Search Results (15)

Search Parameters:
Keywords = multistage hydraulic fracture stimulation

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
35 pages, 15351 KiB
Article
Production Simulation of Stimulated Reservoir Volume in Gas Hydrate Formation with Three-Dimensional Embedded Discrete Fracture Model
by Jianchun Xu, Yan Liu and Wei Sun
Sustainability 2024, 16(22), 9803; https://doi.org/10.3390/su16229803 - 10 Nov 2024
Cited by 1 | Viewed by 1435
Abstract
Natural gas hydrates (NGHs) in the Shenhu area of the South China Sea are deposited in low-permeability clayey silt sediments. As a renewable energy source with such a low carbon emission, the exploitation and recovery rate of NGH make it difficult to meet [...] Read more.
Natural gas hydrates (NGHs) in the Shenhu area of the South China Sea are deposited in low-permeability clayey silt sediments. As a renewable energy source with such a low carbon emission, the exploitation and recovery rate of NGH make it difficult to meet industrial requirements using existing development strategies. Research into an economically rewarding method of gas hydrate development is important for sustainable energy development. Hydraulic fracturing is an effective stimulation technique to improve the fluid conductivity. In this paper, an efficient three-dimensional embedded discrete fracture model is developed to investigate the production simulation of hydraulically fractured gas hydrate reservoirs considering the stimulated reservoir volume (SRV). The proposed model is applied to a hydraulically fractured production evaluation of vertical wells, horizontal wells, and complex structural wells. To verify the feasibility of the method, three test cases are established for different well types as well as different fractures. The effects of fracture position, fracture conductivity, fracture half-length, and stimulated reservoir volume size on gas production are presented. The results show that the production enhancement in multi-stage fractured horizontal wells is obvious compared to that of vertical wells, while spiral multilateral wells are less sensitive to fractures due to the distribution of wellbore branches and perforation points. Appropriate stimulated reservoir volume size can obtain high gas production and production efficiency. Full article
(This article belongs to the Special Issue Advanced Research on Marine and Deep Oil & Gas Development)
Show Figures

Figure 1

16 pages, 8739 KiB
Article
Experimental Investigation of Low-Frequency Distributed Acoustic Sensor Responses to Two Parallel Propagating Fractures
by Teresa Reid, Gongsheng Li, Ding Zhu and A. Daniel Hill
Sensors 2024, 24(12), 3880; https://doi.org/10.3390/s24123880 - 15 Jun 2024
Cited by 2 | Viewed by 1598
Abstract
Low-frequency distributed acoustic sensing (LF-DAS) is a diagnostic tool for hydraulic fracture propagation with far-field monitoring using fiber optic sensors. LF-DAS senses strain rate variation caused by stress field change due to fracture propagation. Fiber optic sensors are installed in the monitoring wells [...] Read more.
Low-frequency distributed acoustic sensing (LF-DAS) is a diagnostic tool for hydraulic fracture propagation with far-field monitoring using fiber optic sensors. LF-DAS senses strain rate variation caused by stress field change due to fracture propagation. Fiber optic sensors are installed in the monitoring wells in the vicinity of a fractured well. From the strain responses, fracture propagation can be evaluated. To understand subsurface conditions with multiple propagating fractures, a laboratory-scale hydraulic fracture experiment was performed simulating the LF-DAS response to fracture propagation with embedded distributed optical fiber strain sensors under these conditions. The experiment was performed using a transparent cube of epoxy with two parallel radial initial flaws centered in the cube. Fluid was injected into the sample to generate fractures along the initial flaws. The experiment used distributed high-definition fiber optic strain sensors with tight spatial resolutions. The sensors were embedded at two different locations on opposite sides of the initial flaws, serving as observation/monitoring locations. We also employed finite element modeling to numerically solve the linear elastic equations of equilibrium continuity and stress–strain relationships. The measured strains from the experiment were compared to simulation results from the finite element model. The experimentally derived strain and strain-rate waterfall plots from this study show the responses to both fractures propagating, while the fracture at the lower position took most of the fluid during the experiment. Interestingly, a fracture first began propagating from the upper flaw of the two flaws, but once the lower fracture was initiated, it grew much faster than the upper fracture. Both fibers were intercepted by the lower fracture, further verifying the strain signature as a fracture is approaching and intersecting an offset fiber. Full article
Show Figures

