This study presents a detailed experimental investigation of wave impact loads generated by a 3D dam break flow over a dry horizontal bed. Three-dimensionality is induced by a rigid obstacle partially blocking the channel, tested in both symmetric and asymmetric configurations. Impact pressures have been measured at three transverse locations on a downstream vertical wall, and peak pressures, rise times, and pressure impulses have been statistically characterized based on repeated experiments until convergence is achieved. The results show that three-dimensional effects significantly modify the spatial distribution and intensity of impact pressures compared to classical 2D dam break cases. In the asymmetric configuration, the obstacle induces strong lateral redirection of the flow, leading to highly impulsive loads at unshielded locations and substantial pressure attenuation in shadowed regions. In contrast, the symmetric configuration produces more uniform pressure distributions with reduced peak values and weaker impulsive behavior. A probabilistic description of pressure peaks, rise times, and impulses is provided. The dataset offers new experimental benchmarks for the validation and calibration of numerical models aimed at predicting wave-induced structural loads in complex three-dimensional impact flows. Full article

The growing threat of dam-break events, fueled by aging infrastructure and climate change, necessitates comprehensive risk management and mitigation strategies. Experimental studies on partial dam-break flows are pivotal for understanding the complex dynamics of these events, particularly in assessing flood risk and refining predictive models. This review synthesizes current experimental investigations on three-dimensional (3D) partial dam-break flows, with an emphasis on breach dynamics, wave impacts, and the role of urban structures. It highlights the challenges in capturing high-resolution 3D flow characteristics and the advancements in measurement techniques such as particle tracking velocimetry and ultrasonic distance meters. The paper discusses the integration of experimental data with numerical models to validate and improve predictive capabilities, stressing the need for continuous refinement of experimental setups and computational approaches. Gaps in the current literature, including the under-representation of irregular breach geometries and complex terrain, are identified, and future research directions are proposed to address these shortcomings. This work underscores the importance of hybrid measurement techniques and interdisciplinary collaboration to enhance dam-break modeling accuracy and flood risk mitigation. Full article

The shallow water equations (SWEs) model fluid flow in rivers, coasts, and tsunamis. Their nonlinearity challenges analytical solutions. We present a numerical algorithm combining the finite integration method with Chebyshev polynomial expansion (FIM-CPE) to solve one- and two-dimensional SWEs. The method transforms partial differential equations into integral equations, approximates spatial terms via Chebyshev polynomials, and uses forward differences for time discretization. Validated on stationary lakes, dam breaks, and Gaussian pulses, the scheme achieved errors below ${10}^{-12}$ for water height and velocity, while conserving mass with volume deviations under ${10}^{-5}$. Comparisons showed superior shock-capturing versus finite difference methods. For two-dimensional cases, it accurately resolved wave interactions over complex topographies. Though limited to wet beds and small-scale two-dimensional problems, the method provides a robust simulation tool. Full article

The complex nature of debris flows suggests that the pore-water pressure evolution and dewatering of a flowing mass caused by the high permeability of soil or terrain could play an essential role in the dynamics behavior of fast landslides. Dewatering causes desaturation, reducing the pore-water pressure and improving the shear strength of liquefied soils. A new approach to landslide propagation modeling considering the dewatering of a mass debris flow has drawn research attention. The problem is characterized by a transition from saturated to unsaturated soil. This paper aims to address this scientific gap. A depth-integrated model was developed to analyze the dewatering of landslides, in which, desaturation plays an important role in the dynamics behavior of the propagation. This study adopted an SPH numerical method to model landslide propagation consisting of pore-water and a soil skeleton in fully or partially saturated soils. In a two-phase model, the soil–water mixture was discretized and represented by two sets of SPH nodes carrying all field variables, such as velocity, displacement, and basal pore-water pressure. The pore-water was described by an additional set of balance equations to take into account its velocity. In the developed two-layer model, an upper desaturated layer and a lower saturated layer were considered to enhance the description of dewatering. This is the so-called two-phase two-layer formulation, which is capable of simulating the entire process of landslides propagation, including the large deformation of soils and corresponding pore-water pressure evolutions, where the effect of the dewatering in saturated soils is also taken into account. A dam-break problem was analyzed through the new and previously developed model. A flume test performed at Trondheim was also used to validate the proposed model by comparing the numerical results with measurements obtained from the experiment. Finally, the model was applied to simulate a real case lahar, which is an appropriate benchmark case used to examine the applicability of the developed model. The simulation results demonstrated that taking into account the effects of dewatering and the vital parameter of relative height is essential for the landslide propagation modeling of a desaturated flowing mass. Full article

