Search Results (49)

This paper describes a compact multi-port sub-6 GHz multiple-input multiple-output (MIMO) antenna system tailored for 5G NR mobile terminals operating in the n77 (3.3–4.2 GHz), n78 (3.3–3.8 GHz), and n79 (4.4–5.0 GHz) frequency bands. The proposed design leverages a shared coupling approach that exploits the smartphone metal frame as the radiating element, facilitating efficient integration within the spatial constraints of modern mobile devices. A two-stage method is used to mitigate the mutual coupling and correlation issues typically encountered when designing compact MIMO configurations. Initially, a four-port structure is used to evaluate broadband impedance and spatial feasibility. Based on the observed limitations in terms of isolation and the envelope correlation coefficient (ECC), the final configuration was reconfigured as an optimized two-port layout with a refined coupling geometry and effective current path control. The fabricated two-port prototype exhibited a measured voltage standing wave ratio below 3:1 across the n78 band on both ports, with the isolation levels attaining –12.4 dB and ECCs below 0.12. The radiation efficiency exceeded −6 dB across the operational band, and the radiation patterns were stable at 3.3, 3.5, and 3.8 GHz, confirming that the system was appropriate for MIMO deployment. The antenna supports asymmetric per-port efficiency targets ranging from −4.5 to −10 dB. These are the realistic layout constraints of commercial smartphones. In summary, this study shows that a metal frame integrated two-port MIMO antenna enables wideband sub-6 GHz operation by meeting the key impedance and system-level performance requirements. Our method can be used to develop a scalable platform assisting future multi-band antenna integration in mass-market 5G smartphones. Full article

The increasing demand for sustainable and renewable energy solutions has made radio frequency energy harvesting (RFEH) a promising technique for powering low-power electronic devices. RFEH captures ambient RF signals from wireless communication systems, such as mobile networks, Wi-Fi, and broadcasting stations, and converts them into usable electrical energy. This approach offers a viable alternative for battery-dependent and hard-to-recharge applications, including streetlights, outdoor night/security lighting, wireless sensor networks, and biomedical body sensor networks. This article provides a comprehensive review of the RFEH techniques, including state-of-the-art rectenna designs, energy conversion efficiency improvements, and multi-band harvesting systems. We present a detailed analysis of recent advancements in RFEH circuits, impedance matching techniques, and integration with emerging technologies such as the Internet of Things (IoT), 5G, and wireless power transfer (WPT). Additionally, this review identifies existing challenges, including low conversion efficiency, unpredictable energy availability, and design limitations for small-scale and embedded systems. A critical assessment of current research gaps is provided, highlighting areas where further development is required to enhance performance and scalability. Finally, constructive recommendations for future opportunities in RFEH are discussed, focusing on advanced materials, AI-driven adaptive harvesting systems, hybrid energy-harvesting techniques, and novel antenna–rectifier architectures. The insights from this study will serve as a valuable resource for researchers and engineers working towards the realization of self-sustaining, battery-free electronic systems. Full article

This research introduces a novel, high-performance multiple-input–multiple-output (MIMO) antenna designed to operate in allocated millimeter-wave (mmWave) 5G wireless communications. Operating in the tri-band, 28, 35, and 38 GHz, the four-port MIMO antenna possesses a compact size—measuring just 50 × 50 × 0.787 mm³ (4.67λ_o × 4.67λ_o × 0.73λ_o). The antenna delivers a remarkable performance, achieving peak gains of 9.6, 7.8, and 13.7 dBi in the tri-band, respectively. The realized bandwidths are 1.1, 2.2, and 3.7 GHz, at the tri-band frequencies. The antenna’s performance was significantly improved by carefully spacing the elements and employing a decoupling technique using metamaterial cells. This minimized interference between the antenna elements, resulting in efficient MIMO operation with a low envelope correlation coefficient of 0.00015 and a high diversity gain approaching 10 dB, and high isolation of 34.5, 22, and 30 dB, in the tri-band. This proposed design is confirmed with experimental measurements and offers a promising candidate for multi-band use of mmWave communication systems. Full article

