The development of potash deposits under complex mining and geological conditions requires the implementation of efficient geotechnologies, including backfilling of mined-out voids. Preserving the water-protective strata and preventing mining-induced accidents are impossible without accurate prediction of the stress–strain state of the backfill mass. Traditional models, based on the Mohr–Coulomb criterion, are unable to properly describe physical and mechanical processes occurring in crushed salt rock, including the transition from dilatancy to compaction and nonlinear hardening. This requires the application of specialized models such as the SRP model. The aim of this study is to investigate the mechanical response of crushed salt rock backfill material under complex loading conditions and to calibrate the parameters of the SRP model in order to improve the accuracy of geomechanical calculations. The shape of the plastic flow surface in the deviatoric plane was established, including both shear and cap components. A nonlinear dependence of the friction angle on mean stress was identified and described by a logarithmic function. The law of plastic hardening was determined, and a non-associated plastic flow rule was confirmed in the shear domain. The calibrated SRP model allows for predicting the backfill mass behavior with high reliability, which is a necessary condition for substantiating the parameters of safe potash mining. Full article

Maintaining the integrity of impermeable strata between mine workings and overlying aquifers is critical, because seepage pathways may cause mine flooding and surface subsidence. In the Upper Kama potash deposit, the impermeable sequence is a 50–140 m thick layered sequence of evaporites and clays overlying mined-out chambers. Under long-term loading, salt rocks tend to creep, soften, and localize damage, which can cause failure in the impermeable strata. In this paper, the Concrete damage-plasticity model, supplemented by the N2PC-MCT viscoplastic creep model, is applied to simulate the initiation and evolution of seepage pathways in the Upper Kama impermeable strata. Model parameters are obtained from published laboratory tests (uniaxial and triaxial compression and tension) and validated using observed ground-surface subsidence. A plane-strain finite-element model incorporates the stratified lithology, interface elements between layers, and sequential excavation. Long-term simulations up to 50 years investigate two operational scenarios: with and without backfilling. The calibrated model reproduces the main stages of surface subsidence and chamber closure. Without backfilling, simulations indicate that tensile damage localizes mainly in a stiff central salt layer of the impermeable strata, with most cracks appearing approximately between 33 and 37 years after the start of mining. With backfill, tensile crack propagation stops and damage remains stable. A hypothetical homogeneous impermeable strata case confirms that the observed central-layer cracking is associated with stiffness contrasts and composite bending in the stratified system. An approximate analytical multilayer beam solution, based on energy minimization, predicts bending stress concentration in stiff intermediate layers and is consistent with the numerical stress distribution. The combined numerical and analytical results provide insight into the mechanisms of long-term conductive fracture initiation in stratified impermeable strata and may serve as a basis for preliminary hazard indication and for planning mitigation measures, including backfilling and focused monitoring of stiff central layers. Because the study is based on a 2D plane-strain model, the quantitative estimates should be regarded as preliminary and require verification by 3D modelling and further field observations. Full article

Potash is a strategically critical mineral resource essential for ensuring national food security, thereby necessitating the exploration of new deposits to sustain long-term supply. This study systematically evaluates the risk of ground subsidence associated with a “brine extraction–replenishment equilibrium” mining scheme through an integrated framework combining three-dimensional geological modeling and numerical simulation. The research focuses on deep potassium-rich brine resources in the Sanshui Basin, Guangdong Province, China. Geological data from 95 boreholes were processed to construct a high-resolution three-dimensional geological model (61.40 km × 35.20 km × 3.50 km) using Petrel software. Numerical simulations based on poroelastic theory were conducted under multiple extraction scenarios, and the predicted subsidence was assessed against relevant engineering standards for highways and building foundations. The results indicate that: (1) brine extraction from consolidated sandstone represents a fluid displacement process, where the equilibrium scheme induces only minor effective stress redistribution without forming dissolution cavities; (2) global subsidence investigations suggests consolidation primarily affects Quaternary unconsolidated strata, making consolidated sandstone extraction associated with extremely low risk; (3) the maximum subsidence is 5.55 mm and 6.82 mm in the primary and secondary exploration areas, with corresponding surface inclinations of 0.00047‰ and 0.00040‰; (4) unlike solution mining that creates large cavities, deep brine extraction generates no significant inter-stratal pressure differentials. These findings demonstrate that under the extraction–replenishment equilibrium scheme, ground subsidence remains well below the regulatory limits, posing no risk to surface infrastructure. This research provides a scientific foundation for safe development of similar deep brine resources globally. Full article

