Search Results (35)

This study examined the effect of build orientation on the surface finish of micro-optofludic (MoF) devices fabricated via a polydimethylsiloxane (PDMS)-based 3D-printing primary–secondary fabrication protocol, where an inkjet 3D-printing technique was implemented. The molds (i.e., primaries) for fabricating the MoF devices were 3D-printed in two orientations: along $XY$ (Dev-1) and across $YX$ (Dev-2) the printhead direction. Next, the surface finish was characterized using a profilometer to acquire the primary profile of the surface along the microchannel’s edge. The results indicated that the build orientation had a strong influence on the latter, since Dev-1 displayed a tall and narrow Gaussian distribution for a channel width of 398.43 ± 0.29 µm; Dev-2 presented a slightly lower value of 393.74 ± 1.67 µm, characterized by a flat and broader distribution, highlighting greater variability due to more disruptive, orthogonally oriented, and striated patterns. These results were also confirmed by hydrodynamically testing the two MoF devices with an air–water slug flow process. A large experimental study was conducted by analyzing the mean period trend in the slug flow with respect to the imposed flow rate and build orientation. Dev-1 showed greater sensitivity to flow rate changes, attributed to its smoother, more consistent microchannel geometry. The slightly narrower average channel width in Dev-2 contributed to increased flow velocity at the expense of having worse discrimination capability at different flow rates. This study is relevant for optimizing 3D-printing strategies for the fabrication of high-performance microfluidic devices, where precise flow control is essential for applications in biomedical engineering, chemical processing, and lab-on-a-chip systems. These findings highlight the effect of microchannel morphology in tuning a system’s sensitivity to flow rate modulation. Full article

In this study, we present a comprehensive numerical investigation of alternating-current electrothermal (ACET) pumping strategies tailored for energy-efficient microfluidic applications. Using coupled electrokinetic and thermal multiphysics simulations in narrow microchannels, we systematically explore the effects of channel geometry, electrode asymmetry and external heating on flow performance and thermal management. A rigorous mesh convergence study confirms velocity deviations below ±0.006 µm/s across the entire operating envelope, ensuring reliable prediction of ACET-driven flows. We demonstrate that increasing channel height from 100 µm to 500 µm reduces peak temperatures by up to 79 K at a constant 2 W heat input, highlighting the critical role of channel dimensions in convective heat dissipation. Introducing a localized external heat source beneath asymmetric electrode pairs enhances convective circulations, while doubling the fluid’s electrical conductivity yields a ~29% increase in net flow rate. From these results, we derive practical design guidelines—combining asymmetric electrode layouts, tailored channel heights, and external heat bias—to realize self-regulating, low-power microfluidic pumps. Such devices hold significant promises for on-chip semiconductor cooling, lab-on-a-chip assays and real-time thermal control in high-performance microelectronic and analytical systems. Full article

Microreactors have the advantages of high heat and mass transfer efficiency, strict control of reaction parameters, easy amplification, and good safety performance, and have been widely used in various fields such as chip manufacturing, fine chemicals, and biomanufacturing. However, narrow microchannels in microreactors often become filled with catalyst particles, leading to blockages. To address this challenge, this study proposes a multiphase flow heat transfer model based on the lattice Boltzmann method (LBM) to investigate the dynamic changes during the bubble collapse process and temperature distribution regularities. Based on the developed three-phase flow dynamics model, this study delves into the shock dynamic evolution process of bubble collapse and analyzes the temperature distribution regularities. Then, the flow patterns under different particle density conditions are explored. The study found that under the action of shock wave, the stable structure of the liquid film of the bubble is destroyed, and the bubble deforms and collapses. At the moment of bubble collapse, energy is rapidly transferred from the potential energy of the bubble to the kinetic energy of the flow field. Subsequently, the kinetic energy is converted into pressure waves. This results in the rapid generation of extremely high pressure in the flow field, creating high-velocity jets and intense turbulent vortices, which can enhance the mass transfer effects of the multiphase flows. At the moment of bubble collapse, a certain high temperature phenomenon will be formed at the collapse, and the high temperature phenomenon in this region is relatively chaotic and random. The pressure waves generated during bubble collapse have a significant impact on the motion trajectories of particles, while the influence on high-density particles is relatively small. The results offer a theoretical basis for understanding mass transfer mechanisms and particle flow patterns in three-phase flow. Moreover, these findings have significant practical implications for advancing technologies in industrial applications, including chip manufacturing and chemical process transport. Full article

