Search Results (36)

Metal nanoparticles supported in carbon materials are the traditional electrocatalyst currently used in many applications. However, these composite materials have many problems associated with the optimization of both components for the specific application, besides the stability of the mixture. Self-supported metallic materials may be an interesting strategy in order to avoid the traditional carbon supports; however, these metallic materials should present highly active surface area. Iron aerogels are presented in this work as effective and affordable unsupported electrocatalysts. The combination of their metallic structure with high porosity (i.e., 85 m² g⁻¹ and 0.45 cm³ g⁻¹ of mesopore volume), due to their interconnected tridimensional structure, leads to a great activity versus the oxygen reduction reaction. A method for producing iron aerogels based on microwave-assisted sol–gel methodology is presented. The incorporation of carbon functionalities to the iron aerogels seems to clearly influence the mechanism of the reaction, favoring the direct mechanism of the oxygen reduction reaction and thus notably improving the performance of the electrocatalysts. Chemical vapor deposition seems to be an adequate methodology for incorporating carbon functionalities to the transition metal structure without affecting the tridimensional network and leading to current densities over 4 mA cm⁻² and great stability even after 10,000 s. Full article

Estimating the effective permittivity of anisotropic fibrous media is critical for advancing electromagnetic applications, requiring detailed microstructural and orientation analyses. This study introduces innovative approaches for disclosing the orientation and microstructure of fibers, leading to mixing relations. It particularly focuses on two specific fiber configurations: 1. wave-curved fibers and 2. a collection of interconnected fibers. The first approach uses sinusoidal wave fibers, considering their curvature and direction. Conversely, the approach for the interconnected fibers operates on the principle of representing fibers as a collection of straight segments. Investigations on fibrous media for both approaches were performed using numerical calculations at the microwave frequency of 2.45 GHz. Each fibrous medium was treated as an effective medium by using fibers significantly smaller than the microwave wavelength. A thorough comparison was made between the proposed mixing relations, numerical data, and state-of-the-art mixing relations to assess their consistency and validity. The comparison of the proposed approaches with traditional models shows an improved accuracy of up to 70% and 8% for the real and imaginary components of the permittivity, respectively. Additionally, the root-mean-square errors were determined as 0.001 + j0.003 and 0.001 – j0.007 for the sinusoidal and interconnected straight fibers approaches, respectively. In addition, a woven alumina fabric was used to compare the experimental resonance frequency with that from simulations using the permittivity of the fabric estimated by the interconnected straight fibers approach. These findings advance the predictive accuracy of permittivity estimation in fibrous media, providing a robust foundation for engineering applications. Full article

Modern integrated circuits (ICs) take advantage of three-dimensional (3D) nanostructures in devices and interconnects to achieve high-speed and ultra-low-power performance. The choice of electrical insulation materials with excellent dielectric strength, electrical resistivity, strong mechanical strength, and high thermal conductivity becomes critical. Diamond possesses these properties and is recently recognized as a promising dielectric material for the fabrication of advanced ICs, which are sensitive to detrimental high-temperature processes. Therefore, a high-rate low-temperature deposition technique for large-grain, high-quality diamond films of the thickness of a few tens to a few hundred nanometers is desirable. The diamond growth rate by microwave plasma chemical vapor deposition (MPCVD) decreases rapidly with lowering substrate temperature. In addition, the thermal conductivity of non-diamond carbon is much lower than that of diamond. Furthermore, a small-grain diamond film suffers from poor thermal conductivity due to frequent phonon scattering at grain boundaries. This paper reports a novel MPCVD process aiming at high growth rate, large grain size, and high sp³/sp² ratio for diamond films deposited on silicon. Graphite paste containing nanoscale graphite and oxy-hydrocarbon binder and solvent vaporizes and mixes with gas feeds of hydrogen, methane, and carbon dioxide to form plasma. Rapid diamond growth of diamond seeds at 450 °C by the plasma results in large-grained diamond films on silicon at a high deposition rate of 200 nm/h. Full article

