In recent years, the scientific community has intensified its efforts to develop a new type of concentrator photovoltaic module that is competitive with conventional modules. These modules are based on internal tracking systems, known as micro-tracking concentrator photovoltaic modules, which generate electrical energy proportional to the direct radiation on the inclined surface. There are several reviews, databases, and models for various components of solar radiation, particularly for global and direct normal radiation. However, readily available data on direct inclined irradiance remain scarce. This paper reviews several available sources of solar radiation data, finding that only the Photovoltaic Geographic Information System and Solar Radiation Database provide direct inclined irradiance data. A comparative statistical analysis was carried out, and a reasonable fit was obtained between both databases. In addition, direct inclined radiation data extracted from these databases were compared with the values calculated using a well-established mathematical model. In addition, worldwide maps were generated to determine areas of interest for this technology. Therefore, this paper presents an original comparative analysis of existing databases containing information on direct inclined irradiation. This information is of interest for the accurate design and performance analysis of micro-tracking concentrator modules. Full article

A photovoltaic-thermal side-absorption concentrated module (PT-SACM) based on spectrum division for photovoltaic-thermal hybrid applications is carried out. In order to reduce the absorption by materials and the axial-chromatic aberration caused by the transmissive optical system and to improve the performance of the entire system, a reflective system, the parabolic mirror array, fabricated by the ultra-precision diamond turning technology, is proposed herein. For the purposes of spectrum division, thinner volume, lightweight, and wide acceptance angle, the proposed module is designed with a diffraction optical element (DOE), a light-guide plate with a micro-structure array and a parabolic mirror array. Among them, the DOE can separate the solar spectrum into the visible band, which is converted to electrical energy via photovoltaics, and the infrared band, whose thermal energy is collected. Experimental measurements show that the overall optical efficiency of the entire system reached 38.32%, while a deviation percentage of 3.5% is calculated based on the simulation. The system has successfully demonstrated the separation of visible and infrared bands of the solar spectrum. Meanwhile, the lateral displacement between the micro-structures of the light-guide plate and the focus of the parabolic mirror array can be used to compensate for the angular deviation of the sun incidence, thereby achieving wide-angle acceptance via the proposed solar concentration system. Full article

This research paper delves into the potential use of solar energy as an alternative energy source for future vehicles. The study introduces a system that overcomes the limitations of traditional solar panels by achieving a reduced thickness of less than 35 mm, while acknowledging the challenges faced by vehicles, such as the inability to maintain a fixed orientation towards the sun and frequent shading from surrounding objects. To tackle these challenges, our system incorporates the design of an asymmetrical and extended polynomial lens and optimizes it to widen the acceptance angle of incident sunlight, enabling the solar panels to capture a wider range of solar radiation, even when the vehicle is not ideally aligned with the sun. The goal of this innovative design is not only to maximize energy output in urban conditions, ensuring efficient solar utilization despite shading challenges, but also to maintain a compact, lightweight structure suitable for installation on vehicle rooftops and competitive with ordinary PV panels. Additionally, our system is a tracking and heat spreader-free structure. This simple structure enables cheaper mass production and the lightweight nature of the structure results in affordable manufacturing and assembly processes. Through collaboration with micro-fabrication, macro-electronic industries, and micro-LED technologies, our system is a strong candidate for a low-cost, high-efficiency system. The results show an optical efficiency of around 52.53% for incident rays at a 45° angle, with the remaining rays captured by adjacent lenses resulting in a total optical efficiency around 76%. Full article

Second-generation thin-film Cu(In, Ga)Se₂ (CIGS) solar cells are a well-established photovoltaic technology with a record power conversion efficiency of 23.6%. However, their reliance on critical raw materials, such as In and Ga, requires new approaches to reduce the amount of critical raw materials employed. The micro-concentrator concept involves the combination of thin-film photovoltaic technology with concentrator photovoltaic technology. This approach reduces the size of the solar cell to the micrometer range and uses optical concentration to collect sunlight from a larger area, focusing it onto micro solar cells. This work is devoted to the development of a process for manufacturing pre-structured substrates with regular arrays of holes with 200 and 250 µm diameters inside a SiO_x insulating matrix. Subsequently, a Cu–In–Ga precursor is deposited by sputtering, followed by photoresist lift-off and the application of a Cu–In–Ga thermal annealing at 500 °C to improve precursor quality and assess pre-structured substrate stability under elevated temperatures. Finally, a two-stage selenization process leads to the formation of CIGS absorber micro-dots. This study presents in detail the fabrication process and explores the feasibility of a bottom-up approach using pre-structured substrates, addressing challenges encountered during fabrication and providing insights for future improvements in CIGS absorber materials. Full article