The capabilities of 6G networks surpass those of existing networks, aiming to enable seamless connectivity between all entities and users at any given time. A critical aspect of achieving enhanced and ubiquitous mobile broadband, as promised by 6G networks, is merging satellite networks with land-based networks, which offers significant potential in terms of coverage area. Advanced routing techniques in next-generation network technologies, particularly when incorporating terrestrial and non-terrestrial networks, are essential for optimizing network efficiency and delivering promised services. However, the dynamic nature of the network, the heterogeneity and complexity of next-generation networks, and the relative distance and mobility of satellite networks all present challenges that traditional routing protocols struggle to address. This paper provides an in-depth analysis of 6G networks, addressing key enablers, technologies, commitments, satellite networks, and routing techniques in the context of 6G and satellite network integration. To ensure 6G fulfills its promises, the paper emphasizes necessary scenarios and investigates potential bottlenecks in routing techniques. Additionally, it explores satellite networks and identifies routing challenges within these systems. The paper highlights routing issues that may arise in the integration of 6G and satellite networks and offers a comprehensive examination of essential approaches, technologies, and visions required for future advancements in this area. 6G and satellite networks are associated with technical terms such as AI/ML, quantum computing, THz communication, beamforming, MIMO technology, ultra-wide band and multi-band antennas, hybrid channel models, and quantum encryption methods. These technologies will be utilized to enhance the performance, security, and sustainability of future networks. Full article

To address the inherent contradiction between low-profile design and high gain in traditional omnidirectional antennas, as well as the narrow bandwidth constraints of ENZ antennas, this study presents a dual-mode ENZ-FP collaborative resonant antenna array design utilizing a substrate-integrated waveguide (SIW). Through systematic analysis of ENZ media’s quasi-static field distribution, we innovatively integrated it with Fabry–Perot (F–P) resonance, achieving unprecedented dual-band omnidirectional radiation at 5.18 GHz and 5.72 GHz within a single ENZ antenna configuration for the first time. The directivity of both frequencies reached 12.0 dBi, with a remarkably low profile of only 0.018λ. We then extended this design to an ENZ-FP dual-mode beam-scanning array. By incorporating phase control technology, we achieved wide-angle scanning despite low-profile constraints. The measured 3 dB beam coverage angles at the dual frequencies were ±63° and ±65°, respectively. Moreover, by loading the impedance matching network, the −10 dB impedance bandwidth of the antenna array was further extended to 2.4% and 2.7%, respectively, thus overcoming the narrowband limitations of the ENZ antenna and enhancing practical applicability. The antennas were manufactured using PCB (Printed Circuit Board) technology, offering high integration and cost efficiency. This provides a new paradigm for UAV (Unmanned Aerial Vehicle) communication and radar detection systems featuring multi-band operation, a low-profile design, and flexible beam control capabilities. Full article

In response to the urgent demands of the Internet of Things for precise indoor target positioning and information interaction, this paper proposes a multi-band analog radio-over-fiber mobile fronthaul system. The objective is to obtain the target’s location in indoor environments while integrating remote beamforming capabilities to achieve wireless access to the targets. Vector signals centered at 3, 4, 5, and 6 GHz for indoor positioning and centered at 30 GHz for wireless access are generated centrally in the distributed unit (DU) and fiber-distributed to the active antenna unit (AAU) in the multi-band analog radio-over-fiber mobile fronthaul system. Target positioning is achieved by radiating electromagnetic waves indoors through four omnidirectional antennas in conjunction with a pre-trained neural network, while high-speed wireless communication is realized through a phased array antenna (PAA) comprising four antenna elements. Remote beamforming for the PAA is implemented through the integration of an optical true time delay pool in the multi-band analog radio-over-fiber mobile fronthaul system. This integration decouples the weight control of beamforming from the AAU, enabling centralized control of beam direction at the DU and thereby reducing the complexity and cost of the AAU. Simulation results show that the average accuracy of localization classification can reach 86.92%, and six discrete beam directions are achieved via the optical true time delay pool. In the optical transmission layer, when the received optical power is 10 dBm, the error vector magnitudes (EVMs) of vector signals in all frequency bands remain below 3%. In the wireless transmission layer, two beam directions were selected for verification. Once the beam is aligned with the target device at maximum gain and the received signal is properly processed, the EVM of millimeter-wave vector signals remains below 11%. Full article

