To enhance the reliability of unmanned hydro-mechanical transmission tractors, a fault diagnosis method for their power-shift system was developed. First, fault types were identified, and sample data was collected via a test bench. Next, a feature extraction method for data dimensionality reduction and a deep learning network called W_SCBAM were introduced for fault diagnosis. Both W_SCBAM and conventional algorithms were trained 20 times, and their performance was compared. Further testing of W_SCBAM was conducted in various application scenarios. The results indicate that the feature extraction method reduces the sample length from 46 to 3. The fault diagnosis accuracy of W_SCBAM for the radial-inlet clutch system has an expectation of 98.5% and a variance of 1.6%, respectively, outperforming other algorithms. W_SCBAM also excels in diagnosing faults in the axial-inlet clutch system, achieving 97.6% accuracy even with environmental noise. Unlike traditional methods, this study integrates the update of a dimensionality reduction matrix into network parameter training, achieving high-precision classification with minimal input data and lightweight network structure, ensuring reliable data transmission and real-time fault diagnosis of unmanned tractors. Full article

Tractors are the most important agricultural power machinery. With the development of tractors toward large-scale and electrification, the design of modern tractor transmission systems increasingly relies on computer simulation technology. However, tractor transmission systems, especially power-shift transmissions and CVTs, are highly complex industrial products that involve specialized knowledge from multiple disciplines. Engineers and researchers find it difficult to choose the correct mathematical model and grasp the trend of technological development when applying simulation technology. To address this issue, we conducted a systematic review of the field and carried out the following work: First, the types and basic principles of tractor transmission systems were introduced; Second, the modeling methods and applications of computer simulation technology in the structural optimization, power-shift control, and energy saving of tractor transmission systems were reviewed; Finally, the method of obtaining simulation parameters through system identification was introduced. Although computer simulation technology has been applied in the development of all tractor transmission systems, there are still some issues that need attention, such as the lack of established shift quality evaluation indicators and driving cycles suitable for tractors, which are crucial for the reliability of simulation results but are rarely studied. These issues need to be addressed in future work. Full article

When shifting gears around a tractor’s power shift transmission, it is necessary to coordinate the control of multiple clutches and formulate a reasonable clutch engagement law to ensure the reliability and power of the power system. This paper explores the impact of different clutch engagement patterns on shifting characteristics in a power-shift tractor with multiple clutches. Shifting performance is comprehensively evaluated using indicators such as shifting time, impact degree, slip energies, and transmission output torque. The aim is to enhance the quality of power shifting, operational efficiency, and the service life of the transmission system. This paper takes the YTO TX4A transmission system as the research object, analyzes its working principle, and establishes a mathematical model of a power shift transmission system under different clutch engagement rules. This model of power shift transmission is established based on Matlab2021/Simulink and the AMESim2021 software platform. A simulation analysis is carried out for four clutches working simultaneously in a tractor’s advance gear II and lift gear III. The simulation results indicate that switching rule C is superior to switching rule A and switching rule B. Compared with the engagement scheme in which the torque exchange overlap time for both sets of clutches is 0.3 s, the scheme with a torque exchange overlap time of 0.15 s indicated a shifting time increase of 0.2 s, a slip energy increase of 4%, and a minimum output torque of the transmission increase of 2%. In the scheme with a torque exchange overlap time of 0 s, the shifting time increased by 0.15 s, the slip energy decreased by 13.5%, and the minimum output torque of the transmission decreased by 17%. Through the study of shifting performance under three different clutch engagement patterns, it is concluded that, during the shift from forward gear II to gear III in the YTO TX4A transmission system, appropriately reducing the torque exchange overlap time for both sets of clutches and avoiding simultaneous torque exchange can reduce the complexity of clutch control. This leads to smoother, more powerful, and more comfortable power shifting, effectively prolonging the service life of the transmission system. Full article

The speed ratio parameters of transmission are crucial factors that affect a vehicle’s power, economy, and comfort. Due to the complex working conditions, multiple working modes, and wide range of speed ratios of agricultural tractors, designing and optimizing speed ratio parameters in power-shift transmissions is a challenging task. This paper proposes a transmission speed ratio optimization method based on the life cycle speed utilization rate of general-purpose agricultural tractors. The speed ratio parameters are optimized and solved using the genetic algorithm, with multi-gear power-shift transmissions in agricultural tractors as the research subject. The optimization results and simulation analysis show that the optimized speed ratio has more and denser gears in the common operating speed range while ensuring the general-purpose agricultural tractors’ use requirements. Compared to commonly used geometric series speed ratios, tractors using the optimized speed ratio parameters in this paper can significantly improve fuel economy. Most importantly, this provides a practical method reference for optimizing speed ratios in multi-gear gearboxes with complex structures. Full article

