Step width is an important clinical motor marker for gait stability assessment. While laboratory-based systems can measure it with high accuracy, wearable solutions based on inertial measurement units do not directly provide spatial information such as distances. Therefore, we propose a magnetic estimation approach based on a pair of shank-worn magnetoelectric (ME) sensors. In this pilot study, we estimated the step width of eight healthy participants during treadmill walking and compared it to an optical motion capture (OMC) reference. In a direct comparison with OMC markers attached to the magnetic system, we achieved a high estimation accuracy in terms of the mean absolute error (MAE) for step width (≤1 cm) and step width variability (<0.1 cm). In a more general comparison with heel-mounted markers during the swing phase, the standard deviation of the error (<0.5 cm, measure for precision), the step width variability estimation MAE (<0.2 cm) and the Spearman correlation (>0.88) of individual feet were still encouraging, but the accuracy was negatively affected by a constant proxy bias (3.7 and 4.6 cm) due to the different anatomical reference points used in each method. The high accuracy of the system in the first case and the high precision in the second case underline the potential of magnetic motion tracking for gait stability assessment in wearable movement analysis. Full article

Optical Motion Capture Systems (OMCSs) are considered the gold standard for kinematic measurement of human movements. However, in situations such as measuring wrist kinematics during a hairdressing activity, markers can be obscured, resulting in a loss of data. Other measurement methods based on non-optical data can be considered, such as magneto-inertial measurement units (MIMUs). Their accuracy is generally lower than that of an OMCS. In this context, it may be worth considering a hybrid system [MIMU + OMCS] to take advantage of OMCS accuracy while limiting occultation problems. The aim of this work was (1) to propose a methodology for coupling a low-cost MIMU (BNO055) to an OMCS in order to evaluate wrist kinematics, and then (2) to evaluate the accuracy of this hybrid system [MIMU + OMCS] during a simple hairdressing gesture. During hair cutting gestures, the root mean square error compared with the OMCS was 4.53° (1.45°) for flexion/extension, 5.07° (1.30°) for adduction/abduction, and 3.65° (1.19°) for pronation/supination. During combing gestures, they were significantly higher, but remained below 10°. In conclusion, this system allows for maintaining wrist kinematics in case of the loss of hand markers while preserving an acceptable level of precision (<10°) for ergonomic measurement or entertainment purposes. Full article

This study assesses the agreement of compressive and shear force estimates at the L5-S1 joint using inertial motion capture (IMC) within a musculoskeletal simulation model during manual lifting tasks, compared against a top-down optical motion capture (OMC)-based model. Thirty-six participants completed lifting and lowering tasks while wearing a modified Plug-in Gait marker set for the OMC and a full-body IMC set-up consisting of 17 sensors. The study focused on tasks with variable load weights, lifting heights, and trunk rotation angles. It was found that the IMC system consistently underestimated the compressive forces by an average of 34% (975.16 N) and the shear forces by 30% (291.77 N) compared with the OMC system. A critical observation was the discrepancy in joint angle measurements, particularly in trunk flexion, where the IMC-based model underestimated the angles by 10.92–11.19 degrees on average, with the extremes reaching up to 28 degrees. This underestimation was more pronounced in tasks involving greater flexion, notably impacting the force estimates. Additionally, this study highlights significant differences in the distance from the spine to the box during these tasks. On average, the IMC system showed an 8 cm shorter distance on the X axis and a 12–13 cm shorter distance on the Z axis during lifting and lowering, respectively, indicating a consistent underestimation of the segment length compared with the OMC system. These discrepancies in the joint angles and distances suggest potential limitations of the IMC system’s sensor placement and model scaling. The load weight emerged as the most significant factor affecting force estimates, particularly at lower lifting heights, which involved more pronounced flexion movements. This study concludes that while the IMC system offers utility in ergonomic assessments, sensor placement and anthropometric modeling accuracy enhancements are imperative for more reliable force and kinematic estimations in occupational settings. Full article

