The rapid development of wireless power transfer (WPT) technology has provided new avenues for supplying continuous and stable power to capsule robots. In this article, we propose a two-dimensional omnidirectional wireless power transfer (OWPT) system, which enables power to be transmitted effectively in multiple spatial directions. This system features a three-dimensional transmitting structure with a Helmholtz coil and saddle coil pairs, combined with a one-dimensional receiving structure. This design provides sufficient internal space, accommodating patients of various body types. Based on the magnetic field calculation and finite element analysis, the saddle coil structure is optimized to enhance magnetic field uniformity; to achieve a two-dimensional rotating magnetic field, a phase difference control method for the excitation signal is developed through the analysis of circuit topology and quantitative synthesis of non-equivalent magnetic field vectors. Finally, an experimental prototype is built, and the experimental results show that the one-dimensional transmitting coil achieves a minimum received voltage stability of 94.5% across different positions. When the three-dimensional transmitting coils operate together, a two-dimensional rotating magnetic field in the plane is achieved at the origin, providing a minimum received power of 550 mW with a voltage fluctuation rate of 7.68%. Full article

Wireless Power Transfer (WPT) has become a key technology to extend network lifetime in Wireless Rechargeable Sensor Networks (WRSNs). The traditional omnidirectional recharging method has a wider range of energy radiation, but it inevitably results in more energy waste. By contrast, the directional recharging mode enables most of the energy to be focused in a predetermined direction that achieves higher recharging efficiency. However, the MC (Mobile Charger) in this mode can only supply energy to a few nodes in each direction. Thus, how to set the location of staying points of the MC, its service sequence and its charging orientation are all important issues related to the benefit of energy replenishment. To address these problems, we propose a Fuzzy Logic-based Directional Charging (FLDC) scheme for Wireless Rechargeable Sensor Networks. Firstly, the network is divided into adjacent regular hexagonal grids which are exactly the charging regions for the MC. Then, with the help of a double-layer fuzzy logic system, a priority of nodes and grids is obtained that dynamically determines the trajectory of the MC during each round of service, i.e., the charging sequence. Next, the location of the MC’s staying points is optimized to minimize the sum of charging distances between MC and nodes in the same grid. Finally, the discretized charging directions of the MC at each staying point are adjusted to further improve the charging efficiency. Simulation results show that FLDC performs well in both the charging benefit of nodes and the energy efficiency of the MC. Full article

High-efficiency wireless power transfer (WPT) systems can present a perfect solution for fast-charging autonomous guided vehicles (AGV) to improve working hours in high-tech warehouses. Stationary charging stations reduce separation distance, improving coupling factor and power transfer efficiency. Analysis and design of the WPT system focused on maximum power at the load with a SS compensation circuit to reach high efficiency while applying the theory of power transformers design to maximize the power handleability with the physical dimensions. The proposed concept fits small AGVs. This paper proposes a unique ferrite structure for the transmitter ferromagnetic core. This novel shape introduces horizontal angular misalignment resistance due to the transmitter’s omnidirectional concave disc ferrite core combined with an E-core ferrite at the receiver side. The proposed WPT system can output 200 W at 100 kHz. A realistic 3D model has been designed into a symmetrical equivalent to reducing complexity and computational effort. The visualization of the magnetic flux distribution demonstrated that the proposed design has a better path to flow without concentrating flux in small regions, reducing heating losses. Full article

This study proposes an analytical model of a WPT system with three orthogonal transmitter coils organised to produce a concentrated and controlled omnidirectional magnetic field suited for charging a moving, rotating load, providing maximal energy transfer without receiving end feedback. In order to create a realistic 3D WPT simulation system and a precise controller design, the mutual coupling values in terms of the receiver angular positions are modelled using the Ansys software. In using the established model of the 3DWPT system, an extremum seeking control (ESC) is used to maximize the power transfer utilizing the input power as an objective function assigned with specified parametric values defining the WPT model. The output power transmitted by the sending-end coils to a load of a moving UAV rotating in orbit is displayed. According to simulation results, when the receiver UAV speed is close to 2250 deg/s, the controller can accomplish a maximum power transfer of 2.6w in almost 1ms. Full article

In order to solve the misalignment problem of wireless power transmission, this paper designed and analyzed the omnidirectional receiver with multi-coil. The circuit models and transmission characteristics of the wireless power transfer system (WPTS) containing multi-coil were established. Besides, an accurate mutual inductance modelling method of the circular coil under different horizontal offset and angular deflection was presented. Based on the circuit models and the mutual inductance model, the relationship between transmission characteristics and the coil parameters were studied. Simultaneously, the design method which can synthetically and quantificationally consider the radius of the coil and the number of turns was proposed. Finally, an omnidirectional receiver with multi-coil using the quantificational model and transmission characteristics in different horizontal offset and angular deflection was designed.The transmission efficiency of three-coils-receiver system was up 12.3% higher than that of one-coil-receiver system and 4% higher than that of two-coils-receiver system when horizontal offset was between 0 cm and 30 cm. Similarly, when angular deflection was between 0 and $\pi /2$, the efficiency of three-coils-receiver system was up 73.25% higher than that of one-coil-receiver system and 1.6% higher than that of two-coils-receiver system. Full article

