We reported on a single-longitudinal-mode operated distributed Bragg reflector laser diode emitting at 1950 nm with an on-chip integrated power amplifier. Second-order Chromium–Bragg gratings are carefully designed and fabricated at the end of the ridge waveguide. Achieving a stable single-mode operation with a large injecting current range of 800 mA from 15 °C to 40 °C. The maximum side-mode suppression ratio (SMSR) is up to 42 dB. To increase the output power, an on-chip integrated master oscillator power amplifier (MOPA) is also introduced. MOPA-DBR lasers with different matching configurations between the gain peak and Bragg wavelength are fabricated, resulting in various amplification consequences. The best device is realized with 40 nm red-shifted between Bragg wavelength and photoluminescence (PL) peak. A power amplification of 5.6 times is achieved with the maximum output power of 45 mW. Thus, we put up the feasibility and key design parameters of on-chip integrated power amplification DBR lasers towards mid-infrared. Full article

Integrated optical amplifiers are the building blocks of on-chip photonic systems, and they are often accompanied by a narrowband filter to limit noise. In this sense, a bandwidth-tunable optical amplifier with narrowband filtering function is crucial for on-chip optical circuits and radio frequency systems. The intrinsic loss and coupling coefficients between resonator and waveguide inherently limit the bandwidth. The parity-time symmetric coupled microresonators operating at exceptional points enable near zero bandwidth. In this study, we propose a parity-time symmetric coupled microresonators system operating near EPs to achieve a bandwidth of 46.4 MHz, significantly narrower than bandwidth of 600.0 MHz and 743.2 MHz achieved by two all-pass resonators with identical gain/loss coefficients. This system also functions as an optical bandwidth-tunable filter. The bandwidth tuning ranges from 175.7 MHz to 7.8 MHz as gain coefficient adjusts from 0.2 dB/cm to 0.4 dB/cm. Our scheme presents a unique method to obtain narrow bandwidth from two broadband resonators and serves as an optical bandwidth-tunable filter, thereby paving a new avenue for exploring non-Hermitian light manipulation in all-optical integrated devices. Full article

In recent years, silicon photonics has achieved great success in optical communication area. More and more on-chip optoelectronic devices have been realized and commercialized on silicon photonics platform, such as silicon-based modulators, filters and detectors. However, on-chip light sources are still not achieved because that silicon is an indirect bandgap material. To solve this problem, the rare earth element erbium (Er) is considered, which emits light covering 1.5 μm to 1.6 μm and has been widely used in fiber amplifiers. Compared to Er-doped fiber amplifiers (EDFA), the Er ion concentration needs to be more than two orders higher for on-chip Er-based light sources due to the compact size integration requirements. Therefore, the choice of the host material is crucially important. In this paper, we review the recent progress in on-chip Er-based light sources and the advantages and disadvantages of different host materials are compared and analyzed. Finally, the existing challenges and development directions of the on-chip Er-based light sources are discussed. Full article

We report the fabrication and optical characterization of Yb³⁺-doped waveguide amplifiers (YDWA) on the thin film lithium niobate fabricated by photolithography assisted chemo-mechanical etching. The fabricated Yb³⁺-doped lithium niobate waveguides demonstrates low propagation loss of 0.13 dB/cm at 1030 nm and 0.1 dB/cm at 1060 nm. The internal net gain of 5 dB at 1030 nm and 8 dB at 1060 nm are measured on a 4.0 cm long waveguide pumped by 976 nm laser diodes, indicating the gain per unit length of 1.25 dB/cm at 1030 nm and 2 dB/cm at 1060 nm, respectively. The integrated Yb³⁺-doped lithium niobate waveguide amplifiers will benefit the development of a powerful gain platform and are expected to contribute to the high-density integration of thin film lithium niobate based photonic chip. Full article

