Search Results (41)

Determining the friction coefficients for uniform flows over very rough bottoms is a long-standing problem in open-channel hydraulics and river engineering. This experimental study presents measurements of the surface deformation as well as Darcy–Weisbach and Manning friction coefficients for steady, turbulent (6058 $\le \mathcal{R}e\le$ 28,502), and subcritical flows (0.14 $\le \mathcal{F}r\le$ 0.52) over large roughness elements, where $\mathcal{F}r$ and $\mathcal{R}e$ denote the Froude and Reynolds numbers, respectively. The experiments were conducted in a rectangular, inclined flume with a train of half-cylinders mounted on the bed, with radii in the range 20 mm $\le a\le$ 50 mm. These obstacles yield a relative submergence 1.45 $\le h_N/a\le$ 4.41 and a constant spacing ratio $e/a=12.8$ across all experimental runs, where $h_N$ and e denote the normal flow depth and the center-to-center spacing between cylinders, respectively. The relative amplitude of the surface profiles, ($\Delta h/a$), was analyzed and found to correlate strongly with $h_N/a$, $\mathcal{R}e$ and $\mathcal{F}r$. The results reveal very high values of the Darcy friction factor, f, which follows scaling laws of the form ${f\propto (h_N/a)}^{\widehat{n}}$, with $\widehat{n}<0$, independent of a, and ${f\propto \mathcal{R}e}^{\beta }$, where $\beta <0$ is closely linked to a. Scaling relationships for the Manning roughness coefficient, (n), were also investigated and are reported herein. Full article

Emergent vegetation in river corridors influences both the flow structure and subsequent fluvial processes. This investigation aimed to analyze the impact of the bending and vegetation components in a sharply curved open channel on the flow field. Experiments were undertaken in a meandering flume (0.9 m wide, wavelength of 3.2 m, and a sinuosity of 1.05) with a 90-degree bend at the end of it, with and without vegetation, to achieve this goal. The individual vegetation elements arranged across the 90-degree bend of the flow channel were physically modelled using rigid plastic stems (of 5 mm and 10 mm diameters). Analysis of the findings from the flow velocimetry, taken at five cross-sections oriented at angles of 0°, 30°, 45°, 60°, and 90°, along the 90-degree bend indicates that as the plant density increases, the effect of centrifugal force from the channel’s bend on the cross-sectional flow patterns decreases. At the same time, the restricting influence of vegetation on lateral momentum transfer becomes more pronounced. Specifically, for increasing vegetation density: (a) higher transverse and vertical velocities are observed (increased by 4.35% and 9.68% for 5 mm and 10 mm reed vegetation, respectively, compared to the non-vegetated case); (b) greater turbulence intensity is seen in the transverse flow direction, along with increased turbulent kinetic energy (TKE); and (c) reduced near-bed Reynolds stresses are found. The average transverse flow velocity for the non-vegetated case is 18.19% of the longitudinal flow velocity and the average vertical velocity for the non-vegetated case and 5 mm and 10 mm reed vegetation is 3.24%, 3.6%, and 5.44% of the longitudinal flow velocity, respectively. Full article

An experimental study was conducted to identify the behaviour of neutrally buoyant microplastics (specific density, 0.94) in different hydrodynamic conditions while focusing on combined wave–current conditions and the mixing across the hyporheic zone. For in-water-column microplastics, it was observed that the streamwise dispersion of neutrally buoyant microplastics is comparable to solute dye in both slow open-channel flow conditions and combined wave–current conditions. However, for in-bed microplastics, when compared to soluble tracers, the longer timespans associated with the hyporheic exchange process allowed the density effects to enhance the vertical exchange when compared to solutes. Full article

