As the iron and steel industry needs to cut its CO₂ emissions drastically, much effort has been put into establishing new—less greenhouse-gas-intensive—production lines fueled by hydrogen and electricity. Blast furnaces, as a central element of hot iron production, are expected to lose importance, at least in European production strategies. Yet, blast furnaces could play a significant role in the transitional phase, as they allow for the implementation of another CO₂-reducing fuel, carbonized wood reducing agents, as a substitute for coal in auxiliary injection systems, which are currently widely used. Wood carbonization yields vastly differing fuel types depending on the severity of the treatment process, mainly its peak temperature. The goal of this study is to define the lowest treatment temperature, i.e., torrefaction temperature, which results in a biogenic reducing agent readily employable in existing coal injection systems, focusing on their conveying properties. Samples of different treatment temperatures ranging from 285 to 340 °C were produced and compared to injection coal regarding their chemical and mechanical properties. The critical conveyability in a standard dense-phase pneumatic conveying system was demonstrated with a sample of pilot-scale high-temperature torrefaction. Full article

Soft actuators, designed for fragile item conveyance and navigation in complex environments, have garnered recent attention. This study proposes a cost-effective soft actuator, created by weaving tubes into twill patterns, capable of transportation and movement. The actuator achieves this by inducing traveling waves on its upper and lower surfaces through sequential pressurization of tubes. Notably, its fabrication does not require specialized molds, contributing to cost efficiency. The single actuator generates traveling waves with two degrees of freedom. Conventional silicone tube-based actuators demonstrate slow transport speeds (3.5 mm/s). To address this, this study replaced silicone tubes with pneumatic artificial muscles, enhancing overall body deformation and actuator speed. Experiments involving both extensional and contractional artificial muscles demonstrated that soft actuators with extensional artificial muscles significantly improved transportation and movement speed to 8.0 mm/s. Full article

This study proposes a negative-pressure fruit-soil separating device for peanuts cultivated in hilly and mountainous areas after combined harvesting, and the mechanism of the movement of the material in the process of material screening, fruit-soil separating, and pneumatic conveying of the device was analyzed. In addition, a four-factor, three-level Box-Behnken regression design test was used to explore the optimum operating parameters of the peanut fruit-soil separation device. The results showed that the best fruit-soil separation effect was achieved when the wind speed of the blower was 13.58 m/s, the height of the suction nozzle from the screen surface was 27 mm, the length of the suction port was 64 mm, and the feeding rate was 600 kg/h. Validation tests demonstrated that the impurity rate of 0.16% and the peanut pod loss rate of 0.2% exceeded the industry standard, indicating superior performance. Full article

This study introduces a novel methodology to evaluate the behaviour of biomass material by examining the ratio of aeration and deaeration time constants. To this end, a series of tests were conducted on four different materials, namely, cottonseed, wood chips, wood pellets, and wheat straw, in order to investigate their aeration and deaeration behaviours. The study derives the aeration and deaeration pressure drop equations, and discusses the corresponding time constant expression. Subsequently, the four materials were conveyed in 12 m long batch-fed and continuous pneumatic conveying pipelines to examine their behaviour in longer pipelines. The results indicate that the aeration and deaeration time constants increased with an increase in air superficial velocity. However, the ratio of the aeration and deaeration time constants was identified as a unique number, where a value close to 1 indicates a higher likelihood of plug flow. On the basis of the results, cottonseed, with the lowest ratio of time constant, was more likely to form a stable plug flow in both batch-fed and continuous pneumatic conveying. Given the unique properties of biomass and the limited research on the pneumatic conveyance of biomass, this methodology represents a novel approach for predicting modes of flow in materials with complex properties. Full article

A series of computational fluid dynamics–discrete element method (CFD-DEM) simulations were applied to seed flow in horizontal-vertical 90-degree elbows. The performance of one-way and two-way CFD-DEM coupling methods was compared. Additionally, simulated seed velocities were compared to the current pneumatic conveying theory for each coupling method. Simulated field peas (Pisum sativum) were pneumatically conveyed to study the effect of air velocity (20, 25, and 30 m/s), seed rate (0.07, 0.21, and 0.42 kg/s), elbow diameter, D, (48.3, 60.3, and 72.4 mm), and elbow bend radius (1.5D, 2.5D, 3.5D, and 4.5D) on seed attributes (trajectory, velocity, and force). Results showed that seed velocity was significantly different between one-way and two-way coupling. Both methods resulted in nearly identical seed trajectory and force. Overall, simulated seed velocities had a strong correlation to values calculated through the current pneumatic conveyance theory. Dimensional analysis revealed that seed contact force was proportional to the elbow diameter to the power of 0.26 and inversely proportional to the elbow bend radius to the power of 0.5. Simulation results indicated that one-way coupling could be suitable to describe seed flow when two-way coupling may not be possible or practical. Full article

Precision fertilizer application technology is necessary to improve the utilization efficiency of fertilizers in agricultural production. Traditional mechanical fertilization systems risk blockages and uneven application when working in multiple crop rows. Pneumatic fertilization systems have improved efficiency and fertilization quality, however, fewer studies have characterized their designs in regards to the motion of the fertilizer particles. Here, we design and evaluate the parameters of the key components of a pneumatic fertilizer discharge system. Numerical simulations were conducted using a coupled EDEM-FLUENT and gas-phase models together with bench tests to examine the effects of inlet wind speed on the efficiency and consistency of the pneumatic fertilization system. The EDEM-FLUENT simulations showed that the number of fertilizer particles in the grid box set by EDEM was 60 particles in the range from t = 0.275 s to t = 0.5 s, and there was no blockage or cut-off in the pipe. The gas-phase simulation showed that there were tiny vortices in the fertilizer conveying pipe, and the maximum flow rate of its backflow was lower than 3.59 m/s, which had little effect on the fertilizer conveyance. The bench test showed that the inlet wind speed was 35–40 m/s, and the fertilization efficiency was 0.29–0.41 kg/s when the maximum variation coefficient of the row discharge consistency of the pneumatic distribution fertilizer discharge system was 5.55%. The coefficient of variation of the average row discharge consistency was 3.93%, and the average fertilizer discharge met the design requirements. Therefore, the pneumatic distribution system achieves stable operation and meets the requirements of fertilization operations. Full article

Flexible printed electronic circuits have recently attracted attention as an alternative promising methodology due to the additive process being more environmentally friendly and using less raw material compared to conventional lithography and chemical vapor deposition. However, printed circuits produced by roll-to-roll (R2R) conveyance are often scratched, which can result in breaks in the conductive tracks, cracks, or pinholes. This study investigated a proposed optimal design for an air bar for use in an R2R printing system. The optimal distance between the roll surface and floating substrate for preventing scratching of the printed circuit was investigated. The optimal design—including the blower frequency, size of air holes, and density of air holes—was investigated using simulations of fluid–structure interactions for estimating substrate behavior during pneumatic flotation. The distribution of air pressure in the space between the substrate and the surface of the air bar was calculated, and the deformation of the substrate by the air pressure was analyzed. The optimal design of the air bar was verified in numerical simulations and experiments using various conditions. Full article
