This study proposes an investigation into the nonlinear vibration of a simply supported, flexible, uniform microbeam associated with its curvature considering the mechanical impact, the electromagnetic actuation, the nonlinear Winkler–Pasternak foundation, and the longitudinal magnetic field. The governing differential equations and the boundary conditions are modeled within the framework of a Euler–Bernoulli beam considering an element of the length of the beam at rest and using the second-order approximation of the deflected beam and the Galerkin–Bubnov procedure. In this work, we present a novel characterization of the microbeam and a novel method to solve the nonlinear vibration of the microactuator. The resulting equation of this complex problem is studied using the Optimal Homotopy Asymptotic Method, employing some auxiliary functions derived from the terms that appear in the equation of motion. An explicit closed-form analytical solution is proposed, proving that our procedure is a powerful tool for solving a nonlinear problem without the presence of small or large parameters. The presence of some convergence-control parameters assures the rapid convergence of the solutions. These parameters are evaluated using some rigorous mathematical procedures. The present approach is very accurate and easy to implement, even for complicated nonlinear problems. The local stability near the primary resonance is studied. Full article

The present investigation focuses on the design and mathematical modeling of a microelectromechanical (MEMS) mode-localized based sensor/actuator system. This device incorporates a sensitive clamped–clamped shallow arch microbeam with an initial curvature shaped to resemble one of the first two symmetric and asymmetric modes of free oscillations of a clamped–clamped beam. The analysis reveals that with a suitable arrangement of the initial shape of the device flexible electrode and a proper tuning of the maximum initial rise and the actuating dc load enables the transition to display certain bistable behavior. This could be a better choice to build a device with a large stroke. Furthermore, the generated data showed the occurrence of mode-veering, indicating a coupling between the concerned symmetric and asymmetric modes of vibrations, and offering the possibility for such a device to be used as a mode-localized MEMS-based sensor utilizing veering and crossing phenomena. Indeed, where a certain energy is exchanged between symmetric and asymmetric modes of a microbeam, it can be utilized to serve as a foundation for the development of a new class of highly precise resonant sensors that can capture, with a certain level of precision, any of the sensed signal amplitudes. Full article

This work investigates the primary and secondary resonances of an electrostatically excited double-clamped microbeam and its feasibility to be used for sensing applications. The sensor design can be excited directly in the vicinity of the primary and secondary resonances. This excitation mechanism would portray certain nonlinear phenomena and it would certainly lead in increasing the sensitivity of the device. To achieve this, a nonlinear beam model describing transverse deflection based on the Euler–Bernoulli beam theory was utilized. Then, a reduced-order model (ROM) considering all geometric and electrical nonlinearities was derived. Three different techniques involving time domain, fast Fourier transforms (FFTs), and frequency domain (FRCs) were used to examine the appearance of subharmonic resonance of order of one-half under various excitation waveforms. The results show that higher forcing levels and lower damping are required to activate this resonance. We note that as the forcing increases, the size of the instability region grows fast and the size of the unstable region increases rapidly. This, in fact, is an ideal place for designing bifurcation inertia MEMS sensors. Full article

This paper investigated the mechanical performance of an electrostatically tunable microbeams-based resonators. The resonator was designed based on two initially-curved microbeams that are electrostatically coupled, offering the potential for improved performance compared to single-beam based resonators. Analytical models and simulation tools were developed to optimize the resonator design dimensions and to predict its performance, including its fundamental frequency and motional characteristics. The results show that the electrostatically-coupled resonator exhibits multiple nonlinear phenomena including mode veering and snap-through motion. A coexistence of two stable branches of solutions for a straight beam case was even obtained due to the direct effect of the coupling electrostatic force with the other curved beam. Indeed, the results are promising for the better performance of coupled resonators compared to single-beam resonators and offer a platform for future MEMS applications including mode-localized based micro-sensors. Full article

The fluid–structure interaction is one of the most important coupled problems in mechanics. The topic is crucial for many high-technology areas. This work considers the interaction between an elastic obstacle and rarefied gas flow, seeking specific problems that arise during this interaction. The Direct Simulation Monte Carlo method was used to model the rarefied gas flow and the linear Euler–Bernoulli beam theory was used to describe the motion of the elastic obstacle. It turned out that the vibrations caused by the gas flow could provoke a resonance-like phenomenon when the frequency of vortex shedding of the flow was close to the natural frequency of the beam. This phenomenon could be useful in certain high-technology applications. Full article