Energy harvesting technology allows Internet of Things (IoT) devices to be powered continuously without needing battery charging or replacement. In addressing existing and emerging massive IoT energy supply challenges, this paper presents the design of multi-sourced multiple input and multiple output (MIMO) multiband hybrid wireless RF-perovskite photovoltaic energy harvesting subsystems for IoT application. The research findings evaluate the efficiency and power output of different RF configurations (1 to 16 antennas) within MIMO RF subsystems. A Delon quadruple rectifier in the RF energy harvesting system demonstrates a system-level power conversion efficiency of 51%. The research also explores the I-V and P-V characteristics of the adopted perovskite tandem cell. This results in an impressive array capable of producing 6.4 V and generating a maximum power of 650 mW. For the first time, the combined mathematical modelling of the system architecture is presented. The achieved efficiency of the combined system is 90% (for 8 MIMO) and 98% (for 16 MIMO) at 0 dBm input RF power. This novel study holds great promise for next-generation 5G/6G smart IoT passive electronics. Additionally, it establishes the hybrid RF-perovskite energy harvester as a promising, compact, and eco-friendly solution for efficiently powering IoT devices in smart cities. This work contributes to the development of sustainable, scalable, and smart energy solutions for IoT integration into smart city infrastructures. Full article

Beyond data transmission, antennas have recently been utilized as sensors, offering the advantage of reducing hardware requirements and power consumption compared to systems where sensors are separate from antennas. Patch antennas, in particular, are widely used across various applications, including sensing, due to their attractive features like compact size and conformability. In addition, they can be easily designed in different ways to sense variations in certain variables. Adding a slot to the patch antenna introduces several advantages, including multiband, wideband operation, and improved impedance bandwidth. Slots also provide a concentrated region of electromagnetic fields, which increases the antenna’s sensitivity for sensing and detection purposes. In this paper, a rectangular patch antenna with a cross slot is designed and proposed for water, ice, and frost detection. Detection is achieved by measuring variations in the resonant frequency in response to water, ice accumulation, and frost. The results indicate that the proposed antenna can detect both water and ice accretion with a frequency shift of up to 1.538, 0.358, and 0.056 GHz, respectively, which reflects good sensitivity levels of the antenna. The effect of the slot on strengthening the near electric field and antenna sensitivity is discussed in this paper. The antenna is fabricated and measured and the indicators of each detection scale have been extracted. The proposed antenna has a simple structure and a small size of (40 × 40 × 1.53 m³). In addition, it can be precisely used to sense different environmental parameters such as frost and ice. Thus, it can serve as a strong candidate for detecting natural disasters like frost damage. Furthermore, the findings in this paper offer valuable insights into how the presence and structure of slots influence the sensitivity response of patch antennas, supporting ongoing research in this field. Full article

In this paper, a novel topology and method for designing a multi-band rectenna is proposed to improve its RF-DC efficiency. The rectifier achieves simultaneous rectification using both series and parallel configurations by connecting two branches to the respective terminals of the diode, directing the energy input from two ports to the anode and cathode of the diode. Six desired operating frequency bands are evenly distributed across these two branches, each of which is connected to antennas corresponding to their specific operating frequencies, serving as the receiving end of the system. To optimize the design process, a low-pass filter is incorporated into the rectifier design. This filter works in conjunction with a matching network that includes filtering capabilities to isolate the two ports of the rectifier. The addition of the filter ensures that each structure within the rectifier can be designed independently without adversely affecting the performance of the already completed structures. Based on the proposed design methodology, a dual-port rectenna operating at six frequency bands—1.85 GHz, 2.25 GHz, 2.6 GHz, 3.52 GHz, 5.01 GHz, and 5.89 GHz—was designed, covering the 4G, 5G, and Wi-Fi/WLAN frequency bands. The measured results indicate that high-power conversion efficiency was achieved at an input power of −10 dBm: 43.01% @ 1.85 GHz, 41.00% @ 2.25 GHz, 41.33% @ 2.6 GHz, 35.88% @ 3.52 GHz, 22.36% @ 5.01 GHz, and 19.27% @ 5.89 GHz. When the input power is −20 dBm, the conversion efficiency of the rectenna can be improved from 5.2% for single-tone input to 27.7% for six-tone input, representing a 22.5 percentage point improvement. The proposed rectenna demonstrates significant potential for applications in powering low-power sensors and other devices within the Internet of Everything context. Full article