The functionality of rivers and open diversion channels can be severely impacted when the epipelic algae group that grows on concrete inclined side walls, which are typical of urban rivers, joins the water flow. This study aims to increase the long-distance transport of epipelic algae groups in urban rivers and open diversion channels through flow scheduling and to anticipate their transport capacity with respect to water flow. Current research on contaminant movement is primarily based on mathematical models with limited data on flake epipelic algae types. A sidewall epipelic algae group in a flume was modeled using a generalized hydrodynamic experimental approach. Hydraulic experiments were conducted to study the physical movement form and transport capacity of the suspended epipelic algae group. This study suggests that the epipelic algae group will create transport movement without sedimentation when the velocity reaches 80–85% of the main flow velocity and settle to the bottom when it falls below 80%. This research can support the mathematical modelling of hydrodynamic transport, provide a research foundation for long-distance transport, and estimate potential gathering places and sediment amounts under different water flow conditions. Full article

Solid–liquid flows are encountered in various industrial and natural environments. The internal structure of such flows is highly sensitive to the grading of the solid particles present. In this experimental study, an extended stereometric method is employed to assess the distributions of velocity of particles of different fractions, distinguished by different colors, in vertical and nearly horizontal granular flows. In the vertical flow experiments, mixtures comprising three fractions of lightweight particles, characterized by a very similar density, size, and shape, were tested. The results affirmed the method’s ability to discern particle velocity differences on the order of millimeters per second, establishing its suitability for characterizing nearly horizontal open-channel flows with bimodal mixtures that are stratified and exhibit more complex velocity distributions. Tilting flume experiments, incorporating additional measurements of water velocity distribution, allowed for the evaluation of local slip between water and particles, as well as between particles of the two fractions in the flow. The results indicated that, although the local slip velocity was relatively small, the average slip velocity between the carrying water and transported particles was significantly larger. This factor must be taken into consideration when evaluating bed friction or bed erosion for granular flow in a channel with an erodible bed. Full article

The fluid dynamics of channel confluences are highly complex due to flow separation and secondary currents. Although numerous studies in the past few decades have focused on the numerical simulation of confluence flow, deformed beds were rarely used. This study attempts to address this issue through numerical simulation of the flow behavior in an open-channel confluence flume with an equilibrium degraded bed in OpenFOAM (version 6.0) to compare the results with a flatbed. In the present study, different turbulence models, including Reynolds-Averaged Navier–Stokes (RANS), large-eddy simulation (LES), and detached eddy simulation (DES) models were performed using rigid-lid and volume-of-fluid (VoF) methods. The accuracy of the models was statistically analyzed by comparing them with observation data. The results demonstrated that the LES model had the best performance, with a minimum average normalized root-mean-square error (NRMSE) of 3% under the VoF assumption. The investigation also further illuminated the intricate interplay of vortical structures within the confluence zone. Notably, the number and behavior of vortices were found to be influenced by channel geometry and size, as well as interactions between separated shear layers. Circulation within the separation zone near the inner bank differed in rotation between the degraded and flatbed cases. Full article

A passive wedge screen, thanks to its many functional and environmental advantages, has recently become a popular type of surface water intake for municipal and industrial purposes. The design solutions proposed in this paper for a passive wedge wire screen intake model and two different deflectors have been experimentally tested under conditions that can be considered as no-flow conditions at the hydraulic flume. There was only a slight flow associated with the operation of the screen, while there was almost no flow in the hydraulic channel itself, such that it would be considered a watercourse. A hydraulic analysis was carried out, including velocity distribution around the screen as well as the determination of head losses with or without deflectors installed inside the screen. Lower inlet and inflow velocities to the surface of the water intake reduce the risk of injury or death to small fish and fry as well as attracting pollutants understood as sediments, debris, and plant remains floating in the river. In order to achieve the lowest possible maximum inlet and inflow velocities at the highest possible intake capacity, it was necessary to equalize the approach velocity distributions. It was shown that by using the proposed deflectors, the approach velocity distributions were equalized and the maximum values of inflow and inlet velocities were reduced. A water intake screen with a deflector with an uneven porosity distribution equalized the approach velocities better than a deflector with equal openings, but the differences were small. Installing the wedge screen model reduced the maximum inlet velocity from exceeding 2 m/s to a value of 0.08 m/s, and after installing deflectors with equal and unequal openings to values of 0.06 m/s and 0.05 m/s, respectively. In addition to laboratory tests, the paper describes the numerical simulations performed in ANSYS Fluent software. The results of the simulations made it possible to obtain a broader study, as well as to compare the velocity values obtained at the measuring points during the laboratory tests. Full article