Figure 1

18 pages, 7765 KiB
Article
Study on Optimization of Stimulation Technology of Heterogeneous Porous Carbonate Reservoir
by Kangjia Zhao, Hualei Xu, Jie Wang, Houshun Jiang and Liangjun Zhang
Processes 2024, 12(6), 1191; https://doi.org/10.3390/pr12061191 - 10 Jun 2024
Cited by 1 | Viewed by 1088
Abstract
Mishrif (M) reservoir of Faihaa (F) oilfield in Iraq is a heterogeneous porous carbonate reservoir. The reservoir properties of each reservoir unit differ greatly, and the distribution of porosity and permeability is non-uniform. Some reservoir units have the problem that the expected production [...] Read more.
Mishrif (M) reservoir of Faihaa (F) oilfield in Iraq is a heterogeneous porous carbonate reservoir. The reservoir properties of each reservoir unit differ greatly, and the distribution of porosity and permeability is non-uniform. Some reservoir units have the problem that the expected production cannot be achieved or the production decline rate is too fast after matrix acidification. This work optimized and compared the process of acid fracturing and hydraulic fracturing techniques. The Mishrif B (MB) and Mishrif C (MC) layers are selected as the target units for fracturing and the perforation intervals are optimized. The acid fracturing process adopted the acid fracturing technology of guar gum pad fluid and gelled acid multi-stage injection. According to the wellhead pressure limit and fracture propagation geometry, the pumping rate is optimized. The recommended maximum pumping rate of acid fracturing is 5.0 m3/min, and the optimized acid volume is 256.4 m3. The pressure changes during hydraulic fracturing and acid fracturing are different. It is recommended that the maximum hydraulic fracturing pump rate is 4.5 m3/min for MB and MC layers, and the amount of proppant in MB and MC layers is 37.5 m3 and 43.7 m3, respectively. The production prediction of two optimized processes is carried out. The results showed that the effect of acid fracturing in MB and MC layers is better than hydraulic fracturing, and it is recommended to adopt acid fracturing technology to stimulate MB and MC layers. Acid fracturing operation is carried out in the X-13 well, and better application results are achieved. The results of this study provide optimized reference ideas for reservoir stimulation in heterogeneous porous reservoirs. Full article
(This article belongs to the Special Issue Recent Advances in Hydrocarbon Production Processes from Geoenergy)
Show Figures

Figure 1

21 pages, 5491 KiB
Article
Multi-Fracture Propagation Considering Perforation Erosion with Respect to Multi-Stage Fracturing in Shale Reservoirs
by Lin Tan, Lingzhi Xie, Bo He and Yao Zhang
Energies 2024, 17(4), 828; https://doi.org/10.3390/en17040828 - 9 Feb 2024
Cited by 3 | Viewed by 1382
Abstract
Shale gas is considered a crucial global energy source. Hydraulic fracturing with multiple fractures in horizontal wells has been a crucial method for stimulating shale gas. During multi-stage fracturing, the fracture propagation is non-uniform, and fractures cannot be induced in some clusters due [...] Read more.
Shale gas is considered a crucial global energy source. Hydraulic fracturing with multiple fractures in horizontal wells has been a crucial method for stimulating shale gas. During multi-stage fracturing, the fracture propagation is non-uniform, and fractures cannot be induced in some clusters due to the influence of stress shadow. To improve the multi-fracture propagation performance, technologies such as limited-entry fracturing are employed. However, perforation erosion limits the effect of the application of these technologies. In this paper, a two-dimensional numerical model that considers perforation erosion is established based on the finite element method. Then, the multi-fracture propagation, taking into account the impact of perforation erosion, is studied under different parameters. The results suggest that perforation erosion leads to a reduction in the perforation friction and exacerbates the uneven propagation of the fractures. The effects of erosion on multi-fracture propagation are heightened with a small perforation diameter and perforation number. However, reducing the perforation number and perforation diameter remains an effective method for promoting uniform fracture propagation. As the cluster spacing is increased, the effects of erosion on multi-fracture propagation are aggravated because of the weakened stress shadow effect. Furthermore, for a given volume of fracturing fluid, although a higher injection rate is associated with a shorter injection time, the effects of erosion on the multi-fracture propagation are more severe at a high injection rate. Full article
Show Figures

