Plasma arc welding (PAW) is commonly employed for welding medium and thick plates due to its capability of single-side welding and double-side forming. Ensuring welding quality necessitates real-time precise identification of the melting state. However, the intricate interaction between the plasma arc and the molten pool, along with substantial signal noise, poses a significant technical hurdle for achieving accurate real-time melting state identification. This study introduces a magnetically controlled method for identifying plasma arc melt-through, which integrates arc voltage and arc pool pressure. The application of an alternating transverse magnetic field induces regular oscillations in the melt pool by the plasma arc. The frequency characteristics of the arc voltage and pressure signals during these oscillations exhibit distinct mapping relationships with various fusion states. A hybrid feature extraction model combining gray correlation analysis (GRA) and the Pearson correlation coefficient (PCC) is devised to disentangle the nonlinear, non-smooth, and high-dimensional repetitive features of the signals. This model extracts features highly correlated with the fusion state to construct a feature vector. Subsequently, this vector serves as input for the fusion classification model, CNN-SVM, facilitating fusion state identification. The experimental results of melt-through under various welding speeds demonstrate the robustness of the proposed method for identifying melt-through through magnetic field-assisted melt pool oscillation, achieving an accuracy of 96%. This method holds promise for integration into the closed-loop quality control system of plasma arc welding, enabling real-time monitoring and control of melt pool quality. Full article

Background. Spatter formation at melt pool swellings at the keyhole rear wall is a major issue for laser deep penetration welding at speeds beyond 8 m/min. A gas nozzle directed towards the keyhole, that supplies shielding gas locally, is advantageous in reducing spatter formation due to its simple utilization. However, the relationship between local gas flow, laser spot size, and the resulting effects on spatter formation at high welding speeds up to 16 m/min are not yet fully understood. Methods. The high-alloy steel AISI 304 (1.4301/X5CrNi18-10) was welded with laser spot sizes of 300 μm and 600 μm while using a specially designed gas nozzle directed to the keyhole. Constant welding depth was ensured by Optical Coherence Tomography (OCT). Spatter formation was evaluated by precision weighing of samples. Subsequent processing of high-speed images was used to evaluate spatter quantity, size, and velocity. The keyhole oscillation was determined by Fast Fourier Transform (FFT) analysis. Tracking the formation of melt pool swellings at the keyhole rear wall provided information on the upward melt flow velocity. Results. The local gas flow enabled a significant reduction in the number of spatters and loss of mass for both laser spot sizes and indicated an effect on surface tension by shielding the processing zone from the ambient atmosphere. The laser spot size affected the upward melt flow velocity and spatter velocity. Full article

To overcome the instability of the traditional magnesium alloy additive process, the research on oscillating laser-arc hybrid additive manufacturing (O-LHAM) for AZ31 Mg alloy was developed first, and it focused on the effect of beam oscillation on process characteristics, such as macroscopic morphology, porosity defects, microstructure, and mechanical properties of thin-walled components. The increasing oscillation frequency was effective in suppressing the defects, including lack of fusion, wavy hump, internal porosity, etc. Compared with the case without oscillation, the average grain size of O-LHAM samples was refined from 22–32 μm to 18–20 μm at 300 Hz, while the percentage of Al₈Mn₅ and Mg₁₇Al₁₂ precipitation increased from 1.42–1.61% to 2.55–3.32%. For this reason, a stirring laminar flow was induced using the oscillating laser in the melt pool, with the ability to disrupt the grain structure and provide more nucleation sites, which is beneficial in reducing the average grain size and promoting the precipitation of the precipitated phase. Meanwhile, for the component without pores, the ultimate tensile strength is 205 MPa, slightly less than the base, but the elongation is 20.7%, twice that of the base. The tensile fracture is characterized by a large number of dimples and some ductile tearing ridges, demonstrating good ductility, which is associated with the grain refinement and precipitation strengthening induced using the oscillating laser. The results indicated that O-LHAM would be an effective method for manufacturing Mg alloy fast and well. Full article

In the present experimental study, the transverse oscillating laser beam technique was applied for the post-melting of metal matrix composite coatings, thermally sprayed with nickel-based self-fluxing NiCrCoFeCBSi alloy and 40 wt.% WC, to improve their hardness and wear resistance. The study was conducted using the single module optical fiber laser at 300 W power, >9554 W/cm² power density, 250–1000 mm/min laser speed, 1 mm and 2 mm transverse oscillation amplitude. Scanning electron microscopy, energy dispersive spectroscopy, Knop hardness measurements, and “Ball-on-disc” dry sliding tests were conducted to study the effect of the processing parameters on the molten pool geometry and microstructure, hardness, and tribology of the processed layers. Oscillating laser processing with an amplitude of 1 mm, 250–750 mm/min laser operating speed, and sample preheating to 400 °C gave a satisfactory result: wide and shallow molten pools of ~200–350 μm in depth, hardness between ~1100 and 1200 HV0.2 and minimum cracks obtained. The coatings obtained with laser beam oscillation and preheating, and ~1150 HV0.2 hardness showed an improvement in the wear resistance and friction coefficient (~0.33) of ~2.9 times and ~20%, respectively, compared with the respective values of the coatings remelted in furnace. Full article