For the optimization of ventricular assist devices (VADs), flow simulations are crucial. Typically, these simulations assume single-phase flow to represent blood flow. However, blood consists of plasma and blood cells, making it a multiphase flow. Cell migration in such flows leads to a heterogeneous cell distribution, significantly impacting flow dynamics, especially in narrow gaps of less than 300 $\mathsf{\mu }$m found in VADs. In these areas, cells migrate away from the walls, forming a cell-free layer, a phenomenon not usually considered in current VAD simulations. This paper addresses this gap by introducing a viscosity model that accounts for cell migration in microchannels under VAD-relevant conditions. The model is based on local particle distributions measured in a microchannels with a blood analog fluid. We developed a local viscosity distribution for flows with particles/cells and a cell-free layer, applicable to both blood and analog fluids, with particle volume fractions of up to 5%, gap heights of 150 $\mathsf{\mu }$m, and Reynolds numbers around 100. The model was validated by comparing simulation results with experimental data of blood and blood analog fluid flow on wall shear stresses and pressure losses, showing strong agreement. This model improves the accuracy of simulations by considering local viscosity changes rather than assuming a single-phase fluid. Future developments will extend the model to physiological volume fractions up to 40%. Full article

The fractionation in microchannels is a promising approach for the delivery of microparticles in narrow property distributions. The underlying mechanisms of the channels are however often not completely understood and are therefore subject to current research. These investigations are done using different numerical and experimental methods. In this work, we present and evaluate our method of combining a numerical Discrete Element Method (DEM)-Lattice Boltzmann Method (LBM) approach with experimental long-exposure fluorescence microscopy, micro-Particle Image Velocimetry (µPIV) and Astigmatism Particle Tracking Velocimetry (APTV) measurements. The suitability of the single approaches and their synergies are evaluated using the exemplary investigation of multidimensional fractionation in different channel geometries. It shows that both, numerical and experimental method are well suited to evaluate particle dynamics in microchannels. As they furthermore show strengths canceling out weaknesses of the respective other method, the combined method is very well suited for the comprehensive analysis of particle dynamics in microchannels. Full article

Introduction: The aim of this paper is to propose a sequential deployment technique for the E-nside off-the-shelf endograft that could potentially enhance target visceral vessel (TVV) cannulation and overstenting in narrow aortic anatomies. Methods: All data regarding patients consecutively treated in two aortic centers with the E-nside graft employing the partial deployment technique were included in the study cohort and analyzed. To execute the procedure with partial endograft deployment, the device should be prepared before insertion by advancing, under fluoroscopy, all four dedicated 400 cm long 0.018″ non-hydrophilic guidewires until their proximal ends reach the cranial graft’s edge. Anticipating this guidewire placement prevents the inability to do so once the endograft is partially released, avoiding potentially increased friction inside the constricted pre-loaded microchannels. The endograft is then advanced and deployed in the standard fashion, stopping just after the inner branch outlets are fully expanded. Tip capture is released, and the proximal end of the device is opened. Visceral vessel bridging is completed from an upper access in the desired sequence, and the graft is fully released after revascularizing one or more arteries. Preventing the distal edge of the graft from fully expanding improves visceral vessel cannulation and bridging component advancement, especially when dealing with restricted lumina. Results: A total of 26 patients were treated during the period December 2019–March 2024 with the described approach. Procedure was performed in urgent settings in 14/26 cases. The available lumen was narrower than 24 mm at the origin of at least one target vessel in 11 out of 26 cases performed (42.3%). Technical success was obtained in 24 out of 26 cases (92.3%), with failures being due to TVVs loss. No intraoperative death or surgical conversion was recorded, and no early reintervention was needed in the perioperative period. Clinical success at 30 days was therefore 80.7%. Conclusions: The described technique could be considered effective in saving space outside of the graft, allowing for safe navigation and target vessel cannulation in narrow visceral aortas, similar to what has already been reported for outer-branched endografts. Full article