Figure 1

12 pages, 2075 KiB
Article
Lab Experiments for Abrasive Waterjet Perforation and Fracturing in Offshore Unconsolidated Sandstones
by Yigang Liu, Peng Xu, Liping Zhang, Jian Zou, Xitang Lan and Mao Sheng
Processes 2023, 11(11), 3137; https://doi.org/10.3390/pr11113137 - 2 Nov 2023
Cited by 3 | Viewed by 1945
Abstract
Multistage hydraulic fracturing has been proven to be an effective stimulation method to extract more oil from the depleted unconsolidated sandstone reservoirs in Bohai Bay, China. The offshore wellbores in this area were completed with a gravel pack screen that is much too [...] Read more.
Multistage hydraulic fracturing has been proven to be an effective stimulation method to extract more oil from the depleted unconsolidated sandstone reservoirs in Bohai Bay, China. The offshore wellbores in this area were completed with a gravel pack screen that is much too difficult to be mechanically isolated in several stages. Hydra-jet fracturing technology has the advantages of multistage fracturing by one trip, waterjet perforation, and hydraulic isolation. The challenges of hydraulic-jet fracturing in offshore unconsolidated sandstone reservoir can be summarized as follows: the long jet distance, high filtration loss, and large pumping rate. This paper proposes full-scale experiments on the waterjet perforation of unconsolidated sandstone, waterjet penetration of screen liners and casing, and pumping pressure prediction. The results verified that multistage hydra-jet fracturing is a robust technology that can create multiple fractures in offshore unconsolidated sandstone. Lab experiments indicate that the abrasive water jet is capable to perforate the screen-casing in less than one minute with an over 10 mm diameter hole. The water jet perforates a deep and slim hole in unconsolidated sandstone by using less than 20 MPa pumping pressure. Recommended perforating parameters: maintain 7% sand concentration and perforate for 3.0 min. Reduce sand ratio to 5%, maintain 3.0 m3/min flow rate, and continue perforating for 7.0 min. The injection drop of the nozzle accounts for more than 62% of the tubing pump pressure. The recommended nozzle combinations for different fracturing flow rates are 8 × ø6 mm or 6 × ø7 mm for 2.5 m3/min and 3.0 m3/min, and 8 × ø7 mm for 3.5 m3/min and 4.0 m3/min. A one-trip-multistage hydra-jet fracturing process is recommended to be used for horizontal wells in offshore unconsolidated sandstone reservoirs. Full article
Show Figures