In this work, we present a versatile, rapid, and low-cost manufacturing technique to develop bioceramic scaffolds that could enhance bone tissue regeneration via microwave preparation using a domestic microwave oven. The scaffolds were prepared by combining hydroxyapatite and water glass (sodium trisilicate solution), foamed by using a microwave oven, and then characterized by means of Scanning Electron Microscopy (SEM) with Energy Dispersive X-ray Analysis (EDX), mechanical properties, infrared spectroscopy (ATR-FTIR), and a density and stability test in water. Furthermore, in vitro tests were performed to verify the affinity of the scaffold for osteoclast cells. The morphology of the samples showed interconnected pores suitable for promoting tissue regeneration and vascularization, while specific mechanical properties were preserved. The physicochemical characterization and the in vitro tests presented promising results for bone regenerative applications. The scaffolds we obtained exhibited comparable properties to those fabricated using a laboratory microwave oven, including the ability to induce the formation of bone-like tissue in vitro. Full article

We present the design and the performance evaluation of a new interconnect for large-scale densely packed electronically scanned antenna arrays that utilize a high-speed digital board-to-board vertical connector. The application targets microwave tissue, imaging in the frequency range from 3 GHz to 8 GHz. The tissue-imaging arrays consist of hundreds of active antenna elements, which require low-reflection, low-loss, and low-crosstalk connections to their respective receiving and transmitting circuits. The small antenna size and the high array density preclude the use of coaxial connectors, which are also expensive and mechanically unreliable. Modern board-to-board high-speed connectors promise bandwidths as high as 12 GHz, along with high pin density, mechanical robustness, and low cost. However, their compatibility with the various transmission lines leading to/from the miniature printed antenna elements and microwave circuitry is not well studied. Here, we focus on the design of the transitions from coplanar waveguide transmission lines to/from a high-speed vertical connector. The performance of the interconnect is examined through electromagnetic simulations and measurements. Comparison is carried out with the expensive sub-miniature push-on sub-micro coaxial connectors commonly used in miniature radio-frequency electronics. The results demonstrate that high-speed vertical connectors can provide comparable performance in the UWB frequency range. Full article

A microwave transmitter/receiver using the low-temperature co-fired ceramic substrate and ball grid array packaging demonstrates superior properties, including high integration, miniaturization, and high electromagnetic shielding. However, it holds limitations of inadequate hermeticity (that is, gas or moist impermeability), high cost, and low reproducibility. In this work, we aim to overcome these difficulties by introducing a new packing technique. The packaging utilizes an electroless plated Ni/Pd/Au surface, resulting in a significant enhancement of the packaging hermeticity by orders of magnitude, approaching the level of <5 × 10⁻⁹ Pa·m³/s. Both Sn63Pb37 and Au80Sn20 solder alloys demonstrate exceptional solderability, attributed to Pd atoms diffusing to the Au layer during soldering at 310 °C. A reliability test of the packaging shows that the shear strength of the solder balls drops after thermal shocks but negligibly affects the hermeticity of the packaging. Furthermore, a meticulously designed internal vertical interconnect structure and I/O interconnections were engineered in the ball grid array packaging, showcasing excellent transmission characteristics within the 10–40 GHz frequency range while ensuring effective isolation between ports. Full article