Laser powder bed fusion (LPBF) attracts the attention of high-end manufacturing sectors for its capability of depositing free-form components with elevated mechanical properties. However, due to the intrinsic nature of the feedstock material and the interaction with the laser beam, the process is prone to defect formation and manufacturing inaccuracies. Therefore, the development of a monitoring architecture capable of measuring the geometrical features of the process tool (i.e., the melt pool generated by the laser-material interaction) is of paramount importance. This information may then be exploited to evaluate process stability. In this work, a high-speed camera was implemented coaxially in the optical chain of an LPBF system to extrapolate the geometrical features of the molten pool surface and its oscillatory behaviour, with elevated spatial and temporal resolution. A secondary light source was tested in both coaxial and off-axis configuration to dominate process emission and assess optimal illumination conditions for extracting the molten pool’s geometrical features. Preliminary results showed that the off-axis configuration of the illumination light enabled direct measurement of the molten pool surface geometry. A newly developed image processing algorithm based on illuminated images obtained via the coaxial observation frame was employed to provide automated identification of the melt pool geometry. Moreover, bright reflections of the external illumination over the melt surface could be clearly observed and used to characterise the oscillatory motion of the molten material. This information may therefore be taken as an indirect indicator of the molten pool penetration depth, hence providing information regarding the subsurface geometry. A successive experimental investigation showed the capability of the monitoring architecture to resolve the molten pool’s length, width and area with elevated acquisition frequency. Molten pool surface oscillations in the kHz range could be correlated to the penetration depth while the molten pool width measured via the high-speed imaging setup corresponded to the track width of the depositions. Hence, the methodological approach for the concurrent measurement of the molten pool’s geometry in three spatial dimensions was demonstrated and may be used to track the stability of LPBF depositions. Full article

The weld penetration variation in laser-MIG hybrid welding under sensitive laser power range was investigated by welding experiments and CFD (computational fluid dynamics) simulation. During this investigation, joints of AH36 sheets were welded with varying laser powers by the laser-MIG hybrid welding process. In addition, the CFD model was established based on experimental parameters and measurement results. Moreover, surface tension, electromagnetic force, buoyancy, recoil pressure, evaporative condensation, evaporative heat exchange, melt drop transfer, and other factors were considered. The influence of various factors on molten pool depth and keyhole depth were studied, including temperature, velocity, and flow direction of liquid metal. The results show that the weld-forming effect is better at the laser power is 7.5 kW in the range of sensitive laser power. After the keyhole is formed, its depth gradually entered the stage of linear increase, oscillation increase, and oscillation balance. Increasing the laser power can effectively shorten the time of the two growth stages and allow the keyhole to enter the balance stage earlier. During the oscillation balance state of the keyhole, the molten metal under the keyhole flowed to the molten pool root in the reverse direction of welding; it can also promote weld penetration. Full article

A computer model has been developed to investigate the processes of heat and mass transfer under the influence of concentrated energy sources on materials with specified thermophysical characteristics, including temperature-dependent ones. The model is based on the application of the volume of fluid (VOF) method and finite-difference approximation of the Navier–Stokes differential equations formulated for a viscous incompressible medium. The “predictor-corrector” method has been used for the coordinated determination of the pressure field which corresponds to the continuity condition and the velocity field. The modeling technique of the free liquid surface and boundary conditions has been described. The method of calculating surface tension forces and vapor recoil pressure has been presented. The algorithm structure is given, the individual modules of which are currently implemented in the Microsoft Visual Studio environment. The model can be applied for studying the metal transfer during the deposition processes, including the processes with electron beam spatial oscillation. The model was validated by comparing the results of computational experiments and images obtained by a high-speed camera. Full article

This paper reports a mechanism understanding how to reduce the solder joint failure phenomenon in the laser spot micro-welding process of ultra-thin steel sheets. An optimization method to improve solder joint service life is proposed. In this study, the time-dependent dynamic behaviors of the keyhole and the weld pool are simulated, and the temperatures in the keyhole of two different laser pulse waveforms are compared. The results show that laser energy attenuation mode (LEAM) can only obtain shallow weld depth because of the premature decay of the laser power of waveform, resulting in the laser beam that cannot be concentrated in the keyhole. The temperature inside the keyhole of LEAM fluctuates significantly, which shows a downward trend. Due to the existence of the peak power of waveform in laser energy continuous mode (LECM), the large angle of inclination of the wall of the keyhole inside the melt pool is more conducive to the multiple reflections of the laser beam in the keyhole and increases the absorption rate of the laser energy by the base material, resulting in the “keyhole effect”. But the temperature in the keyhole gradually rises, close to the evaporation temperature. A method combining LEAM and LECM to improve the solder joint service life by optimizing the temperature in the keyhole indirectly by adjusting the peak power of the laser pulse waveform is proposed in this study. The experimental results show that the weld depth can be optimized from 0.135 mm to 0.291 mm, and the tensile strength can be optimized from 88 MPa to 288 MPa. The bonding performance between the upper and lower plates is effectively improved. It can reach the required weld depth in a short time and improve the welding efficiency of the laser spot micro-welding process. The simulation results show that the temperature inside the keyhole is well optimized below the evaporation temperature of the material, which can avoid the violent evaporation of the welding process and keep the whole welding process in a stable state. By optimizing the laser pulse waveform, the temperature inside the keyhole can reach 3300 K, and it is always in a stable state than before optimization. The stable temperature inside the keyhole can help to reduce violent oscillation and spattering of the molten pool and improve welding efficiency and joint life. The research can help provide effective process guidance for the optimization of different laser pulse waveforms in the micro-welding process. Full article