Wireless power transfer (WPT) has been extensively studied from various aspects such as far field and near field, operating frequency, coil design, matched capacitance values, misaligned locations of transmitting and receiving coils, distance variance between them, target loads in the specific locations, environment, and operating conditions. This is due to the usefulness of WPT technology in many applications, including the revolutionary method of auto-recharging of unmanned aerial vehicles (UAVs). This paper presents analytical modeling of a WPT-link with two orthogonal transmitting coils arranged to produce an omnidirectional magnetic field suitable for charging a moving rotating load, maximizing energy transfer without any feedback from the receiving end. To achieve a suitable 2D WPT simulation system, as well as an accurate control design, the mutual coupling values in terms of receiver angular rotation are simulated using Ansys software. Power transfer is maximized by using extremum seeking control (ESC), making use of the input power as an objective function with specific parameter values that represent the WPT model to obtain the results. The results shown are those of the input power transmitted by the transmitting-end coils to a load of an orbiting mobile UAV. Based on the simulation results, the controller can achieve maximum power transfer in 100 µs of duration when the speed of the UAV is close to 314 rad/s. Full article

Many studies have been conducted on multi-output systems that transfer power to multiple receivers in conventional planar-type wireless power transfer (WPT) systems; however, few studies and analyses have taken into account the mutual inductance between receivers in multi-output omnidirectional WPT systems. In this paper, the correlation between the mutual inductance between receivers and the power transfer efficiency (PTE) in a multi-output omnidirectional WPT system is analyzed, and a limitation in terms of a reduction in the PTE with an increase in the influence of the mutual inductance between the receivers is presented. To solve this problem, a resonant network design method is proposed to reduce the influence of mutual inductance between receivers, and appropriate canceling capacitor values are selected using the weighted sum method among multi-objective optimization methods. The proposed method is through simulations and experiments, and it presents the potential for improvement in the problems that occur when transferring power to multiple receivers. Full article

Wirelessly powered, very compact sensors are highly attractive for many emerging Internet-of-things (IoT) applications; they eliminate the need for on-board short-life and bulky batteries. In this study, two electrically small rectenna-based wirelessly powered light and temperature sensors were developed that operate at 915 MHz in the 902–928-MHz industrial, scientific, and medical (ISM) bands. First, a metamaterial-inspired near-field resonant parasitic (NFRP) Egyptian axe dipole (EAD) antenna was seamlessly integrated with a highly efficient sensor-augmented rectifier without any matching network. It was electrically small and very thin, and its omnidirectional property was ideal for capturing incident AC wireless power from any azimuthal direction and converting it into DC power. Both a photocell as the light sensor and a thermistor as the temperature sensor were demonstrated. The resistive properties of the photocell and thermistor changed the rectifier’s output voltage level; an acoustic alarm was activated once a threshold value was attained. Second, an electrically small, low-profile NFRP Huygens antenna was similarly integrated with the same light- and temperature-sensor-augmented rectifiers. Their unidirectional nature was very suitable for surface-mounted wireless power transfer (WPT) applications (i.e., on-body and on-wall sensors). Measurements of the prototypes of both the light- and temperature-sensor-augmented omni- and unidirectional rectenna systems confirmed their predicted performance characteristics. Full article

In order to implement the omnidirectional wireless power transfer (WPT), a novel three-phase-shifted drive omnidirectional WPT system is proposed. This system is comprised of three independent phase-adjusted excitation sources, three orthogonal transmitting coils, and one planar receiving coil. Based on the mutual coupling theory, the power transfer efficiency is derived and the corresponding control mechanism for maximizing this efficiency is presented. This control mechanism only depends on the currents’ root-mean-square (RMS) values of the three transmitting coils and simple calculations after each location and/or posture change of the receiving coil, which provides the real-time possibility to design an omnidirectional WPT system comparing with the other omnidirectional systems. In aid of computer emulation technique, the efficiency characteristic versus the omnidirectional location and posture of the receiving coil is analyzed, and the analytical results verify the validity of the control mechanism. Lastly, a hardware prototype has been set up, and its omnidirectional power transmission capacity has been successfully verified. The experimental results show that the wireless power is omnidirectional and it can be effectively transmitted to a load even though its receiving coil moves and/or rotates in a 3-D energy region. Full article

An omnidirectional magnetically coupled resonant wireless power transfer (WPT) system based on rotary transmitting coil is presented. The proposed scheme can ease the variations of the transfer efficiency and output power caused by the deviation of transfer direction, and improve the unbalanced power distribution phenomenon between the receivers, which are still not fully achieved in current WPT systems. The modified coupled-mode model is built first to describe the non-rotary multi-receiver WPT system. The analysis indicates that the transfer efficiency and output power of the system can be expressed as functions of the deviation angle between the transmitting coil and receiving coil, which has a non-negligible influence on the system performances. Then, the modified high order coupled-mode model containing time-varying parameters about the deviation angle is derived for the proposed omnidirectional WPT system. Theoretical analysis and simulated results indicate that this system can transfer power to multiple receivers around the transmitter synchronously and evenly, which is very suitable for wireless charging for household appliances indoors. The scheme feasibility and theoretical analysis are verified by experimental results. Full article