With the onset of winter in cold regions, border ice begins to form, impacting sediment transport rate and distribution. Understanding the effect of ice cover is crucial in regions with prolonged sub-freezing temperatures, as water bodies remain frozen for a considerable part of the year. While the existing literature includes many studies on sediment transport in open channel flow and several studies on completely ice-covered flow, there is limited research on sediment transport in partially ice-covered channels. Addressing this gap, the current study conducted laboratory experiments in a rectangular flume at the Hydraulics Research and Testing Facility, University of Manitoba, Canada. The investigation focused on examining the influence of asymmetric border ice, varying coverage ratios in asymmetric partially ice-covered flow, and changing flow strengths on bedload transport rate and distribution. Additionally, a comparison was made with symmetric partially ice-covered flow conditions. The findings indicate that the presence of asymmetric border ice indeed affected the bedload transport distribution within the channel, causing non-uniform bedload transport distribution across the channel width, with peak values concentrated in the center of the open flow section. Increased asymmetry in border ice leads to greater asymmetry in bedload transport rate distribution. Despite these pronounced differences in bedload transport rate across the channel width, the cross-section-averaged bedload transport rate could still be estimated utilizing the conventional equations, used for open channel flow, fully ice-covered flow, and symmetric partially ice-covered flow, with the effect of ice cover accounted for by incorporating an additional boundary in the calculation of the wetted perimeter, leading to adjustments in the flow strength. Full article

This study proposes a new empirical model for estimating local scour along the base of longitudinal training walls for granular riverbeds. The model’s performance was rigorously assessed through experiments conducted in an open-channel flume, encompassing variations in granulometric characteristics, slope, and flow rates. The investigation involved a comparative analysis of six commonly employed equations for scour estimation. The results consistently demonstrated a tendency of the selected equations to overestimate scour depth within the longitudinal structures. In contrast, the new proposed equation considers factors such as the well-graded granular bedding represented by the Coefficient of uniformity (C_u) and the embedment of the longitudinal wall. This allows for a more robust identification of the scour behavior of longitudinal walls. This research enhances our comprehension of local scour in riverbeds. It provides engineers and researchers with a valuable tool for more accurate predictions, thereby contributing to the improved design and maintenance of river environment structures. Full article

Due to climate change, the intensity of extreme rainfall has been observed to increase with a shorter duration, causing flash floods (strong, unsteady flow) that lead to serious loss of life and economic damage all over the world. In this study, by repeating the same flume experiments twenty times over a bare bed or with a submerged vane installed, the hydrodynamic characteristics of a strong, unsteady open-channel flow were investigated. Acoustic Doppler velocimetry (ADV) was used to measure the instantaneous three-dimensional velocity, and the ensemble average method was then adopted to obtain the time-varying mean flow velocities. Reynolds decomposition was applied to disintegrate the instantaneous velocity to time-varying average velocity and fluctuating velocity. Turbulence characteristics such as turbulent intensity, turbulent bursting, and power spectral density (PSD) were analyzed against water depth variations. The results show that the loop pattern of the streamwise velocity against the water depth variations could significantly affect the turbulence characteristics of unsteady flow. Near the bed, the peaks of the turbulent intensity and the TKE lag behind the peak of the water depth. The PSD revealed that the turbulent energy increases at the rising and falling stages were due to the generation of small-scale turbulence vortices or eddies. As a submerged vane was present, the increase in the angle of attack caused the increase in the turbulent intensity and TKE, which means that the induced vortex became stronger and the wake region was larger. When the angle of attack was equal to $20°$, the TKE abruptly enlarged in the falling stages, implying the breaking-up of the induced vortex. The PSD of the transverse fluctuation velocity showed multiple spikes at the high-frequency part, possibly denoting the shedding frequency from the induced vortex. Further downstream, behind the submerged vane, the peak frequencies of the PSD became imperceptible, likely because of the induced vortex decays or other factors such as the turbulence generated from the free surface or the channel bed mixing with the turbulence from the induced vortex. Full article

