic ferroelectric phase transitions. A conceptual complication appears here, where both the excitation and the ground state ordering are built from the intermolecular electronic transfer. To describe both thermodynamic and dynamic effects on the same root, we adopt, for the phase transition, a view of the excitonic insulator—a hypothetical phase of a semiconductor that appears if the exciton energy becomes negative. After the initial pumping pulse, a quasi-condensate of excitons can appear as a macroscopic quantum state that then evolves, while interacting with other degrees of freedom which are prone to an instability. The self-trapping of excitons enhances their density, which can locally surpass a critical value to trigger the phase transformation. The system is stratified in domains that evolve through dynamical phase transitions and may persist even after the initiating excitons have recombined. Full article

With the advancement of space exploration and optical communication toward deep space, the high-precision evaluation and image stabilization of space optical payloads under micro-vibration have become increasingly critical. To address these challenges and ensure sub-micro-radian pointing accuracy for high-precision space optical payloads (HPSOPs), this paper proposes a high-precision micro-vibration testing scheme and a two-stage image stabilization system. The micro-vibration testing scheme is based on an automated quasi-zero stiffness suspension device (AQZSSD), which enhances testing sensitivity and environmental disturbance resistance, ensuring the accuracy of the results. The two-stage image stabilization system integrates three bipod vibration isolation legs (BVILs) and a decoupled fast steering mirror (FSM), extending control bandwidth and achieving comprehensive vibration suppression. Micro-vibration testing and image stabilization experiments were conducted under disturbances from multiple vibration sources. Experimental results demonstrate that the AQZSSD introduces disturbances below 0.4 Hz, confirming its quasi-zero stiffness characteristics in alignment with theoretical predictions. Furthermore, the line-of-sight (LOS) jitter root mean square (RMS) value is reduced from 1.253 μrad to 0.276 μrad, achieving sub-micro-radian stability. Additionally, due to the coupling effect of the micro-vibration response, the collaborative testing results were found to be lower than the linear superposition of individual sources. This work offers critical theoretical and technical support for the development of HPSOPs, with potential applications in future space missions and advanced optical technologies. Full article

Fiber-optic tip sensors offer significant potential in biomedical applications due to their high sensitivity, compact size, and resistance to electromagnetic interference. This study focuses on advancing phase demodulation techniques for ultra-short Fabry–Pérot cavities within limited spectral bandwidths to enhance their application in biomedicine and diagnostics. We propose a novel sparse-sampled white-light interferometry system for respiratory monitoring, utilizing a monolithic integrated semiconductor tunable laser for quasi-continuous frequency scanning across 191.2–196.15 THz at a sampling rate of 5 kHz. A four-step phase-shifting algorithm (PSA) ensures precise phase demodulation, enabling high sensitivity for short-cavity fiber-optic sensors under constrained spectral bandwidth conditions. Humidity sensors fabricated via a self-growing polymerization process further enhance the system’s functionality. The experimental results demonstrate the system’s capability to accurately capture diverse breathing patterns—including normal, rapid, and deep states—with fast response and recovery times. These findings establish the system’s potential for real-time respiratory monitoring in clinical and point-of-care settings. Full article
