Many commercial wearable sensor systems typically rely on a single continuous cardiorespiratory sensing modality, photoplethysmography (PPG), which suffers from inherent biases (i.e., differences in skin tone) and noise (e.g., motion and pressure artifacts). In this research, we present a wearable device that provides robust estimates of cardiorespiratory variables by combining three physiological signals from the upper arm: multiwavelength PPG, single-sided electrocardiography (SS-ECG), and bioimpedance plethysmography (BioZ), along with an inertial measurement unit (IMU) providing 3-axis accelerometry and gyroscope information. We evaluated the multimodal device on 16 subjects by its ability to estimate heart rate (HR) and breathing rate (BR) in the presence of various static and dynamic noise sources (e.g., skin tone and motion). We proposed a hierarchical approach that considers the subject’s skin tone and signal quality to select the optimal sensing modality for estimating HR and BR. Our results indicate that, when estimating HR, there is a trade-off between accuracy and robustness, with SS-ECG providing the highest accuracy (low mean absolute error; MAE) but low reliability (higher rates of sensor failure), and PPG/BioZ having lower accuracy but higher reliability. When estimating BR, we find that fusing estimates from multiple modalities via ensemble bagged tree regression outperforms single-modality estimates. These results indicate that multimodal approaches to cardiorespiratory monitoring can overcome the accuracy–robustness trade-off that occurs when using single-modality approaches. Full article

The rate of oxygen consumption, which is measured as the volume of oxygen consumed per mass per minute (VO₂) mL/kg/min, is a critical metric for evaluating cardiovascular health, metabolic status, and respiratory function. Specifically, VO₂ is a powerful prognostic predictor of survival in patients with heart failure (HF) because it provides an indirect assessment of a patient’s ability to increase cardiac output (CO). In addition, VO₂ measurements, particularly VO₂ max, are significant because they provide a reliable indicator of your cardiovascular fitness and aerobic endurance. However, traditional VO₂ assessment requires bulky, breath-by-breath gas analysis systems, limiting frequent and continuous monitoring to specialized settings. This study presents a novel wrist-worn multiwavelength photoplethysmography (PPG) device and machine learning algorithm designed to estimate VO₂ continuously. Unlike conventional wearables that rely on static formulas for VO₂ max estimation, our algorithm leverages the data from the PPG wearable and uses the Beer–Lambert Law with inputs from five wavelengths (670 nm, 770 nm, 810 nm, 850 nm, and 950 nm), incorporating the isosbestic point at 810 nm to differentiate oxy- and deoxy-hemoglobin. A validation study was conducted with eight subjects using a modified Bruce protocol, comparing the PPG-based estimates to the gold-standard Parvo Medics gas analysis system. The results demonstrated a mean absolute error of 1.66 mL/kg/min and an R² of 0.94. By providing precise, individualized VO₂ estimates using direct tissue oxygenation data, this wearable solution offers significant clinical and practical advantages over traditional methods, making continuous and accurate cardiovascular assessment readily available beyond clinical environments. Full article

Photoplethysmography (PPG) is a non-invasive method used for cardiovascular monitoring, with multi-wavelength PPG (MW-PPG) enhancing its efficacy by using multiple wavelengths for improved assessment. This study explores how contact force (CF) variations impact MW-PPG signals. Data from 11 healthy subjects are analyzed to investigate the still understudied specific effects of CF on PPG signals. The obtained dataset includes simultaneous recording of five PPG wavelengths (470, 525, 590, 631, and 940 nm), CF, skin temperature, and the tonometric measurement derived from CF. The evolution of raw signals and the PPG DC and AC components are analyzed in relation to the increasing and decreasing faces of the CF. Findings reveal individual variability in signal responses related to skin and vasculature properties and demonstrate hysteresis and wavelength-dependent responses to CF changes. Notably, all wavelengths except 631 nm showed that the DC component of PPG signals correlates with CF trends, suggesting the potential use of this component as an indirect CF indicator. However, further validation is needed for practical application. The study underscores the importance of biomechanical properties at the measurement site and inter-individual variability and proposes the arterial pressure wave as a key factor in PPG signal formation. Full article