The ability to estimate lower-extremity mechanics in real-world scenarios may untether biomechanics research from a laboratory environment. This is particularly important for military populations where outdoor ruck marches over variable terrain and the addition of external load are cited as leading causes of musculoskeletal injury As such, this study aimed to examine (1) the validity of a minimal IMU sensor system for quantifying lower-extremity kinematics during treadmill walking and running compared with optical motion capture (OMC) and (2) the sensitivity of this IMU system to kinematic changes induced by load, grade, or a combination of the two. The IMU system was able to estimate hip and knee range of motion (ROM) with moderate accuracy during walking but not running. However, SPM analyses revealed IMU and OMC kinematic waveforms were significantly different at most gait phases. The IMU system was capable of detecting kinematic differences in knee kinematic waveforms that occur with added load but was not sensitive to changes in grade that influence lower-extremity kinematics when measured with OMC. While IMUs may be able to identify hip and knee ROM during gait, they are not suitable for replicating lab-level kinematic waveforms. Full article

Objective gait analysis provides valuable information about the locomotion characteristics of sound and lame horses. Due to their high accuracy and sensitivity, inertial measurement units (IMUs) have gained popularity over objective measurement techniques such as force plates and optical motion capture (OMC) systems. IMUs are wearable sensors that measure acceleration forces and angular velocities, providing the possibility of a non-invasive and continuous monitoring of horse gait during walk, trot, or canter during field conditions. The present narrative review aimed to describe the inertial sensor technologies and summarize their role in equine gait analysis. The literature was searched using general terms related to inertial sensors and their applicability, gait analysis methods, and lameness evaluation. The efficacy and performance of IMU-based methods for the assessment of normal gait, detection of lameness, analysis of horse–rider interaction, as well as the influence of sedative drugs, are discussed and compared with force plate and OMC techniques. The collected evidence indicated that IMU-based sensor systems can monitor and quantify horse locomotion with high accuracy and precision, having comparable or superior performance to objective measurement techniques. IMUs are reliable tools for the evaluation of horse–rider interactions. The observed efficacy and performance of IMU systems in equine gait analysis warrant further research in this population, with special focus on the potential implementation of novel techniques described and validated in humans. Full article

Marker-based Optical Motion Capture (OMC) systems and associated musculoskeletal (MSK) modelling predictions offer non-invasively obtainable insights into muscle and joint loading at an in vivo level, aiding clinical decision-making. However, an OMC system is lab-based, expensive, and requires a line of sight. Inertial Motion Capture (IMC) techniques are widely-used alternatives, which are portable, user-friendly, and relatively low-cost, although with lesser accuracy. Irrespective of the choice of motion capture technique, one typically uses an MSK model to obtain the kinematic and kinetic outputs, which is a computationally expensive tool increasingly well approximated by machine learning (ML) methods. Here, an ML approach is presented that maps experimentally recorded IMC input data to the human upper-extremity MSK model outputs computed from (‘gold standard’) OMC input data. Essentially, this proof-of-concept study aims to predict higher-quality MSK outputs from the much easier-to-obtain IMC data. We use OMC and IMC data simultaneously collected for the same subjects to train different ML architectures that predict OMC-driven MSK outputs from IMC measurements. In particular, we employed various neural network (NN) architectures, such as Feed-Forward Neural Networks (FFNNs) and Recurrent Neural Networks (RNNs) (vanilla, Long Short-Term Memory, and Gated Recurrent Unit) and a comprehensive search for the best-fit model in the hyperparameters space in both subject-exposed (SE) as well as subject-naive (SN) settings. We observed a comparable performance for both FFNN and RNN models, which have a high degree of agreement (r${}_{\mathrm{avg},\mathrm{SE},\mathrm{FFNN}}={0.90}_{\pm 0.19}$, r${}_{\mathrm{avg},\mathrm{SE},\mathrm{RNN}}={0.89}_{\pm 0.17}$, r${}_{\mathrm{avg},\mathrm{SN},\mathrm{FFNN}}={0.84}_{\pm 0.23}$, and r${}_{\mathrm{avg},\mathrm{SN},\mathrm{RNN}}={0.78}_{\pm 0.23}$) with the desired OMC-driven MSK estimates for held-out test data. The findings demonstrate that mapping IMC inputs to OMC-driven MSK outputs using ML models could be instrumental in transitioning MSK modelling from ‘lab to field’. Full article