This work aims to create a web-based real-time monitoring system for electrical energy consumption inside a specific residence. This electrical energy is generated from a micro-CPV system lying on the roof of this residence. The micro-CPV is composed of a Fresnel lens as the main optical element, a spherical lens as the secondary optical element, and a multi-junction solar cell. A tiny photovoltaic concentrator system with a geometric concentration ratio of 100× is analyzed in the first part of this study, while the second part is designed to monitor the electricity generated by the micro-CPV system. An ESP8266 controller chipset is used to build the sensing peripheral node, which controls a relay and a PZEM-004T current sensor. As a result, the optical element used has approximately 83% optical efficiency, with an acceptance angle of 1.5°. Regarding the monitoring system, the architecture demonstrates the ability of the system to monitor current and energy consumption in real time using a computer or smartphone and a web server specially designed to continuously update the power consumption profile in a specific smart home environment. The whole electric power consumption monitoring system generally worked well. The monitoring system is configured to provide excellent accuracy for a 0.6% hit. Full article

The heat absorbed by the heat transfer fluid for cooling a concentrated photovoltaic thermal (CPVT) solar collector can be used for purposes such as residential heating and cooking. Because of the combined production of heat and power, these systems are proposed for individual or commercial use in rural areas. In this study, a hybrid system was proposed to increase the electrical efficiency of the system. Experiments were conducted in winter conditions. Two operational modes were compared, namely a CPVT system with HP (HP-CPVT) and without HP (CPVT). The evaporator of the heat pump was settled inside the triangular trough receiver. The effects of cooling the PV system with a heat pump in the bifacial CPVT system on the electrical and thermal energy efficiencies were investigated. The electricity and thermal energy efficiencies of the CPVT system were calculated as 12.54% and 38.37% in the HP-CPVT system, respectively, and 10.05% and 81.97% in the CPVT system, respectively. The electrical exergy efficiencies of the CPVT system with and without HP were 14.65% and 10.73%, respectively. The thermal exergy efficiencies of the CPVT system with and without HP were 82.47% and 85.63%, respectively. The thermal heat obtained from the HP-CPVT system can be used for heating needs. Thus, the bifacial HP-CPVT system was an example of the micro-CHP system. Full article

Numerous numerical and experimental studies have been conducted regarding the Concentrated Photovoltaic Thermal (CPVT) system because of its significant potential for efficient conversion of solar energy. The overall efficiency of the CPVT system is strongly dependent on the device, which extracts excess heat from photovoltaic cells. The most efficient cooling technology involves active cooling, which means that heat is collected from the PV cell via the forced flow of heat transfer fluid. This research paper provides an extensive discussion on devices dedicated to active-cooling CPVT systems, taking into account the latest solutions. First, a short introduction regarding CPVT systems and their main components is presented. The second part of this study presents state-of-the-art solutions in the field of heat extraction devices for the active cooling of photovoltaic cells. The available solutions are classified into two main groups depending on the scale of internal channels: macro- and micro-. Each geometry of the heat receiver is juxtaposed with the corresponding concentrating element, photovoltaic cell, concentration ratio, heat transfer fluid, and operating parameters of the specified system. In addition, this paper discusses the advantages and disadvantages of various devices for heat extraction and provides a comparative study of these devices. Finally, a set of recommendations for CPVT cooling devices is provided. Full article

In recent decades, advances in the development of solar tracking systems (STSs) have led to concentrating solar technologies to increase their energy conversion efficiency. These systems, however, still have areas of opportunity or improving their performance and reducing their manufacturing costs. This paper presents the design, construction and evaluation of a high-precision dual-axis solar tracking system with a technology readiness level of 7–8. The system is controlled by a low-cost Arduino board in a closed-loop control using a micro-electromechanical solar sensor. Real-time tracking experiments were performed under a clear sky as well as during partly and mostly cloudy days. Solar tracking accuracy was evaluated in an operational environment using test procedures adapted from the International Electrotechnical Commission (IEC) 62817 standard. The total mean instantaneous solar tracking error on a clear day measured with a calibrated digital solar sensor was 0.37${}^{°}$ and 0.52${}^{°}$ with a developed pinhole projection system. Similarly, the total mean reported solar tracking accuracy achieved was 0.390${}^{°}$ on a sunny day and 0.536${}^{°}$ on a partially cloudy day. An annual power generation analysis considering a conventional photovoltaic (PV) panel system and a typical concentrator photovoltaic (CPV) module as payloads was also presented. Simulations showed an increase in the generation of up to 37.5% for a flat panel with dual-axis tracking versus a fixed panel. In the case of the CPV system, first, a ray tracing study was implemented to determine the misalignment coefficient, then the annual power generation was estimated. The developed STS allowed the CPV modules to reach at least 90% of their nominal energy conversion efficiency. Full article