In the pursuit of enhancing thermal management for miniaturized electronic devices, our study delves into the impact of entry effects on Ledinegg instability and flow maldistribution within parallel microchannels. Utilizing a coupled model that incorporates phase change and pressure drop dynamics in boiling flow, we examine microchannels characterized by a 50 length-to-diameter ratio and a 200 μm hydraulic diameter. Our findings unveil a significant influence of entry effects, which narrow the total flow excursion interval, thereby bolstering system stability. Specifically, as the heat flux escalates from 5 W/cm² to 120 W/cm², the entry effects increasingly mitigate flow instability and maldistribution in parallel channels, diminishing the total flow rate range susceptible to flow instability by 4.73% and 47.52%, while narrowing the total flow rate range corresponding to uneven flow distribution by 4.70% and 46.75%, respectively. Furthermore, entry effects expand the inlet subcooling range necessary for stabilizing the parallel channel system by 38.89% and 1000%. This research not only underscores the importance of considering entry effects in microchannel design but also opens avenues for further exploration into enhancing thermal management solutions. Full article

As an essential component of chip laboratories and microfluidic systems, micromixers are widely used in fields such as chemical and biological analysis. In this work, a square cavity micromixer with multiple structural parameters (baffles, obstacles, and gaps) has been proposed to further improve the mixing performance of micromixers. This study examines the comprehensive effects of various structural parameters on mixing performance. The impact of baffle length, obstacle length-to-width ratio, gap width, and obstacle shape on the mixing index and pressure drop were numerically studied at different Reynolds numbers (Re). The results show that the mixing index increases with baffle length and obstacle length-to-width ratio and decreases with gap width at Re = 0.1, 1, 10, 20, 40, and 60. The mixing index can reach more than 0.98 in the range of Re ≥ 20 when the baffle length is 150 μm, the obstacle length-to-width ratio is 600/100, and the gap width is 200 μm. The pressure drop of the microchannel is proportional to baffle length and obstacle length-to-width ratio. Combining baffles and obstacles can further improve the mixing performance of square cavity micromixers. A longer baffle length, larger obstacle length-to-width ratio, narrower gap width, and a more symmetrical structure are conducive to improving the mixing index. However, the impact of pressure drop must also be considered comprehensively. The research results provide references and new ideas for passive micromixer structural design. Full article

Ion current rectification (ICR) is the ratio of ion current by forward bias to backward bias and is a critical indicator of diode performance. In previous studies, there have been many attempts to improve the performance of this ICR, but there is the intrinsic problem for geometric changes that induce ionic rectification due to fabrication problems. Additionally, the high ICR could be achieved in the narrow salt concentration range only. Here, we propose a multi-layered bipolar ionic diode based on an asymmetric nanochannel network membrane (NCNM), which is realized by soft lithography and self-assembly of homogenous-sized nanoparticles. Owing to the freely changeable geometry based on soft lithography, the ICR performance can be explored according to the variation of microchannel shape. The presented diode with multi-layered configuration shows strong ICR performance, and in a broad range of salt concentrations (0.1 mM~100 mM), steady ICR performance. It is interesting to note that when each anion-selective (AS) and cation-selective (CS) NCNM volume was similar to each optimized volume in a single-layered device, the maximum ICR was obtained. Multi-physics simulation, which reveals greater ionic concentration at the bipolar diode junction under forward bias and less depletion under backward in comparison to the single-layer scenario, supports this tendency as well. Additionally, under different frequencies and salt concentrations, a large-area hysteresis loop emerges, which indicates fascinating potential for electroosmotic pumps, memristors, biosensors, etc. Full article