Quantitative information on how well a horse clears a jump has great potential to support the rider in improving the horse’s jumping performance. This study investigated the validation of a GPS-based inertial measurement unit, namely Alogo Move Pro, compared with a traditional optical motion capture system. Accuracy and precision of the three jumping characteristics of maximum height (Zmax), stride/jump length (lhorz), and mean horizontal speed (vhorz) were compared. Eleven horse–rider pairs repeated two identical jumps (an upright and an oxer fence) several times (n = 6 to 10) at different heights in a 20 × 60 m tent arena. The ground was a fiber sand surface. The 24 OMC (Oqus 7+, Qualisys) cameras were rigged on aluminum rails suspended 3 m above the ground. The Alogo sensor was placed in a pocket on the protective plate of the saddle girth. Reflective markers placed on and around the Alogo sensor were used to define a rigid body for kinematic analysis. The Alogo sensor data were collected and processed using the Alogo proprietary software; stride-matched OMC data were collected using Qualisys Track Manager and post-processed in Python. Residual analysis and Bland–Altman plots were performed in Python. The Alogo sensor provided measures with relative accuracy in the range of 10.5–20.7% for stride segments and 5.5–29.2% for jump segments. Regarding relative precision, we obtained values in the range of 6.3–14.5% for stride segments and 2.8–18.2% for jump segments. These accuracy differences were deemed good under field study conditions where GPS signal strength might have been suboptimal. Full article

Background: A validity and reliability assessment of inertial measurement unit (IMU)-derived joint angular kinematics during walking is a necessary step for motion analysis in the lower extremity prosthesis user population. This study aimed to assess the accuracy and reliability of an inertial measurement unit (IMU) system compared to an optical motion capture (OMC) system in transtibial prosthesis (TTP) users. Methods: Thirty TTP users were recruited and underwent simultaneous motion capture from IMU and OMC systems during walking. Reliability and validity were assessed using intra- and inter-subject variability with standard deviation (S.D.), average S.D., and intraclass correlation coefficient (ICC). Results: The intra-subject S.D. for all rotations of the lower limb joints were less than 1° for both systems. The IMU system had a lower mean S.D. (^o), as seen in inter-subject variability. The ICC revealed good to excellent agreement between the two systems for all sagittal kinematic parameters. Conclusion: All joint angular kinematic comparisons supported the IMU system’s results as comparable to OMC. The IMU was capable of precise sagittal plane motion data and demonstrated validity and reliability to OMC. These findings evidence that when compared to OMC, an IMU system may serve well in evaluating the gait of lower limb prosthesis users. Full article

Shoulder dysfunctions represent the third musculoskeletal disorder by frequency. However, monitoring the movement of the shoulder is particularly challenging due to the complexity of the joint kinematics. The 3D kinematic analysis with optical motion capture systems (OMCs) makes it possible to overcome clinical tests’ shortcomings and obtain objective data on the characteristics and quality of movement. This systematic review aims to retrieve the current knowledge about using OMCs for 3D shoulder kinematic analysis in patients with musculoskeletal shoulder disorders and their corresponding clinical relevance. The Preferred Reporting Items for Systematic reviews and Meta-Analyses (PRISMA) guidelines were used to improve the reporting of the review. Studies employing OMCs for 3D kinematic analysis in patients with musculoskeletal shoulder disorders were retrieved. Eleven articles were considered eligible for this study. OMCs can be considered a powerful tool in orthopedic clinical research. The high costs and organizing complexities of experimental setups are likely outweighed by the impact of these systems in guiding clinical practice and patient follow-up. However, additional high-quality studies on using OMCs in clinical practice are required, with standardized protocols and methodologies to make comparing clinical trials easier. Full article