The objectives of this study are the development and verification of a simulation model of the partial PST (power-shift transmission) tractor based on actual field operations. The PST simulation model was verified for the asphalt driving condition, and performance was evaluated for asphalt driving, plow, and rotary tillage. In this study, the traditional, APS (Auto Power Shift) ECO, and APS power engine modes were used to analyze fuel consumption. The statistical analysis proved that the experimental and simulation results were in a linear relationship, with an accuracy of over 98%. Finally, the results suggested that users could utilize the 95-kW partial PST tractor in the APS ECO engine mode with higher fuel economy compared to the traditional and APS power modes. Full article

Due to the harsh working environment of the tractor, the transmission can often be faulty. In order to ensure the reliability of its operation, it must be monitored and the fault discovered. In this paper, the support vector machine (SVM) method is used. The eigenvector conversion of the original data uses the following eigenvectors: Three fault modes (leakage fault of shift clutch hydraulic cylinder, blockage fault of oil passage, and blockage fault of proportional valve spool) are identified in matrix and laboratory (MATLAB) with the help of the library for support vector machines (LibSVM) toolkit, and the classification accuracy of test samples is 90%. The normal mode of the PST electro-hydraulic system and the three kinds of fault modes mentioned above are discriminated against, and the correct rate of fault diagnosis reaches 95%, which meets the needs of practical engineering. Analysis of the fault recording data of the power shifting transmission shift solenoid valve shows that the difference between fault pressure data and normal data is small, and the value of traffic data is greater. This method can realize the fault mode online recognition based on controller area network (CAN) communication, and the research results provide a theoretical basis for the fault diagnosis of the PST electro-hydraulic control system. Full article

Tractors are usually applied in field operations, road transport, and other operations. Modern agriculture has higher design requirements for tractor powertrains due to the complicated working environments and various operations. To meet the driving requirements of the tractor under multiple operations, a mechanic-electronic-hydraulic powertrain system (MEH-PS) for tractors has been designed according to the characteristics of the hydro-mechanical composite transmission and electromechanical hybrid system. The principle of multiple driven and transmission modes of MEH-PS are introduced, the speed regulation characteristic curve of hydro-mechanical transmission (HMT) is given, and the related power element model, tractor model, and efficiency model are established. The HMT optimal economy transmission ratio control strategy and hybrid rule-based optimization energy management strategy were developed. Take three typical tractor operations for analysis: ploughing, harvesting, and transport. The results show that the engine operating points are mainly distributed in the higher load area, the tractor maintains high system efficiency, and the relative error between simulated and tested fuel consumption is within 5%, which further proves the reliability of the model. The solution also showed lower fuel consumption in all three operations compared to DLG’s announced PowerShift tractors and CVT tractors. Thus, the powertrain system can meet the tractor’s drive requirements under complex operating conditions and maintain high efficiency and is therefore suitable for tractors that need to operate frequently in the field and on the road. Full article

This study is focused on the estimation of fuel consumption of the power-shift transmission (PST) tractor based on PTO (power take-off) dynamometer test. The simulation model of PST tractor was developed using the configurations and powertrain of the real PST tractor. The PTO dynamometer was installed to measure the engine load and fuel consumption at various engine load levels (40, 50, 60, 70, 80, and 90%), and verify the simulation model. The axle load was also predicted using tractor’s specifications as an input parameter of the simulation model. The simulation and measured results were analyzed and compared statistically. It was observed that the engine load, as well as fuel consumption, were directly proportional to the engine load levels. However, it was statistically proved that there was no significant difference between the simulation and measured engine torque and fuel consumption at each load level. The regression equations show that there was an exponential relationship between the fuel consumption and engine load levels. However, the specific fuel consumptions (SFC) for both simulation and measured were linear relationships and had no significant difference between them at each engine load level. The results were statistically proved that the simulation and measured SFCs were similar trends. The plow tillage operation could be performed at the gear stage of 7.65 km/h with higher working efficiency at low fuel consumption. The drawback of this study is to use a constant axle load instead of dynamic load. This study can provide useful information for both researchers and manufacturers related to the automated transmission of an agricultural tractor, especially PST tractor for digital farming solutions. Finally, it could contribute to the manufacturers developing a new agricultural tractor with higher fuel efficiency. Full article