In this paper, a method based on deep learning is proposed to predict the parameters of bonded metal wires, which solves the problem that the transmission characteristics of S-parameters cannot be predicted. In an X-band microwave chip circuit, gold wire bonding technology is often used to realize bonding interconnection, and the arch height and span of the bonded metal wire will have a great influence on the microwave transmission characteristics. By predicting the S-parameters of the bonded metal wire, the relationship between the structure parameters of the single wire and the transmission performance of the microwave device can be deduced. First, the gold wire bonding model is established in HFSS simulation software. After parameter optimization, the simulation results meet the requirements of establishing data sets. Then the sampling range of S parameters is set, and the parameters are scanned to establish data sets. Second, the artificial neural network model is built. The model adds a dropout mechanism to the hidden layer to enhance the generalization of the neural network, prevent overfitting phenomenon, and significantly improve the model’s prediction performance. Finally, the model predicts the corresponding relationship between the arch height and span of the bonding wire and the insertion loss, return loss and standing wave ratio. The mean square error of the test set is less than 0.8. The experimental results show that compared with the traditional process measurement method, this method can quickly and accurately infer whether the microwave characteristics of the bonded product are qualified, which greatly reduces the time and economic cost of the engineer and improves the work efficiency. Full article

The exploitation of unavoidable food supply chain wastes resulting from primary and secondary processing for chemicals, materials, and bioenergy is an important concept in the drive towards circular-based, resource-efficient biorefineries rather than petroleum refineries. The potential production of hydrogels (materials) from unavoidable food supply chain wastes, which are naturally rich in biopolymers such as cellulose, hemicellulose, pectin, and lignin, represents an interesting opportunity. However, these intertwined and interconnected biopolymers require separation and deconstruction prior to any useful application. Thus, this study aims to explore the formation of hydrogels from defibrillated celluloses (MW-DFCs) produced via acid-free stepwise microwave hydrothermal processing of blackcurrant pomace residues. Initially, pectin was removed from blackcurrant pomace residues (MW, 100–160 °C), and the resultant depectinated residues were reprocessed at 160 °C. The pectin yield increased from 2.36 wt.% (MW, 100 °C) to 3.07 wt.% (MW, 140 °C) and then decreased to 2.05 wt.% (MW, 160 °C). The isolated pectins were characterized by attenuated total reflectance infrared spectroscopy (ATR-IR), thermogravimetric analysis (TGA), and ¹³C NMR (D₂O). The cellulosic-rich residues were reprocessed (MW, 160 °C) and further characterized by ATR-IR, TGA, and Klason lignin analysis. All the MW-DFCs contained significant lignin content, which prevented hydrogel formation. However, subsequent bleaching (H₂O₂/OH⁻) afforded off-white samples with improved gelling ability at the concentration of 5% w/v. Confocal laser microscopy (CLSM) revealed the removal of lignin and a more pronounced cellulosic-rich material. In conclusion, the microwave-assisted defibrillation of blackcurrant pomace, an exploitable unavoidable food supply chain waste, affords cellulosic-rich materials with the propensity to form hydrogels which may serve useful applications when put back into food products, pharmaceuticals, cosmetics, and home and personal care products. Full article

Metal–organic framework (MOF)-derived composites have gained wide attention due to their specific structures and enhanced performance. In this work, we prepared carbon nanotubes with Fe nanoparticles connected to two-dimensional (2D) hierarchical carbon network composites via a low-pressure gas–solid reaction strategy. Specifically, the three-dimensional (3D) networks derived from ZIF-8 exploited the carbon nanotubes with the function of charge modulation. Meanwhile, we utilized the interconnected 2D nanostructures to optimize impedance matching and facilitate multiple scattering, ultimately improving the overall microwave absorption performance. Furthermore, based on the well-designed structures, the composites prepared at 800 °C (Fe-N-C@CNTs-800) achieved the best reflection loss (RL) of −58.5 dB, thereby obtaining superior microwave absorption performance. Overall, this study provides a good groundwork for further investigation into the modification and dimension design of novel hierarchical microwave absorbers. Full article

The aim of the article is to provide a summary of the work carried out in the framework of a research project funded by the Italian Ministry of Research. The main goal of the activity was to introduce multiple tools for reliable, affordable, and high-performance microwave hyperthermia for cancer therapy. The proposed methodologies and approaches target microwave diagnostics, accurate in vivo electromagnetic parameters estimation, and improvement in treatment planning using a single device. This article provides an overview of the proposed and tested techniques and shows their complementarity and interconnection. To highlight the approach, we also present a novel combination of specific absorption rate optimization via convex programming with a temperature-based refinement method implemented to mitigate the effect of thermal boundary conditions on the final temperature map. To this purpose, numerical tests were carried out for both simple and anatomically detailed 3D scenarios for the head and neck region. These preliminary results show the potential of the combined technique and improvements in the temperature coverage of the tumor target with respect to the case wherein no refinement is adopted. Full article