This paper aims to evaluate the crucial influence of the width of dam gate and its position, as well as initial water depth, on the evolution of rarefaction waves on reservoirs, and of shock waves over dry flood plain areas. The large eddy simulation (LES) model and volume of fluid (VOF) method are used to simulate three objectives. Firstly, validation of the presented numerical model, and of mesh sensitivity analysis, are conducted by means of a physical test case, taken from the literature, showing very good accuracy with a small value of RMSE among all hydraulic features in the case of fine mesh. In this direction, the 3D result is also compared with the published 2D one, to prove the necessity of using a 3D model in performing dam–break flow in an early stage. The second aim is to look for insight into the following 3D hydraulic characteristics of dam–break flow: water depth, velocity hydrograph and streamline, vorticity, the q–criterion incorporated with variety of breach size, initial water stage and the reservoir outlet’s location. The influence of the dam gate’s place on peak discharge is pointed out by means of a 3D model, while the existing analytical solution is not specified. With the same conditions of initial water depth, breach width and geometry, an analytical solution gives the same peak discharge, while a 3D numerical one indicates that a symmetrical dam gate provides a greater value than does the asymmetrical case, and also a value greater than that of an analytical result. Full article

Dam break inundation mapping is essential for risk management and mitigation, emergency action planning, and potential consequences assessment. To quantify flood hazard associated with dam failures, flooding variables must be predicted by efficient and robust numerical models capable to effectively cope with the computational difficulties posed by complex flows on real topographies. Validation against real-field data of historical dam-breaks is extremely useful to verify models’ capabilities and accuracy. However, such catastrophic events are rather infrequent, and available data on the breaching mechanism and downstream flooding are usually inaccurate and incomplete. Nevertheless, in some cases, real-field data collected after the event (mainly breach size, maximum water depths and flood wave arrival times at selected locations, water marks, and extent of flooded areas) are adequate to set up valuable and significant test cases, provided that all other data required to perform numerical simulations are available (mainly topographic data of the floodable area and input parameters defining the dam-break scenario). This paper provides a review of the historical dam-break events for which real-field datasets useful for validation purposes can be retrieved in the literature. The resulting real-field test cases are divided into well-documented test cases, for which extensive and complete data are already available, and cases with partial or inaccurate datasets. Type and quality of the available data are specified for each case. Finally, validation data provided by dam-break studies on physical models reproducing real topographies are presented and discussed. This review aims at helping dam-break modelers: (a) to select the most suitable real-field test cases for validating their numerical models, (b) to facilitate data access by indicating relevant bibliographic references, and (c) to identify test cases of potential interest worthy of further research. Full article

Urban flooding as a result of inadequate drainage capacity, failure of flood defenses, etc. is usually featured with highly transient hydrodynamics. Reliable and efficient prediction and forecasting of these urban flash floods is still a great technical challenge. Meanwhile, in urban environments, the flooding hydrodynamics and process may be influenced by flow regulation and flood protection hydraulic infrastructure systems, such as sluice gates, which should be effectively taken into account in an urban flood model. However, direct simulation of hydraulic structures is not a current practice in 2D urban flood modeling. This work aims to develop a robust numerical approach to directly simulate the effects of gate structures in a 2D high-resolution urban flood model. A new modeling component is developed and fully coupled to a finite volume Godunov-type shock-capturing shallow water model, to directly simulate the highly transient flood waves through hydraulic structures. Different coupling approaches, i.e., flux term coupling and source term coupling, are implemented and compared. A numerical experiment conducted for an analytical dam-break test indicates that the flux term coupling approach may lead to more accurate results, with the calculated RMSE against water level 28%–38% less than that produced by the source term coupling approach. The flux term coupling approach is therefore adopted to improve the current urban flood model, and it is further tested by reproducing the laboratory experiments of flood routing in a flume with partially open sluice gates, conducted in the hydraulic laboratory at the Zhejiang Institute of Hydraulics and Estuary, China. The numerical results are compared favorably with experimental measurements, with a maximum RMSE of 0.0851 for all the individual tests. The satisfactory results demonstrate that the flood model implemented with the flux coupling approach is able to accurately simulate the flow through hydraulic structures, with enhanced predictive capability for urban flood modeling. Full article

