In this study, chemical deposition was used to synthesize structures of Ga₂O₃ -NW/SiO₂/Si (NW—nanowire) at 348 K and SnO₂-NW/SiO₂/Si at 323 K in track templates SiO₂/Si (either n- or p-type). The resulting crystalline nanowires were δ-Ga₂O₃ and orthorhombic SnO₂. Computer modeling of the delta phase of gallium oxide yielded a lattice parameter of a = 9.287 Å, which closely matched the experimental range of 9.83–10.03 Å. The bandgap is indirect with an Eg = 5.5 eV. The photoluminescence spectra of both nanostructures exhibited a complex band when excited by light with λ = 5.16 eV, dominated by luminescence from vacancy-type defects. The current–voltage characteristics of δ-Ga₂O₃ NW/SiO₂/Si-p showed one-way conductivity. This structure could be advantageous in devices where a reverse current is undesirable. The p-n junction with a complex structure was formed. This junction consists of a polycrystalline nanowire base exhibiting n-type conductivity and a monocrystalline Si substrate with p-type conductivity. The I–V characteristics of SnO₂-NW/SiO₂/Si suggested near-metallic conductivity due to the presence of metallic tin. Full article

We demonstrate two distinct experimental processes involving the large-area growth of ordered and disordered silicon nanowire arrays (SiNWs) on a p-type silicon substrate using the metal-assisted chemical etching method. The two processes are based on the etching of monocrystalline silicon wafers by randomly distributed Ag films and ultra-thin Au films with ordered nano-mesh arrays, respectively, wherein the growth of SiNWs is implemented using a specific proportion of a HF-containing solution at room temperature. In this study, the microstructural change mechanisms for the two morphologically different arrays before and after annealing were investigated using Raman spectra. The effects of various mechanisms on the observed Raman scattering peak’s deviation from symmetry, redshift and broadening were analyzed. The evolution of the unstable amorphous structures of nanoscale materials during the high-temperature annealing process was observed via high-resolution scanning electron microscope (SEM) observations. The scattering peak parameters determined from the Raman spectra led to conclusions concerning the various mechanisms by which high-temperature annealing influences the microstructures of the two morphologically different SiNWs fabricated on the p-type silicon substrate. Therefore, the deviation of SiNWs from the monocrystalline silicon scattering peak at 520.05 cm⁻¹ when changing the diameter of the nanowire columns was calculated to further analyze the effect of thermal annealing on Raman characteristics. Full article

The optical properties of silicon nanowire arrays (SiNWs) are closely related to surface morphology due to quantum effects and quantum confinement effects of the existing semiconductor nanocrystal. In order to explore the influence of the diameters and distribution density of nanowires on the light absorption in the visible to near infrared band, we report the highly efficient method of multiple replication of versatile homogeneous Au films from porous anodic aluminum oxide (AAO) membranes by ion sputtering as etching catalysts; the monocrystalline silicon is etched along the growth templates in a fixed proportion chemical solution to form homogeneous ordered arrays of different morphology and distributions on the surface. In this system, we demonstrate that the synthesized nanostructure arrays can be tuned to exhibit different optical characteristics in the test wavelength range by adjusting the structural parameters of AAO membranes. Full article

Molecular dynamics (MD) simulation was employed to examine the deformation and phase transformation of mono-crystalline Si nanowire (SiNW) subjected to tensile stress. The techniques of coordination number (CN) and centro-symmetry parameter (CSP) were used to monitor and elucidate the detailed mechanisms of the phase transformation throughout the loading process in which the evolution of structural phase change and the dislocation pattern were identified. Therefore, the relationship between phase transformation and dislocation pattern was established and illustrated. In addition, the electrical resistance and conductivity of SiNW were evaluated by using the concept of virtual electric source during loading and unloading similar to in situ electrical measurements. The effects of temperature on phase transformation of mono-crystalline SiNWs for three different crystallographically oriented surfaces were investigated and discussed. Simulation results show that, with the increase of applied stress, the dislocations are initiated first and then the phase transformation such that the total energy of the system tends to approach a minimum level. Moreover, the electrical resistance of (001)- rather than (011)- and (111)-oriented SiNWs was changed before failure. As the stress level of the (001) SiNW reaches 24 GPa, a significant amount of metallic Si-II and amorphous phases is produced from the semiconducting Si-I phase and leads to a pronounced decrease of electrical resistance. It was also found that as the temperature of the system is higher than 500 K, the electrical resistance of (001) SiNW is significantly reduced through the process of axial elongation. Full article