With the increasing demand for multi-function and highly integrated space-borne microwave products, a three-dimensional heterogeneous integration based on special substrates and other systems-in-package has difficulty with meeting the requirements of high reliability in space. Through simulation, the thermal-deformation resistance of traditional interconnections meets the requirements of high reliability, but its transmission performance at high frequency is poor. Based on the above, a novel microwave horizontal coaxial transition structure with good thermal-deformation resistance and excellent microwave characteristics is proposed. The design formula of the structure is derived, and the basic size of the structure can be quickly calculated. The transition structure and a vertical matching structure can realize microwave interconnection by combining microstrip impedance transformation and gold-ribbon interconnection. The complex microwave circuit is laid out and partitioned in a three-dimensional way, and thus a space-borne microwave metallic system-in-package method based on high reliability microwave interconnections is implemented. A Ka-band receiving system-in-package is used as an example to carry out the actual test and validation. The better characteristics of the Ka-band receiving channel on the satellite are obtained, and its excellent reliability is verified by the temperature cycle and mechanical vibration test. Full article

This paper presents a low-loss, high-transmission, broadside-coupled, transverse, reciprocal, two-port, and nature-inspired Ka-band transition design to move the electromagnetic energy of a rectangular waveguide (RWG) to the microstrip (MS) line. The proposed transition is simple in structure, with an excellent insertion loss, S₁₂/S₂₁, (IL) near −0.40 dB and return loss, S₁₁/S₂₂, of <−21 dB, while the VSWR value is very close to one. Thus, this transition is an outstanding candidate for MIC/MMIC-based millimeter wave, military, and RADAR applications, as well as in wireless and satellite communications as a compatible connector. This transition also provides a bandwidth of 21.50 GHz (23.52–45.0 GHz) for the abovementioned microwave applications, at a <−10 dB return loss (RL). The proposed transition model also exhibits a −15 dB absolute bandwidth of 27.06–23.44 GHz, with an insertion loss < −0.60 dB. Due to a return loss of <−15 dB over an ultra-wide bandwidth, the proposed transition is not only a good candidate for full Ka-band (26–40 GHz) applications but also covers applications for K-band from 23.74 GHz to 26.0 GHz, Q-band applications from 33.0 to 45.0 GHz, and U-band applications from 40.0 GHz to 45 GHz, with approximately 97% power transmission between the transmission lines and only 3% power reflections. The impedance matching at the designed frequency between the RWG and MS line is achieved by flaring one end of the MS line inside the RWG in a fishtail shape, without the need for a quarter-wave/tapered/exponential/Binomial, or multi-section Chebyshev transformer. The main goal of this research was to design a multi-section impedance-transformer-free, simple, and easy-to-fabricate MS line, to share electromagnetic (EM) energy between an MS line and RWG in 30 GHz satellite applications and 30 GHz high-frequency applications, for interconnects screen printed on an organic substrate for flexible, wearable, textile conformal antennas. This work also presents an exact RLC electrical equivalence model of the MS line (fishtail) to RWG transition at 30 GHz. The novelty of this work is that the proposed transition can be used for four microwave bands of electromagnetic energy transmission, with extremely low reflection, and with a compact, simple-design MS line, and simple RWG. Full article