Figure 1

10 pages, 3270 KiB
Article
Investigation into the Perforation Optimization in Conglomerate Reservoir Based on a Field Test
by Qinghu Fan, Yonggui Ma, Junping Wang, Liang Chen, Zhiquan Ye, Yajun Xu, Huan Li and Bo Wang
Processes 2023, 11(8), 2446; https://doi.org/10.3390/pr11082446 - 14 Aug 2023
Cited by 1 | Viewed by 1325
Abstract
The Mahu conglomerate reservoir is characterized by strong heterogeneity and the uneven stimulation of the horizontal lateral during hydraulic fracturing. The optimization of the perforation number per cluster is of great value for horizontal well multi-stage fracturing (HWMF) because the suitable perforation number [...] Read more.
The Mahu conglomerate reservoir is characterized by strong heterogeneity and the uneven stimulation of the horizontal lateral during hydraulic fracturing. The optimization of the perforation number per cluster is of great value for horizontal well multi-stage fracturing (HWMF) because the suitable perforation number not only promotes the uniform propagation of multiple fractures but also prevents excessive perforation erosion. In this work, a typical well in the Mahu conglomerate reservoir was selected, and a field test of optimizing the perforation number was carried out. The perforation schemes of three, five, and eight perforations per cluster were designed in nine fracturing stages, respectively. The wellhead pressure under different perforation schemes was compared and analyzed with the step-down flow rate test, and the optimal perforation number per cluster in the Mahu conglomerate reservoir was selected as eight. The theoretical calculation results show that eight perforations per cluster can generate the perforation friction of 5 MPa, sufficient to overcome the mechanical property differences among multiple clusters within one stage. The downhole video technology shows that the perforation erosion area is the most uniform with the case of eight perforations per cluster. Moreover, the optical fiber monitoring results show that the perforation number of eight per cluster can realize the simultaneous initiation and uniform propagation of six fractures or five fractures within one stage. This work is of great significance for the efficient development of the Mahu conglomerate reservoir through HWMF. Full article
(This article belongs to the Special Issue Heavy Oils Conversion Processes (II))
Show Figures

Figure 1

21 pages, 11686 KiB
Article
Productivity Analysis and Evaluation of Fault-Fracture Zones Controlled by Complex Fracture Networks in Tight Reservoirs: A Case Study of Xujiahe Formation
by Jiujie Cai, Haibo Wang and Fengxia Li
Sustainability 2023, 15(12), 9736; https://doi.org/10.3390/su15129736 - 18 Jun 2023
Cited by 1 | Viewed by 1887
Abstract
The development of tight gas reservoirs presents a significant challenge for sustainable development, as it requires specialized techniques that can have adverse environmental and social impacts. To address these challenges, efficient development technologies, such as multistage hydraulic fracturing, have been adopted to enable [...] Read more.
The development of tight gas reservoirs presents a significant challenge for sustainable development, as it requires specialized techniques that can have adverse environmental and social impacts. To address these challenges, efficient development technologies, such as multistage hydraulic fracturing, have been adopted to enable access to previously inaccessible natural gas resources, increase energy efficiency and security, and minimizing environmental impacts. This paper proposes a novel evaluation method to analyze the post fracturing productivity controlled by complex fault fracture zones in tight reservoirs. In this article, a systematic method to evaluate stimulated reservoir volume (SRV) and fault-fracture zone complexity after stimulation was established, along with the analysis and prediction of productivity through coupled fall-off and well-test analyses. Focusing on the Xujiahe formation in the Tongnanba anticline of northeastern Sichuan Basin, a 3D geological model was developed to analyze planar heterogeneity. The fall-off analytical model, coupled with rock mechanical parameters and fracturing parameters such as injection rates, fracturing fluid viscosity, and the number of clusters within a single stage, was established to investigate the fracture geometric parameters and complexities of each stage. The trilinear flow model was used to solve the well-test analysis model of multi-stage fractured horizontal wells in tight sandstone gas reservoirs, and well-test curves of the heterogeneous tight sandstone gas fracture network model were obtained. The results show that hydraulic fractures connect the natural fractures in fault-fracture zones. An analysis of the relationship between the fracture geometric outcomes of each segment and the net pressure reveals that as the net pressure in the fracture increases, the area ratio of natural fractures to main fractures increases notably, whereas the half length of the main fracture exhibits a decreasing trend. The overall area of natural fractures following stimulation is 7.64 times greater than that of the main fractures and is mainly a result of the extensive development of natural fractures in the target interval. As the opening ratio of natural fractures increases, the length of the main fractures decreases accordingly. Therefore, increasing net pressure within fractures will significantly enhance the complexity of fracturing fractures in shale gas reservoirs. Furthermore, the initial production of Well X1–10, which is largely controlled by fault-fracture zones, and the cumulative gas production after one year, are estimated. The systematic evaluation method in this study proposed a new way to accurately measure fracturing in tight reservoirs, which is a critical and helpful component of sustainable development in the natural gas industry. Full article
Show Figures

