Search Results (30)

Few studies have examined Hybrid Aquatic–Aerial Vehicles (HAAVs), autonomous vehicles designed to operate in both air and water, especially those that are aircraft-launched and recovered, with a variable-sweep design to free dive into a body of water and breach under buoyant and propulsive force to re-achieve flight. The novel design research examines the viability of a recoverable sonar-search child aircraft for maritime patrol, one which can overcome the prohibitive sea state limitations of all current HAAV designs in the research literature. This paper reports on the analysis from computational fluid dynamic (CFD) simulations of such an HAAV diving into static seawater at low speeds due to the reverse thrust of two retractable electric-ducted fans (EDFs) and its subsequent breach back into flight initially using a fast buoyancy engine developed for deep-sea research vessels. The HAAV model entered the water column at speeds around 10 ms⁻¹ and exited at 5 ms⁻¹ under various buoyancy cases, normal to the surface. Results revealed that impact force magnitudes varied with entry speed and were more acute according to vehicle mass, while a sufficient portion of the fuselage was able to clear typical wave heights during its breach for its EDF propulsors and wings to protract unhindered. Examining the medium transition dynamics of such a novel HAAV has provided insight into the structural, propulsive, buoyancy, and control requirements for future conceptual design iterations. Research is now focused on validating these unperturbed CFD dive and breach cases with pool experiments before then parametrically and numerically examining the effects of realistic ocean sea states. Full article

Outboard Dynamic-inlet Waterjets (ODW) are axisymmetric units, powered by a self-contained pump, that, by processing a uniform undisturbed streamtube, can operate more efficiently than conventional marine propulsors. This feature also provides methodological convenience, enabling accurate numerical investigations of the system alone using 2D axisymmetric models. Leveraging this property, the present study bridges the gap on the design principles required to tailor ODW geometries across multiple operating conditions. Reynolds-Averaged Navier Stokes (RANS) equations are solved, including turbulence and cavitation models, to draw the propulsor’s characteristic maps and identify two relevant operating points, set by the combination of a specified pump rotational regime with an advancing velocity. Simulations for these in- and off-design conditions are systematically performed over a database of 512 randomly sampled geometric variants. The corresponding results show that optimised shapes improving the inlet Pressure Recovery (PR) and nacelle drag at cruise conditions result in beneficial outcomes also at take-off operations, where lip cavitation may occur. Thus, analysing together the off-design PR and the cruise net force underscores their conflicting behaviour. In fact, while nacelles shortened by $12\%$ can reduce overall drag and enhance nominal net thrust by $2\%$, designs featuring a $34\%$ wider capture area improve off-design PR by over $1.5\%$, albeit at the cost of compromised propulsive efficiency under any operating range. Full article

This study investigated the impact of different load distribution ratios between two rotors on the unsteady performance of dual-stage pump-jet propulsors using Computational Fluid Dynamics (CFDs) and experimental methods. The Shear Stress Transport (SST) k-ω model was employed to solve turbulence problems, and the numerical simulation method used was validated. The following conclusions were drawn: Different load distribution ratios of the dual-stage rotors have no significant impact on the overall propulsion performance of the propulsor. As the load distribution ratio is aft-shifted, the axial unsteady force of the entire propulsor continuously decreases, with a reduction of up to 53.6%. This is due to the gradual reduction in the energy of the first-stage rotor, leading to a more uniform Blade-Passing Frequency Velocity Harmonic Coefficient (BPFVHC) in front of the second-stage rotor, thereby gradually reducing the unsteady force of the second-stage rotor. The experimental results also indicate that the aft-shifted load model can reduce the sound pressure level of the propulsor. Compared to the prototype propulsor, the sound pressure level at the Blade-Passing Frequency decreases by 6.67 dB, or about 78.5%, in sound energy. This study has important implications for the low-excitation design of dual-stage pump-jet propulsors. Full article