A new dual-band low-noise amplifier (LNA) operating at L1/E1 1.575 GHz and L5/E5 1.192 GHz center frequencies for global navigation satellite system receivers is proposed. A doubled common-source amplifier architecture is used with a single input, shared gate inductor, and two outputs to split the RF signal into separate RX channels. The main advantage of the proposed circuit is compatibility with widespread multi-band antennas with single RF connectors dedicated to high-precision applications, as well as the possibility to use cheap SAW filters with small footprints to build low-cost, highly accurate GNSS receiver modules. The input and both outputs are well matched to 50 Ω impedance. The LNA is designed with a 110 nm CMOS process, consuming 6.13 mA current from a 1.5 V supply. The measured noise figures and voltage gains of the dual-band LNA are, respectively, NF1/NF5 = 3.23/3.5 dB and G1/G5 = 21.22/18.2 dB in the band of interest for each channel. The measured impedance matching at the input (S11) and output (S22) of the dual-band low-frequency amplifier is as follows: S11_L1 = −23.89, S11_L5 = −8.42, S22_L1 = −12.65, S22_L5 = −15.08. The one-decibel compression points are L1 band PdB1 = −37.71 dBm and L5 band PdB5 = −34.72 dBm, respectively. Full article

The proliferation of Internet of Things (IoT) devices, such as trackers and sensors, necessitates a delicate balance between device miniaturization and performance. This extends to the antenna system, which must be both efficient and multiband operational while fitting within space-constrained electronic enclosures. Traditional antennas, however, struggle to meet these miniaturization demands. Reconfigurable antennas have emerged as a promising solution for adapting their frequency, radiation pattern, or polarization in response to changing requirements, making them ideal for IoT applications. Among various reconfiguration techniques (electrical, mechanical, optical, and material-based), electrical reconfiguration reigns supreme for IoT applications. Its suitability for compact devices, cost-effectiveness, and relative simplicity make it the preferred choice. This paper reviews various approaches to realizing IoT reconfigurable antennas, with a focus on electrical reconfiguration techniques. It categorizes these techniques based on their implementation, including PIN diodes, digital tunable capacitors (DTCs), varactor diodes, and RF switches. It also explores the challenges associated with the development and characterization of IoT reconfigurable antennas, evaluates the strengths and limitations of existing methods, and identifies open challenges for future research. Importantly, the growing trend towards smaller IoT devices has led to the development of antenna boosters. These components, combined with advanced reconfiguration techniques, offer new opportunities for enhancing antenna performance while maintaining a compact footprint. Full article

This study presents a compact and stable gain spacecraft antenna that operates in all Global Navigation Satellite System (GNSS) bands from 1.164 GHz to 1.610 GHz. The proposed antenna structure based on the single-feed crossed bowtie antenna concept consists of four triangular patches excited with a 90° phase difference in between to generate right-hand circular polarization (RHCP), without needing complex feed networks. The radiator part of the antenna is covered by a radome and is also supported by a cylindrical dielectric cavity frame (DCF) to weaken the diffracted waves propagating along the ground plane while increasing vibration resistance. The fabricated antenna provides a return loss better than 10 dB with lower than 3 dB axial ratio and a stable gain around 7.2 ± 0.3 dBic over the entire GNSS bands, as well as a more compact and lightweight structural performance. It is also verified that the structural integrity and functional performance of the fabricated antenna remain consistent despite exposure to an equivalent vibration level in the launch process. The presented all-band spacecraft GNSS antenna is an innovative implementation with space industry insight for multi-band space applications that have application-specific limitations and provides consistent performance, as well as operational safety with the antenna design simplicity. Full article