The synthesis of nanoparticles in microchannels promises the advantages of small size, uniform shape and narrow size distribution. However, only with insights into the mixing processes can the most suitable designs and operating conditions be systematically determined. Coaxial lamination mixers (CLM) built by 2-photon polymerization can operate long-term stable nanoparticle precipitation without fouling issues. Contact of the organic phase with the microchannel walls is prevented while mixing with the aqueous phase is intensified. A coaxial nozzle allows 3D hydrodynamic focusing followed by a sequence of stretch-and-fold units. By means of a digital twin based on computational fluid dynamics (CFD) and numerical evaluation of mixing progression, the influences of operation conditions are now studied in detail. As a measure for homogenization, the mixing index ($\mathrm{MI}$) was extracted as a function of microchannel position for different operating parameters such as the total flow rate and the share of solvent flow. As an exemplary result, behind a third stretch-and-fold unit, practically perfect mixing ($\mathrm{MI}>0.9)$ is predicted at total flow rates between 50 µL/min and 400 µL/min and up to 20% solvent flow share. Based on $\mathrm{MI}$ values, the mixing time, which is decisive for the size and dispersity of the nanoparticles, can be determined. Under the conditions considered, it ranges from 5 ms to 54 ms. A good correlation between the predicted mixing time and nanoparticle properties, as experimentally observed in earlier work, could be confirmed. The digital twin combining CFD with the $\mathrm{MI}$ methodology can in the future be used to adjust the design of a CLM or other micromixers to the desired total flow rates and flow rate ratios and to provide valuable predictions for the mixing time and even the properties of nanoparticles produced by microfluidic antisolvent precipitation. Full article

Droplets generated in microfluidic channels are effective self-contained micromixers and micro-reactors for use in a multiplicity of chemical synthesis and bioanalytical applications. Droplet microfluidic systems have the ability to generate multitudes of droplets with well-defined reagent volumes and narrow size distributions, providing a means for the replication of mixing within each droplet and thus the scaling of processes. Numerical modelling using computational fluid dynamics (CFD) is a useful technique for analysing and understanding the internal mixing in microfluidic droplets. We present and demonstrate a CFD method for modelling and simulating mixing between two species within a droplet travelling in straight microchannel, using a two-phase moving frame of reference approach. Finite element and level set methods were utilised to solve the equations governing the coupled physics between two-phase flow and mass transport of the chemical species. This approach had not been previously demonstrated for the problem of mixing in droplet microfluidics and requires less computational resources compared to the conventional fixed frame of reference approach. The key conclusions of this work are: (1) a limitation of this method exists for flow conditions where the droplet mobility approaches unity, due to the moving wall boundary condition, which results in an untenable solution under those conditions; (2) the efficiency of the mixing declines as the length of the droplet or plug increases; (3) the initial orientation of the droplet influences the mixing and the transverse orientation provides better mixing performance than the axial orientation and; (4) the recirculation inside the droplet depends on the superficial velocity and the viscosity ratio. Full article