Fetlock joint angle (FJA) pattern is a sensitive indicator of lameness. The first aim of this study is to describe a network of inertial measurement units system (IMUs) for quantifying FJA simultaneously in all limbs. The second aim is to evaluate the accuracy of IMUs for quantifying the sagittal plane FJA overground in comparison to bi-dimensional (2-D) optical motion capture (OMC). 14 horses (7 free from lameness and 7 lame) were enrolled and analyzed with both systems at walk and trot on a firm surface. All enrolled horses were instrumented with 8 IMUs (a pair for each limb) positioned at the dorsal aspect of the metacarpal/metatarsal bone and pastern and acquiring data at 200 Hz. Passive markers were glued on the center of rotation of carpus/tarsus, fetlock, and distal interphalangeal joint, and video footages were captured at 60 Hz and digitalized for OMC acquisition. The IMU system accuracy was reported as Root Mean Square Error (RMSE) and Pearson Correlation Coefficient (PCC). The Granger Causality Test (GCT) and the Bland–Altman analysis were computed between the IMUs and OMC patterns to determine the agreement between the two systems. The proposed IMU system was able to provide FJAs in all limbs using a patented method for sensor calibration and related algorithms. Fetlock joint range of motion (FJROM) variability of three consecutive strides was analyzed in the population through 3-way ANOVA. FJA patterns quantified by IMUs demonstrated high accuracy at the walk (RMSE 8.23° ± 3.74°; PCC 0.95 ± 0.03) and trot (RMSE 9.44° ± 3.96°; PCC 0.96 ± 0.02) on both sound (RMSE 7.91° ± 3.19°; PCC 0.97 ± 0.03) and lame horses (RMSE 9.78° ± 4.33°; PCC 0.95 ± 0.03). The two systems’ measurements agreed (mean bias around 0) and produced patterns that were in temporal agreement in 97.33% of the cases (p < 0.01). The main source of variability between left and right FJROM in the population was the presence of lameness (p < 0.0001) and accounted for 28.46% of this total variation. IMUs system accurately quantified sagittal plane FJA at walk and trot in both sound and lame horses. Full article

Inertial Measurement Units (IMUs) have gained popularity in gait analysis and human motion tracking, and they provide certain advantages over stationary line-of-sight-dependent Optical Motion Capture (OMC) systems. IMUs appear as an appropriate alternative solution to reduce dependency on bulky, room-based hardware and facilitate the analysis of walking patterns in clinical settings and daily life activities. However, most inertial gait analysis methods are unpractical in clinical settings due to the necessity of precise sensor placement, the need for well-performed calibration movements and poses, and due to distorted magnetometer data in indoor environments as well as nearby ferromagnetic material and electronic devices. To address these limitations, recent literature has proposed methods for self-calibrating magnetometer-free inertial motion tracking, and acceptable performance has been achieved in mechanical joints and in individuals without neurological disorders. However, the performance of such methods has not been validated in clinical settings for individuals with neurological disorders, specifically individuals with incomplete Spinal Cord Injury (iSCI). In the present study, we used recently proposed inertial motion-tracking methods, which avoid magnetometer data and leverage kinematic constraints for anatomical calibration. We used these methods to determine the range of motion of the Flexion/Extension (F/E) hip and Abduction/Adduction (A/A) angles, the F/E knee angles, and the Dorsi/Plantar (D/P) flexion ankle joint angles during walking. Data (IMU and OMC) of five individuals with no neurological disorders (control group) and five participants with iSCI walking for two minutes on a treadmill in a self-paced mode were analyzed. For validation purposes, the OMC system was considered as a reference. The mean absolute difference (MAD) between calculated range of motion of joint angles was $5.00°$, $5.02°$, $5.26°$, and $3.72°$ for hip F/E, hip A/A, knee F/E, and ankle D/P flexion angles, respectively. In addition, relative stance, swing, double support phases, and cadence were calculated and validated. The MAD for the relative gait phases (stance, swing, and double support) was $1.7$%, and the average cadence error was $0.09$ steps/min. The MAD values for RoM and relative gait phases can be considered as clinically acceptable. Therefore, we conclude that the proposed methodology is promising, enabling non-restrictive inertial gait analysis in clinical settings. Full article

In biomechanics, joint kinetics has an important role in evaluating the mechanical load of the joint and understanding its motor function. Although an optical motion capture (OMC) system has mainly been used to evaluate joint kinetics in combination with force plates, inertial motion capture (IMC) systems have recently been emerging in joint kinetic analysis due to their wearability and ubiquitous measurement capability. In this regard, numerous studies have been conducted to estimate joint kinetics using IMC-based wearable systems. However, these have not been comprehensively addressed yet. Thus, the aim of this review is to explore the methodology of the current studies on estimating joint kinetic variables by means of an IMC system. From a systematic search of the literature, 48 studies were selected. This paper summarizes the content of the selected literature in terms of the (i) study characteristics, (ii) methodologies, and (iii) study results. The estimation methods of the selected studies are categorized into two types: the inverse dynamics-based method and the machine learning-based method. While these two methods presented different characteristics in estimating the kinetic variables, it was demonstrated in the literature that both methods could be applied with good performance for the kinetic analysis of joints in different daily activities. Full article