The construction of large-scale water diversion projects has effectively alleviated the current situation of the uneven distribution of water resources in China. However, due to the siltation of very fine sediment and organic matter on the side wall of an open channel, and the slow velocity of the side wall flow field, it is easy for epipelic algae to be produced, which affects water quality. Because prototype observation cannot be used to predict the series of flow in real time, and the calculation of the mathematical model is affected by parameter limitations, these two methods often cannot truly reflect the hydrodynamic characteristics of an open channel with epipelic algae. Therefore, by referring to the design parameters of the water diversion project channel, this study took the epipelic algae growing on the side wall of an open channel as the research object and used the scale of 1:30 to carry out a generalized flume experiment. Through the analysis of the physical characteristics of the prototype sample, and the simulation of the cohesive force between the oblique side wall and the epipelic algae, multi-group and multi-series hydrodynamic tests were carried out. The velocity distribution law and flow field distribution law were analyzed. The research results show that the presence of epipelic algae has a certain hindering effect on the flow velocity and significantly reduces the range of the peak velocity of the channel along the water depth. The position of the maximum velocity on the vertical line of the channel flow appears at the relative water depth of 0.6. In the case of small flow, the epipelic algae group only reduces the average flow rate of the channel by 5~6%; in the case of large flow, the effect of epipelic algae on the channel flow rate is minimal. This paper includes important scientific guiding significance and practical value for the regulation of water quantity and water quality safety, as well as the protection of long-distance projects. Full article

Subsurface perforated pipes drain infiltrated stormwater runoff while attenuating the peak flow. The Manning roughness coefficient (n) was identified as a fundamental parameter for estimating roughness in various subsurface channels. Hence, in this work, the performance of a six-row non-staggered sand-slot perforated pipe as a sample of the subsurface drainage is investigated experimentally in a laboratory flume at Universiti Sains Malaysia (USM) aimed at determining the Manning roughness coefficients (n) of the pipe and assessing the relationship between the Manning’s n and the hydraulic parameters of the simulated runoff flow under the conditions of the tailgate channel being opened fully (GFO) and partially (GPO), as well as the pipe having longitudinal slopes of 1:750 and 1:1000. Water is pumped into the flume at a maximum discharge rate of 35 L/s, and the velocity and depth of the flow are measured at nine points along the inner parts of the pipe. Based on the calculated Reynolds numbers ranging from 38,252 to 64,801 for both GFO and GPO conditions, it is determined that most of the flow in the perforated pipe is turbulent, and the calculated flow discharges and velocities from the outlets under GFO are higher than the flow and velocity rates under GPO with similar pipe slopes of 1:750 and 1:1000. The Manning coefficients are calculated at nine points along the pipe and range from 0.004 to 0.009. Based on the ranges of the calculated Manning’s n, an inverse linear relationships between the Manning coefficients and the flow velocity under GFO and GPO conditions are observed with the R² of 0.975 and 0.966, as well as 0.819 and 0.992 resulting from predicting the values of flow velocities with the equations v = ((0.01440 − n)/0.009175), v = ((0.01330 − n)/0.00890), v = ((0.02007 − n)/0.01814), and v = ((0.01702 − n)/0.01456) with pipe slopes of 1:750 and 1:1000, respectively. It is concluded that since the roughness coefficient (Manning’s n) of the pipe increases, it is able to reduce the flow velocity in the pipe, resulting in a lower peak of flow and the ability to control the quantity of storm water in the subsurface urban drainages. Full article