This manuscript investigates the supercritical carbon dioxide (sCO${}_2$) power cycle employed in the power block of concentrated solar power (CSP) plants—solar tower—as an alternative for solar desalination, developed with either distillation or reverse osmosis. This concept is investigated as a possible up-scaling of the SOLMIDEFF project, originally based on a hot-air micro gas turbine combined with a solar dish collector. For the upscaled concept, five different sCO${}_2$ cycles are considered, chosen amongst the best-performing configurations proposed in the literature for CSP applications, and modelled with Thermoflex software. The influence of ambient conditions is studied, considering two minimum cycle temperatures (35 °C and 50 °C), corresponding to Santa Cruz de Tenerife and Abu Dhabi, respectively. The results show that the low temperatures at the inlet of the heat rejection unit compromise the viability of distillation technologies. On the other hand, the high thermal efficiency achieved by these cycles, especially with the recompression and partial cooling layouts, reduces the specific energy consumption when combined with reverse osmosis (RO), below that of photovoltaic (PV)+RO. Feed-water preheating is explored as a solution to further reduce energy consumption, concluding that its actual interest is not clear and strongly depends on the location considered and the corresponding water quality standards. Full article

Black silicon (BSi) fabrication via surface texturization of Si-wafer in recent times has become an attractive concept regarding photon trapping and improved light absorption properties for photovoltaic applications. In this study, surface texturization has been conducted on mono-crystalline Si(100) wafer using a wet chemical anisotropic etching process with IPA:KOH solution to form micro-pyramidal surface structures. Moreover, the optimized properties of the fabricated BSi wafers are used for numerical simulation using PC1D software to analyze the performance of the solar cell and establish the correlation among relevant parameters. Effects such as doping concentration, texturization, passivation, and anti-reflection coating of BSi on the solar cell performance have numerically been investigated. Results show that textured surface obtained from the wet chemical anisotropic etching process has successfully reduced the reflectance of the BSi wafer and surpassed the solar cell efficiency by 2%, which is mainly attributed to the optical confinement of the textured pyramids on the surface with a height of 1–2 μm and angles of 70 degrees. Furthermore, the doping concentration of the p-type wafer and n-type emitter were optimized to be 1 × 10¹⁶ cm⁻³ and 1 × 10¹⁸ cm⁻³, respectively. In the case of device optimization, the SiO₂ passivation layer with a refractive index of 1.48 and the Si₃N₄ ARC layer with a refractive index of 2.015 has been identified as the best combination for the solar cell performance. These optimized parameters eventually result in 23.14% conversion efficiency from numerical simulation for solar cells that use black silicon wafers as fabricated in this study. Full article

As the scaling of silicon PV cells and module manufacturing has driven solar energy penetration up and costs down, concentrator photovoltaic technologies, originally conceived as a cost-saving measure, have largely been left behind. The loss of market share by CPV is being locked in even as solar energy development encounters significant obstacles related to space constraints in many parts of the world. The inherently higher collection efficiency enabled by the use of concentrators could substantially alleviate these challenges, but the revival of CPV for this purpose requires substantial reinvention of the technology to actually capture the theoretically possible efficiency gains, and to do so at market-friendly costs. This article will discuss recent progress in key areas central to this reinvention, including miniaturization of cells and optics to produce compact, lightweight “micro-CPV” systems; hybridization of CPV with thermal, illumination and other applications to make use of unused energy streams such as diffuse light and waste heat; and the integration of sun-tracking into the CPV module architecture to enable greater light collection and more flexible deployment, including integration into built structures. Applications showing particular promise include thermal applications such as water heating, industrial processes and desalination; agricultural photovoltaics; building-integrated photovoltaics with dynamic daylighting capabilities; and chemical processes including photocatalysis and hydrogen production. By appropriately tailoring systems to the available solar resource and local energy demand, we demonstrate how CPV can finally achieve real-world efficiencies, or solar resource utilization factors, far higher than those of standard silicon-based PV systems. This makes the argument for sustained development of novel CPV designs that can be applied to the real-world settings where this efficiency boost will be most beneficial. Full article