A Drift-Free 3D Orientation and Displacement estimation method (DFOD) based on a single inertial measurement unit (IMU) is proposed and validated. Typically, body segment orientation and displacement methods rely on a constant- or zero-velocity point to correct for drift. Therefore, they are not easily applicable to more proximal segments than the foot. DFOD uses an alternative single sensor drift reduction strategy based on the quasi-cyclical nature of many human movements. DFOD assumes that the quasi-cyclical movement occurs in a quasi-2D plane and with an approximately constant cycle average velocity. DFOD is independent of a constant- or zero-velocity point, a biomechanical model, Kalman filtering or a magnetometer. DFOD reduces orientation drift by assuming a cyclical movement, and by defining a functional coordinate system with two functional axes. These axes are based on the mean acceleration and rotation axes over multiple complete gait cycles. Using this drift-free orientation estimate, the displacement of the sensor is computed by again assuming a cyclical movement. Drift in displacement is reduced by subtracting the mean value over five gait cycle from the free acceleration, velocity, and displacement. Estimated 3D sensor orientation and displacement for an IMU on the lower leg were validated with an optical motion capture system (OMCS) in four runners during constant velocity treadmill running. Root mean square errors for sensor orientation differences between DFOD and OMCS were 3.1 ± 0.4° (sagittal plane), 5.3 ± 1.1° (frontal plane), and 5.0 ± 2.1° (transversal plane). Sensor displacement differences had a root mean square error of 1.6 ± 0.2 cm (forward axis), 1.7 ± 0.6 cm (mediolateral axis), and 1.6 ± 0.2 cm (vertical axis). Hence, DFOD is a promising 3D drift-free orientation and displacement estimation method based on a single IMU in quasi-cyclical movements with many advantages over current methods. Full article

In the context of human–robot collaborative shared environments, there has been an increase in the use of optical motion capture (OMC) systems for human motion tracking. The accuracy and precision of OMC technology need to be assessed in order to ensure safe human–robot interactions, but the accuracy specifications provided by manufacturers are easily influenced by various factors affecting the measurements. This article describes a new methodology for the metrological evaluation of a human–robot collaborative environment based on optical motion capture (OMC) systems. Inspired by the ASTM E3064 test guide, and taking advantage of an existing industrial robot in the production cell, the system is evaluated for mean error, error spread, and repeatability. A detailed statistical study of the error distribution across the capture area is carried out, supported by a Mann–Whitney U-test for median comparisons. Based on the results, optimal capture areas for the use of the capture system are suggested. The results of the proposed method show that the metrological characteristics obtained are compatible and comparable in quality to other methods that do not require the intervention of an industrial robot. Full article

Human identification based on motion capture data has received signification attentions for its wide applications in authentication and surveillance systems. The optical motion capture system (OMCS) can dynamically capture the high-precision three-dimensional locations of optical trackers that are implemented on a human body, but its potential in applications on gait recognition has not been studied in existing works. On the other hand, a typical OMCS can only support one player one time, which limits its capability and efficiency. In this paper, our goals are investigating the performance of OMCS-based gait recognition performance, and realizing gait recognition in OMCS such that it can support multiple players at the same time. We develop a gait recognition method based on decision fusion, and it includes the following four steps: feature extraction, unreliable feature calibration, classification of single motion frame, and decision fusion of multiple motion frame. We use kernel extreme learning machine (KELM) for single motion classification, and in particular we propose a reliability weighted sum (RWS) decision fusion method to combine the fuzzy decisions of the motion frames. We demonstrate the performance of the proposed method by using walking gait data collected from 76 participants, and results show that KELM significantly outperforms support vector machine (SVM) and random forest in the single motion frame classification task, and demonstrate that the proposed RWS decision fusion rule can achieve better fusion accuracy compared with conventional fusion rules. Our results also show that, with 10 motion trackers that are implemented on lower body locations, the proposed method can achieve 100% validation accuracy with less than 50 gait motion frames. Full article
