Search Results (6)

The distributed electric tilt-rotor Unmanned Aerial Vehicle (UAV) combines the vertical take-off and landing (VTOL) capability of helicopters with the high-speed cruise performance of fixed-wing aircraft, offering a transformative solution for Urban Air Mobility (UAM). However, aerodynamic interference between rotors is a new challenge to improving their flight efficiency, especially the dynamic interactions during the transition phase of non-parallel tandem dual-rotor systems, which require in-depth investigation. This study focuses on the aerodynamic performance evolution of the tilt-rotor system during asynchronous transition processes, with an emphasis on quantifying the influence of rotor tilt angles. A customized experimental platform was developed to investigate a counter-rotating dual-rotor model with fixed axial separation. Key performance metrics, including thrust, torque, and power, were systematically measured at various tilt angles (0–90°) and rotational speeds (1500–3500 RPM). The aerodynamic coupling mechanisms between the front and rear rotor disks were analyzed. The experimental results indicate that the relative tilt angle of the dual rotors significantly affects aerodynamic interference between the rotors. In the forward tilt mode, the thrust of the aft rotor recovers when the tilt angle reaches 45°, while in the aft tilt mode, it requires a tilt angle of 75°. By optimizing the tilt configuration, the aerodynamic performance loss of the aft rotor due to rotor-to-rotor aerodynamic interference can be effectively mitigated. This study provides important insights for the aerodynamic performance optimization and transition control strategies of the distributed electric tilt-rotor UAV. Full article

This paper introduces a phase one computational design analysis study of a hydrokinetic horizontal parallel stream direct-drive (no gear box) counter-rotating Darrieus turbine system. This system consists of two Darrieus rotors that are arranged in parallel and horizontal to the water stream and operate in counter-rotation due to the incoming flow. One of the rotors directly drives an armature coil rotor and the other one a permanent magnet generator. A two-dimensional (2-D) and three-dimensional (3-D) computational fluid dynamic (CFD) simulation study was conducted to assess the hydrokinetic performance of the design. From a high computational cost and time perspective, the simulation setup was reduced from a 3-D to a 2-D analysis. Although useful information was obtained from the 3-D simulations, the output performance could be assessed with the 2-D simulations without compromising the integrity of the turbine output results. A scaled experimental design prototype was developed for static (non-movement of the rotors with dynamic fluid flow) particle image velocimetry (PIV) studies. The PIV studies were used as a benchmark for validating and verifying the CFD simulations. This paper outlines the prototype development, PIV experimental setup and results, computational simulation setup and results, as well as recommendations for future work that could potentially improve overall performance of the proposed design. Full article

The design and implementation of a multi-stage PID (MS-PID) controller for non-inertial referenced UAVs are highly complex. Symmetrical multirotor UAVs are unstable systems, and it is thought that the kinematics of the symmetrical UAV rotor, such as the quadrotor and hexacopter resembles the kinematics of an inverted pendulum. Several researchers have investigated the structure and design of PID controllers for high-order systems during the last decade. The designs were always concerned with the enhanced response, robustness, model reduction and performance of PID controllers. An accurate tuning process of such a controller depends on the engineer’s experience level. This is due to the number of variables and hyperparameters tuned during the process. An adaptive genetic algorithm (AGA) is utilized to optimize the MS-PID controllers for controlling the quadrotor in this study. The proposed method optimizes the offline-planned approach, providing several possibilities for adapting the controllers with various paths and or varying weather conditions. The MS-PID parameters are optimized in parallel, as every PID controller affects the other controller’s behavior and performance. Furthermore, the proposed AGA generates new chromosomes for “new solutions” by randomly developing new solutions close to the previous best values, which will prevent any local minima solution. This study intends to investigate the design and development of a highly tuned robust multi-stage PID controller for a symmetrical multirotor UAV. The work presents a model for a non-referenced inertial frame multirotor UAV (quadcopter). Once the model is defined, a robust multi-stage PID controller for the non-inertial referenced frame symmetrical multirotor UAV is designed, tuned, and tested. A genetic algorithm (GA) will be used to tune the MS-PID controller. Finally, the performance comparison between the proposed and conventional methods is presented. The results show that the proposed method provides stability improvement, better transient response, and power consumption. Full article

This paper presents a motion control scheme for a new concept of omnidirectional aerial vehicle for transportation and manipulation tasks. The considered aerial platform is a novel quadrotor with the capability of providing multi-directional thrust by adding an actuated gimbal mechanism in charge of modifying the orientation of the frame on which the four rotors are mounted. The above mechanical design, differently from other omnidirectional unmanned aerial vehicles (UAVs) with tilted propellers, avoids internal forces and energy dissipation due to non-parallel propellers’ axes. The proposed motion controller is based on a hierarchical two-loop scheme. The external loop computes the force to be applied to the vehicle and the reference values for the additional joints, while the inner loop computes the joint torques and the moment to be applied to the multirotor. In order to make the system robust with respect to the external loads, a compensation of contact forces is introduced by exploiting the estimate provided by a momentum based observer. The stability of the motion control scheme is proven via Lyapunov arguments. Finally, two simulation case studies prove the capability of the omnidirectional UAV platform to track a 6-DoFs trajectory both in free motion and during a task involving grasping and transportation of an unknown object. Full article

A finite element model of an aero-engine dual-rotor system with intermediate bearing supported by six bearings is set up. Three modes of non-concentricity caused by the assembly process are defined, namely parallel non-concentricity, front deflection angle non-concentricity and rear deflection angle non-concentricity. The influence of the non-concentricity on the vibration characteristics of the dual-rotor system is investigated in detail. The results show that the parallel non-concentricity and the front deflection angle non-concentricity have a significant influence on the bending vibration modals of the high-pressure rotor and the low-pressure rotor, but have little influence on the local vibration modals of the rotors. With the increase in the magnitude of the non-concentricity, the natural frequencies of the bending modals decrease continuously, and the mode shapes of bending modals and that of local modals may be interchanged, leading to the emergence of bending modals in advance. Therefore, the key parameters to be controlled in the assembly process are the parallel non-concentricity and the front deflection angle non-concentricity. In order to prevent the bending modal of the dual-rotor system from appearing in advance, it is necessary to control the parallel non-concentricity within 2 mm and the front deflection angle non-concentricity amount within 0.18°. Full article

A vibration excitation system (VES) in a form of an active coupling is proposed, designed and manufactured. The system is equipped with a set of piezoelectric stack actuators uniformly distributed around the rotor axis and positioned parallel to each other. The actuator arrangement allows an axial displacement of the coupling halves as well as their rotation about any transverse axis. Through the application of the VES an aimed vibration excitation is realised in a co-rotating coordinate system, which enables a non-invasive and precise modal analysis of rotating components. As an example, the VES is applied for the characterisation of the structural dynamic behaviour of a generic steel rotor at different rotational speeds. The first results are promising for both stationary and rotating conditions. Full article