The measurement of hemoglobin is a vital index for diagnosing and monitoring diseases in clinical practice. At present, solutions need to be found for the soreness, high risk of infection, and inconvenient operation associated with invasive detection methods. This paper proposes a method for non-invasively detecting hemoglobin levels based on multi-wavelength photoplethysmography (PPG) signals. AFE4490 and TMUX1109 were used to implement the low-cost collection of an eight-LED transmissive PPG signal. We used seven regular LEDs and one broadband LED (Osram SFH4737) as light sources. Additionally, a finger clip integrating multiple sensors was designed and manufactured via 3D printing to simultaneously monitor the LED–sensor distance and the pressure from the tester’s finger during PPG signal acquisition. We used a method to extract features from PPG signals using a sliding-window’s variance and an evaluation metric for PPG signals based on the AdaCost classification. Data were gathered from 56 participants from the Nephrology department, including 16 anemic patients. Pearson correlation analysis was conducted on the collected data to remove any data with a weak correlation. The advantage of using a broadband LED as a light source was also demonstrated. Several non-invasive hemoglobin regression models were created by applying AdaBoost, BPNN, and Random Forest models. The study’s results indicate that the AdaBoost model produced the best performance, with a mean absolute error (MAE) of 2.67 g/L and a correlation coefficient (R²) of 0.91 The study results show that the device we designed and manufactured can achieve effective non-invasive hemoglobin detection and represents a new methodological approach to obtaining measurements that can be applied in a clinical setting. Full article

Over the past few years, there has been increased interest in photoplethysmography (PPG) technology, which has revealed that, in addition to heart rate and oxygen saturation, the pulse shape of the PPG signal contains much more valuable information. Lately, the wearable market has shifted towards a multi-wavelength and multichannel approach to increase signal robustness and facilitate the extraction of other intrinsic information from the signal. This transition presents several challenges related to complexity, accuracy, and reliability of algorithms. To address these challenges, anomaly detection stages can be employed to increase the accuracy and reliability of estimated parameters. Powerful algorithms, such as lightweight machine learning (ML) algorithms, can be used for anomaly detection in multi-wavelength PPG (MW-PPG). The main contributions of this paper are (a) proposing a set of features with high information gain for anomaly detection in MW-PPG signals in the classification context, (b) assessing the impact of window size and evaluating various lightweight ML models to achieve highly accurate anomaly detection, and (c) examining the effectiveness of MW-PPG signals in detecting artifacts. Full article

Photoplethysmography (PPG) is widely used to assess cardiovascular health. However, its usage and standardization are limited by the impact of variable contact force and temperature, which influence the accuracy and reliability of the measurements. Although some studies have evaluated the impact of these phenomena on signal amplitude, there is still a lack of knowledge about how these perturbations can distort the signal morphology, especially for multi-wavelength PPG (MW-PPG) measurements. This work presents a modular multi-parametric sensor system that integrates continuous and real-time acquisition of MW-PPG, contact force, and temperature signals. The implemented design solution allows for a comprehensive characterization of the effects of the variations in these phenomena on the contour of the MW-PPG signal. Furthermore, a dynamic DC cancellation circuitry was implemented to improve measurement resolution and obtain high-quality raw multi-parametric data. The accuracy of the MW-PPG signal acquisition was assessed using a synthesized reference PPG optical signal. The performance of the contact force and temperature sensors was evaluated as well. To determine the overall quality of the multi-parametric measurement, an in vivo measurement on the index finger of a volunteer was performed. The results indicate a high precision and accuracy in the measurements, wherein the capacity of the system to obtain high-resolution and low-distortion MW-PPG signals is highlighted. These findings will contribute to developing new signal-processing approaches, advancing the accuracy and robustness of PPG-based systems, and bridging existing gaps in the literature. Full article

Photoplethysmography (PPG) is an affordable and straightforward optical technique used to detect changes in blood volume within tissue microvascular beds. PPG technology has found widespread application in commercial medical devices, enabling measurements of oxygen saturation, blood pressure, and cardiac output; the assessment of autonomic nerve function; and the diagnosis of peripheral vascular disease. Recently, the growing demand for non-invasive, portable, cost-effective technology, along with advancements in small semiconductor components, has led to the integration of PPG into various wrist-worn wearable devices. Multiple sensor structures have been proposed and, through appropriate signal processing and algorithmic application, these wearable devices can measure a range of health indicators during daily life. This paper begins by addressing the market status of wrist-worn wearable devices, followed by an explanation of the fundamental principles underlying light operation and its interaction with living tissue for PPG measurements. Moving on to technological advancements, the paper addresses the analog front end for the measurement of the PPG signal, sensor configurations with multiple light emitters and receivers, the minimum sampling rate required for low-power systems, and the measurement of stress, sleep, blood pressure, blood glucose, and activity using PPG signals. Several challenges in the field are also identified, including selecting the appropriate wavelength for the PPG sensor’s light source, developing low-power interpolation methods to extract high-resolution inter-beat intervals at a low sampling rate, and exploring the measurement of physiological phenomena using multi-wavelength PPG signals simultaneously collected at the same location. Lastly, the paper presents future research directions, which encompass the development of new, reliable parameters specific to wearable PPG devices and conducting studies in real-world scenarios, such as 24-h long-term measurements. Full article