The latest research on applying beam oscillation in laser beam fusion cutting revealed significant process improvements regarding speed and quality. The reason for this increasing process efficiency remains unexplained; however, theoretical investigations suggest the change in energy deposition (respectively heat conduction) as the cause. The present paper aims to analyze the energy deposition by a novel temperature measurement method. For this purpose, a conventional laser beam cutting setup was equipped with beam oscillation technology and a high-speed temperature measurement setup. Various characteristics of the temperature distribution in the process zone (spatial and temporal resolved temperature profiles, maximum and average values, as well as melt pool size) were evaluated for different conditions of beam oscillation (amplitude, frequency, cutting speed). Additionally, the geometrical properties of the process zone, defining the absorptivity have been measured. The comparison with static beam shaping reveals strong temperature volatility, which is induced by the way of energy deposition and an improved absorptivity over a substantial part of the cut front, with the overall result of enhanced heat conduction. For the first time, changed mechanisms applying beam oscillation instead of static beam shaping have been experimentally identified. Based on these measurements, a previously developed explanatory model was not only confirmed but also extended. Full article

In this study, the effects of ultrasonic on melt pool dynamic, microstructure, and properties of underwater wet flux-cored arc welding (FCAW) joints were investigated. Ultrasonic vibration enhanced melt flow and weld pool oscillation. Grain fragmentation caused by cavitation changed microstructure morphology and decreased microstructure size. The proportion of polygonal ferrite (PF) reduced or even disappeared. The width of grain boundary ferrite (GBF) decreased from 34 to 10 μm, and the hardness increased from 204 to 276 HV. The tensile strength of the joint increased from 545 to 610 MPa, and the impact toughness increased from 65 to 71 J/mm² due to the microstructure refinement at the optimum ultrasonic power. Full article

In order to study internal relation among the behavior of the weld pool, the microstructure of weld bead and the waveform of short-circuiting gas metal arc welding (S-GMAW), a high speed photograph-images analysis system was formed to extract characteristics of weld pool behavior. Three representative waveform control methods were used to provide partly and fully penetrated weld pools and beads. It was found that the behavior of the weld pool was related to the instantaneous power density of the liquid bridge at the break-up time. Weld pool oscillation was triggered by the explosion of the liquid bridge, the natural oscillation frequencies were derived by the continuous wavelet transform. The change of weld pool state caused the transition of oscillation mode, and it led to different nature oscillation frequencies between partial and full penetration. Slags flow pattern could be an indication of the weld pool flow. Compared with the scattered slags on fully penetrated weld pool, slag particles accumulated on partially penetrated weld pools. The oscillating promoted the convection of the welding pool and resulted in larger melting width and depth, the grain size, and the content of pro-eutectoid ferrite in the weld microstructure of S235JR increased, the content of acicular ferrite decreased. Full article

Beam oscillation in laser material processing makes it possible to influence process behavior in terms of energy distribution, stability, melt pool dynamics and solidification. Within the setup presented here, the beam is oscillated transverse to the welding direction, and the filler wire is fed to the melt pool of a butt joint with an air gap. One advantage of this setup is the large gap bridging ability. Certain parameter sets lead to the so-called buttonhole welding method, which allows laser welding of smooth and nearly ripple-free seams. Observations showed a transition area between conventional keyhole and buttonhole welding in which the process is destabilized. Welds made with parameter sets from this area contain critical seam defects. Welding experiments with high-speed video recording and a simplified analytical model about the wire-beam interaction have helped to elucidate the mechanisms behind this. EN AW-6082 sheet material in 1.5 mm thickness and ML 4043 filler wire with 1.2 mm diameter were used. The investigations lead to the conclusion that partially melted wire segments result at certain parameter relations which hinder the formation of a buttonhole. If these segments are prevented, buttonhole welding occurs. In the transition area, these segments are very small and can lead to the detachment of a buttonhole, resulting in the named seam defects. Full article

Keyhole laser welding experiments with 1.5 mm thick aluminum sheets (EN AW-6082) were carried out with transversal beam oscillation and wire feeding. A circular cavity, which was named buttonhole, formed directly behind the laser spot at certain oscillation frequencies. The welding states “no buttonhole”, “unstable buttonhole”, and “stable buttonhole” were distinguished. The melt pool dynamics were experimentally analyzed and correlated with the resulting roughness and waviness of the seam surfaces. Criteria for stable buttonhole welding were derived. On the basis of the cavity radii relations, it is shown that capillary pressure conditions can explain the movement of the buttonhole with the process. Full article