This study tackles the critical challenges of stress evolution and pillar optimization in underground potash mining, with a focus on the 351-stope of Kaiyuan Mining in Laos. Integrating theoretical calculations, large-scale 3D numerical modeling, and an AHP-Fuzzy comprehensive evaluation, we systematically analyze the complex mechanical behaviors of the mining environment. Applying key stratum theory, we reveal the unique mechanism by which overlying hard rock bends without fracturing in carnallite layers under room-and-pillar conditions. Comparative numerical simulations of four pillar-width schemes—involving 8 m rooms with 10 m, 8 m, 6 m, and 4 m pillars—show that reducing pillar width markedly increases vertical stress, triggers exponential roof subsidence, and expands pillar failure zones. Using an AHP-Fuzzy method that incorporates safety, technical, and economic factors, the Simultaneous Backfilling with 8 m Mining and 6 m Pillar Retention is identified as the optimal scheme. This configuration demonstrates superior stability, exhibiting an average pillar stress of 9.3 MPa and only limited plastic failure zones at pillar ends. These findings offer a robust scientific and technical foundation for enhancing the safety, efficiency, and sustainability of underground potash mining operations. Full article

The advent of digital mining has become a tangible reality in recent years. This digital evolution requires a predictive understanding of key elements, particularly considering the reliable communication infrastructures needed for autonomous machines. The LoRa technology and its underground propagation behavior can make an important contribution to this digitalization. Since LoRa operates with a high signal budget and long ranges in sub-GHz frequencies, its behavior is very promising for underground sensor networks. The aim of the development and series of measurements was to observe LoRa’s applicability and propagation behavior in active salt mines and to detect and identify effects arising from the special environment. The propagation of LoRa was measured via packet loss and signal strength in line-of-sight and non-line-of-sight configurations over entire mining sections. The aim was to analyze the performance of LoRa at the macroscopic level. LoRa operated at 868 MHz in the free band, and units were equipped with omni-directional antennas. The K+S Group’s active salt and potash mine Werra, Germany, was kindly opened as a distinctive experimental setting. The LoRa exhibited characteristics that were highly distinctive in this environment. The presence of the massive salt allowed the signal to bounce along drift edges with near-perfect reflection, which enabled travel over kilometers due to a waveguide-like effect. A packet loss of below $15\%$ showed that LoRa communication was possible over distances exceeding 1000 m with no line-of-sight in room-and-pillar structures. Measured differences of $\Delta 50\mathrm{dBm}$ values confirmed consistent path loss across different materials and tunnel geometries. This effect occurs due to the physical structure of the mining drifts, facilitating the containment and direction of signals, minimizing losses during propagation. Further modeling and measurements are of great interest, as they indicate that LoRa can achieve even better outcomes underground than in urban or indoor environments, as this waveguide effect has been consistently observed. Full article

Utilizing potassium salt aggregates and waste brine to produce underground cemented filling materials can address the waste storage issue. However, it is essential for the backfill materials to meet specific transport characteristics. This paper examines the transportation characteristics of lime-cemented mine backfill for a potash mine. The parameters were optimized for the cemented backfill process of potash mines through loop experiments and model simulations. Results indicate that the slump and fluidity of the backfill slurry diminished with increasing lime content and solid concentration. Additionally, the growth rate of pressure loss at the bent pipe and the pressure loss per unit distance in a horizontal pipe increased rapidly over transportation time, indicating a decline in the flowability of the backfill slurry. The lime dosage and solid concentration must align with the backfill requirements. When the lime dosage is 0.5%, the solid content is 70–75%; conversely, with a lime dosage of 0.7% and solid content of 65%, the maximum pumpable time extends to 1 h. The compressive strength of the cured backfill material after 28 days exceeds 1.01 MPa, meeting the transportation requirements for 300 m vertical pipes and 5000 m horizontal pipes. In the case study, the actual flow rate of backfill slurry surpasses the calculated critical flow rate. The estimated and measured values of on-site pressure loss per unit distance in a horizontal pipe exhibit a strong correlation. As the pressure loss per unit distance in a horizontal pipe rises, the discrepancy between the calculated and measured values also increases. When the solid content exceeds 65%, the loop test slightly enhances the compressive strength of the lime-cemented backfill. The findings from this article can aid in determining the on-site backfill process parameters with lime as a binder. Full article