Although the small-scale effect and nonlinear damping on the nonlinear vibration of microbeam electrostatic resonators are important, they have been overlooked by researchers. We use the slender beam model including the small-scale effect and nonlinear damping to investigate the nonlinear vibrations of the electrostatic resonators in the present paper. We apply the Galerkin method on a nonlinear partial differential equation to obtain the nonlinear ordinary differential equations for the first and third modes. The two equations include constant terms. The multiple-scale method is used to obtain the approximate analytical solutions of the two equations. The approximate analytical solutions discover the effects of driving electric field, small-scale effect, and nonlinear damping on structural vibrations. The results suggest that the small-scale effect, the direct current (DC) voltage, and the alternating current (AC) voltage have some critical effects on the vibrations of microresonators. Full article

With the constant need for the development of smart devices, Micro-Electro-Mechanical Systems (MEMS) based smart sensors have been developed to detect hazard materials, micro-particles or even toxic substances. Identifying small particles using such micro-engineering technology requires designing sensors with high sensitivity, selectivity and ease of integration with other electronic components. Nevertheless, the available detection mechanism designs are still juvenile and need more innovative ideas to be even more competitive. Therefore, this work aims to introduce a novel, smart and innovative micro-sensor design consisting of two weakly electrostatically coupled microbeams (both serving as sensors) and electrically excited using a stationary electrode assuming a dc/ac electric signal. The sensor design can be tuned from straight to eventually initially curved microbeams. Such an arrangement would develop certain nonlinear phenomena, such as the snap-through motion. This behavior would portray certain mode veering/mode crossing and ultimately mode localization and it would certainly lead in increasing the sensitivity of the mode-localized based sensing mechanism. These can be achieved by tracking the change in the resonance frequencies of the two microbeams as the coupling control parameter is varied. To this extent, a nonlinear model of the design is presented, and then a reduced-order model considering all geometric and electrical nonlinearities is established. A Long-Time Integration (LTI) method is utilized to solve the static and dynamics of the coupled resonators under primary lower-order and higher-order resonances, respectively. It is shown that the system can display veering and mode coupling in the vicinity of the primary resonances of both beams. Such detected modal interactions lead to an increase in the sensitivity of the sensor design. In addition, the use of two different beam’s configurations in one device uncovered a possibility of using this design in detecting two potential substances at the same time using the two interacting resonant peaks. Full article

Due to their unique properties—coherent radiation, diffraction limited focusing, low spectral bandwidth and in many cases short light pulses—lasers play an increasing role in live cell microscopy. Lasers are indispensable tools in 3D microscopy, e.g., confocal, light sheet or total internal reflection microscopy, as well as in super-resolution microscopy using wide-field or confocal methods. Further techniques, e.g., spectral imaging or fluorescence lifetime imaging (FLIM) often depend on the well-defined spectral or temporal properties of lasers. Furthermore, laser microbeams are used increasingly for optical tweezers or micromanipulation of cells. Three exemplary laser applications in live cell biology are outlined. They include fluorescence diagnosis, in particular in combination with Förster Resonance Energy Transfer (FRET), photodynamic therapy as well as laser-assisted optoporation, and demonstrate the potential of lasers in cell biology and—more generally—in biomedicine. Full article

The present paper develops a new Bernoulli–Euler theory of microbeams for the consideration of small-scale effects and nonlinear terms, which are induced by the axial elongation of the beam and Kelvin–Voigt damping. The non-resonance and primary resonance of microbeams are researched through the application of Galerkin and multiple scale methods to the new model. The results suggest the following: (1) Nonlinear damping slightly affects the vibration amplitudes under the non-resonance condition; (2) nonlinear damping can significantly change the bifurcation points that induce a jump in the vibration amplitudes under the primary resonance condition. The current researches indicate that nonlinear damping is necessary for an accurate description of microbeam vibrations. Full article