Figure 1

29 pages, 9095 KiB
Article
Real-Time Simulation of Hydraulic Fracturing Using a Combined Integrated Finite Difference and Discontinuous Displacement Method: Numerical Algorithm and Field Applications
by Shihao Wang, Xiangyu Yu, Philip H. Winterfeld and Yu-Shu Wu
Water 2023, 15(5), 938; https://doi.org/10.3390/w15050938 - 28 Feb 2023
Cited by 5 | Viewed by 3718
Abstract
Real-time simulation of hydraulic fracturing operations is of critical importance to the field-scale stimulation applications. In this paper, we present an efficient yet reasonably accurate program for the numerical modeling of dynamic fractures. Our program, named as FracCSM, is based on combined Integrated [...] Read more.
Real-time simulation of hydraulic fracturing operations is of critical importance to the field-scale stimulation applications. In this paper, we present an efficient yet reasonably accurate program for the numerical modeling of dynamic fractures. Our program, named as FracCSM, is based on combined Integrated Finite Difference (IFD) method and Discontinuous Displacement Method (DDM). FracCSM simulates the initiation and propagation of hydraulic fractures with DDM and mass/heat transport inside fractures by IFD. The frictional loss within the wellbore is also taken into consideration. In this way, we are able to model the propped height and length of the fractures subject to the stress interference effect. Moreover, FracCSM captures the stress shadow effect of multi-stage fractures. To facilitate the monitoring and decision making during the hydraulic fracturing process, we have developed a general framework that supports real-time simulation of fracture propagation. Our developed program demonstrates sound accuracy in comparison with existing simulators. The novelty of this work is the combined simulation algorithm to simulate the multiphysical process during hydraulic fracturing operations. We will demonstrate the program structure as well as the field applications of FracCSM to the real-time simulation of hydraulic fracturing operations in Sulige tight sandstone reservoir. Full article
(This article belongs to the Special Issue Fluid Dynamics Modeling in Porous Media)
Show Figures

Figure 1

18 pages, 9728 KiB
Article
An Improved Integrated Numerical Simulation Method to Study Main Controlling Factors of EUR and Optimization of Development Strategy
by Yihe Du, Hualin Liu, Yuping Sun, Shuyao Sheng and Mingqiang Wei
Energies 2023, 16(4), 2011; https://doi.org/10.3390/en16042011 - 17 Feb 2023
Cited by 6 | Viewed by 1876
Abstract
Gas reservoir numerical simulation is an important method to optimize the development strategy of shale gas reservoirs which has been influenced by the multi-stage fracture. The regular fracture network model was used to build a conventional numerical simulation, in which it was difficult [...] Read more.
Gas reservoir numerical simulation is an important method to optimize the development strategy of shale gas reservoirs which has been influenced by the multi-stage fracture. The regular fracture network model was used to build a conventional numerical simulation, in which it was difficult to show the true situation of fracture propagation. However, the physical parameters not only affect the production, but also influence the stimulation effect; moreover, the quality of the fracturing effect also affects the production which causes the input and out parameters to be inaccurate. To solve this problem, the process simulation must be completed from geology to engineering to gas reservoir. The main controlling factors of production are identified with geological and engineering factors such as horizontal stage length, the volume of fracturing fluid, well spacing, production allocation, and proppant mass. Therefore, on the basis of the integrated simulation method of a hydraulic fracturing network simulation and an unstructured grid high-precision numerical simulation, this paper builds an integrated numerical simulation of a shale gas reservoir coupled with geology and engineering to optimize the development strategy with production as the target. Taking four wells of a platform as an example, the EUR (estimated ultimate recovery) has increased by 25% after the optimization of the development strategy. Full article
(This article belongs to the Special Issue Optimization and Simulation of Intelligent Oil and Gas Wells)
Show Figures