This paper addresses the numerical simulation of unsteady, non-isothermal ventilation in a dead-end mine working of a potash mine excavated using a borer miner. During its operations, airflow can become unsteady due to the variable operating modes of the borer miner, the switching on and off of its motor cooling fans, and the movement of a shuttle car transporting ore. While steady ventilation in a dead-end working with a borer miner has been previously studied, the specific features of air microclimate parameter distribution in more complex and realistic unsteady scenarios remain unexplored. Our experimental studies reveal that over time, air velocity and, particularly, air temperature experience significant fluctuations. In this study, we develop and parameterize a mathematical model and perform a series of numerical simulations of unsteady heat and mass transfer in a dead-end working. These simulations account for the switching on and off of the borer miner’s fans and the movement of the shuttle car. The numerical model is calibrated using data from our experiments conducted in a potash mine. The analysis of the first factor is carried out by examining two extreme scenarios under steady-state ventilation conditions, while the second factor is analyzed within a fully unsteady framework using a dynamic mesh approach in the ANSYS Fluent 2021 R2. The numerical results demonstrate that the borer miner’s operating mode notably impacts the velocity and temperature fields, with a twofold decrease in maximum velocity near the cabin after the shuttle car departed and a temperature difference of about 1–1.5 °C between extreme scenarios in the case of forcing ventilation. The unsteady simulations using the dynamic mesh approach revealed that temperature variations were primarily caused by the borer miner’s cooling system, while the moving shuttle car generated short-term aerodynamic oscillations. Full article

Known as the “Ear of the Earth”, Lop Nor has become one of China’s four largest uninhabited areas due to environmental changes. Lop Nor is rich in mineral resources, including potassium salt, which has good quality and has been largely mined since 2002. This study focuses on the surrounding area of the Lop Nor Potash Salt Field, which covers an area of 80,036.39 square kilometers, spanning from 39.29° N to 41.84° N and 88.92° E to 92.26° E. The research is based on 1 km resolution precipitation, potential evapotranspiration, temperature data, and 250 m resolution NDVI data spanning 2002–2022. This study is devoted to exploring the trend of precipitation changes in the region surrounding the Lop Nor salt field since the start of the construction of the salt field, exploring the climatic impacts of the construction of the salt field on the surrounding region, and analyzing the correlations related to the changes in precipitation by selected meteorological factors. The Sen and Trend-Free Pre-Whitening Mann–Kendall trend analysis method was used to analyze the trend of precipitation data over the years. Combining with the data of the salt field location, the influence of the development of the salt field on regional precipitation was analyzed both temporally and spatially. The bias correlation analysis method was used to explore the correlation between maximum temperature, potential evapotranspiration, Normalized Difference Vegetation Index, and precipitation. The results of this analysis indicate that between 2002 and 2022, the study area exhibited both increasing and decreasing trends in precipitation. The region experiencing decreasing precipitation is predominantly located in the southwestern part of the study area, encompassing approximately 62% of the total area. Conversely, the area showing increasing precipitation is situated in the northeastern part, accounting for 38% of the total area. Field visits and survey data further corroborated the observed trend of increased precipitation in the northeastern region. Based on these findings, it is hypothesized that the development of salt flats has contributed to the increased precipitation, thereby alleviating regional drought conditions. Additionally, a partial correlation analysis of meteorological factors and precipitation revealed significant correlation. Temperature, potential evapotranspiration (PET), and the Normalized Difference Vegetation Index (NDVI) all exhibited varying degrees of correlation with precipitation. Temperature and potential evapotranspiration were the primary meteorological factors showing significant individual correlations. This study discusses the impact of salt field development and other climatic factors on the drought situation in Lop Nor and quantitatively analyzes the trend of precipitation changes in the study area and the factors affecting it. Water resources are scarce in China’s desert areas, and this research can provide a scientific basis for the state to formulate long-term plans for ecological protection and desert management, and it can also provide guidance for industrial development in desert areas. At the same time, it can provide important data and cases for global climate change research, offering experience and technical support for international cooperation in desertification control. Full article