In this paper, we use the nonlinear hardening stiffness of drive mode deal with the contradiction between gain and bandwidth of the linear micro-gyroscope, to improve the bandwidth and gain in sense direction. Firstly, in order to adjust the distance between two resonant peaks, we changed an incomplete two-degree-of-freedom(2-DoF) sense mode system of the micro-gyroscope into a complete 2-DoF system. Afterward, according to the given nonlinear coefficient of stiffness of drive mode, the structure size of driving micro-beams was designed to obtain a nonlinear micro-gyroscope with controllable stiffness. Finally, we investigated the effects of peaks spacing, damping, and driving nonlinearity on gain and bandwidth, and the nonlinear micro-gyroscope was optimized by orthogonal experiment method and response surface method. The results reveal that the peaks spacing has a great influence on the gain and bandwidth of both linear and nonlinear micro-gyroscopes. The larger the peaks spacing, the lower the gain, but higher gain can be achieved when the resonant frequency of the drive mode is close to the lower-order resonant frequency of the sense mode. Driving nonlinearity leads to the response peak of the Coriolis force to have a hardening characteristic, thus forming a wide platform in the sense direction. Hardening of the response peak of the Coriolis force allows the micro-gyroscope to obtain a higher gain while the bandwidth of the sense mode is also greatly improved. In addition, parameter optimization can make the gain and bandwidth of the micro-gyroscope optimal. When the peaks spacing is small and the nonlinear stiffness coefficient is about 10^12.2, under the premise that the gain is basically constant, the bandwidth of the sense mode increases about 1.76 times compared with the linear gyroscope. Damping can suppress the influence of nonlinearity in a micro-gyroscope system. Within a certain range, the frequency response of the nonlinear micro-gyroscope tends to be a linear system with the increase in damping, resulting in narrower bandwidth and lower gain. Full article

Controlling the nonlinearities of MEMS resonators is critical for their successful implementation in a wide range of sensing, signal conditioning, and filtering applications. Here, we utilize a passive technique based on geometry optimization to control the nonlinearities and the dynamical response of MEMS resonators. Also, we explored active technique i.e., tuning the axial stress of the resonator. To achieve this, we propose a new hybrid shape combining a straight and initially curved microbeam. The Galerkin method is employed to solve the beam equation and study the effect of the different design parameters on the ratios of the frequencies and the nonlinearities of the structure. We show by adequately selecting the parameters of the structure; we can realize systems with strong quadratic or cubic effective nonlinearities. Also, we investigate the resonator shape effect on symmetry breaking and study different linear coupling phenomena: crossing, veering, and mode hybridization. We demonstrate the possibility of tuning the frequencies of the different modes of vibrations to achieve commensurate ratios necessary for activating internal resonance. The proposed method is simple in principle, easy to fabricate, and offers a wide range of controllability on the sensor nonlinearities and response. Full article

The purpose of this study is to use a multi-technique approach to detect the effects of spatially fractionated X-ray Microbeam (MRT) and Minibeam Radiation Therapy (MB) and to compare them to seamless Broad Beam (BB) irradiation. Healthy- and Glioblastoma (GBM)-bearing male Fischer rats were irradiated in-vivo on the right brain hemisphere with MRT, MB and BB delivering three different doses for each irradiation geometry. Brains were analyzed post mortem by multi-scale X-ray Phase Contrast Imaging–Computed Tomography (XPCI-CT), histology, immunohistochemistry, X-ray Fluorescence (XRF), Small- and Wide-Angle X-ray Scattering (SAXS/WAXS). XPCI-CT discriminates with high sensitivity the effects of MRT, MB and BB irradiations on both healthy and GBM-bearing brains producing a first-time 3D visualization and morphological analysis of the radio-induced lesions, MRT and MB induced tissue ablations, the presence of hyperdense deposits within specific areas of the brain and tumor evolution or regression with respect to the evaluation made few days post-irradiation with an in-vivo magnetic resonance imaging session. Histology, immunohistochemistry, SAXS/WAXS and XRF allowed identification and classification of these deposits as hydroxyapatite crystals with the coexistence of Ca, P and Fe mineralization, and the multi-technique approach enabled the realization, for the first time, of the map of the differential radiosensitivity of the different brain areas treated with MRT and MB. 3D XPCI-CT datasets enabled also the quantification of tumor volumes and Ca/Fe deposits and their full-organ visualization. The multi-scale and multi-technique approach enabled a detailed visualization and classification in 3D of the radio-induced effects on brain tissues bringing new essential information towards the clinical implementation of the MRT and MB radiation therapy techniques. Full article