Photoplethysmography (PPG) is used to measure blood volume changes in the microvascular bed of tissue. Information about these changes along time can be used for estimation of various physiological parameters, such as heart rate variability, arterial stiffness, and blood pressure, to name a few. As a result, PPG has become a popular biological modality and is widely used in wearable health devices. However, accurate measurement of various physiological parameters requires good-quality PPG signals. Therefore, various signal quality indexes (SQIs) for PPG signals have been proposed. These metrics have usually been based on statistical, frequency, and/or template analyses. The modulation spectrogram representation, however, captures the second-order periodicities of a signal and has been shown to provide useful quality cues for electrocardiograms and speech signals. In this work, we propose a new PPG quality metric based on properties of the modulation spectrum. The proposed metric is tested using data collected from subjects while they performed various activity tasks contaminating the PPG signals. Experiments on this multi-wavelength PPG dataset show the combination of proposed and benchmark measures significantly outperforming several benchmark SQIs with improvements of 21.3% BACC (balanced accuracy) for green, 21.6% BACC for red, and 19.0% BACC for infrared wavelengths, respectively, for PPG quality detection tasks. The proposed metrics also generalize for cross-wavelength PPG quality detection tasks. Full article

(1) Background: Traumatic brain injuries (TBI) result in high fatality and lifelong disability rates. Two of the primary biomarkers in assessing TBI are intracranial pressure (ICP) and brain oxygenation. Both are assessed using standalone techniques, out of which ICP can only be assessed utilizing invasive techniques. The motivation of this research is the development of a non-invasive optical multimodal monitoring technology for ICP and brain oxygenation which will enable the effective management of TBI patients. (2) Methods: a multiwavelength optical sensor was designed and manufactured so as to assess both parameters based on the pulsatile and non-pulsatile signals detected from cerebral backscatter light. The probe consists of four LEDs and three photodetectors that measure photoplethysmography (PPG) and near-infrared spectroscopy (NIRS) signals from cerebral tissue. (3) Results: The instrumentation system designed to acquire these optical signals is described in detail along with a rigorous technical evaluation of both the sensor and instrumentation. Bench testing demonstrated the right performance of the electronic circuits while a signal quality assessment showed good indices across all wavelengths, with the signals from the distal photodetector being of highest quality. The system performed well within specifications and recorded good-quality pulsations from a head phantom and provided non-pulsatile signals as expected. (4) Conclusions: This development paves the way for a multimodal non-invasive tool for the effective assessment of TBI patients. Full article

The grown interest in healthcare applications has made biomedical engineering one of the fastest growing disciplines in recent years. Photoplethysmography (PPG) has gained popularity in recent years due to its versatility for noninvasive monitoring of vital signs such as heart rate, respiratory rate, blood oxygen saturation and blood pressure. In this work, an adjustable PPG-based educational device called PPG EduKit, which aims to facilitate the learning of the PPG technology for a wide range of engineering and medical disciplines is proposed. Through the use of this educational platform, the PPG signal can be understood, modified and implemented along with the extraction of its relevant physiological information from a didactic, intuitive and practical way. The PPG Edukit is evaluated for the extraction of physiological parameters such as heart rate and blood oxygen level, demonstrating how its features contribute to engineering and medical students to assimilate technical concepts in electrical circuits, biomedical instrumentation, and human physiology. Full article