Water wave dynamics and its engineering application have always been a key issue in the field of hydraulics, and effective and efficient numerical methods need to be proposed to perform three-dimensional (3-D) simulation of large-scale water fluctuation in engineering practice. A single-phase free-surface lattice Boltzmann method (SPFS-LB method) is coupled with a large-eddy simulation approach for simulating large-scale free water surface flows, and the simulation is accelerated on a GPU (graphic processing unit). The coupling model is used to simulate the evolution process of dam-break wave after complete and partial dam-break. The formation mechanism of horizontal and vertical vortices in water after partial dam-break and the advance and evolution process of dam-break flow on non-contour riverbed are analyzed. The method has been verified to be reasonable and can obtain a more accurate time curve of water level fluctuation. Applying this method to practical arch dams, discharge coefficients consistent with empirical formulas can be obtained by comparison and analysis, and the surface flow phenomena (such as tongue diffusion, surface fragmentation, and surface fusion) can be well simulated by this method. In addition, based on the key technology of parallel computing on a GPU, the implementation of the SPFS-LB model on a GPU unit achieves tens of millions of lattice updates per second, which is over fifty times higher than that on a single CPU chip. It is proved that the proposed method for large-scale water fluctuations can be used to study practical engineering problems. The mathematical model method realizes the efficient and accurate simulation of practical physical problems. Full article

Multiphase flow of oil, gas, and water occurs in a reservoir’s underground formation and also within the associated downstream pipeline and structures. Computer simulations of such phenomena are essential in order to achieve the behavior of parameters including but not limited to evolution of phase fractions, temperature, velocity, pressure, and flow regimes. However, within the oil and gas industry, due to the highly complex nature of such phenomena seen in unconventional assets, an accurate and fast calculation of the aforementioned parameters has not been successful using numerical simulation techniques, i.e., computational fluid dynamic (CFD). In this study, a fast-track data-driven method based on artificial intelligence (AI) is designed, applied, and investigated in one of the most well-known multiphase flow problems. This problem is a two-dimensional dam-break that consists of a rectangular tank with the fluid column at the left side of the tank behind the gate. Initially, the gate is opened, which leads to the collapse of the column of fluid and generates a complex flow structure, including water and captured bubbles. The necessary data were obtained from the experience and partially used in our fast-track data-driven model. We built our models using Levenberg Marquardt algorithm in a feed-forward back propagation technique. We combined our model with stochastic optimization in a way that it decreased the absolute error accumulated in following time-steps compared to numerical computation. First, we observed that our models predicted the dynamic behavior of multiphase flow at each time-step with higher speed, and hence lowered the run time when compared to the CFD numerical simulation. To be exact, the computations of our models were more than one hundred times faster than the CFD model, an order of 8 h to minutes using our models. Second, the accuracy of our predictions was within the limit of 10% in cascading condition compared to the numerical simulation. This was acceptable considering its application in underground formations with highly complex fluid flow phenomena. Our models help all engineering aspects of the oil and gas industry from drilling and well design to the future prediction of an efficient production. Full article

In the context of dam breaks, tsunami, and flash floods, it is paramount to quantify the time-history of forces by the rapidly transient flow to vertical structures and the characteristics of the induced flow patterns. To resemble on-land tsunami-induced flow, a free-surface-piercing structure is exposed to long leading depression waves in a tsunami flume where long waves run up and down a 1:40 smooth and impermeable sloping beach after its generation by a volume-driven wave maker. The structure and its surrounding were monitored with force transducers, pressure gauges and cameras. Preparatory steady-state experiments were accomplished to determine the drag force coefficient of the square cylinder at various water depths. The flow during wave run-up and draw-down acting on the structure resulted in distinct flow pattern which were characteristic for the type of flow-structure interaction. Besides bow wave propagating upstream, a standing or partially-standing wave was observed in front of the structure together with a wake formation downstream, while a von Kármán vortex street developed during the deceleration phase of the flow motion and during draw-down. Force measurements indicated a sudden increase in the stream-wise total force starting with the arrival of the flow front during initial run-up. Lateral velocities showed significant oscillations in correlation with the von Kármán vortex street development. A comparison of the total measured base force with the analytically-calculated share of the drag force revealed that forces were prevailingly drag-dominated. Full article