In today’s world, advanced technologies are indispensable. In the field of mining, the use of machine-learning techniques is a reliable and productive way to solve various problems. This article touches upon the issues of increasing the recovery rate at potash mines, using the technology of backfilling with hardening materials. The compositions of backfills with increased strength are developed. The results of laboratory studies are given. To reduce the labor intensity of the experimental work, as well as to develop and validate methodological approaches to machine-learning introduction in the fields of mining and geomechanical research, this paper also presents the results of the predicted calculated values of the multi-component backfill strength, obtained with the help of neural networks. Full article

Airborne dust is an important contaminant affecting the health and the environment, and a crucial concern in many workplaces such as animal facilities and potash mines. One of the techniques used for dust control is electrostatic particle ionization (EPI). This technology has been proven effective in reducing airborne dust; however, it has downsides, such as the generation of ozone and corrosion of electrodes. Thus, this study tested a corrosion-resistant carbon-fiber discharge electrode and compared it with electrodes commonly used in EPI systems, that is, stainless-steel and tungsten electrodes, in terms of collection efficiency for potash dust and wheat flour (representative of livestock dust), ozone production, and power consumption. The carbon-fiber electrode performed comparably to stainless-steel electrodes, particularly for potash dust, and performed better than the tungsten electrode in terms of dust collection efficiency. Moreover, it had the lowest energy consumption and generated the least amount of ozone. However, because of the limitations of this study (e.g., fewer samples, low air velocity, controlled conditions, and the use of wheat flour instead of livestock dust), tests under real barn or mining conditions are necessary to confirm the results. Full article

This study evaluated the properties and processing of cemented paste backfills (CPBs) for potash mining through loop tests. The CPBs were made with steel slags as the binder, granulated potash tailings as the aggregate, and waste brine water as the liquid phase. The effects of solid concentration and steel slag dosage on the transport and mechanical properties of CPBs were assessed. The loop test demonstrated that all CPB slurries performed well, exhibiting strong long-distance pipeline transport capabilities. The 28-day compressive strength of the backfills exceeded 1 MPa, meeting the design requirements for backfill strength. The key rheological parameters, including yield stress (τ₀) and viscosity coefficient (η), were comprehensively and theoretically analyzed based on the variations in pressure loss per unit distance of the filling slurry measured during the loop test. The empirical formulas for CPB pressure loss, accounting for varying flow rates and pipeline diameters, were derived with an error margin under 2%. The response surface analysis showed that the affecting extents of factors on pressure loss in CPB slurry were ranked as follows: solid concentration > cementing agent content > flow rate. This study offered valuable guidance for the processing of potash mine backfill operations. Full article

This paper investigates the flow performance and mechanical properties of underground gelled filling materials made from potash mine tailings, using lime as a gel. It demonstrates the feasibility of using lime as a gel, potash mine tailings as aggregate, and replacing water with potash mine tailings to create filling materials that meet design requirements for flow and compressive strength. The role of lime in the hardening process is explored through X-ray diffraction, scanning electron microscopy with energy-dispersive X-ray spectroscopy, thermogravimetric analysis, and infrared analysis. Results show that hydration products vary with lime dosage. With 9% lime (L9), the products are primarily ghiaraite (CaCl₂·4H₂O) and carnallite (KMgCl₃·6H₂O); with 5% lime (L5), tachyhydrite (CaMg₂Cl₆·12H₂O) predominates, along with minor amounts of antarcticite (CaCl₂·6H₂O) and korshunovskite (Mg₂Cl(OH)₃·4H₂O); and with 2.6% lime (L2.6), the products include tachyhydrite, ghiaraite, bischofite (MgCl₂·6H₂O), and korshunovskite. These hydration products form a dense, interwoven structure, enhancing the strength of the filling material. This study offers a theoretical foundation for using lime gel as a filling material in potash mining, with significant implications for sustainable mining practices. Full article