This paper reconciles the assessment of fan and propeller performance by deriving common metrics that describe their design and operational characteristics and applies them to real-world design examples. Historically, various applications with large differences in flight Mach number and thrust requirements have led to different design methodologies and performance descriptors for ducted and unducted propulsors, making direct comparisons between these propulsion concepts challenging until today. One of the limitations of conventional propeller design methods is the difficulty in isolating the aerodynamic performance of blade sections from the overall design concept. The overall efficiency is largely impacted by top-level design parameters, while the aerodynamic quality is determined by the shaping and spanwise stacking of blade profiles. In contrast, turbomachinery design focuses primarily on the efficiency of the compression process and their respective efficiency metrics. This paper addresses these issues by systematically breaking down propeller efficiency into contributions commonly used in turbomachinery design. By applying consistent methodologies, we thereby enable a fair and quantitative comparison of the potential performance benefit of each concept. Furthermore, using common performance metrics simplifies the design process, making it more accessible to less experienced designers and facilitating the exploration of alternative design approaches for unducted propulsors. Full article

The high-speed and efficient swimming characteristics of tuna are valuable for designing bio-inspired underwater vehicles. Tuna use their highly deformable caudal fins as propulsors during swimming. Caudal fin deformation is categorized into skeletal-controlled active deformation and fluid-induced flexible passive deformation. To investigate how flexible passive deformation affects propulsion performance, simulations of four caudal fins with varying flexibilities under two $St$ numbers in a uniform flow are conducted using the finite volume method. This study finds that the medium-flexibility caudal fin achieves a higher time-averaged thrust coefficient without sacrificing efficiency under both high and low $St$ numbers. At a high $St$ number, the medium-flexibility caudal fin enhances thrust by reducing detrimental secondary flows. At a low $St$ number, the medium-flexibility caudal fin increases thrust by strengthening vortex rings, which induces a stronger backward jet. Full article

Marine propeller design requirements have risen in quantity and quality in recent decades. Reduced propeller cavitation is targeted to ensure that comfort requirements and environmental regulations are met. This paper presents the development of a mesh refinement process for the numerical prediction of tip vortex cavitation (TVC) using the commercial CFD package STAR-CCM+. Given the strong dependence on the mesh resolution within the areas of interest, mesh refinement and the use of field functions for adaptive meshing were demonstrated. The developed numerical model was substantiated against relevant published test data. Subsequently, the validated mesh refinement process was extended to scaled-up models representing medium- and full-scale propellers. The results showed that this process can be applied to CFD simulations to capture the minimum pressure within a tip vortex core. This process is also applicable to different types of hydrodynamic propulsors at both model scale and full scale. Additionally, the cavitation inception scaling law was evaluated for all small-scale and full-scale models, and it was found that the scaling parameter obtained using the developed refinement process was somewhat close to that obtained using existing methods. It is expected that the mesh refinement process developed in this study can be used to investigate the effect of scaling on tip vortex cavitation inception. Full article

The imperative for energy conservation and environmental protection has led to the development of innovative aircraft designs. This study explored a novel thrust control configuration for blended-wing-body (BWB) aircraft with distributed electric boundary-layer ingestion (BLI) propulsors, addressing the issues of sagging and altitude loss during landing. The research focused on a small-scale BWB demonstrator equipped with six BLI fans, each with a 90 mm diameter. Various thrust control configurations were evaluated to achieve significant thrust reduction while maintaining lift, including dual-layer sleeve, separate flap-type, single-stage linkage flap-type, and dual-stage linkage flap-type configurations. The separate flap-type configuration was tested through ground experiments. Control experiments were conducted under three different experimental conditions as follows: deflection of the upper cascades only, deflection of the lower cascades only, and symmetrical deflection of both cascades. For each condition, the deflection angles tested were 0°, 10°, 20°, 30°, 40°, 50°, and 60°. The thrust reductions observed for these three conditions were 0%, 37.5%, and 27.5% of the maximum thrust, respectively, without additional changes in the pitch moment. A combined thrust adjustment method maintaining a zero pitch moment demonstrated a linear thrust reduction to 20% of its initial value. The experiment concluded that the novel thrust control configuration effectively adjusted thrust without altering the BLI fans’ rotation speed, solving the coupled lift–thrust problem and enhancing BWB landing stability. Full article