Integrated optics, having the unique properties of small size, low loss, high integration, and high scalability, is attracting considerable attention and has found many applications in optical communications, fulfilling the requirements for the ever-growing information rate and complexity in modern optical communication systems. Femtosecond laser fabrication is an acknowledged technique for producing integrated photonic devices with unique features, such as three-dimensional fabrication geometry, rapid prototyping, and single-step fabrication. Thus, plenty of femtosecond laser-fabricated on-chip devices have been manufactured to realize various optical communication functions, such as laser generation, laser amplification, laser modulation, frequency conversion, multi-dimensional multiplexing, and photonic wire bonding. In this paper, we review some of the most relevant research progress in femtosecond laser-fabricated photonic chips for optical communications, which may break new ground in this area. First, the basic principle of femtosecond laser fabrication and different types of laser-inscribed waveguides are briefly introduced. The devices are organized into two categories: active devices and passive devices. In the former category, waveguide lasers, amplifiers, electric-optic modulators, and frequency converters are reviewed, while in the latter, polarization multiplexers, mode multiplexers, and fan-in/fan-out devices are discussed. Later, photonic wire bonding is also introduced. Finally, conclusions and prospects in this field are also discussed. Full article

Ultraviolet (UV) light plays an important role in air/water/surface sterilization now. Maintaining a certain light intensity is often required to attain the targeted effect. In this paper, on-chip power monitoring of a UV-A light-emitting diode (LED) via sapphire substrate is reported. A p–i–n photodiode loop that surrounds the UV-A LED was designed and fabricated to monitor the output power by detecting the scattered light of the LED propagating through the sapphire substrate. No particular waveguide structure or processing parameter control was needed. The monitoring responsivities per unit of surface-emitting power obtained were approximately 21 and 25 mA/W at photodiode biases of 0 and 3 V, respectively. When combined with a transimpedance amplifier, a monitoring responsivity of 1.87 V/mW at zero bias was measured, and a different monitoring responsivity could be customized by adjusting the gain of the transimpedance amplifier. The operation principle of this device might be applicable to UV-B or UV-C LEDs. Full article

Rare-earth ion-doped potassium yttrium double tungstate, RE:KY(WO₄)₂, is a promising candidate for small, power-efficient, on-chip lasers and amplifiers. Thin KY(WO₄)₂-on-glass layers with thicknesses ranging between 0.9 and 1.6 μm are required to realize on-chip lasers based on high refractive index contrast waveguides operating between 1.55 and 3.00 µm. The crystalline nature of KY(WO₄)₂ makes the growth of thin, defect-free layers on amorphous glass substrates impossible. Heterogeneous integration is one of the promising approaches to achieve thin KY(WO₄)₂-on-glass layers. In this process, crystal samples, with a thickness of 1 mm, are bonded onto a glass substrate and thinned down with an extensive lapping and polishing procedure to the desired final thickness. In this study, a lapping and polishing process for KY(WO₄)₂ was developed toward the realization of integrated active optical devices in this material. Full article

In this paper, we demonstrate two subsystems based on Silicon Photonics, towards meeting the network requirements imposed by disaggregation of resources in Data Centers. The first one utilizes a 4 × 4 Silicon photonics switching matrix, employing Mach Zehnder Interferometers (MZIs) with Electro-Optical phase shifters, directly controlled by a high speed Field Programmable Gate Array (FPGA) board for the successful implementation of a Bloom-Filter (BF)-label forwarding scheme. The FPGA is responsible for extracting the BF-label from the incoming optical packets, carrying out the BF-based forwarding function, determining the appropriate switching state and generating the corresponding control signals towards conveying incoming packets to the desired output port of the matrix. The BF-label based packet forwarding scheme allows rapid reconfiguration of the optical switch, while at the same time reduces the memory requirements of the node’s lookup table. Successful operation for 10 Gb/s data packets is reported for a 1 × 4 routing layout. The second subsystem utilizes three integrated spiral waveguides, with record-high 2.6 ns/mm², delay versus footprint efficiency, along with two Semiconductor Optical Amplifier Mach-Zehnder Interferometer (SOA-MZI) wavelength converters, to construct a variable optical buffer and a Time Slot Interchange module. Error-free on-chip variable delay buffering from 6.5 ns up to 17.2 ns and successful timeslot interchanging for 10 Gb/s optical packets are presented. Full article