Simple, instantaneous, contactless, multiple-point metamaterial-inspired microwave sensors, composed of multi-band, low-profile metamaterial-inspired antennas, were developed to detect and identify meningioma tumors, the most common primary brain tumors. Based on a typical meningioma tumor size of 5–20 mm, a higher operating frequency, where the wavelength is similar or smaller than the tumor target, is crucial. The sensors, designed for the microwave Ku band range (12–18 GHz), where the electromagnetic property values of tumors are available, were implemented in this study. A seven-layered head phantom, including the meningioma tumors, was defined using actual electromagnetic parametric values in the frequency range of interest to mimic the actual human head. The reflection coefficients can be recorded and analyzed instantaneously, reducing high electromagnetic radiation consumption. It has been shown that a single-band detection point is not adequate to classify the nonlinear tumor and head model parameters. On the other hand, dual-band and tri-band metamaterial-inspired antennas, with additional detecting points, create a continuous function solution for the nonlinear problem by adding extra observation points using multiple-band excitation. The point mapping values can be used to enhance the tumor detection capability. Two-point mapping showed a consistent trend between the S₁₁ value order and the tumor size, while three-point mapping can also be used to demonstrate the correlation between the S₁₁ value order and the tumor size. This proposed multi-detection point technique can be applied to a sensor for other nonlinear property targets. Moreover, a set of antennas with different polarizations, orientations, and arrangements in a network could help to obtain the highest sensitivity and accuracy of the whole system. Full article

In this article, the authors present the design of a compact multiband monopole antenna measuring 30 × 10 × 1.6 mm³, which is aimed at optimizing performance across various communication bands, with a particular focus on Wi-Fi and sub-6G bands. These bands include the 2.4 GHz band, the 3.5 GHz band, and the 5–6 GHz band, ensuring versatility in practical applications. Another important point is that this paper demonstrates effective methods for reducing mutual coupling through two meander slits on the common ground, resembling a defected ground structure (DGS) between two antenna elements. This approach achieves mutual coupling suppression from −6.5 dB and −9 dB to −26 dB and −13 dB at 2.46 GHz and 3.47 GHz, respectively. Simulated and measured results are in good agreement, demonstrating significant improvements in isolation and overall multiple-input multiple-output (MIMO) antenna system performance. This research proposes a compact multiband monopole antenna and demonstrates a method to suppress coupling in multiband antennas, making them suitable for internet of things (IoT) sensor devices and Wi-Fi infrastructure systems. Full article

This paper presents rooftop automobile antennas designed for Long-Term Evolution (LTE), Wireless Local Area Network (WLAN) and navigation system applications. The proposed antennas are housed within a shark-fin structure on the car’s roof, and comprise a main antenna and a diversity antenna. The main antenna and diversity antenna combine for spatial diversity, receiving and processing the same signal to optimize signal quality. To accommodate the limited space within the shark-fin housing, various miniaturization and multiband techniques are utilized. The hexagonal substrate is more closely fitted to the shape of the shark fin, thus making full use of the space of the shark-fin shell. The main antenna and the diversity antenna are perpendicular to each other, which saves the space of the overall antenna and improves the utilization rate of the overall antenna space. The proposed main antenna, compactly sized at 50 mm × 20 mm × 1.59 mm, maintains a VSWR value below 2 across the frequency range of 1.19–2.8 GHz, enabling support for LTE bands 1, 2, 3, 4, 7, 11, 15, 16, 34, 39, 40, and 41, as well as WLAN 2400 bands. The diversity antenna maintains a VSWR value below 2 across the frequency range of 1.5–2.6 GHz, which can cover BeiDou B1-1, LTE 1, 2, 3, 4, 7, 11, 15, 16, 34, 39, and 40, and WLAN 2400 bands. The main antenna and the diversity antenna both demonstrate favorable radiation patterns on the azimuth plane. Simulation and measurement results exhibit a high level of agreement. Full article