In this research, we investigate the structural behavior, including the snap-through and pull-in instabilities, of in-plane microelectromechanical COSINE-shaped and electrically actuated clamped-clamped micro-beams resonators. The work examines various electrostatic actuation patterns including uniform and non-uniform parallel-plates airgap arrangements, which offer options to actuate the arches in the opposite and same direction of their curvature. The nonlinear equation of motion of a shallow arch is discretized into a reduced-order model based on the Galerkin’s expansion method, which is then numerically solved. Static responses are examined for various DC electrostatic loads starting from small values to large values near pull-in and snap-through instability ranges, if any. The eigenvalue problem of the micro-beam is solved revealing the variations of the first four natural frequencies as varying the DC load. Various simulations are carried out for several case studies of shallow arches of various geometrical parameters and airgap arrangements, which demonstrate rich and diverse static and dynamic behaviors. Results show few cases with multi-states and hysteresis behaviors where some with only the pull-in instability and others with both snap-through buckling and pull-in instabilities. It is found that the micro-arches behaviors are very sensitive to the electrode’s configuration. The studied configurations reveal different possibilities to control the pull-in and snap-through instabilities, which can be used for improving arches static stroke range as actuators and for realizing wide-range tunable micro-resonators. Full article

We report a novel electrostatic self-excited resonator driven by DC voltage that achieves variable velocity-position characteristics via applying the pre-tension/pre-compression constraint. The resonator consists of a simply supported micro-beam, two plate electrodes, and two adjustable constraint bases, and it can be under pre-compression or pre-tension constraint by adjusting the distance L between two constraint bases (when beam length l > L, the resonator is under pre-compression and when l < L, it is under pre-tension). The oscillating velocity of the beam reaches the maximum value in the position around electrodes under the pre-compression constraint and reaches the maximum value in the middle position between two electrodes under the pre-tension condition. By changing the constraint of the microbeam, the position of the maximum velocity output of the oscillating beam can be controlled. The electrostatic self-excited resonator with a simple constraint structure under DC voltage has great potential in the field of propulsion of micro-robots, such as active rotation control of flapping wings. Full article

Background: Microbeam Radiation Therapy (MRT) induces a transient vascular permeability window, which offers a novel drug-delivery system for the preferential accumulation of therapeutic compounds in tumors. MRT is a preclinical cancer treatment modality that spatially fractionates synchrotron X-rays into micrometer-wide planar microbeams which can induce transient vascular permeability, especially in the immature tumor vessels, without compromising vascular perfusion. Here, we characterized this phenomenon using Chicken Chorioallantoic Membrane (CAM) and demonstrated its therapeutic potential in human glioblastoma xenografts in mice. Methods: the developing CAM was exposed to planar-microbeams of 75 Gy peak dose with Synchrotron X-rays. Similarly, mice harboring human glioblastoma xenografts were exposed to peak microbeam doses of 150 Gy, followed by treatment with Cisplatin. Tumor progression was documented by Magnetic Resonance Imaging (MRI) and caliper measurements. Results: CAM exposed to MRT exhibited vascular permeability, beginning 15 min post-irradiation, reaching its peak from 45 min to 2 h, and ending by 4 h. We have deemed this period the “permeability window”. Morphological analysis showed partially fragmented endothelial walls as the cause of the increased transport of FITC-Dextran into the surrounding tissue and the extravasation of 100 nm microspheres (representing the upper range of nanoparticles). In the human glioblastoma xenografts, MRI measurements showed that the combined treatment dramatically reduced the tumor size by 2.75-fold and 5.25-fold, respectively, compared to MRT or Cisplatin alone. Conclusions: MRT provides a novel mechanism for drug delivery by increasing vascular transpermeability while preserving vessel integrity. This permeability window increases the therapeutic index of currently available chemotherapeutics and could be combined with other therapeutic agents such as Nanoparticles/Antibodies/etc. Full article