Figure 1

18 pages, 6588 KiB
Article
Experimental Investigation of the Growth Law of Multi-Fracture during Temporary Plugging Fracturing within a Stage of Multi-Cluster in a Horizontal Well
by Yanchao Li, Qing Zhang and Yushi Zou
Processes 2022, 10(4), 637; https://doi.org/10.3390/pr10040637 - 24 Mar 2022
Cited by 8 | Viewed by 2122
Abstract
Temporary plugging fracturing in a horizontal well with multi-stages and multi-clusters is usually used to improve stimulation efficiency and increase the gas production from shale gas reservoirs. However, the fracture propagation geometry and the mechanism of temporary plugging are still unclear, which restricts [...] Read more.
Temporary plugging fracturing in a horizontal well with multi-stages and multi-clusters is usually used to improve stimulation efficiency and increase the gas production from shale gas reservoirs. However, the fracture propagation geometry and the mechanism of temporary plugging are still unclear, which restricts the further optimization of temporary plugging fracturing scheme. In this study, taking the Longmaxi shale as the research object and considering the intrafracture and intrastage temporary plugging, the true tri-axial hydraulic fracturing system was used to put forward an experimental method for simulating the temporary plugging fracturing in a horizontal well with multi-stages and multi-clusters. Afterward, the effects of the size combination and concentration of temporary plugging agents and the cluster number in a stage on the fracture geometry created in the secondary fracturing were investigated in detail. The results show that an optimal fracture propagation geometry tends to be obtained by using the combinations of 100 to 20/70 mesh, and 20/70 to 10~18 mesh temporary plugging agents for the intrafracture and intrastage temporary plugging, respectively. Increasing the proportion of the temporary plugging agent of a larger particle size can improve the effectiveness of intrafracture and intrastage temporary plugging fracturing, and tends to open new fractures. With the increase in temporary plugging agent concentration and the cluster number within a stage, both the number of diverting fractures formed and the overall complexity of fractures tend to increase. After fracturing, the rock specimen with a high peak in the temporary plugging pressure curve has more transverse fractures, indicating a desirable diversion effect. By contrast, the fractured rock specimen with a low peak pressure has no transverse fracture, generally with fewer fractures and poor diversion effect. Full article
Show Figures

Figure 1

24 pages, 3839 KiB
Article
Frac-n-Flow Testing to Screen Brittle Fracture Stages in Wolfcamp Formation, Permian Basin, USA
by Zhengwen Zeng
Energies 2021, 14(17), 5450; https://doi.org/10.3390/en14175450 - 1 Sep 2021
Cited by 2 | Viewed by 2309
Abstract
A new technique, fracturing-and-flowing (frac-n-flow) testing, is introduced for horizontal drilling and multistage hydraulic fracturing (HDMHF) practitioners to check if the next stage would be a brittle fracture using the instantaneous shut-in pressure (ISIP) from the current stage. It was developed to reduce [...] Read more.
A new technique, fracturing-and-flowing (frac-n-flow) testing, is introduced for horizontal drilling and multistage hydraulic fracturing (HDMHF) practitioners to check if the next stage would be a brittle fracture using the instantaneous shut-in pressure (ISIP) from the current stage. It was developed to reduce the number of not-flowing clusters in HDMHF treatments due to stress shadows in the development of tight oil reserves in Wolfcamp, Permian Basin, USA, and other similar fields. Preliminary frac-n-flow testing results show that a medium (200–1000 psi) increase in confining pressure under representative field in-situ stresses can transfer Indiana limestone from brittle fracturing to semi-ductile failing. Consequently, folds of increase (FOI) of matrix permeability vary from +13 (i.e., increase by 1300%) to −0.39 (i.e., decrease by 39%). Limestone is one of the major lithological components in Wolfcamp formation. Field ISIP data of two HDMHF wells in Wolfcamp formation show that the maximum stress shadows are +1297 psi and +1716 psi, respectively. These stress shadows might have transferred the fracturing process from brittle to semi-ductile, converting the corresponding stages from being stimulated and conductive (fracturing-n-flowing) to being damaged and not-flowing (failing-n-not-flowing). Field completion reports of the two wells confirmed that screen-out and other interruptions of operation occurred in these high stress shadowed stages. Full article
Show Figures