The increasing use of drones for safety-critical applications, particularly beyond visual lines of sight and over densely populated areas, necessitates safer and more reliable designs. To address this need, this paper introduces a novel methodology integrating Null Controllability with the Model-Based Safety Assessment (MBSA) framework AltaRica 3.0 to optimize propulsor configurations and system architectures. The main advancement of this method lies in the automation of reliability modeling and the integration of controllability assessment, eliminating restrictions on the types of propulsor configurations and system architectures that can be evaluated and significantly reducing the effort required for each design iteration. Through a hexarotor drone case study, the proposed method enabled a high number of design iterations, efficiently exploring various aspects of the design problem simultaneously, such as configuration, system architecture, and controllability hypothesis, which is not possible with state-of-the-art techniques. This approach demonstrated significant reliability improvements by implementing and optimizing redundancies, reducing the probability of loss of control by up to 99%. The case study also highlighted the increasing difficulty of enhancing reliability with each iteration and confirmed that it is unnecessary to consider more than two simultaneous failures for design optimization. A comparison of reliability figures with previous studies highlights the crucial role of system architecture in effectively enhancing drone design reliability. This work advances the field by providing an effective multidisciplinary modeling framework for drone design, enhancing reliability in safety-critical applications. Full article

Electric propulsion systems have emerged as a disruptive technological approach towards achieving sustainable and climate-neutral aviation. To expand the operational envelope of such propulsion units in terms of altitude and velocity, an enclosing duct and counter-rotating rotors to enhance efficiency can be utilized. In this study, an iterative CFD-based design tool developed for these novel propulsion systems is utilized to design a reference engine, having a classic rotor–stator configuration. Being the key component of this propulsor, a manufacturing process for composite blades is presented. This effort aims to make state-of-the-art technology accessible to smaller research projects, promoting the widespread adoption of electric propulsion technology in the aviation sector. By experimental investigations of the blade elongation both in tensile tests and engine operation, measuring the tip clearance with a high-speed camera, this process could be validated to facilitate the transferability of research. Finally, the performance of the manufactured engine is measured by a five-hole miniature probe, not only in design point but also in off-design operation. The results indicate that a substantial reduction in discrepancies between initial specifications, subsequent CFD simulations, and experimental investigations compared to conventional design tools relying on empirical formulations can be achieved due to the CFD-based approach. This allows the CFD-based tool to be validated for designing scalable contra-rotating fan engines. Full article

To reduce the structural vibration of the duct structure in pump-jet propulsors (PJPs) and lower the induced vibration noise, this study learned from the “processor box” in an aero-engine and set a certain number of axial slots in the PJP. First, using finite element analysis, both dry and wet modes of the PJP ducts with and without an axial slot structure were simulated for analysis. Next, with the two-way fluid–solid coupling calculation method, the vibration performances of the PJP ducts with and without axial slots were contrasted and studied. The differences in calculation results under different duct structures were compared from three aspects—the vibration displacement, velocity, and acceleration of the duct and mesh nodes. According to the present results, after the addition of axial slots, the vibration displacement, the vibration velocity, and the vibration acceleration can be significantly reduced, especially in the back segment of the duct. Meanwhile, it can be concluded that it is quite important to select vibration acceleration for structural analysis in evaluating the PJP vibration. This study can provide a reference for further designs of low-noise PJPs. Full article

This paper presents the design and experimental verification of a hubless rim-driven propulsor (HRDP) for an unmanned underwater drone. The bearings of the HRDP are required to rotate and fix the propeller. However, the bearing increases the weight and size of the propulsor. Therefore, this paper proposes a structure in which the rotor of a surface-mounted permanent magnet synchronous motor (SPMSM) and a hubless propeller are combined without the bearings in the rim-driven propulsor. The design procedure of the propulsor is established and the response surface method (RSM) is used to design and optimize the proposed structure. The validity of the HRDP with the proposed structure is verified through simulation results using an electromagnetic field (EF) analysis and computational fluid analysis, and test results using a water tank. Finally, compared to the initial HRDP, the weight of the SPMSM in the optimized HRDP is decreased by 7.3%, and by reducing the required torque by about 19%, power consumption is reduced by about 24.66 W. Full article