Laser-induced plasma micromachining (LIPMM) can be used to fabricate high-quality microstructures of hard and brittle materials. The liquid medium of the LIPMM process plays a key role in inducing the plasma and cooling the materials, but the liquid medium is overheated which induces lots of bubbles to defocus the laser beam and reduce machining stability. In this paper, a comparative investigation on bubble behavior and its effect on the surface integrity of microchannels in three types of liquids and at different depths during LIPMM has been presented. Firstly, the formation mechanism of microbubbles was described. Secondly, a series of experiments were conducted to study the number and maximum diameter of the attached bubbles and the buoyancy movement of floating bubbles in the LIPMM of single-crystal silicon under deionized water, absolute ethyl alcohol, and 5.6 mol/L phosphoric acid solution with a liquid layer depth of 1–5 mm. It was revealed that the number and maximum diameter of attached bubbles in deionized water were the highest due to its high tension. Different from the continuous rising of bubbles at the tail of the microchannels in the other two liquids, microbubbles in 5.6 mol/L phosphoric acid solution with high viscosity rose intermittently, which formed a large area of bubble barrier to seriously affect the laser focus, resulting in a discontinuous microchannel with an unablated segment of 26.31 $\mathsf{\mu }$m. When the depth of the liquid layer was 4 mm, absolute ethyl alcohol showed the advantages in narrow width (27.15 $\mathsf{\mu }$m), large depth (16.5 $\mathsf{\mu }$m), and uniform depth profile of the microchannel by LIPMM. This was because microbubbles in the anhydrous ethanol quickly and explosively spread towards the edge of the laser processing zone to reduce the bubble interference. This research contributes to a better understanding of the behavior and influence of bubbles in different liquid media and depths in LIPMM of single-crystal silicon. Full article

Investigating floating cells along a narrow microchannel (e.g., a blood vessel) for their transiting speeds and the corresponding roles of cell physical properties can deepen our understanding of circulating tumor cells (CTCs) metastasis via blood vessels. Many existing studies focus on the cell transiting process in blood vessel-like microchannels; further analytical studies are desired to summarize behaviors of the floating cell movement under different conditions. In this work, we perform a theoretical analysis to establish a relation between the transiting speed and key cell physical properties. We also conduct computational fluid dynamics simulation and microfluidic experiments to verify the theoretical model. This work reveals key cell physical properties and the channel configurations determining the transiting speed. The reported model can be applied to other works with various dimensions of microchannels as a more general way to evaluate the cancer cell metastasis ability with microfluidics. Full article

Liquid–liquid slug flow in a microcapillary, with its improved heat and mass transfer properties and narrow residence time, plays a vital role in process intensification. Knowledge of the flow properties in microchannels along variables’ controllability (e.g., phase ratio, slug length along with classical variables, such as pressure, temperature, and flow velocity) during operation is crucial. This work aids in this by using magnetofluidics to manipulate these parameters. A ferrofluid with reproducible properties is produced and, together with another phase, stable slug flow is generated. Micro-gear pumps and syringe pumps, with their traditional mechanical components, result in parts degrading over time due to fatigue caused by pressure differentials and corrosive chemicals. The microflow is also disturbed by the invasive nature of these pumps. A considerably energy-efficient, non-invasive alternative, with reduced mechanical interfacing is suggested in this work. It uses magnetic gradients to manipulate two-phase flow, one of which is a magnetically active phase. Conveying concepts using permanent magnets in the immediate vicinity of the flow are investigated. To operate this pump continuously and to be able to regulate the phase ratio, an electromagnetic non-invasive valve is developed. Phase separation is also carried out with an existing decanter design, modified using electromagnetism to work without a selective membrane, usually necessary for phase separation at this scale. This pump is then compared with similar pumps developed in the past. Full article

The paper presents the results of experimental research on pool boiling heat transfer of dielectric liquid FC-72. Measurements were made at atmospheric pressure on open surfaces with microchannels. Heat transfer surfaces, in the form of parallel milled microchannels, were made of copper. The rectangular cross-sectional microchannels were 0.2 to 0.5 mm deep and 0.2 to 0.4 mm wide. The surfaces, compared to a smooth flat surface, provided a five-fold increase in the heat transfer coefficient and a two-fold increase in the critical heat flux. The article analyses the influence of the width and height of the microchannel on the heat transfer process. The maximum heat flux was 271.7 kW/m², and the highest heat transfer coefficient obtained was 25 kW/m²K. Furthermore, the experimental results were compared with selected correlations for the nucleate pool boiling. Full article