The sand–gravel brine deposit in the Mahai Basin is a newly discovered large-scale potassium–bearing brine deposit. The potassium–bearing brine is primarily found at depths exceeding 150 m within the porous alluvial and fluvial sand–gravel reservoir of the Middle to Lower Pleistocene. This deposit is characterized by a relatively shallow water table, moderate–to–strong aquifer productivity, high salinity, and a KCl content that meets the conditions for exploitation, with the advantage of reduced salt crystallization during well mining, making it a potential reserve base for potash development. A geochemical analysis of the sand–gravel brine revealed consistent trends for the major ions K⁺, Na⁺, Mg²⁺, Cl⁻, and SO₄²⁻ along the east–west axis of the alluvial fan, while Ca²⁺ showed an opposite trend compared to Mg²⁺. Along the exploration lines from north to south, the concentrations of the main ions gradually increase. The brine is enriched in Na⁺ and Cl⁻ ions, while SO₄²⁻ and HCO₃⁻ are depleted. In the K⁺-Na⁺-Mg²⁺/Cl⁻-H₂O (25 °C) quaternary phase diagram, the brine falls within the halite stability field, with the hydrochemical type classified as chloride type. The brine coefficient characteristics indicate a multi-source origin involving residual evaporation, salt rock leaching, and metamorphic sedimentary brine. Comparison studies of the ionic composition and isotopic signatures (δD, δ¹⁸O, δ³⁷Cl, and δ⁷Li) of deep sand–gravel brines in the study area with interstitial and confined brines in the southern depression suggest similar geochemical characteristics between them. The genetic analysis of the deposit proposes that during the basin tectonic evolution, the potassium-rich interstitial and confined brines originally located in the southern depression of the Mahai Basin were displaced under compressional forces and migrated northward as the depositional center shifted, eventually backfilling into the loose alluvial and fluvial sand and gravel reservoirs at the front of the Saishiteng Mountains, forming the deep sand–gravel brine deposits in the foreland. Full article

The thermal regime of underground mines, shaped by air temperature, velocity, and relative humidity, is a crucial factor for production and the health and safety of miners. While many aspects of this thermal regime have been thoroughly studied in the literature, local heat sources from mechanized equipment, such as load–haul–dump machines, conveyors, and auxiliary fans, have received comparatively little attention despite their significant impact on the thermal environment in mining development areas and stopes. This paper presents findings from a comprehensive study of the microclimatic air parameters in several nickel–copper and potash mines. We focus specifically on variations in air temperature in areas where mining equipment is operational. The heat output from different types of equipment, including load–haul–dump units, cutter–loaders, drilling rigs, conveyors, and auxiliary fans, has been quantified. We established empirical relationships for heat emissions from these machines and conducted a comparative analysis of their heat outputs. The main advantage of these relationships is their simplicity and the minimal number of input parameters required, making them practical for use in the field. Full article

The article describes the peculiarities of strength and stability evaluation for deep geotechnical structures located in salt rock masses at great depths. A number of numerical studies are presented for the deep mining excavations of various cross-sections. The numerical simulations are conducted using a specific coupled algorithm of the finite element method (FEM) and distinct element method (DEM), which allows not only the prediction of dangerous zones in the undermined rock mass but also to simulation of the block fracture of the rock mass directly. Potential critical zones in the rock mass are established using an original complex limit state criterion for rock masses and FEM simulation results. Mentioned original criterion is a specific multicriterial method, which considers potential tensile, compressive and shear failure as well as crack propagation. To define the block-structure formulation in the rock mass it is proposed to use the Lade criterion in the complex limit state zones. Furthermore, block-structured rock mass behavior is simulated using DEM to predict its block-like fracture. The results of numerical studies clearly show that the mechanical behavior of potash salt rock masses significantly differ at moderate and great mining depths. Namely, the volume of the limit state zones nonlinearly increases with the increase in the mining depths up to double the size of the excavation cross-section. However, the exact amount of potentially failed rock mass has to be established using the direct DEM simulation in the limit state zones. Full article