An increase in energy demand that is caused by fast economic development, a limited and constantly decreasing supply of traditional energy sources, as well as excessive environmental pollution that is caused by an increasing concentration of dust and gases in the atmosphere constitute the main factors that contribute to the ever-increasing interest in renewable sources of energy. The most important and promising renewable source of energy is thought to be solar energy. The aim of the paper is to assess the macroeconomic investment efficiency of photovoltaic installations in order to meet the demand for electric energy in single-family homes in Polish conditions. The conducted analysis comprises market characteristics and legal regulations concerning the sale of electric energy in Poland. Calculations were made for 320 variants that differed with regard to investment location, building orientation, and roof inclination. The results indicate that the most beneficial region for photovoltaic micro-installations, from a social perspective, is the south-east of and central Poland. The highest values of economic efficiency were achieved in the case of a southern roof inclination as well as a south-eastern and south-western building orientation. No big differences were observed in the economic investment efficiency for the panel inclinations. The calculated Discounted Payback Period, depending on the calculation method, equals 5.4 to 10 years. The results of the study confirm that the implemented support instruments for investments in photovoltaic installations producing energy for single-family house demand is economically viable. Full article

Solar energy can be converted into useful energy via photovoltaic cells or with a photothermal absorber. While these technologies are well-developed and commercially viable, significant benefits can be realised by pulling these two technologies together in photovoltaic/thermal (PV/T) systems which can provide both heat and electricity from a single collector. Emerging configurations in the PV/T field aim to incorporate micro and/or nanotechnology to boost total solar utilisation even further. One example of this is the nanofluid-based PV/T collector. This type of solar collector utilises nanofluids—suspensions of nanoparticles in traditional heat transfer fluids—as both an optical filter and as a thermal absorber. This concept seeks to harvest the whole solar spectrum at its highest thermodynamic potential through specially engineered nanofluids which transmit the portion of solar spectrum corresponding to the PV response curve while absorbing the rest as heat. Depending on the nanoparticle concentration, employing nanofluids in a flowing system may come with a price—an efficiency penalty in the form of increased pumping power (due to increased viscosity). Similarly, microchannel-based heat exchangers have been shown to increase heat transfer, but they may also pay the price of high pumping power due to additional wall-shear-related pressure drop (i.e., more no-slip boundary area). To develop a novel PV/T configuration which pulls together the advantages of these micro and nanotechnologies with minimal pumping power requirements, the present study experimentally investigated the use of nanofluids in patterned hydrophobic microchannels. It was found that slip with the walls reduced the impact of the increased viscosity of nanofluids by reducing the pressure drop on average 17% relative to a smooth channel. In addition, flowing a selective Ag/SiO₂ core–shell nanofluid over a silicon surface (simulating a PV cell underneath the fluid) provided a 20% increase in solar thermal conversion efficiency and ~3% higher stagnation temperature than using pure water. This demonstrates the potential of this proposed system for extracting more useful energy from the same incident flux. Although no electrical energy was extracted from the underlying patterned silicon, this study highlights potential a new development path for micro and nanotechnology to be integrated into next-generation PV/T solar collectors. Full article

This paper presents an energy-efficient solar energy harvesting and sensing microsystem that harvests solar energy from a micro-power photovoltaic module for autonomous operation of a gas sensor. A fully integrated solar energy harvester stores the harvested energy in a rechargeable NiMH microbattery. Hydrogen concentration and temperature are measured and converted to a digital value with 12-bit resolution using a fully integrated sensor interface circuit, and a wireless transceiver is used to transmit the measurement results to a base station. As the harvested solar energy varies considerably in different lighting conditions, in order to guarantee autonomous operation of the sensor, the proposed area- and energy-efficient circuit scales the power consumption and performance of the sensor. The power management circuit dynamically decreases the operating frequency of digital circuits and bias currents of analog circuits in the sensor interface circuit and increases the idle time of the transceiver under reduced light intensity. The proposed microsystem has been implemented in a 0.18 µm complementary metal-oxide-semiconductor (CMOS) process and occupies a core area of only 0.25 mm². This circuit features a low power consumption of 2.1 µW when operating at its highest performance. It operates with low power supply voltage in the 0.8V to 1.6 V range. Full article