Submarines with pumpjet propulsors have recently been used in many countries to improve their propulsion and noise performance. The pumpjet has the advantage of improving noise and cavitation performance by increasing the pressure inside the duct, and it has good efficiency at a low advance ratio. This study analyzed the propulsive performance of a pumpjet propulsor affixed to a SUBOFF submarine as a function of variations in the design parameters using computational fluid dynamics analysis. The incidence angle and camber of the duct and the pitch angle of the stator were selected as the design parameters. To investigate the propulsion performance as a function of the design parameter variations, each case’s thrust, torque, and efficiency were compared, and the velocity and pressure fields of each case were analyzed. In addition, the efficiency was analyzed using the non-dimensional mass flow rate and area ratio difference for each case. The duct incidence angle contributed most dominantly to the dimensionless flow rate and the difference in area ratio, and these two factors resulted in high efficiency at certain values. It is expected that further research will be conducted in the near future that takes into account cavitation inception speed and cavitation. Full article

The self-propelled swimming of a flexible propulsor is numerically investigated by using fluid-structure interaction simulations. A distributed active moment mimicking the muscle actuation in fish is used to drive the self-propulsion. The active moment imposed on the body of the swimmer takes the form of a traveling wave. The influences of some key parameters, such as the wavenumber, the amplitude of moment density and the Reynolds number, on the performance of straight-line swimming are explored. The influence of the ground effect on speed and efficiency is investigated through the simulation of near-wall swimming. The turning maneuver is also successfully performed by adopting a simple evolution law for the leading-edge deflection angle. The results of the present study are expected to be helpful to the design of bio-inspired autonomous underwater vehicles. Full article

The growth of the airline industry has highlighted the need for more environmentally conscious aviation, leading to the conceptualization of more fuel-efficient aircraft. One concept that has received significant attention and has been associated with improved fuel efficiency is the boundary layer ingesting (BLI) propulsion system, which refers to the ingesting of the aircraft wake by the propulsors. Although BLI has theoretically been proven to reduce fuel burn, this can potentially be offset by the reduced efficiency and stability experienced by the propulsor in the presence of distorted inflow. Therefore, engine intakes must be optimized in order to mitigate the effects of BLI on the propulsion system. In this work, the shape optimization of a BLI intake is investigated using a free-form deformation technique in combination with a multi-objective genetic algorithm, in order to minimize pressure losses and distortion at the engine inlet. The optimization is performed on an S-duct intake at a cruise altitude of approximately 37,000 feet and a free stream Mach number of 0.7. An optimization strategy was developed for the task which was able to produce a Pareto optimal set of designs with improved pressure recovery and distortion. The general trend of the optimal designs shows that to reduce distortion the optimizer accelerates the flow to reduce the size of the low total pressure region and increase the dynamic pressure at the engine inlet. In contrast, the pressure recovery was increased by reducing velocity as well as shifting the maximum velocity region to the outlet, which reduces the viscous dissipation losses within the intake. The final result is a fully autonomous optimization strategy resulting in reduced pressure losses and reduced distortion leading to higher efficiency BLI S-duct intake designs. Full article

This paper presents a 10 kW, 12-slot 10-pole surface-mounted permanent magnet synchronous motor (SPMSM) design with fractional-slot concentrated winding for a podded propulsion system. Its load is a propeller that is proportional to the square of the rotational speed and the fifth power of the propeller diameter. Taking this into account, three SPMSMs with rated rotational speeds of 600, 1200, and 1800 rpm with the same rated output power of 10 kW were analyzed. These were designed under the same conditions (i.e., torque per rotor volume, air-gap length, current density, power factor, fill-factor, and supply voltage). Based on the SPMSMs designed by electromagnetic analysis, the housing of a podded propulsor for each SPMSM was modeled for mechanical analysis, including such parameters as forced vibration, radiated noise, and modal acoustics analysis in air and water. From the modal acoustics analysis, it is confirmed that the natural frequencies of a structure in water are lower than those in air because of the added mass effect of water. Full article