Figure 1

26 pages, 14502 KiB
Article
An Analytical Model for Production Analysis of Hydraulically Fractured Shale Gas Reservoirs Considering Irregular Stimulated Regions
by Kaixuan Qiu and Heng Li
Energies 2020, 13(22), 5899; https://doi.org/10.3390/en13225899 - 12 Nov 2020
Cited by 5 | Viewed by 1760
Abstract
Shale gas reservoirs are typically developed by multistage, propped hydraulic fractures. The induced fractures have a complex geometry and can be represented by a high permeability region near each fracture, also called stimulated region. In this paper, a new integrative analytical solution coupled [...] Read more.
Shale gas reservoirs are typically developed by multistage, propped hydraulic fractures. The induced fractures have a complex geometry and can be represented by a high permeability region near each fracture, also called stimulated region. In this paper, a new integrative analytical solution coupled with gas adsorption, non-Darcy flow effect is derived for shale gas reservoirs. The modified pseudo-pressure and pseudo-time are defined to linearize the nonlinear partial differential equations (PDEs) and thus the governing PDEs are transformed into ordinary differential equations (ODEs) by integration, instead of the Laplace transform. The rate vs. pseudo-time solution in real-time space can be obtained, instead of using the numerical inversion for Laplace transform. The analytical model is validated by comparison with the numerical model. According to the fitting results, the calculation accuracy of analytic solution is almost 99%. Besides the computational convenience, another advantage of the model is that it has been validated to be feasible to estimate the pore volume of hydraulic region, stimulated region, and matrix region, and even the shape of regions is irregular and asymmetrical for multifractured horizontal wells. The relative error between calculated volume and given volume is less than 10%, which meets the engineering requirements. The model is finally applied to field production data for history matching and forecasting. Full article
(This article belongs to the Special Issue Development of Unconventional Reservoirs 2020)
Show Figures

Graphical abstract

8 pages, 4754 KiB
Article
Application of Bionic Technologies on the Fracturing Plug
by Lin Chen, Ran Wei, Songbo Wei and Xinzhong Wang
Biomimetics 2019, 4(4), 78; https://doi.org/10.3390/biomimetics4040078 - 5 Dec 2019
Cited by 2 | Viewed by 3287
Abstract
The dissolvable bridge plug is one of the most important tools for multi-stage hydraulic fracturing in the field of oil/gas development. The plug provides zonal isolation to realize staged stimulation and, after fracturing, the plug is fully dissolved in produced liquids. A bionic [...] Read more.
The dissolvable bridge plug is one of the most important tools for multi-stage hydraulic fracturing in the field of oil/gas development. The plug provides zonal isolation to realize staged stimulation and, after fracturing, the plug is fully dissolved in produced liquids. A bionic surface was introduced to improve the performance of the plug. Surface dimples in the micron dimension were prepared on the dissolvable materials of the plug. The experimental results showed that the surface dimples changed the hydrophilic and hydrophobic properties of the dissolvable materials. The dissolution rate has a great relation with the parameters of the dimples and can be controlled by choosing the dimples’ parameters to some degree. Full article
(This article belongs to the Special Issue Selected Papers from ICBE2019)
Show Figures