Wire bonds are one of the most common interconnects used in microelectronics; however, their application to millimeter wave monolithic microwave integrated circuits (MMICs) may severely decrease the overall system performance due to transmission loss, radiation loss, and impedance mismatch. The goal of this work was to optimize a wire-bonded patch antenna to minimize losses and maximize the gain in the frequency range from 81 to 83 GHz. Optimization was based on electromagnetic simulations of different variants of the wire bond. Results show that the optimized structure demonstrates two major advantages. Firstly, it does not require any external matching network; hence, it can be directly connected to a contact pad of an MMIC die. Secondly, the wire bond radiation effect is utilized to enhance the patch antenna gain at the broadside direction. Full article

Bone tissue may suffer from bone injury and bone defects due to accidents or diseases. Since the demand for autologous bone and allograft tissue far exceeds the supply, bone scaffolds have taken the lead. The use of bone scaffolds is one of the measures to help heal or regenerate bone tissue. Therefore, a new bone scaffold was proposed in this study, which has a simpler preparation process and stronger performance. This study proposes bone scaffolds with an attempt to use polymers that are synthesized separately with three types of minerals as the filler using the microwave foaming method as follows. A 0.1 wt% of montmorillonite (MMT), zinc oxide (ZnO), or titanium dioxide (TiO₂) is added to chitosan (CS)/gelatin mixtures, respectively, after which sodium bicarbonate is added as a foaming agent, thereby forming porous gels. The polymer synthesized from three minerals was used as filler. The following microwave foaming method was adopted: 0.1 wt% MMT, ZnO, or TiO₂ was added to the CS/gelatin mixture, and then sodium bicarbonate was added as a foaming agent to form a porous gel. Next, porous gels and polycaprolactone were combined in a self-made mold in order to form bone scaffolds. A stereo microscope is used to observe the morphology of bone scaffolds, after which the pore size analysis, pore connectivity, swell property, porosity, and compressive strength are tested, examining the effects of the mineral type on bone scaffolds. The test results indicate that with MMT being the filler and sodium bicarbonate being the foaming agent, the resulting bone scaffolds yield a porous structure with a pore size between 120 μm and 370 μm. Besides, the incorporation of polycaprolactone also provides samples of 1MCG-P, 2MCG-P, and 5MCG-P with a certain compressive strength of 150–170 MPa. To sum up, the test results substantiate that a combination of the microwave foaming method and MMT generates a porous structure for bone scaffolds (1MCG-P, 2MCG-P, and 5MCG-P), involving a porosity of 38%, an inter-connected porous structure, and the compressive strength that exceeds 150 MPa. Full article

Although numerous methods have been widely used to prepare nickel hydroxide materials, there is still a demand for lowering the required heating time, temperature, and cost with maintaining a high-quality nanomaterial for electrochemical energy storage. In this research, we study the relationship between microwave-assisted heating parameters and material properties of nickel hydroxide nanoflakes and evaluate their effect on electrochemical performance. X-ray diffraction spectra show that the samples prepared at the highest temperature of 220 °C have crystallized in the beta phase of nickel hydroxide crystal. While the sample synthesized at 150 °C in 30 min contains both beta and alpha phases. Interestingly, we obtained the pure alpha phase at 150 °C in just 10 min. A scanning electron microscope shows that increasing the temperature and heating time leads to enlarging the diameter of the macro-porous flower-like clusters of interconnected nanoflakes. Electrochemical measurements in potassium hydroxide electrolytes demonstrate that the alpha phase’s electrodes have much higher capacities than samples containing only the beta phase. The maximum areal capacity of 17.7 µAh/cm² and gravimetric capacity of 35.4 mAh/g are achieved, respectively, at 0.2 mA/cm² and 0.4 A/g, with a small equivalent series resistance value of 0.887 ohms on flexible stainless-steel mesh as a current collector. These improved nickel hydroxide electrodes can be ascribed to utilizing the diffusion-controlled redox reactions that are detected up to the high scan of 100 mV/s. Such fast charge-discharge processes expand the range of potential applications. Our nickel hydroxide electrode, with its rapid preparation at medium temperature, can be a cost-effective candidate for flexible supercapacitors and batteries. Full article