The objective of this study is the simulation of the most affected design factors and variables of the clutch pack for the power-shift transmission (PST) of a tractor based measured data. The simulation model, the mathematical model of sliding velocity, a moment of inertia, and clutch engagement pressure of clutch pack were developed using the powertrain and configurations of the real PST tractor. In this study, the sensor fusion method was used to precisely measure the proportional valve pressure by test bench, which was applied to the simulation model. The clutch engagement times were found 1.20 s at all temperatures for determined factors. The engagement pressures have a significant difference at various temperatures (25 to 100 °C) of the hydraulic oils after the 1.20 s but the most affected factors were satisfied with the simulation conditions that ensure the clutch engagement on time. Finally, this sensor fusion method is believed to be helpful in realizing precision agriculture through minimization of power loss and maximum energy efficiency of tractors. Full article

Automatic mechanical transmission (AMT) with a gearshift assistant mechanism is a novel transmission architect concept aiming to improve the torque interruption and driveline jerk of AMT. During the shifting process, the shifting performance deteriorates as the varying road gradient and the friction coefficient worsen the coupling effect between the motor torque and the clutch friction torque. This paper focuses on improving the controller’s robustness of AMT with a gearshift assistant mechanism against the perturbed parameters during the stage of torque gap filling. In this paper, a detailed powertrain simulation model was presented. Based on a decoupling controller and a disturbance compensator, proportional-integral-differential (PID) controllers are applied to enhance the robustness and the decoupling effect. The PID parameters are automatically tuned by employing the Nelder-Mead method. In the tuning process, a cost function was established to demonstrate the outputs’ reference tracking performance, and the PID parameters are tuned by minimizing the cost function. Finally, the tuned parameters are stored in PID maps to make them adjustable online. Simulation results show that with the perturbed parameters well estimated, the upshift process was successful and the torque filling effect was also acceptable. The proposed transmission is a promising structure for industry applications. Full article

An automatic control strategy for forward speed in the planting process is proposed to improve the fuel economy and reduce the labor intensity of drivers. Models of tractors with power-shift transmission (PST) and a precise pneumatic planter with an electric-driven seed metering device are built as research objects and simulated using Matlab with Simulink. The economic comprehensive control strategies for forward speed, including gear-shift schedule and cruise control strategy, are developed. Four levels control mode with different fuel economy performances are implemented to meet different driver or operation condition requirements. In addition, the control strategy is developed for the seed-metering device motor to maintain the required seed spacing in planting. Finally, the fuel economy and effectiveness of the control strategies for forward speed and planting quality are verified by simulations with Matlab/Simulink and Matlab/Stateflow. The simulation results verify the satisfactory performance of the proposed control strategies. The error of seed spacing is less than 3% when planting with speed fluctuation. Under the premise of ensuring planting quality and driver’s demands, the cruise control strategies for forward speed have more significant effects on the fuel economy than previous cruise control strategies. Furthermore, the control mode with higher level has better fuel economy and a larger speed deviation range. Full article

In this paper, energetic loss models in the events of shifting gear and starting engine in a parallel Hybrid Electric Vehicle equipped with an Automated Manual Transmission (AMT) will be introduced. The optimal control algorithm for the start-stop, power split and gear shift problem based on Dynamic Programming-Pontryagin’s Minimum Principle control approach is used to evaluate the effect of gear shift and engine start losses on the optimal solution. Furthermore, with preview route information available, a model predictive control algorithm is utilized to investigate the achievable fuel savings with respect to the prediction horizon. Under influence of the gear shift loss, simulation results of the prototype hybrid passenger car disclose a superior fuel efficiency property of the powershift AMT over its normal AMT counterpart. Sensitivity analysis of the traction force interruption time in a gear shift process can give a new perception on fuel economy benefit of powershift transmissions (e.g. automatic, dual clutch, powershift AMT, etc.) over a normal AMT. The study also reveals a minimum prediction length of 4s required for the design of such a realtime implementable controller to get the possible maximum fuel economy level under the impact of the engine start loss. Full article