Figure 1

21 pages, 7266 KiB
Article
Numerical Analysis of Transient Pressure Behaviors with Shale Gas MFHWs Interference
by Dapeng Gao, Yuewu Liu, Daigang Wang and Guofeng Han
Energies 2019, 12(2), 262; https://doi.org/10.3390/en12020262 - 15 Jan 2019
Cited by 10 | Viewed by 3679
Abstract
After the large-scale horizontal well pattern development in shale gas fields, the problem of fast pressure drop and gas well abandonment caused by well interference becomes more serious. It is urgent to understand the downhole transient pressure and flow characteristics of multi-stage fracturing [...] Read more.
After the large-scale horizontal well pattern development in shale gas fields, the problem of fast pressure drop and gas well abandonment caused by well interference becomes more serious. It is urgent to understand the downhole transient pressure and flow characteristics of multi-stage fracturing horizontal well (MFHW) with interference. Therefore, the reservoir around the MFHW is divided into three regions: fracturing fracture, Stimulated reservoir volume (SRV), and unmodified matrix. Then, multi-region coupled flow model is established according to reservoir physical property and flow mechanism of each part. The model is numerically solved using the perpendicular bisection (PEBI) grids and the finite volume method. The accuracy of the model is verified by analyzing the measured pressure recovery data of one practical shale gas well and fitting the monitoring data of the later production pressure. Finally, this model is used to analyze the effects of factors, such as hydraulic fractures’ connectivity, well distance, the number of neighboring wells and well pattern arrangement, on the transient pressure and seepage characteristics of the well. The study shows that the pressure recovery double logarithmic curves fall in later part when the well is disturbed by a neighboring production well. The earlier and more severe the interference, the sooner the curve falls off and the larger the amplitude shows. If the well distance is closer, and if there are more neighboring wells and interconnected corresponding fracturing segments, the more severe interference appears among the wells. Moreover, the well interference may still exist even without interlinked fractures or SRV. Especially, severe interference will affect production when the hydraulic fractures are connected directly, and the interference is weaker when only SRV induced fracture network combined between wells, which is beneficial to production sometimes. When severe well interference occurs, periodic well shut-in is needed to help restore the reservoir pressure and output capacity. In the meanwhile, the daily output should be controlled reasonably to prolong the stable production time. This research will help to understand the impact of well interference to gas production, and to optimize the well spacing and achieve satisfied performance. Full article
(This article belongs to the Special Issue Development of Unconventional Reservoirs)
Show Figures

Figure 1

15 pages, 1391 KiB
Article
Numerical Simulation of Fluid Flow through Fractal-Based Discrete Fractured Network
by Wendong Wang, Yuliang Su, Bin Yuan, Kai Wang and Xiaopeng Cao
Energies 2018, 11(2), 286; https://doi.org/10.3390/en11020286 - 24 Jan 2018
Cited by 31 | Viewed by 5162
Abstract
Abstract: In recent years, multi-stage hydraulic fracturing technologies have greatly facilitated the development of unconventional oil and gas resources. However, a quantitative description of the “complexity” of the fracture network created by the hydraulic fracturing is confronted with many unsolved challenges. Given [...] Read more.
Abstract: In recent years, multi-stage hydraulic fracturing technologies have greatly facilitated the development of unconventional oil and gas resources. However, a quantitative description of the “complexity” of the fracture network created by the hydraulic fracturing is confronted with many unsolved challenges. Given the multiple scales and heterogeneity of the fracture system, this study proposes a “bifurcated fractal” model to quantitatively describe the distribution of induced hydraulic fracture networks. The construction theory is employed to generate hierarchical fracture patterns as a scaled numerical model. With the implementation of discrete fractal-fracture network modeling (DFFN), fluid flow characteristics in bifurcated fractal fracture networks are characterized. The effects of bifurcated fracture length, bifurcated tendency, and number of bifurcation stages are examined. A field example of the fractured horizontal well is introduced to calibrate the accuracy of the flow model. The proposed model can provide a more realistic representation of complex fracture networks around a fractured horizontal well, and offer the way to quantify the “complexity” of the fracture network in shale reservoirs. The simulation results indicate that the geometry of the bifurcated fractal fracture network model has a significant impact on production performance in the tight reservoir, and enhancing connectivity of each bifurcate fracture is the key to improve the stimulation performance. In practice, this work provides a novel and efficient workflow for complex fracture characterization and production prediction in naturally-fractured reservoirs of multi-stage fractured horizontal wells. Full article
(This article belongs to the Special Issue Flow and Transport Properties of Unconventional Reservoirs)
Show Figures

Figure 1
