The spin relaxation rate of Xe isotopes is a key characteristic of nuclear magnetic resonance gyroscopes (NMRGs). A pump-induced biphasic relaxation (PBR) model is proposed to describe the pump dependence of the transverse relaxation rate of ¹²⁹Xe nuclear spin. The distribution of electron polarization is theoretically analyzed based on the Bloch–Torrey equations and the volume-averaged polarization is evaluated through NMR frequency shift measurements. Experimental results confirm the theoretical quadratic dependence between Γ and $P_{Rb}$ with a high fitting accuracy (R² = 0.9969). The predicted linear (R² > 0.9966) and hyperbolic (R² > 0.9942) regimes of Γ versus pump power are also observed. Validation across different pump power conditions shows agreement between the model and measurements, with an average relative deviation of 0.2169%. The multi-stage process of nuclear spin relaxation is quantified, thereby providing a robust validation for the PBR model. Full article

Surface collisions at Pyrex walls limit the spin coherence in nuclear magnetic resonance gyroscopes (NMRG) vapor cells, while the cavity–stem junction introduces geometry dependent exchange that perturbs the transverse spin relaxation time $T_2$ of ¹²⁹Xe atoms. We combine $T_2$ measurements with Monte Carlo simulations of confined diffusion and surface collisions to decompose the relaxation of Xe atoms and derive a cavity–stem geometry correction for wall relaxation. A structural coupling factor (SCF) is introduced to compress stem length and aperture diameter into a dimensionless metric for diffusion-limited mixing, enabling prediction of the transverse relaxation rate versus geometry. Across eight simulated configurations, the model yields $R^2=0.982$ and agrees with experiments within 7–$9\%$, comparable to the measurement uncertainty ($\pm 0.015{\mathrm{s}}^{-1}$). Using the validated framework, geometry optimization reduces the relaxation rate from $0.225$ to $0.131{\mathrm{s}}^{-1}$ (a $41.8\%$ improvement). This Pyrex surface-collisional analysis provides an in-situ, $T_2$-based route to compare effective surface depolarization across fabrication and surface-treatment protocols while accounting for cavity–stem coupling. Full article

Reliable modeling of pressure-broadened spectra is essential for maintaining physical consistency in alkali vapor-cell diagnostics. In this work, we investigate the low-power absorption spectra of isotopically enriched ⁸⁷Rb vapor cells at the D₁ and D₂ transitions, systematically comparing three fitting algorithms: single Lorentzian, hyperfine-resolved Voigt, and the doublet Lorentzian approximation. Experiments were performed across optical intensities from 40 nW to 10 mW, buffer-gas pressures from 200 Torr to 520 Torr, and temperatures between 370 K and 390 K. It is shown that when the pressure broadening dominates over Doppler broadening and the optical intensity remains below the saturation regime, the reduced doublet Lorentzian model achieves a fitting accuracy of R² > 0.996. Under the pressure conditions of 350 Torr, the fitting error for both the doublet and Voigt approximations remains below 0.3% for the D₂ line and below 0.1% for the D₁ line. At the pressures of 520 Torr and under elevated optical intensities, the spectrum evolves toward a single-peaked profile, rendering a single Lorentzian model sufficient. The quantitative applicability boundary of the doublet approximation in ⁸⁷Rb vapor cells is established, defining the operational regime where hyperfine-resolved modeling can be reduced under collision-dominated conditions in NMRG systems. Full article

The spin-exchange-pumped nuclear magnetic resonance gyroscope (NMRG) is a pivotal tool in quantum navigation. The transverse relaxation of atoms critically impacts the NMRG’s performance parameters and is essential for judging normal operation. Conventional methods for measuring transverse relaxation typically use dual beams, which involves complex optical path and frequency stabilization systems, thereby complicating miniaturization and integration. This paper proposes a method to construct a ¹³³Cs parametric resonance magnetometer using a single-beam vertical-cavity surface-emitting laser (VCSEL) to measure the transverse relaxation of ¹²⁹Xe and ¹³¹Xe. Based on this method, the volume of the gyroscope probe is significantly reduced to 50 cm³. Experimental results demonstrate that the constructed Cs-Xe NMRG can achieve a transverse relaxation time (T₂) of 8.1 s under static conditions. Within the cell temperature range of 70 °C to 110 °C, T₂ decreases with increasing temperature, while the signal amplitude inversely increases. The research lays the foundation for continuous measurement operations of miniaturized NMRGs. Full article

Inertial navigation systems generally consist of timing, acceleration, and orientation measurement units. Although much progress has been made towards developing primary timing sources such as atomic clocks, acceleration and orientation measurement units often require calibration. Nuclear Magnetic Resonance (NMR) gyroscopes, which rely on continuous measurement of the simultaneous Larmor precession of two co-located polarized noble gases, can be configured to have scale factors that depend to first order only on fundamental constants. The noble gases are polarized by spin-exchange collisions with co-located optically pumped alkali-metal atoms. The alkali-metal atoms are also used to detect the phase of precession of the polarized noble gas nuclei. Here we present a version of an NMR gyroscope designed to suppress systematic errors from the alkali-metal atoms. We demonstrate rotation rate angle random walk (ARW) sensitivity of $16\mathsf{\mu }\mathrm{Hz}/\sqrt{\mathrm{Hz}}$ and bias instability of ∼800 nHz. Full article

Nuclear magnetic resonance gyroscopes (NMRGs) may be operated in an environment with violent vibration that usually contains both linear components and angular components. To analyze the influence of angular vibration on an NMRG, cross-axis coupling effects are studied. The cross-axis rotation rates induce an equivalent magnetic field. Its influence can be described by the Bloch equations. The approximate frequency shift and amplitude of the spin oscillator with an equivalent magnetic field in the cross-axis were obtained, which was validated by numerical simulation. The findings show that the angular vibration component leads to a remarkable error for the NMRG. When the angular vibration frequency is near the Larmor frequency, the oscillation frequency of the spins may be locked to the angular vibration frequency, destroying the NMRG’s ability to measure rotation rates. The cross-axis coupling problem should be considered in the design of an NMRG and corresponding inertial navigation systems. Full article

With the rapid progress of cutting-edge research such as quantum measurement technology, nuclear magnetic resonance (NMR) gyroscopes represent a major development direction of high-precision micro-miniature gyroscopes, which have significant advantages such as high precision, small size, and low power consumption. It is meaningful to measure the relaxation times of noble-gas atoms which are crucial indicators to accurately and quickly characterize the vapor cell performance as a core component of gyroscopes. In this paper, a test platform for relaxation time is built and an automatic relaxation time test system based on free induction decay (FID) and the π pulse method is designed to accelerate the relaxation time test. Firstly, the formula of the atomic dynamic process based on the Bloch equation was deduced, a GUI (Graphical User Interface) simulation based on the derived differential equation was conducted, and the moving process of the magnetic moment was visually described. Then, the virtual instrument was used to integrate multiple test instruments into an auto-test system, and LabVIEW programming was used for control to realize the automation of the test process on the test platform. Finally, the test results in different conditions were compared. The results show that the test system is stable and reliable with excellent man–machine interaction, and the measurement efficiency was increased by about 185%, providing an effective test scheme for vapor cell performance. Full article