Photoplethysmography (PPG), a noninvasive optical sensing technology, has been widely used to measure various physiological indices. Over-the-counter PPG devices are typically composed of a single-wavelength light source, namely, single-wavelength PPG (SW-PPG). It is known that signals of SW-PPG are easily contaminated or distorted by measurement conditions such as motion artifacts, wearing pressure, and skin type. Since lights of different wavelengths can penetrate skin tissues at different depths, how to effectively construct a multiwavelength PPG (MW-PPG) device or even an all-wavelength PPG (AW-PPG) device has attracted great attention. There is also a very interesting question, that is, what could be the potential benefits of using MW-PPG or AW-PPG devices? This paper demonstrates the construction of an AW-PPG portable device and conducts a preliminary evaluation. The presented device consists of four light-emitting diodes, a chip-scale spectrometer, a microcontroller, a Bluetooth Low Energy transceiver, and a phone app. The maximum ratio combining algorithm (MRC) is used to combine the PPG signals derived from different wavelengths to achieve a better signal-to-noise ratio (S/N). The PPG signals from the developed MRC-AW-PPG device versus those from the conventional SW-PPG device are compared in terms of different hydrostatic pressure conditions. It has been observed that the MRC-AW-PPG device can provide more stable PPG signals than that of a conventional PPG device. The results shine a light on the potential benefits of using multiple wavelengths for the next generation of noninvasive PPG sensing. Full article

Many camera-based remote photoplethysmography (PPG) applications require sensing in near infrared (NIR). The performance of PPG systems benefits from multi-wavelength processing. The illumination source in such system is explored in this paper. We demonstrate that multiple narrow-band LEDs have inferior color homogeneity compared to broadband light sources. Therefore, we consider the broadband option based on phosphor material excited by LEDs. A first prototype was realized and its details are discussed. It was tested within a remote-PPG monitoring scenario in darkness and the full system demonstrates robust pulse-rate measurement. Given its accuracy in pulse rate extraction, the proposed illumination principle is considered a valuable asset for large-scale NIR-PPG applications as it enables multi-wavelength processing, lightweight set-ups with relatively low-power infrared light sources. Full article

Photoplethysmography (PPG) is an easy and convenient method by which to measure heart rate (HR). However, PPG signals that optically measure volumetric changes in blood are not robust to motion artifacts. In this paper, we develop a PPG measuring system based on multi-channel sensors with multiple wavelengths and propose a motion artifact reduction algorithm using independent component analysis (ICA). We also propose a truncated singular value decomposition for 12-channel PPG signals, which contain direction and depth information measured using the developed multi-channel PPG measurement system. The performance of the proposed method is evaluated against the R-peaks of an electrocardiogram in terms of sensitivity (Se), positive predictive value (PPV), and failed detection rate (FDR). The experimental results show that Se, PPV, and FDR were 99%, 99.55%, and 0.45% for walking, 96.28%, 99.24%, and 0.77% for fast walking, and 82.49%, 99.83%, and 0.17% for running, respectively. The evaluation shows that the proposed method is effective in reducing errors in HR estimation from PPG signals with motion artifacts in intensive motion situations such as fast walking and running. Full article

The multi-wavelength photoplethysmography sensors were introduced to measure depth-dependent blood volume based on that concept that the longer the light wavelength, the deeper the penetration depth near visible spectrum band. In this study, we propose an omnidirectional optical sensor module that can measure photoplethysmogram while using multiple wavelengths, and describe implementation detail. The developed sensor is manufactured by making a hole in a metal plate and mounting an LED therein, and it has four wavelength LEDs of blue (460 nm), green (530 nm), red (660 nm), and IR (940 nm), being arranged concentrically around a photodetector. Irradiation light intensity was measured by photoluminescent test, and photoplethymogram was measured with each wavelength simultaneously at a periphery of the human body such as fingertip, earlobe, toe, forehead, and wrist, in order to evaluate the developed sensor. As a result, the developed sensor module showed a linear increase of irradiating light intensity according to the number of LEDs increases, and pulsatile waveforms were observed at all four wavelengths in all measuring sites. Full article

Multi-wavelength photoplethysmography (MW-PPG) sensing technology has been known to be superior to signal-wavelength photoplethysmography (SW-PPG) sensing technology. However, limited by the availability of sensing detectors, many prior studies can only use conventional bulky and pricy spectrometers as the detectors, and hence cannot bring the MW-PPG technology to daily-life applications. In this study we developed a chip-scale MW-PPG sensor using innovative on-chip spectrometers, aimed at wearable applications. Also in this paper we present signal processing methods for robustly extracting the PPG signals, in which an increase of up to 50% in the signal-to-noise ratio (S/N) was observed. Example measurements of saturation of peripheral blood oxygen (SpO₂) and blood pressure were conducted. Full article