The study of embankment breaching is not an easy practice, as it includes various parameters to meet the suitability of the design approach, especially when we consider it for the long term. Embankment breach studies generally include the prediction of different breach parameters. The important physical and hydrodynamic parameters of the flood wave generated from the embankment failure are breach width, breach slope, formation time, peak outflow, and time to failure. Out of these parameters, peak outflow is a very important breach parameter, as it deflects the magnitude of destruction on the downstream side of the embankment and affects the evacuation plans for the downstream population. The prediction of breach peak outflow due to overtopping of the embankment is very essential for dam failure prevention and mitigation, as well as for the design of an early warning system. Many researchers have used dam failure data, comparative studies, experimental studies, or regression techniques to develop various models for predicting peak outflow. The present paper analyzes the results of the design for forty experiments carried out in two different laboratory water channels (flumes). Different embankment models are overtopped with the objective of studying the breach behavior during overtopping. The study was inspired by reports in the open literature of embankment failures that resulted in catastrophic conditions. With experimental data, an efficient model is developed for predicting breach peak outflow (Q_p) by correlating with other independent embankment breach parameters for cohesive as well as non-cohesive embankments. The model is validated with historical and laboratory data compiled in the past. For the validation of current investigational work, the experimental data of the present study are compared with the model already developed by other researchers. From the study and analysis, it is observed that breach peak outflow depends upon hydraulic, geometric, and geotechnical parameters of embankments. Being a phenomenon that is active for a short duration only, the manual measurement of various parameters of the modeling process poses some limitations under laboratory conditions. Full article

Large-scale coherent structures (LSCSs) in rough-bed open-channel flow (OCF) are significant in turbulence research. A recent breakthrough is the bimodal feature of LSCSs on regular rough-bed OCF (i.e., LSCSs exhibit two typical motions: large-scale motions (LSMs) and very-large-scale motions (VLSMs)). However, the presence and characteristics of LSMs and VLSMs in irregularly arranged rough-bed OCF remain unclear. Thus, in this study, high-precision indoor flume experiments were performed under typical irregularly arranged rough-bed conditions, and time-resolved particle image velocimetry was used for velocity measurements. Statistical quantities of velocity fluctuations revealed that the friction Reynolds number and roughness exerted a certain modulation on the velocity fluctuating properties. The spectra of velocity fluctuations provided direct and statistical evidence for the presence of LSMs and VLSMs in irregularly arranged rough-bed OCF. VLSMs contributed more than 60% of the streamwise turbulent kinetic energy and 40% of the Reynolds shear stress in the outer region of the irregularly arranged rough-bed OCF, which was slightly higher than that in the smooth-bed or regular rough-bed OCF scenarios. No apparent dependence of the wavelength of VLSMs on the flow submergence (H/d₅₀) was observed in the present irregularly arranged rough-bed OCF, which is in contrast to that reported for regular rough-bed OCF. Furthermore, the relationship between the peak wavelength of VLSMs and the aspect ratio did not strictly follow a linear increase, in contrast to that documented in the literature. Full article

Spatially heterogeneous turbulent flow refers to nonuniform flow with coexisting multiple flow velocities, which is widely distributed in fish natural or husbandry environments, and its hydraulic parameters affect fish swimming behavior. In this study, a complex hydrodynamic environment with three flow velocity regions (low, medium, and high) coexisting in an open-channel flume was designed to explore volitional swimming ability, the spatial-temporal distribution of fish swimming trajectories, and the range of preferred hydrodynamic parameters of Schizothorax prenanti individual and schooling (three fish). The results showed that the swimming speed of individual fish during upstream migration was significantly higher than that of fish schools (p < 0.05). The swimming trajectories of fish schooling showed that they spent more time synchronously exploring the flow environment during upstream migration compared with individual fish. By superimposing the fish swimming trajectories on the environmental flow field, the range of hydrodynamic environments preferred by fish in complex flow fields was quantified. This research provides a novel approach for investigating the natural swimming behavior of fish species, and a theoretical reference for the restoration of fish natural habitats or flow enrichment of husbandry environments. Full article
